Janome Memory Craft 6650 User manual

Instruction Book
Memory Craft 6650

1
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be followed, including the
following:
This sewing machine is designed and manufactured for household use only.
Read all instructions before using this sewing machine.
DANGER— To reduce the risk of electric shock:
1. An appliance should never be left unattended when plugged in. Always unplug
this sewing machine from the electric outlet immediately after using and before
cleaning.
WARNING— To reduce the risk of burns, re, electric shock, or injury to persons:
1. Do not allow to be used as a toy. Close attention is necessary when this sewing machine is used
by or near children.
2. Use this appliance only for its intended use as described in this owner’s manual.
Use only attachments recommended by the manufacturer as contained in this owner’s manual.
3. Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if
it has been dropped or damaged, or dropped into water.
Return this sewing machine to the nearest authorized dealer or service center for examination,
repair, electrical or mechanical adjustment.
4. Never operate the appliance with any air opening blocked. Keep ventilation openings of this
sewing machine and foot controller free from accumulation of lint, dust and loose cloth.
5. Never drop or insert any object into any opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
8. To disconnect, turn all controls to the off (“O”) position, then remove plug from outlet.
9. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
10. Keep ngers away from all moving parts. Special care is required around the sewing machine
needle and/or cutting blade.
11. Always use the proper needle plate. The wrong plate can cause the needle to break.
12. Do not use bent needles.
13. Do not pull or push fabric while stitching. It may deect the needle causing it to break.
14. Switch this sewing machine off (“O”) when making any adjustment in the needle area, such as
threading the needle, changing the needle, threading the bobbin or changing the presser foot, and
the like.
15. Always unplug this sewing machine from the electrical outlet when removing covers, lubricating, or
when making any other adjustments mentioned in this owner’s manual.
SAVE THESE INSTRUCTIONS
For Europe only:
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
For outside Europe (except U.S.A and Canada):
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Please note that on disposal, this product must be safely recycled in accordance with relevant
National legislation relating to electrical/electronic products. If in doubt please contact your
retailer for guidance. (European Union only)

