Jasic CUT40HF User manual

Copyright©2022 Shenzhen JASIC Technology Co., Ltd.
CUT40HF/CUT40NHF
CUT45PFC
IGBT INVERTER CUTTER

Page 2
Thank you for selecting this new JASIC welder equipment!
This operating manual contains important information on the use and maintenance of this
product, as well as safe handling of the product. Please refer to technical parameters of the
equipment in Technical Parameter section in this manual, and read the manual carefully
before using the equipment for the first time. For your own safety and that of your working
environment, please pay particular attention to the safety instructions in the manual and
operate the equipment according to the instructions. For more information on JASIC
products, please contact JASIC Technology, consult an authorized JASIC dealer or visit
JASIC website at www.jasictech.com.
Disclaimer
Shenzhen JASIC Technology Co., Ltd. solemnly promises that this product is manufactured according
to relevant domestic and international standards, and that this product conforms to EN60974-1
International Safety Standard. Patents protect the relevant design scheme and manufacturing technology
adopted in this product
1. The information contained in this Manual has been made every effort to be accurate and perfect, and
the company will not be responsible for any errors
and omissions arising from non-compliance with this Manual.
2. JASIC reserves the right to amend this Manual at any time without prior notice.
3. Although the contents of this Manual have been carefully checked, there may still be inaccuracies. If
users find out, please consult with our company.
4. It is forbidden to copy, record, reprint or disseminate the contents of this Manual without the prior
authorization of JASIC.
Manufacturer: Shenzhen JASIC Technology Co. Ltd
Registered Trademark: JASIC
Registered Address: No.3 Qinglan 1st Road, Pingshan District, Shenzhen, Guangdong, China
Postcode: 518118
Tel: [phone] Fax: [phone]
Website: www.jasictech.com E-mail: [e-mail]

Page 3
Contents
1. Safety precautions.......................................................................................................................... 5
1.1. General safety.............................................................................................................................. 5
1.2. Other precautions........................................................................................................................ 8
2. Description of symbols................................................................................................................... 9
3. Product overview.......................................................................................................................... 10
4. Technical parameters................................................................................................................... 11
5. Installation...................................................................................................................................... 12
5.1. External interface description.................................................................................................. 12
5.2. Power installation...................................................................................................................... 13
5.3. Connection of cutting torch, earth cable and gas hose....................................................... 14
6. Control panel................................................................................................................................. 15
6.1. Overview..................................................................................................................................... 15
6.2. Display of parameters and error codes..................................................................................15
6.3. Parameter adjustment knob.....................................................................................................16
6.5. Selection of working mode.......................................................................................................17
6.6. Gas check function....................................................................................................................17
6.7. Cutting current configuration................................................................................................... 18
6.8. 2T/4T function settings............................................................................................................. 18
6.9. Cutting torch length and post-flow time configuration......................................................... 18
6.10. Help........................................................................................................................................... 19
6.11. Language selection................................................................................................................. 19
6.12. Unit configuration.................................................................................................................... 19
6.13. Back-end configuration...........................................................................................................19
6.14. User manual............................................................................................................................. 20
6.15. Protective indication................................................................................................................21
7. Cutting function operation........................................................................................................... 21
7.1. Cutting operation....................................................................................................................... 21
8. Maintenance.................................................................................................................................. 23
8.1. Power supply maintenance......................................................................................................23
9. Troubleshooting.............................................................................................................................24
9.1. Common malfunction analysis and solution..........................................................................24
9.2. Alarms and solutions................................................................................................................. 25
10. Packaging, transportation, storage and waste disposal.......................................................26
10.1. Transportation requirements................................................................................................. 26
10.2. Storage conditions.................................................................................................................. 26
10.3. Waste disposal.........................................................................................................................26
Appendix 1: Wiring diagram of CUT45PFC.................................................................................. 27
Appendix 2: Exploded-view drawing of CUT45PFC.................................................................... 28
Appendix 3: List of CUT45PFC common spare parts................................................................. 29
Appendix 4: Wiring diagram of CUT40HF/CUT40NHF............................................................... 30
Appendix 5: Exploded-view drawing of CUT40HF/CUT40NHF.................................................31
Appendix 6: List of CUT40HF/CUT40NHF common spare parts.............................................. 32

Page 4
For your safety, please read this manual carefully before installing and
operating this JASIC equipment.
Pay extra attention to all content marked with " ".
All operations must be carried out by professional, suitably qualified
persons!

