OWNER’S MANUAL
JAS Bravo 2.4
Vacuum Tube
Integrated Amplifier
NOTE: Before installing your new Bravo 2.4 audio amplifier, please read this
manual carefully. It will inform you of the product specifications and also proper
installation and operation procedures.
For additional requests
If you have any additional questions regarding the installation
or operation of our products, you are welcome to contact us directly via
email: “ [e-mail] “, and please check frequently our JAS Audio
official website: “ http://www.jas-audio.com “.
Page 1 of 6
http://www.jas-audio.com

JAS AUDIO HIGH FIDELITY
Integrated Amplifier
Welcome to JAS Audio Family! This JAS Bravo 2.4 integrated amplifier is designed and
manufactured to the highest quality standards. The design denotes performance,
elegance, and simplicity. You will find this tube amplifier visually pleasing and easy to use
without going through pages of instructions. IMPORTANT: before operating the unit, make
sure you are familiar with the safety measures documented below.
Bravo 2.4 OWNER’S MANUAL
Introduction
Thank you for purchasing the JAS Audio Bravo 2.4 Integrated Amplifier. Standing on the
chassis immediate in front of the transformer casing are two 5Z3P rectifier tubes. On either side of
the chassis are two KT88 drive stage tubes for each channel output, whereas the two 12AT7 driver
tubes and the only 12AU7 tube for signal amplification are in the middle.
Overlaid with hand
finished solid wooden board engraved with the Bravo logo and other indications, a
stylish and elegant appearance is put in front of the audience. Made of aluminum alloy,
the front panel of 8mm in thickness is a representation of coherence in design of making
the chassis robust and the gear working with durability.
Page 2 of 6
http://www.jas-audio.com

Preliminary
Bravo 2.4 features an aluminum alloy panel of 8mm in thickness that holds the on-off knob
on the left, analogue volume control knob in the middle and the selector on the right. Signal
input to four sets of RCA connectors is selectable by turning the selector
It is important to be careful with tube installation. Please do not
force anything, easy does it! This precaution is mentioned to help
you obtain pleasing results and avoid damage! If you have any
trouble replacing or changing tubes, please don’t hesitate to call
your dealer!
___________________________________________________________
Tube Replacement
Caution: Make sure the amplifier has been unplugged for 30 minutes from the AC mains
before replacing the tubes, to avoid any risk of shock or discomfort from high temperature.
Although tube life span varies depending on the nature and degree of use, under normal
home use, the KT88 output tubes, the 12AT7 driver tubes and the 12AU7 signal
amplification tube should last years in the Bravo 2.4.
Cautionary Terms
When the following cautionary terms are used in this manual, these
definitions apply:
Electrical hazard! Misuse or failure to follow instructions properly
may result in personal injury or death!
CAUTION: No risk of personal injury; however, misuse or failure
to follow instructions may result in damage to equipment.
NOTE: No risk of personal injury or equipment damage; however,
misuse or failure to follow instructions may prevent proper performance
NOS types of KT88, 12AT7, 12AU7, 5Z3P tubes will work fine in the JAS Bravo 2.4
Amplifier. The amplifier voltage settings will also work fine with all compatible types.
NOTE: LOOK CAREFULLY at the tube pins and socket and make sure that you
insert the pins correctly. In most cases, replacing tubes presents no problem. The
tube can be made to release by pulling it out gently (sometimes with a little back and forth
wiggling). Nevertheless, it is possible to force the tube pins into the socket the wrong way!
If you install the tube wrongly you will probably damage the amplifier and the tube. This
kind of damage will not be covered by the manufacturer’s warranty. If you have any doubts
at all about this, please call your local dealer for help.
Page 3 of 6
http://www.jas-audio.com

Unpacking before installation
All shipping containers have been specially designed to protect their contents and special
care has been taken to prevent damage under normal shipping conditions. Mishandling
should be evident upon inspection of the shipping container. If shipping damage is found
after visual inspection, take care not to destroy the evidence. If necessary, document the
damage with photographs and contact the carrier immediately.
Caution: On reception, carefully remove your new Bravo 2.4 from its packing carton and
examine it closely for signs of shipping damage. It is recommended to save all original
packing cartons and crates to protect your amplifier from damage should you wish to store
it or ship it for after-sales service.
Installation and Set up
Three-way binding posts provide output to the speaker system (4 or 8 ohm connections).
Power Requirements: The Bravo 2.4 is designed to operate from the AC mains (house
current) and is pre-set in the factory according to local supply of the import region. A
standard IEC AC power socket with a built-in fuse is provided on the back chassis panel.
Caution: There is a power on-off knob located on the left of the Bravo front panel.
When it is at Power On position, the output tubes will light up.
Power On Operation
Your new amplifier is ready for operation after the speaker cables, interconnect cables
and tubes have been correctly installed.
We recommended extreme high quality silver cables for speaker, interconnect, and power
connections. Please ask your local dealer for additional information.
Features
ƒ Push-pull circuitry for dynamic sound with a balance in definition and texture in
sonic performance
ƒ Selected and matched KT88, 12AT7 and 5Z3P tubes
ƒ Separate wide-band audio power and output transformers
ƒ All transformers are electrically isolated and mechanically shock-mounted
ƒ Additional internal damping material for added control of mechanical resonance
ƒ 4 and 8-ohm output impedance taps for optimum speaker impedance matching
ƒ Factory pre-set on Voltage Operations with fuse protects amplifier circuit in case of
current overload
ƒ Bravo series tube amplifiers are handcrafted to meet high quality standards
Running-In Period
The tubes, capacitors and the output transformers take approximately 100 hours of
music playing to fully settle in for peak performance.
Small imperfections in the tube
surfaces will ‘boil off’ during the break in period as well.
Page 4 of 6
http://www.jas-audio.com