2
TABLE OF CONTENTS
ESSENTIAL PARTS
Names of Parts................................................................ 4
Standard Accessories ..................................................5-6
Stitch Reference Chart .................................................... 7
GETTING READY TO SEW
Connecting the Power Supply ......................................... 8
Operating Instructions: .................................................... 8
Controlling Sewing Speed ............................................... 9
Foot Control..................................................................... 9
Machine Operating Keys ................................................10
Function Keys and Jog Dials..................................... 11-12
Raising and Lowering the Presser Foot .........................13
Knee Lifter (Option) ........................................................13
Replacing the Presser Foot............................................14
Adjusting the Foot Pressure ...........................................15
Removing and Attaching the Foot Holder ......................15
Attaching the Professional Grade Foot HP (Option) ......16
Attaching the Darning Foot PD-H...................................16
Replacing Needles .........................................................17
Fabric and Needle Chart ................................................17
Winding the Bobbin .................................................. 18-20
Inserting the Bobbin ...................................................... 21
Threading the Machine............................................. 22-23
Built-in Needle Threader ............................................... 24
Drawing up the Bobbin Thread ..................................... 25
Replacing the Needle Plate........................................... 26
Balancing Thread Tension............................................. 27
Dropping the Feed Dog ................................................. 28
Selecting the Sewing Mode........................................... 29
Selecting the Pattern ..................................................... 30
Mode 1: Direct pattern selection mode........................ 30
Customizing direct pattern selection ........................... 31
Pattern Selection in Mode 2 and Mode 3 .................... 32
• Using numeral keys................................................... 32
• Using jog dials........................................................... 32
• Using arrow keys....................................................... 33
Customizing Machine Settings...................................... 33
Screen brightness ....................................................... 34
Buzzer sound .............................................................. 34
Auto thread cutting ...................................................... 34
Needle stop position.................................................... 34
Adjustable start-up speed (START/STOP key)............ 34
Adjustable start-up speed (Foot control) ..................... 35
Favorite stitch adjustment (FS) ................................... 35
Resume setting ........................................................... 35
Bobbin winding speed ................................................. 35
Language selection ..................................................... 35
Auto-off timer............................................................... 36
Reset all to default....................................................... 36
BASIC SEWING
Straight Stitch ........................................................... 37-39
Sewing from the Edge of Thick Fabric .......................... 37
Changing Sewing Direction........................................... 37
Turning a Square Corner............................................... 37
Securing Seams ............................................................ 38
Cutting Threads............................................................. 38
Needle Plate Guides ..................................................... 38
Adjusting the Needle Drop Position .............................. 39
Adjusting the Stitch Length ........................................... 39
Favorite Stitch Adjustment............................................. 40
Sewing with the Professional grade foot HP (Option) ....41
Variety of Straight Stitches ....................................... 42-43
Straight Stitch in Center Needle Position .................... 42
Lock-a-matic Stitch...................................................... 42
Locking Stitch .............................................................. 42
Straight Stitch in Left Needle Position ......................... 43
Triple Stretch Stitch ..................................................... 43
Stretch Stitches ........................................................... 43
Zipper Sewing ..........................................................44-46
Rolled Hem.................................................................... 47
Gathering....................................................................... 48
Pintucking...................................................................... 48
Basting .......................................................................... 49
Zigzag Stitches.............................................................. 50
Adjusting the stitch length ........................................... 50
Adjusting the stitch width............................................. 50
Variety of Overcasting Stitches ................................ 51-52
Multiple Zigzag Stitch .................................................. 51
Overcasting Stitch ....................................................... 51
Knit Stitch .................................................................... 51
Double Overcasting Stitch........................................... 52
Overlocking Stitch ....................................................... 52
Blind Hemming.........................................................53-54
Shell Tuck...................................................................... 55
Variety of Buttonholes ................................................... 56
Sensor (Square) Buttonhole..................................... 57-60
Adjusting the buttonhole width .................................... 60
Adjusting the buttonhole stitch density ........................ 60
Using the Stabilizer Plate .............................................. 61
Automatic (square) Buttonhole ................................. 62-63
Round End and Fine Fabric Buttonholes ...................... 64
Keyhole Buttonholes ..................................................... 64
Stretch Buttonhole......................................................... 64
Knit Buttonhole.............................................................. 64
Corded Buttonhole ........................................................ 65
Button Sewing ............................................................... 66
Darning.......................................................................... 67
Tacking .......................................................................... 68
Eyelet............................................................................. 69
DECORATIVE STITCHES
Applique ........................................................................ 70
Fringing.......................................................................... 71
Drawn Work...............................................................71-72
Smocking....................................................................... 72
Fagoting......................................................................... 73
Scallop........................................................................... 73
Patchwork Piecing..........................................................74
Angle Scales on the Needle Plate..................................74
Patchwork.......................................................................74
Quilting .......................................................................... 75
Stippling......................................................................... 75
Clasp Stitch ................................................................... 76
Free Motion Quilting (1) ............................................ 76-77
Free Motion Quilting (2)................................................. 77
Satin Stitches ................................................................ 78
Elongation ratio ........................................................... 78
Twin Needle Sewing.................................................79-80

3
TABLE OF CONTENTS
PROGRAMMING A PATTERN COMBINATION
Pattern Combination...................................................... 81
Editing a Pattern Combination....................................... 82
Deleting a Pattern.......................................................... 82
Inserting a Pattern......................................................... 83
Duplicating a Pattern ..................................................... 83
Programming Auto-lock Stitch....................................... 84
Automatic Thread Cutting.............................................. 84
Mirror Image .................................................................. 85
Pattern Combination with a Mirror Image...................... 86
Sewing the Pattern from the Beginning......................... 87
Sewing the Pattern Combination from the Beginning ... 87
Bridge Stitches .........................................................88-89
Uniform Stitch Adjustment............................................. 89
Individual Stitch Adjustment .......................................... 90
MONOGRAMMING
Entering Monogram Letters with Jog Dials ................... 91
• Selecting a character style.......................................... 91
• Selecting a letter (character)....................................... 92
Programming a Monogram............................................ 93
Spacing ......................................................................... 94
Reducing the size of letters........................................... 94
STORING AND RECALLING A PATTERN
COMBINATION
Storing a Pattern Combination ...................................... 95
Recalling a Stored Combination.................................... 96
Deleting a Stored Combination ..................................... 96
Correcting Distorted Stitch Patterns.............................. 97
CARE AND MAINTENANCE
Cleaning the Hook Area ................................................ 98
Problems and Warning Signals.............................. 99-100
Troubleshooting............................................................101
Stitch Chart...................................................................102
Stitch Chart (Monogram)............................................. 103

