Jasic TIG200PACDC PFC User manual

Copyright©2022 Shenzhen JASIC Technology Co., Ltd.
TIG200PACDC PFC LCD
TIG200PACDC LCD
IGBT INVERTER WELDER

Page 2
Thank you for selecting this new JASIC equipment!
This operating manual contains important information on the use and maintenance of this
product, as well as safe handling of the product. Please refer to technical parameters of the
equipment in Technical Parameter section in this manual, and read the manual carefully
before using the equipment for the first time. For your own safety and that of your working
environment, please pay particular attention to the safety instructions in the manual and
operate the equipment according to the instructions. For more information on JASIC
products, please contact JASIC Technology, consult an authorized JASIC dealer or visit
JASIC website at www.jasictech.com.
Disclaimer
Shenzhen JASIC Technology Co., Ltd. solemnly promises that this product is manufactured according
to relevant domestic and international standards, and that this product conforms to EN60974-1
International Safety Standard. Patents protect the relevant design scheme and manufacturing technology
adopted in this product.
1. Whilst every effort has been made to ensure that the information contained within this manual is
complete and accurate, no liability can be accepted for any errors or omissions. Please note products are
subject to continual development and may be subject to change without notice.
2. Though contents in this manual have been carefully checked, there may be inaccuracies. Please do not
hesitate contact us in case of any inaccuracy.
3. Do not copy, record, reproduce or transmit the contents of this manual without prior permission from
JASIC.
Manufacturer: Shenzhen JASIC Technology Co. Ltd
Registered Trademark: JASIC
Registered Address: No.3 Qinglan 1st Road, Pingshan District, Shenzhen, Guangdong, China
Postcode: 518118
Tel: [phone] Fax: [phone]
Website: www.jasictech.com E-mail: [e-mail]

Page 3
Contents
1. Safety precautions.......................................................................................................................... 5
1.1. General safety.............................................................................................................................. 5
1.2. Other precautions........................................................................................................................ 8
2. Description of symbols................................................................................................................... 9
3. Product overview.......................................................................................................................... 10
4. Technical parameters................................................................................................................... 11
5. Installation...................................................................................................................................... 13
5.1. External interface description.................................................................................................. 13
5.2. Power installation...................................................................................................................... 14
5.3. MMA electrode holder and earth cable connection..............................................................15
5.4. TIG welding torch and earth cable connection..................................................................... 16
5.5. Wired handheld remote controller connection (optional).................................................... 18
5.6. Installation of wireless receiver module (optional)............................................................... 19
6. Control panel................................................................................................................................. 20
6.1. LCD panel...................................................................................................................................20
6.2. LCD screen function table........................................................................................................20
6.3. Welding mode............................................................................................................................ 24
6.4. Gas check function....................................................................................................................25
6.5. Channel storage........................................................................................................................ 25
6.6. Parameter setting...................................................................................................................... 26
6.7. Function setting......................................................................................................................... 27
6.8. Other functions...........................................................................................................................28
6.9. User Manual............................................................................................................................... 35
6.10. Alarm function.......................................................................................................................... 36
6.11. Screen protection function..................................................................................................... 36
7. Welding function operation..........................................................................................................37
7.1. Function table.............................................................................................................................37
7.2. MMA function............................................................................................................................. 38
7.3. TIG function................................................................................................................................ 39
8. Maintenance.................................................................................................................................. 50
8.1. Power supply maintenance......................................................................................................50
8.2. Welding torch maintenance..................................................................................................... 51
9. Troubleshooting.............................................................................................................................53
9.1. Common malfunction analysis and solution..........................................................................53
9.2. Alarm and solutions................................................................................................................... 55
10. Packaging, transportation, storage and waste disposal.......................................................56
10.1. Transportation requirements................................................................................................. 56
10.2. Storage conditions.................................................................................................................. 56
10.3. Waste disposal.........................................................................................................................56
Appendix 1: Wiring diagram............................................................................................................ 58
Appendix 2: List of common spare parts 1....................................................................................59
Appendix 3: List of common spare parts 2....................................................................................60

Page 4
For your safety, please read this manual carefully before installing and
operating this JASIC equipment.
Pay extra attention to all content marked with " ".
All operations must be carried out by professional, suitably qualified
persons!