Page 5
1. Safety precautions
1.1. General safety
SAFETY INSTRUCTION
These general safety norms cover both arc welding machines and plasma cutting
machines unless otherwise noted.
It is important that users of this equipment protect yourselves and others from harm or even
death.
The equipment must only be used for the purpose it was designed for. Using it in any other
way could result in damage or injury and in breach of the safety rules.
Only suitably trained and competent persons should use the equipment.
Pacemaker wearers should consult your doctor prior to using this equipment
PPE and workplace safety equipment must be compatible for the application of work
involved.
Always carry out a risk assessment before carrying out any welding or cutting activity
Only qualified personnel should operate this machine!
·Always use the appropriate personal protective equipment.
·Always pay attention to the safety of other persons around the working zone
·Do not carry out any maintenance with the power on the machine
Electric shock——May cause serious injury or even death!
·The equipment should be installed by a qualified person and in accordance
with current standards in operation. It is the user's responsibility to ensure that
the equipment is connected to a suitable power supply. Consult with your utility
supplier if required. Do not use the equipment with the covers removed.
·Do not touch live electrical parts or parts, which are electrically charged.
·Turn off all equipment when not in use.
Fumes and gases——May be hazardous to your health.
Locate the equipment in a well-ventilated position and keep your head out of the
fume.
Do not breathe the fume.
Ensure the working zone is well ventilated and provision should be made for
suitable local fume extraction system to be in place.
If ventilation is poor, wear an approved air fed welding helmet or respirator.
Read and understand the Material Safety Data Sheets (MSDS’s) and the
manufacturer’s instructions for metals, consumable, coatings, cleaners and
de-greasers.
Do not work in locations near any de-greasing, cleaning or spraying operations.
Be aware that heat and rays of the arc can react with vapours to form highly
toxic and irritating gases.

Page 6
Arc rays——May injure the eyes and burn the skin.
The arc rays from all processes produce intense, visible and invisible (ultraviolet
and infrared) rays that can burn eyes and skin.
·Wear an approved welding helmet fitted with an appropriate shade of filter lens
to protect your face and eyes when working or watching.
·Wear approved safety glasses with side shields under your helmet.
·Never use broken or faulty welding helmets.
·Always ensure there are adequate protective screens or barriers to protect
others from flash, glare and sparks from the working area.
·Ensure that there are adequate warnings that welding or cutting is taking place.
·Wear suitable protective flame resistant clothing, gloves and footwear.
Precautions against fire and explosion
Avoid causing fires due to sparks and hot waste or molten metal.
Ensure that appropriate fire safety devices are available near the welding and
cutting area.
Remove all flammable and combustible materials from the welding, cutting and
surrounding areas.
Do not weld or cut fuel and lubricant containers, even if empty. These must be
carefully cleaned before they can be welded or cut.
Always allow the welded or cut material to cool before touching it or placing it in
contact with combustible or flammable material.
Do not work in atmospheres with high concentrations of combustible fumes,
flammable gases and dust.
Always check the work area half an hour after cutting to make sure that no fires
have begun.
Take care to avoid accidental contact of electrode to metal objects. This could
cause arcs, explosion, overheating or fire.
Risks due to hot material ·
The process will create hot metal, sparks and drips of molten metal, so it's very
important to ensure the operator is equipped with full PPE and to always ensure
there are adequate protective screens or barriers to protect others from flash,
glare and sparks from the working area. Hot surfaces will create fires and will
burn any exposed skin.
Always protect your eyes and body. Use the correct welding screen and filter
lens and wear full PPE protective clothing.
Do not touch any hot surfaces or parts bare handed.
Always allow hot surfaces and parts to cool down first before touching or
moving.
If you are required to move hot parts, ensure you use proper tools and insulated
welding gloves (PPE) to prevent burns to your hands and arms.

Page 7
Noise——Excessive noise may be harmful to hearing
·Protect your ears by ear shields or other hearing protectors.
·Give warning to nearby personnel that noise may be potentially
hazardous to hearing.
Risks due to magnetic fields
The magnetic fields created by high currents may affect the operation of
pacemakers or electronically controlled medical equipment.
Wearers of vital electronic equipment should consult their physician before
beginning any arc welding, cutting, gouging or spot welding operations.
Do not go near welding equipment with any sensitive electronic equipment as
the magnetic fields may cause damage.
Keep the torch cable and work return cable as close to each other as possible
throughout their length, this can help minimize your exposure to harmful
magnetic fields.
Do not wrap the cables around the body.
Protection from moving parts
When the machine is in operation keep away from moving parts such as motors
and fans.
Moving parts, such as the fan, may cut fingers and hands and snag garments.
Protections and coverings may be removed for maintenance and controls only
by qualified personnel after first disconnecting the power supply cable.
Replace the coverings and protections and close all doors when the intervention
is finished and before starting the equipment.
Take care to avoid getting fingers trapped when loading and feeding wire during
set up and operation.
When feeding wire be careful to avoid pointing it at other people or towards your
body.
Always ensure machine covers and protective devices are in operation.
Troubleshooting
Before the machines are dispatched from the factory, they have already been
checked thoroughly. The machine should not be tampered with or altered.
Maintenance must be carried out carefully. If any wire becomes loose or is
misplaced, it maybe potentially dangerous to user!
Only professional maintenance personnel should repair the machine!
Ensure the power is disconnected before working on the machine. Always wait
5 minutes after power switch off before removing the panels.
If you still do not fully understand or cannot solve the problem after reading the
instructions in this manual, you should contact the supplier or JASIC's service
center immediately for professional help.