q
w
r
t
u
i
o
!0
!1
!2
!3
!4!5
y
!6
!9
!8
!7
e
@0
@1
@3
@4
@5@6
@7
#1
#0
#2
#3
#4
#5
#6
#7
#8 #9
$0
%1
%0
$9
$2
$8
$3
$4$5
$6
$7
$1
@9
@2
@8
%2
4
ESSENTIAL PARTS
Names of Parts
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
!4
!5
!6
!7
!8
!9
@0
@1
@2
@3
@4
@5
@6
@7
@8
@9
#0
#1
#2
#3
#4
#5
#6
#7
#8
#9
$0
$1
$2
$3
$4
$5
$6
$7
$8
$9
%0
%1
%2
Foot pressure dial
Thread take-up lever
Left thread guide
Upper thread guide
Stitch reference chart
LCD screen
Retractable thread guide
Bobbin winder spindle
Bobbin winder stopper
Bobbin thread cutter (upper)
Function keys
Stitch length adjusting dial (Jog dial)
Stitch width adjusting dial (Jog dial)
Knee lifter socket *
Feed balancing dial
Thread tension dial
Needle plate release lever
Thread cutter (on face plate)
Needle threader lever
Lower thread guide
Needle cramp screw
Needle bar thread guide
Needle
Zigzag foot A
Hook cover release button
Hook cover plate
Bobbin thread cutter
Needle plate
Feed dog
Foot holder
Setscrew
Lever
Needle threader
Buttonhole lever
Start/stop key
Reverse key
Auto-lock key
Needle up/down key
Thread cutter key
Speed control slider
Presser foot lifter
Spool pins
Power switch
Foot control jack
Machine socket
Drop feed lever
Thread cutter jack *
Handwheel
Right thread guide
Carrying handle
Bobbin winding tension disk
Stitch chart bracket
NOTE:
To carry the sewing machine, hold the carrying handle
with your hand, and support the sewing machine with
the other hand.
NOTE:
Sewing machine design and specications are subject
to change without prior notice.
* Knee lifter is the optional item.
* Thread cutter switch is the optional item.

qwer
t y
u
i
o!0 !2
!3
!1
!4 !5 !6 !7
!8 @0
!9
@1
@2 @3
@5@4
5
Standard Accessories
No. Part Name Part No.
1Zigzag foot A (Set on the machine) 859802006
2 Overcasting foot M 859810007
3Satin stitch foot F 85980 6011
4Blind hemming foot G 859807001
5 Zipper foot E 859805009
6 Automatic buttonhole foot R 862822013
7Stabilizer plate 859832016
8 Rolled hem foot D 859804008
9 Darning foot PD-H 859839002
10 Convertible free motion quilting foot
QB-S 858820018
11 Close-toe foot 858 820111
12 Open-toe foot 858821019
13 Clear view foot 202002521
14 Bobbin X 5 (1 set on the machine) 102261103
15 Needle set 859856005
16 Lint brush 802424004
17 Seam ripper (Buttonhole opener) 647808009
18 Quilting guide bar 755802001
19 Screwdriver 820832005
20 Net X 2 624806006
21 Spool holder (large) X 2 822020503
22 Spool holder (small) X 2 822019509
23 Spool rest X 2 770850001
24 Needle plate (set on the machine) 861606016
25 Straight stitch needle plate 862817118