Page 5
1. Safety precautions
1.1. General safety
SAFETY INSTRUCTION
These general safety norms cover both arc welding machines and plasma cutting
machines unless otherwise noted.
It is important that users of this equipment protect yourselves and others from harm or even
death.
The equipment must only be used for the purpose it was designed for. Using it in any other
way could result in damage or injury and in breach of the safety rules.
Only suitably trained and competent persons should use the equipment.
Pacemaker wearers should consult your doctor prior to using this equipment
PPE and workplace safety equipment must be compatible for the application of work
involved.
Always carry out a risk assessment before carrying out any welding or cutting activity
Only qualified personnel should operate this machine!
·Always use the appropriate personal protective equipment.
·Always pay attention to the safety of other persons around the working zone
·Do not carry out any maintenance with the power on the machine
Electric shock——May cause serious injury or even death!
·The equipment should be installed by a qualified person and in accordance
with current standards in operation. It is the user's responsibility to ensure that
the equipment is connected to a suitable power supply. Consult with your utility
supplier if required. Do not use the equipment with the covers removed.
·Do not touch live electrical parts or parts, which are electrically charged.
·Turn off all equipment when not in use.
Fumes and gases——May be hazardous to your health.
Locate the equipment in a well-ventilated position and keep your head out of the
fume.
Do not breathe the fume.
Ensure the working zone is well ventilated and provision should be made for
suitable local fume extraction system to be in place.
If ventilation is poor, wear an approved air fed welding helmet or respirator.
Read and understand the Material Safety Data Sheets (MSDS’s) and the
manufacturer’s instructions for metals, consumable, coatings, cleaners and
de-greasers.
Do not work in locations near any de-greasing, cleaning or spraying operations.
Be aware that heat and rays of the arc can react with vapours to form highly
toxic and irritating gases.

Page 6
Arc rays——May injure the eyes and burn the skin.
The arc rays from all processes produce intense, visible and invisible (ultraviolet
and infrared) rays that can burn eyes and skin.
·Wear an approved welding helmet fitted with an appropriate shade of filter lens
to protect your face and eyes when working or watching.
·Wear approved safety glasses with side shields under your helmet.
·Never use broken or faulty welding helmets.
·Always ensure there are adequate protective screens or barriers to protect
others from flash, glare and sparks from the working area.
·Ensure that there are adequate warnings that welding or cutting is taking place.
·Wear suitable protective flame resistant clothing, gloves and footwear.
Precautions against fire and explosion
Avoid causing fires due to sparks and hot waste or molten metal.
Ensure that appropriate fire safety devices are available near the welding and
cutting area.
Remove all flammable and combustible materials from the welding, cutting and
surrounding areas.
Do not weld or cut fuel and lubricant containers, even if empty. These must be
carefully cleaned before they can be welded or cut.
Always allow the welded or cut material to cool before touching it or placing it in
contact with combustible or flammable material.
Do not work in atmospheres with high concentrations of combustible fumes,
flammable gases and dust.
Always check the work area half an hour after cutting to make sure that no fires
have begun.
Take care to avoid accidental contact of electrode to metal objects. This could
cause arcs, explosion, overheating or fire.
Risks due to hot material ·
The process will create hot metal, sparks and drips of molten metal, so it's very
important to ensure the operator is equipped with full PPE and to always ensure
there are adequate protective screens or barriers to protect others from flash,
glare and sparks from the working area. Hot surfaces will create fires and will
burn any exposed skin.
Always protect your eyes and body. Use the correct welding screen and filter
lens and wear full PPE protective clothing.
Do not touch any hot surfaces or parts bare handed.
Always allow hot surfaces and parts to cool down first before touching or
moving.
If you are required to move hot parts, ensure you use proper tools and insulated
welding gloves (PPE) to prevent burns to your hands and arms.