The amplifier will sound good right out of the box but it will improve as break-in occurs.
After the first couple of hours you will notice increased depth and tighter bass. This
break-in phenomenon is true of
most high performance audio amplifiers .
Aftercare
The chassis may be cleaned with a soft towel cleaner. The frequency of cleaning will be
governed by the cleanliness of the operating environmental. Spray the cleaner on the
towel, not on the amplifier! Avoid abrasive cleaners! Feather dusters are
good for cleaning
the amp.
Limited Warranty
This product has been designed and manufactured to the highest quality and standards.
However, if something does go wrong with this product, JAS Audio and its national
distributors
warrant, free of charge, labor (exclusion may apply) and replacement parts in
any country
served by an official JAS Audio distributor.
This limited warranty is valid for a period of 2years from the date of purchase of
an amplifier or six months for vacuum tubes.
Terms and Conditions
1. The warranty is limited to the repair of the equipment. Neither transportation, nor any
other
costs, nor any risk involved in removal, transportation and
installation of products is covered by this warranty.
2. This warranty will not be applicable other than in case of defects in materials and/ or
workmanship at the time of purchase and will not be applicable:
a. for damages caused by incorrect installation, connection or packing,
b.
for damages caused by any use than described in the user manual, or by
negligence, or by modifications, or by use of parts that are
not made or authorized by JAS Audio,
c.
for damages caused by faulty or unsuitable auxiliary equipments,
d.
for damages caused by accident, lighting, water, fire heat,
war, public disturbances or any other cause beyond the reasonable control
of JAS Audio and its appointed distributors,
e.
for products whose serial number has been altered, deleted, removed or made
illegible,
f.
if repairs or modifications have been performed by an unauthorized person.
3. This guarantee complements any national/regional law obligations of dealers or
national distributors and
does not affect your statutory rights as a customer.
How to claim repairs under warranty
Should service be required, please follow the following procedure:
1. If the equipment is being used in the country of purchase, you should
contact the JAS Audio Authorized dealer from whom the equipment
was purchased.
2.
If the equipment is being used outside the country of purchase, you
should contact JAS Audio National distributor in the country of residence
who will advise where
the equipment can be serviced.
Page 5 of 6
http://www.jas-audio.com

TO VALIDATE YOUR WARRANTY, YOU WILL NEED THE ORIGINAL
SALES INVOICE OR OTHER PROOF OF OWNERSHIPAND DATE OF
PURCHASE.
Technical Specifications
Product Model: JAS Bravo 2.4
Description: VacuumTubeAmplifier
Technical Features: Push-pull circuit topology
Power Requirement: AC 110/117, 220/240 @ 50-60Hz set factory pre-set
for matching mains supply
PowerOutput: 50WX2@（4
Ω , 8 Ω ）
Input Sensitivity: 0.67V for 50W
Input Impedance: 47K Ω
Frequency Response: 10Hz (-0.5dB) --- 80KHz (- 3dB)
Total Harmonic Distortion: ≤1%
S/Nratio: 90dB
Tubecomplement: KT88x 4, 5Z3P x 2, 12AT7 (CV455) x 2, 12AU7 x 1
Static Power Consumption: ≤180W
Chassis Dimensions: 430mm (W) x 330mm (D) x 185mm (H)
Packing Box Sizes: 540mm (W) x 470mm (D) x 310mm (H)
Net Weight: 20 Kgs
Gross/Shipping Weight: 21.5 Kgs
JAS AUDIO is constantly striving new design improvements, we reserve the
right to change or modify product specifications without prior notice or
obligation.
Note: All Bravo 2.4 amplifiers have their own serial number (S/N xxxxx), marked on
the back of the chassis and also printed on the exterior of the packing box.
Happy Listening to all music lovers!
Best Regards ,
Set your mind free!
Version 1.3 and Copyright © Oct 2009 JAS AUDIO