@6
@7
#0
#2 #3
#1
@9
@8
6
* The power supply cable included may differ from the
illustration.
No. Part Name Part No.
26 Stitch reference chart 866629009
27 Stitch chart bracket 846285007
28 Setscrew X 2 000163600
29 Dust cover 767805001
30 Instruction book 866800408
31 Instructional DVD 866809005
32 Power cable *
U.S.A. and Canada 856519004
U.K. 830377008
Australia 830314018
33 Foot control C-1036

q
w
qw
7
Stitch Reference Chart
Attaching the stitch chart bracket
Align the screws with the holes on the backside of the
machine. Firmly tighten screws with screwdriver.
Stitch chart position
The stitch chart can be placed in two positions on the
chart bracket, store or view.
q Back slots
w Front slots
The back slots qon the bracket are for store position.
Slide stitch chart down between the back slots until the
stitch chart stops.
The front slots won the brackets are for view position.
Pull up and out the stitch chart from back slots. Slide
stitch chart down between the front slots.
Clip board
Flip over the stitch chart (Mode 3 side) and then clip or
sewing instructions, notes, etc., to board.
NOTE:
Do not clip multiple layers of paper or cardboard.
Slide paper under clips; do not raise clips.

e
w
q
z
c
r
t
z
v
q
t
r
w
y
u
e
8
WARNING:
While in operation, always keep your eyes on the
sewing area, and do not touch any moving parts such
as the thread take-up lever, handwheel or needle.
Always turn off the power switch and unplug the
machine from the power supply:
- when leaving the machine unattended.
- when cleaning the machine.
Do not place any objects on the foot control.
GETTING READY TO SEW
Connecting the Power Supply
zFirst make sure the power switch qis off.
xInsert the machine plug wof the power supply cable
into the machine socket e.
cInsert the power supply plug rinto the wall outlet t,
and turn the power switch qon.
q Power switch
w Machine plug
e Machine socket
r Power supply plug
t Wall outlet
If you wish to use the foot control, insert the pin connector
into the jack on the machine.
zFirst make sure the power switch qis off.
xInsert the pin connector r into the jack ton the
machine.
cInsert the machine plug wof the power supply cord
into the machine socket e.
vInsert the power supply plug yinto the wall outlet u,
and turn the power switch qon.
q Power switch
w Machine plug
e Machine socket
r Pin connector
t Foot control jack
y Power supply plug
u Wall outlet
NOTE:
The start/stop key does not work when the foot control
is connected.
Operating Instructions:
The symbol “O” on a switch indicates the “off” position of
the switch.
For the U.S.A. and Canada only
Polarized plug (one blade wider than the other):
To reduce the risk of electric shock, this plug is intended
to t in a polarized outlet only one way. If it does not t
fully in the outlet, reverse the plug. If it still does not t,
contact a qualied electrician to install the proper outlet.
Do not modify the plug in any way.
NOTE:
Make sure to use the power supply cable that came
with the machine.
If you turn off the power switch, wait for 5 seconds
before turning it on again.

9
Controlling Sewing Speed
Speed control slider
You can limit the maximum sewing speed with the speed
control slider according to your sewing needs.
To increase the sewing speed, move the slider to the right.
To decrease the sewing speed, move the slider to the left.
Foot Control
Pressing on the foot control can vary sewing speed.
The harder you press the foot control, the faster the
machine runs.
NOTE:
• The machine runs at the maximum speed set by
the speed control slider when the foot control is
fully depressed.
• You can select the desired start-up speed from
slow, medium or high (refer to page 35).
NOTE:
If you start the machine with the presser foot up, the
LCD screen will advise you to lower the presser foot.
Lower the presser foot and start sewing.
Operating Instructions:
Foot control model YC-485EC-1 is for use with this
sewing machine.