Page 7
Noise——Excessive noise may be harmful to hearing
·Protect your ears by ear shields or other hearing protectors.
·Give warning to nearby personnel that noise may be potentially
hazardous to hearing.
Risks due to magnetic fields
The magnetic fields created by high currents may affect the operation of
pacemakers or electronically controlled medical equipment.
Wearers of vital electronic equipment should consult their physician before
beginning any arc welding, cutting, gouging or spot welding operations.
Do not go near welding equipment with any sensitive electronic equipment as
the magnetic fields may cause damage.
Keep the torch cable and work return cable as close to each other as possible
throughout their length, this can help minimize your exposure to harmful
magnetic fields.
Do not wrap the cables around the body.
Protection from moving parts
When the machine is in operation keep away from moving parts such as motors
and fans.
Moving parts, such as the fan, may cut fingers and hands and snag garments.
Protections and coverings may be removed for maintenance and controls only
by qualified personnel after first disconnecting the power supply cable.
Replace the coverings and protections and close all doors when the intervention
is finished and before starting the equipment.
Take care to avoid getting fingers trapped when loading and feeding wire during
set up and operation.
When feeding wire be careful to avoid pointing it at other people or towards your
body.
Always ensure machine covers and protective devices are in operation.
Troubleshooting
Before the machines are dispatched from the factory, they have already been
checked thoroughly. The machine should not be tampered with or altered.
Maintenance must be carried out carefully. If any wire becomes loose or is
misplaced, it maybe potentially dangerous to user!
Only professional maintenance personnel should repair the machine!
Ensure the power is disconnected before working on the machine. Always wait
5 minutes after power switch off before removing the panels.
If you still do not fully understand or cannot solve the problem after reading the
instructions in this manual, you should contact the supplier or JASIC's service
center immediately for professional help.

Page 8
1.2. Other precautions
Warning! Location
The machine should be located in a suitable position and environment. Care
should be taken to avoid moisture, dust, steam, oil or corrosive gases. Place
on a secure level surface and ensure that there is adequate clearance
around the machine to ensure natural airflow.
Warning! The handle or strap on the machine is only suitable for manual
lifting of the machine. If mechanical equipment such as crane is used to lift
the machine, please ensure the machine is secured with suitable lifting
equipment.
Warning!
Input connection
Before connecting the machine, you should ensure that the correct supply is
available. Details of the machine requirements can be found on the data
plate of the machine or in the technical parameters shown in the manual. The
equipment should be connected by a suitably qualified competent person.
Always ensure the equipment has a proper grounding.
Never connect the machine to the mains supply with the panels removed.
1) When the operator's movement is limited by the surroundings (for example, the operator
can only bend his knees, barefoot, or lie down during operation), the operator shall practice
proper insulation and avoid direct contact with conductive parts on the equipment.
2) Do not use the machine in closed containers in narrow spaces where conductive
components cannot be removed.
3) Do not use the machine in humid environments where the operator is prone to the risk of
electric shock.
4) Do not use the machine in sunlight or rain, and no water or rainwater shall seep into the
machine.
5) Do not perform gas shielded welding in an environment with strong air flow.
6) Avoid welding or cutting in dusty area or environment with corrosive chemical gas.
7) The ambient temperature must be between-10°C and 40°C during operation and
between-25°C and 50°C during storage.
8) Welding or cutting shall be carried out in a relatively dry environment, and the air humidity
shall not exceed 90%.
9) The inclination of the machine shall not exceed 10°.
10) Ensure that the input power supply voltage does not exceed 15% of the rated voltage of
the machine.
11) Beware of falling when welding or cutting at heights.

Page 9
2. Description of symbols
Warning! Read the Manual
Current unit "A"
WEEE tag
Time unit "S"
Overheat indicator
Percentage
VRD function indicator
Frequency unit "Hz"
Warning tag
Lift TIG mode
MMA mode
Wireless receiver module indicator
MMA current
Pairing of wireless simple remote
controller (optional)
MMA hot start current
Remote control key
MMA arc force current
Water cooler function
HF arc ignition mode
Parameter adjustment knob and
confirmation key
DC mode
Pulse mode

Page 10
3. Product overview
This is a digital inverter AC/DC welder with complete functions, excellent performance and
advanced technology. It supports AC TIG (with optional square wave, triangular wave and
sine wave), AC pulse TIG, DC TIG, DC pulse TIG, MMA (DC), and TIG spot welding (DC/AC),
and can be widely used for precise welding of an extensive range of materials. The unique
electrical structure and air passage design inside the machine increase the dissipation of
heat generated by power devices, thus improving the duty cycle of the machine. Due to the
unique heat dissipation efficiency of the air passage, it can effectively prevent damage to the
power devices and the control circuits caused by fan dust inhalation, thus greatly improving
the reliability of the machine.
Note: The functions described below are only a general overview, and the specific
functions are subject to the machine model.
Main functions include:
Multiple welding modes and optional torch control modes.
Real-time output current display: Easily displays the welder output state.
Anti-stick function: Prevents the welding electrode from sticking to the workpiece
during welding.
VRD function: Protects the operators from high voltage electric shock when the
machine is not operational.
MMA hot start function: Makes MMA arc ignition easier and more reliable.
Smart fan temperature control: Prolongs the fan lifespan and reduces internal dust
accumulation.
TIG welding: Supports both contact and non-contact arc ignition. Non-contact arc
ignition includes a high-voltage arc ignition circuit for high arc ignition success rate.
Parameters are automatically saved when the machine is turned off or during power cut,
after restarting, the welder will restore previous parameters.
Optional wired handheld remote controller and wireless remote controllers.