Page 8
1.2. Other precautions
Warning! Location
The machine should be located in a suitable position and environment. Care
should be taken to avoid moisture, dust, steam, oil or corrosive gases. Place
on a secure level surface and ensure that there is adequate clearance
around the machine to ensure natural airflow.
Warning! The handle or strap on the machine is only suitable for manual
lifting of the machine. If mechanical equipment such as crane is used to lift
the machine, please ensure the machine is secured with suitable lifting
equipment.
Warning!
Input connection
Before connecting the machine, you should ensure that the correct supply is
available. Details of the machine requirements can be found on the data
plate of the machine or in the technical parameters shown in the manual. The
equipment should be connected by a suitably qualified competent person.
Always ensure the equipment has a proper grounding.
Never connect the machine to the mains supply with the panels removed.
1) When the operator's movement is limited by the surroundings (for example, the operator
can only bend his knees, barefoot, or lie down during operation), the operator shall practice
proper insulation and avoid direct contact with conductive parts on the equipment.
2) Do not use the machine in closed containers in narrow spaces where conductive
components cannot be removed.
3) Do not use the machine in humid environments where the operator is prone to the risk of
electric shock.
4) Do not use the machine in sunlight or rain, and no water or rainwater shall seep into the
machine.
5) Do not perform gas shielded welding in an environment with strong air flow.
6) Avoid welding or cutting in dusty area or environment with corrosive chemical gas.
7) The ambient temperature must be between-10°C and 40°C during operation and
between-25°C and 50°C during storage.
8) Welding or cutting shall be carried out in a relatively dry environment, and the air humidity
shall not exceed 90%.
9) The inclination of the machine shall not exceed 10°.
10) Ensure that the input power supply voltage does not exceed 15% of the rated voltage of
the machine.
11) Beware of falling when welding or cutting at heights.

Page 9
2. Description of symbols
Warning! Read the Manual
Electric shock risk warning
WEEE tag
Current unit "A"
Overheat protection indicator
Overcurrent protection indicator
2T continuous cut
4T continuous cut
Mesh cutting
Home
Return
Encoder

Page 10
3. Product overview
This is a digital inverter air plasma cutter featuring advanced technology with excellent
performance. It provides a stable DC arc and can cut carbon steel, low alloy steel, stainless
steel and other materials. Moreover, it offers adjustable cutting torch length setting and post
flow time setting. It is a durable machine with a wide range of applications.
The unique electrical structure and air passage design inside the machine increases
dissipation of heat generated by the power device, thus improving its duty cycle. Benefitting
from its unique air passage, it effectively prevents damage to the power device and control
circuits from dust drawn in by the fan, thus greatly improving the reliability of the machine.
Its main functions are:
Three cutting modes: 2T and 4T continuous cutting, and mesh cutting.
Stepless adjustment of cutting current for more precise current adjustment.
On-demand fan: prolongs the life of the fan and reduces accumulation of dust inside
the machine.
Parameters are automatically saved, and the state before shutdown is restored after
starting again.
Factory settings restore function.
The machine can be optionally equipped with a CNC interface to support CNC
equipments.