q
w
e
r t
10
Press the auto-lock key to sew a locking stitch
immediately. The machine will automatically stop.
When the machine is stopped, and press the auto-
lock key to turn on the auto-lock function. The
machine will immediately sew locking stitches and
automatically stop when the machine is started.
• When any other stitches are selected;
Press the auto-lock key to sew a locking stitch at the
end of current pattern. The machine will automatically
stop.
When the machine is stopped, and press the auto-lock
key to turn on the auto-lock function. The machine will
sew a locking stitch at the end of the current pattern
and automatically stop when the machine is started.
The machine will trim the threads automatically after
locking the stitch when the auto thread cutting is
turned on (refer to page 34).
r Needle up/down key
Press this key to bring the needle bar up or down.
The machine will stop with the needle in down position.
However, you can change the needle stop position in the
machine setting mode (refer to page 34).
tThread cutter key
After nish sewing, press this key to trim the threads. The
needle bar automatically rises after trimming the threads
(refer to page 38).
After using auto thread cutting or threading the bobbin
holder, you can start sewing without drawing up the
bobbin thread.
NOTE:
The thread cutter key does not function:
- directly after turning on the power.
- when the presser foot is raised with the foot lifter.
- after being pressed 3 times in a row.
Use the thread cutter on the face plate if the thread is
#30 or thicker (refer to page 38 ).
There will be particular functions of the reverse key
when the patterns shown above are selected. Refer to
pages 42, 62-63, 67 and 68 for instructions.
e Auto-lock key
• When following stitch patterns are selected;
• When any other stitches are selected;
If you press the reverse key when sewing any other
patterns, the machine will immediately sew locking
stitches and automatically stop.
• When following stitch patterns are selected;
Mode 1 Mode 2
Mode 1 Mode 2
Machine Operating Keys
q Start/stop key
Press this key to start or stop the machine.
The machine starts running slowly for the rst few
stitches, it then runs at the speed set by the speed
control slider. The machine runs slowly as long as this
key is pressed.
The key will turn red when the machine is running, and
green when it has been stopped.
Pressing and holding this key while sewing will slow
down the sewing speed and the machine will stop when
the key is released.
NOTE:
• The start/stop key cannot be used when the foot
control is connected to the machine.
• You can select the desired start-up speed from
slow, medium or high (refer to page 34).
• If you start the machine with the presser foot up,
the LCD screen will advise you to lower the presser
foot. Lower the presser foot and start sewing.
w Reverse key
• When following stitch patterns are selected;
The machine will sew in reverse as long as the
reverse key is pressed. Release the key to sew
forward.
When the machine is stopped and foot control is
disconnected, the machine will sew in reverse slowly
as long as the reverse key is pressed.
Release the key to stop the machine.
Mode 1 Mode 2

u i
q w e r t y
q
w
e
r
t
y
u i
11
qMode key (refer to page 29)
When the power is turned on, the pattern selection mode
1 is set automatically.
Each time you press the mode key, the mode will change
from 1 to 3. The selected mode is indicated on the upper
left corner of the LCD screen.
Function Keys and Jog Dials
wStitch display key (refer to pages 30, 32, 91)
In mode 1, press the stitch display key to open or close
the direct pattern reference window.
In mode 2 or 3, press the stitch display key to open or
close the pattern selection window.
eTwin needle key (refer to page 80)
Press this key when sewing with a twin needle.
rMirror image key (refer to pages 85-86)
Press this key to sew a mirror image of the selected
pattern.
tElongation key (refer to page 78)
Press this key to elongate satin stitch patterns.
yBobbin winding key
Press this key to wind the bobbin (refer to page 20).
uStitch width adjusting dial (refer to pages 32, 33,
39, 50, 89-91, 95-96, etc)
Turn this jog dial to alter the stitch width or needle drop
position of the selected stitch pattern.
You can also alter the page number or move the cursor
with this dial .
iStitch length adjusting dial (refer to pages 32, 33,
39, 50, 92, 95-96, etc)
Turn this jog dial to alter the stitch length of the selected
pattern.
You can also move the cursor with this dial.