Page 11
4. Technical parameters
Item
Unit
Parameters
Model
/
TIG200PACDC PFC
TIG200PACDC
Input voltage
VAC
AC115±15%~230V±15%
AC230V±15%
Input frequency
Hz
50/60
50/60
Rated input current
(AC230V)
A
20.2@TIG
22.4@MMA
31.6@TIG
34.1@MMA
Rated input current
(AC115V)
A
30.6@TIG
32.8@MMA
/
Rated input power
(AC230V)
kVA
4.7@TIG
5.6@MMA
6.0@TIG
7.0@MMA
Rated input power
(AC115V)
kVA
3.5@TIG
3.9@MMA
/
Output current range
(TIG_DC)
A
230V: 5~200
115V: 5~160
5~200
Output current range
(TIG_AC)
A
230V: 20~200
115V: 20~160
20~200
Output current range (MMA)
A
230V: 10~160
115V: 10~120
10~160
Rated operating voltage
(AC230V)
V
18@TIG 26.4@MMA
18@TIG
26.4@MMA
Rated operating voltage
(AC115V)
V
16.4@TIG
14.8@MMA
/
Arc force range
A
0~-40
0~40
Hot start range
A
0~80
0~80
No-load voltage
V
64
60
VRD voltage
V
11.5
11.5
AC output frequency
Hz
20~250
20~250
AC balance
%
20~-60
20~60
Base current
A
5~200
5~200
Pulse frequency (DC)
Hz
0.5~200
0.5~200
Pulse frequency (AC)
Hz
AC frequency: 20Hz
Pulse frequency: 0.5-2Hz
AC frequency: 20Hz
Pulse frequency:
0.5-2Hz
AC frequency: 250Hz
Pulse frequency: 0.5-25Hz
AC frequency: 250Hz
Pulse frequency:
0.5-25Hz

Page 12
Pulse duty factor
%
10~90
10~90
Pre-flow time
S
0~3
0~3
Post-flow time
S
0~15
0~15
Upslope time
S
0~10
0~10
Downslope time
S
0~10
0~10
Spot welding time
S
0.1-10
0.1-10
Remote controller
-
Digital remote controller,
analog remote controller,
wireless remote controller
Digital remote controller,
analog remote controller,
wireless remote
controller
Arc start mode
/
HF arc ignition and lift arc
ignition
HF arc ignition and lift
arc ignition
Duty cycle
%
TIG: 25%
MMA: 30%
TIG: 25%
MMA: 20%
Efficiency
%
80
80
Power factor
/
0.95
0.75
Insulation class
/
H
H
Protection class
/
IP23S
IP23S
Dimensions L*W*H
mm
490*165*341
490*165*341
Package dimensions L*W*H
mm
735*230*440
735*230*440
Net weight
Kg
12
12
Overall total weight
Kg
16.9
16.7
Characteristics
/
CC
CC
Pollution level
/
Level 3
Level 3

Page 13
5. Installation
Warning! All connections shall be made after the power supply is turned off.
Warning! Electric shock may cause death; after power failure, there is still a
high voltage on the equipment, do not touch the live parts on the equipment.
Warning! Incorrect input voltage may damage the equipment.
Warning! This product meets the requirements of Class A equipment in EMC
requirements and is not to be connected to a residential low-voltage power
supply grid.
5.1. External interface description
(Front panel view) (Rear panel view)
a. Power switch
b. Input power cord
c. Inlet nozzle
d. Water cooler socket
e. Negative polarity
f. TIG welding torch gas connector
g. Positive polarity
h. 9-pin aviation socket
i. Wireless receiver module (optional)

