Jangus Wi Sure-Fit User manual
Wi Sure-Fit
USER GUIDE
EL Series Earset/Lavalier Microphone
TM
TM
Thank You For Choosing the Wi Sure-Fit™EL Series Earset/Lavalier Microphone.
Congratulations on your purchase of the Wi Sure-Fit™ EL Series Earset/Lavalier Microphone. We’re condent you’ll
nd it the nest, most natural sounding and most innovative earset and lavalier microphone available.
Please thoroughly read this User’s Manual for all the features and information necessary to install and
operate your new Wi Sure-Fit™EL Series Earset/Lavalier Microphone.
For additional support, please visit www.jangusmusic.com
Wi Sure-Fit EL Series
CONGRATULATIONS
What is included in the package?
Verify that you have received all of the items listed below.
Wi Sure-Fit EL Series
3
PACKING LIST
MIC
Windscreen
Wi Sure-Fit™ ELM Earset
(If specied by part number)
Wi Sure-Fit™ EL Earset
(If specied by part number)
Wi Simple-Twist™ Detachable
Earset Cable
Wi Simple-Twist™ Detachable Lavalier
Cable (If specied by part number)
Rubber Instrument
Mic Clip Carrying Case
Earset/Lavalier
Cable Clip
Wi Simple-Twist™ Detachable Adapters for use with
Wi AudioStream™, AKG™, Shure™ Sony™, Audio-
Technica™ and Sennheiser™ pocket wireless systems
(If specied by part number)
Wi Sure-Fit EL Series
4
jRemovable MIC: Simple-Twist removable microphone capsule for ear-worn, lavalier and instrument
miking applications
kEarset MIC Port: Simple-Twist removable microphone capsule port
lSilicon Spacer: Silicon cheek spacer
mBoom: Sure-Fit bendable boom design
nBoom Lock: Adjusting the boom length, left and right ear placement boom conguration and
keeping boom securely in place
oCable Port: Simple-Twist detachable cable port
pIn-Ear Receiver: Integrated in-ear receiver (Wi Sure-Fit ELM model)
qEL Ear Mount: Sure-Fit advanced ergonomic silicon ear mount (Wi Sure-Fit EL model)
rLavalier MIC Port: Simple-Twist detachable Lavalier cable with removable microphone capsule port
FEATURES
Wi Sure-Fit EL Series
5
FEATURES
o
k
l
m
n
j
p
q
r
Wi Sure-Fit EL Series
6
Handling The Wi Sure-Fit EL Series
The Wi Sure-Fit EL Series is a high-precision instrument and
it is designed for durability and exibility. The following are
some of the basic precautions to prevent damage to
the Wi Sure-Fit EL.
Do not bend the boom over sharp edges such as
the end of your ngernail or twist the boom
around a tight radius less than 1/2” diameter.
Use the thumb and index nger to do small
bends at multiple points of the boom to get the
desired curvature.
HANDLING
O
P
O
P
HANDLING
P
Wi Sure-Fit EL Series
7
Do not bend and wrap the cables in any way that
creates severe coiling or strain on the cables.
Always detach the earset cable and the removable
adapter when storing the Wi Sure-Fit microphone
O
O
P
Wi Sure-Fit EL Series
8
GETTING STARTED
The Wi Sure-Fit Earset & Lavalier
Delivering unmatched value, comfort, sound
quality and secure t, the Wi Sure-Fit™ EL Series
earset and lavalier microphone delivers three (3)
applications in one versatile microphone including
ear-worn, lavalier and video camera/instruments
miking applications. Jangus Music’s ultra-small
removable MIC capsule mounted on an ultra-thin,
rugged, bendable, adjustable length and incred-
ibly lightweight boom captures vocals clearly with
excellent rejection of wind and ambient noise. The
Wi Sure-Fit™ EL Series is an excellent choice for
pastors, artists, tness instructors, speaking and
singing performers, video camera miking and hard
to MIC instruments.
Detailed information on connecting the Wi Sure-Fit™
Earset/Lavalier Microphone to the Wi AudioStream™ Pocket
Portable Stereo Digital Wireless System can be found at
http://www.jangusmusic.com
Connecting The Earset Cable
The Wi Sure-Fit™ EL Series ultra-low-prole detachable cable
delivers minimum visibility with maximum durability. Optional adapters
give the Wi Sure-Fit™ EL series earset great exibility for use with
different pocket wireless systems including Wi AudioStream™, AKG™,
Shure™, Sony™, Audio-Technica™ and Sennheiser™.
1. Locate the detachable earset cable and the appropriate
detachable adapter for your pocket wireless system.
2. Fasten the adapter end of the earset cable to the screw
connector located on the pocket wireless system adapter.
3. Fasten the earset end of the earset cable to the screw
connector located on the silicon ear mount.
Repeat the above steps to connect the in-ear receiver cable to the
adapter and the in-ear receiver port for the Wi Sure-Fit ELM model
with integrated in-ear receiver.
Wi Sure-Fit EL Series
9
GETTING STARTED
P
Q
Wi Sure-Fit EL Series
10
EARSET CUSTOM FITTING
Left or Right Ear Placement
The Wi Sure-Fit EL Series can easily be converted from right
to left ear wearing preferences with a Simple-Twist™. This un-
matched time saving feature delivers exceptional exibility
for venues needing to accommodate multiple users and their
wearing preferences.
1. Press the boom locking switch located on the bottom
of the Silicon ear mount.
2. Rotate the boom 180 degrees to the preferred
ear wearing preference.
3. Release the locking switch when rotation is complete.
No need to rework the bend or reshape the boom again when
switching from left to right ear placement. The boom maintains
its original angle to capture vocals from the near-the-mouth
position, from the opposite side.