!4
!5 !6
!0o !1 !3!2
o
!1
!2
!3
!0
12
oFolder/FS key
This key has two functions.
1: To stock or to recall the programmed pattern
combinations (refer to page 95-96).
2: To register or to delete the favorite stitch settings
(refer to page 40).
!0 Arrow keys (refer to pages 33, 82, 83)
Press “ ” or “ ” to select the stitch pattern, edit the
pattern combination, move the cursor or tun the page,
etc.
!1 Startover key (refer to page 87)
Press this key to sew a pattern combination from the
beginning.
!2 Lockout key
Press this key to lockout the machine when threading the
machine, replacing the accessories etc.
To reduce the risk of injury, all keys except the lockout
key are deactivated.
To unlock the machine, press this key again.
!3 Set key (refer to page 33)
Press this key to enter the machine setting mode for
customizing the machine settings.
!4 Numeral keys (refer to page 30-32)
• Mode 1:
You can select direct stitch patterns by pressing
corresponding keys.
• Mode 2, 3:
Enter a 3-digit pattern number to select the desired
stitch pattern.
!5 Clear key (refer to page 82)
Press this key to delete the memorized pattern or cancel
the settings.
!6 Memory key (refer to page 31, 32, 81)
Press this key to select the desired pattern, register
programmed pattern combinations, or conrm settings.
Function Keys and Jog Dials

e
w
r
e
t
q
w
q
r
t
13
Raising and Lowering the Presser Foot
NOTE:
If you start the machine with the presser foot up, the
LCD screen will advise you to lower the presser foot.
Lower the presser foot and start sewing.
The presser foot lifter or the knee lifter (option) raises and
lowers the presser foot.
You can raise the presser foot about 7 mm (1/4˝) higher
than the normal up position by exerting more pressure
when lifting the presser foot. This allows for changing the
needle plate and helps you to place layers of thick fabric.
q Presser foot lifter
w Presser foot
e Up position
r Extra lifted position
t Down position
CAUTION:
Do not turn the handwheel or press the up/down
needle key when the presser foot is in extra lifted
position. It may cause damage to the presser foot.
Knee Lifter (Option)
The knee lifter is extremely helpful when sewing
patchwork, quilting etc, since it allows you to handle the
fabric while your knee controls the presser foot.
Attaching the knee lifter
Match the ribs on the knee lifter with the notches in the
knee lifter socket and insert the knee lifter.
q Knee lifter
w Rib
e Knee lifter socket
Adjusting the knee lifter
The angle of the knee lifter can be adjusted to t you.
Loosen the setscrew and slide the angle bar in or out to
adjust the angle of the knee lifter.
Tighten the setscrew to secure the angle bar.
r Setscrew
t Angle bar
Using the knee lifter
Push the knee lifter with your knee to easily move the
presser foot up and down.
You can control how high the foot rises by the amount of
knee pressure you exert.

u
r
t
y
z
c
v
x
qw
e
14
CAUTION:
To avoid damaging the lever, do not push it down.
Replacing the Presser Foot
CAUTION:
Always make sure to press the lockout key to before
replacing the presser foot.
Use the proper foot for the selected pattern.
The wrong foot can cause the needle to break.
z Raise the needle by pressing the needle up/down key.
Press the lockout key.
q Needle up/down key
w Lockout key
x Raise the presser foot lifter.
e Presser foot lifter
c Press the black lever on the back of the foot holder.
The presser foot will drop off.
r Lever
v Place the presser foot so that the pin on the foot lies
just under the groove of the foot holder.
Lower the presser bar to lock the foot in place.
Each foot is marked with an identication letter.
t Pin
y Groove
u Identication letter

qw
t
t
r
y
r
q
w
e
e
15
Removing and Attaching the Foot Holder
Remove the foot holder before using Professional grade
foot HP (option), Darning foot PD-H or Convertible free
motion quilting foot QB-S.
CAUTION:
Always make sure to press the lockout key to lockout
the machine before replacing the foot holder.
Removing the foot holder
Raise the needle by pressing the needle up/down key.
Press the lockout key and raise the presser foot with the
presser foot lifter.
qNeedle up/down key
wLockout key
ePresser foot lifter
Loosen the setscrew and remove the foot holder.
r Setscrew
tFoot holder
Attaching the foot holder
Attach the foot holder to the presser bar from the rear.
Tighten the thumbscrew securely with the screwdriver.
yPresser bar
Adjusting the Foot Pressure
The foot pressure dial should be set at “3” for regular
sewing.
Reduce the pressure for appliqué, sewing on ne
synthetics and elastic fabrics.
Set the dial at “1” when sewing extra ne fabrics.
Consult information on the LCD screen for the
recommended foot pressure setting.
q Foot pressure dial
w Setting mark
e Recommended foot pressure setting
NOTE:
Do not reduce the foot pressure lower than “0”.