Page 14
5.2. Power installation
Warning! The electrical connection of equipment shall be carried out by
suitably qualified personnel.
Warning! All connections shall be made after the power supply is turned off.
Warning! Incorrect input voltage may damage the equipment.
1) Connect the welder to the corresponding voltage grade according to its specified input
voltage. DO NOT connect to the wrong voltage grade.
2) Ensure that the input power cable is in good contact with the power terminal or socket.
3) Ensure the input voltage value is within the specified input voltage range.
4) Ground the power supply well. (As shown in the diagram, the Euro plug has a
grounding terminal, no additional grounding is required.)
5) Ensure that the welder power switch is turned off.
(Wiring diagram)
NOTE! If the input cable needs to be extended, please use a cable with larger
cross-sectional area to reduce the voltage drop, 3x2.5mm2 or more is recommended.

Page 15
5.3. MMA electrode holder and earth cable connection
(Wiring diagram)
Pay attention to the polarity of the wiring before MMA. Generally, there are two connection
methods for DC welder: DCEN and DCEP.
DCEN: The electrode holder is connected to the negative polarity, and the workpiece is
connected to the positive polarity;
DCEP: The electrode holder is connected to the positive polarity, and the workpiece is
connected to the negative polarity.
The operator can also choose the DCEN according to the base metal and electrode type
being used. Generally speaking, it is recommended to adopt DCEP for basic electrode (i.e.,
welding electrode connected to the positive polarity), while no special provisions are made
for acid electrode.
1) Ensure that the welder power switch is turned off.
2) Insert the cable plug with electrode holder into the corresponding socket on the front
panel of the welder and tighten it clockwise.
3) Insert the cable plug with earth clamp into the corresponding socket on the front panel of
the welder and tighten it clockwise.
NOTE! If you want to use long secondary cables (electrode holder cable and earth
cable), you must ensure that the cross-sectional area of the cable is increased
appropriately in order to reduce the voltage drop due to the cable length.

Page 16
5.4. TIG welding torch and earth cable connection
1) Ensure that the welder power switch is turned off.
2) Insert the cable plug with the earth clamp into the positive socket on the front panel of the
welder and tighten it clockwise.
3) Insert the cable plug of the welding torch into the corresponding negative socket on the
front panel of the welder and tighten it clockwise.
NOTE! The positive and negative polarities should not be reversed as this will prevent
normal welding operation.
4) Insert the welding torch gas connector into the gas vent on the front panel.
5) Connect the gas hose of the argon cylinder to the inlet nozzle on the rear panel of the
machine.
(Wiring diagram)
NOTE! If you want to use long secondary cables (torch cable and earth cable), you
must ensure that the cross-sectional area of the cable is increased appropriately in
order to reduce the voltage drop due to the cable length.
6) In AC TIG welding mode, please shorten the power cable as much as possible. If the
cable must be extended, please pay attention to the following:
● Bind the cables for the base metal and the welding torch together.
● Straighten the cable as much as possible.
● If the cable cannot be straightened, straddle the welding torch cable across the base
metal.

Page 17
● If excessive cable must be wound up, please refer to the following good practices
Bad practice
Good practice
Do not wind up excess cable along the same
direction.
Wind up the same number of turns in the
cable winding direction and the opposite
direction, and stack them together.

Page 18
5.5. Wired handheld remote controller connection (optional)
(Wiring diagram)
Insert the 9-pin aviation plug of the handheld remote controller directly into the
corresponding aviation socket of the machine.
NOTE! Please check that the machine supports wired handheld remote controller
before installation.

Page 19
5.6. Installation of wireless receiver module (optional)
(Installation drawing)
Remove the wireless remote controller plug cover shown in the above left figure. Insert into
the wireless receiver module shown in the above right figure.
1) Remove the screws on the left cover of the machine.
2) Remove the buckle inside the front panel of the machine and pull out the wireless plug.
3) Insert the wireless receiver module into the front panel, and then connect the receiver
module connection line to the CN2 socket on the control panel PK-442.
NOTE! Please check that the machine supports wireless handheld remote controller
before installation.

Page 20
6. Control panel
6.1. LCD panel
6.2. LCD screen function table
a
Back to
main menu
Press the "Home" key to return to the main menu
interface.
b
Gas check
function
1. Press the gas check icon to open the submenu
and enter the gas check state; after 20s, the
system will automatically exit the gas check
function and return to the previous menu;
2. During gas check, press any key to close the
gas check function.
a
b
c
d
e
g
h
i
j
k
p
f
l
m
n