qw
16
Attaching the Darning Foot PD-H
Attach the darning foot PD-H to the presser bar by
putting the pin on the needle clamp screw.
qPin
wNeedle clamp screw
Tighten the setscrew rmly with the screwdriver.
Attaching the Professional Grade Foot HP
(Option)
Attach the professional grade foot HP to the presser bar.
Tighten the setscrew rmly with the screwdriver.

t
r
e
qw
17
Replacing Needles
CAUTION:
Always make sure to press the lockout key to lockout
the machine before replacing the needle.
Raise the needle by pressing the needle up/down key.
Press the lockout key.
qNeedle up/down key
wLockout key
Loosen the needle clamp screw by turning it
counterclockwise.
Remove the needle from the clamp.
eNeedle clamp screw
Insert a new needle into the needle clamp with the at
side of the needle to the rear.
rFlat side
When inserting the needle into the needle clamp, push it
up against the stopper pin and tighten the needle clamp
screw rmly with a screwdriver.
Fabric Thread Needle
Fine
Lawn
Georgette
Tricot
Organza
Crepe
Silk #80-100
Cotton #80-100
Synthetic #80-100
Blue tip needle
Universal needle
#9/65-11/75
Medium
Sheeting
Jersey
Broadcloth
Fleece
Silk #50
Cotton #50-80
Synthetic #50-80
Red tip needle
Purple tip needle
Universal needle
#11/ 75 -14 /9 0
Heavy
weight
Denim
Tweed
Coating
Quilting
Silk #30-50
Cotton #40-50
Synthetic #40-50
Red tip needle
Purple tip needle
Universal needle
#14/90-16/100
Fabric and Needle Chart
• For general sewing, use red tip needle.
• Fine threads and needles should be used for sewing
ne fabrics.
• In general, use the same thread for both needle and
bobbin.
• Use a blue tip needle for sewing ne fabrics, stretch
fabrics, tricot and buttonholes to prevent skipped
stitches.
• Use a purple tip needle for sewing knits, free quilting
and across the hem to prevent skipped stitches.
• Use a stabilizer or interface to stretch or ne fabrics
to prevent seam puckering.
• Always test the thread and needle size on a small
piece of the same fabric you will use for actual
sewing.
NOTE:
1 x twin needle, 2 x blue tip needle (#11/75), 1 x red tip
needle (#14/90) and 1 x purple tip needle (#14/90) are
included in the needle case (Part No. 859856005).
To check needle straightness, place the at side of the
needle onto something at (a needle plate, glass etc.).
The gap between the needle and the at surface should
be consistent.
tGap
Never use a blunt needle.

q
w
e
rr
tt
q
e
wu
y
i
r
q
w
e
18
Use the large spool holder for ordinary spools, while the
small spool holder for small spools.
r Small spool
t Small spool holder
NOTE:
Avoid using a paper cored spool when it begins to
empty since it will not unwind smoothly. It may cause
the thread to bunch or slip when using the auto thread
cutter.
Winding the Bobbin
Removing the bobbin
Slide the hook cover release button to the right, and
remove the hook cover plate.
qHook cover release button
wHook cover plate
Lift out the bobbin from the bobbin holder.
eBobbin
NOTE:
Use the “J” plastic bobbins for horizontal hook (marked
with “J” r). Using other bobbins, such as pre-wound
paper bobbins, may cause stitching problems and/ or
damage to the bobbin holder.
Setting the spool of thread
Place the spool of thread on the spool pin with
the thread coming off the spool as shown.
Attach the spool holder, and press it rmly against the
spool of thread.
q Spool of thread
w Spool pin
eLarge spool holder
Setting the thread cone
Use the spool rest and the spool net for thread cones.
Attach the spool rests on the spool pin.
Place the spool cone on the spool pin.
Cover the thread cone with the spool net if the thread is
shaky or kinky when sewing.
If the net is too long for a spool, fold the net and place it
on the spool.
w Spool pin
yThread cone
u Spool rest
i Spool net