Page 11
4. Technical parameters
Item
Unit
Parameters
Model
/
CUT45PFC
CUT40HF
CUT40NHF
Input voltage
VAC
AC95~265V
AC230V±15%
AC230V±15%
Input frequency
Hz
50/60
50/60
50/60
Rated input current
(AC230V)
A
23
31
31
Rated input current
(AC115V)
A
31
/
/
Rated input power
(AC230V)
kVA
5.3
7.1
7.1
Rated input power
(AC115V)
kVA
3.6
/
/
Output current range
A
20～45
20～40
20～40
No-load voltage
V
300
280
280
Rated working voltage
V
98
96
96
Arc start mode
NHF
HF
NHF
Duty cycle
%
25
25
25
Power factor
0.99
0.6
0.6
Insulation class
H
H
H
Protection class
IP23S
IP23S
IP23S
Dimensions L*W*H
mm
546×165.8×341.1
546×165.8×341.1
546×165.8×341.1
Net weight
Kg
10
9.6
9.2
Overall total weight
Kg
14.5
14.1
13.7
Power supply
efficiency (at maximum
input current)
%
86
88
88
Idle state power
W
11.7
10.8
10.8
Characteristics
CC
CC
CC
Pollution level
Grade 3
Grade 3
Grade 3

Page 12
5. Installation
Warning! All connections shall be made with the power supply is turned off.
Warning! Electric shock may cause death; after power failure, there is still a
high voltage on the equipment, do not touch the live parts on the equipment.
Warning! Incorrect input voltage may damage the equipment.
Warning! This product meets the requirements of Class A equipment in EMC
requirements and is not to be connected to a residential low-voltage power
supply grid.
5.1. External interface description
(Front view) (Rear view)
a. Power switch
b. Input power cord
c. Fast socket (positive output)
d. Central plasma adapter (negative output)
e. CNC aviation socket (optional) (arc voltage output, torch trigger signal input)

Page 13
5.2. Power installation
Warning! The electrical connection of equipment shall be carried out by
suitably qualified personnel.
Warning! All connections shall be made after the power supply is off.
Warning! Incorrect voltage may damage the equipment.
1) Ensure the input voltage value is within the specified input voltage range.
2) Ensure that the power switch of the cutter is turned off.
3) Connect the input power cord to the input terminal or plug the power cord into the
corresponding socket (if any) and ensure a good contact.
4) Ground the power supply well. (As shown in the diagram, the European plug has a
grounding terminal, so no additional grounding is required.)
(Wiring diagram)
NOTE!
If the input cable needs to be extended, please use a cable with larger cross-sectional
area to reduce the voltage drop, 3x2.5mm2 or more is recommended.

Page 14
5.3. Connection of cutting torch, earth cable and gas hose
1) Ensure that the power switch of the cutting machine is turned off.
2) Insert the cable plug with earth clamp into the corresponding positive fast socket on the
front panel of the machine and tighten it clockwise.
3) Insert the central plasma plug of the cutting torch into the negative central plasma socket
on the front panel of the machine and tighten it clockwise.
4) Connect the regulator input on the rear panel to the output interface of the compressed air
source, and fix it firmly with a clamp.
(Wiring diagram)
NOTE! If you want to use long secondary cables (plasma torch cable and earth cable),
you must ensure that the cross-sectional area of the cable is increased appropriately
in order to reduce the voltage drop due to the cable length.
Compressed air

Page 15
6. Control panel
6.1. Overview
a. Home: return to Home page
b. Return: return to upper level
c. Confirm: go to next level
d. Function adjustment knob: adjust the parameter or focal spot
e. LCD screen: display information
6.2. Display of parameters and error codes
1) Display the current configuration, operation mode, post-flow time, and information prompt
on current operation.
a
c
b
d
e

Page 16
2) When the factory settings are restored, a prompt window is displayed.
3) When the barcode queried, the machine barcode is displayed.
4) When the product is not working correctly, an error code is displayed.
6.3. Parameter adjustment knob
1) Parameter adjustment: When adjusting the parameter, the focal spot is cancelled. Rotate
the knob to adjust the parameter. Rotating clockwise increases the value, and
counterclockwise decreases it. As the knob is rotated, the parameter is adjusted in the
display area.
2) Focal spot adjustment: When adjusting the focal spot, the focal spot moves. Rotate the
knob to adjust it. Rotate the knob clockwise to shift the focal spot to the next element, and
counterclockwise to shift it to the previous element.

Page 17
6.4. Button operation
1) Home: After pressing Home, the screen jumps to the Home page.
2) Confirm: After pressing Confirm, the current focal spot response operation is performed.
3) Return: After pressing Return, the screen returns to the upper-level menu.
6.5. Selection of working mode
1) Before cutting, press the Home button to return to the home page; rotate the knob to
select Continuous Cut or Mesh Cut; and press Confirm to select the corresponding cut
mode.
、
6.6. Gas check function
1) In non-cutting state, select the gas check function on the Continuous Cut or Mesh Cut
page.
2) If the gas check animation is played, it indicates that the machine is in Gas Check mode.
3) Press Gas Check again or wait for 20s to close the animation and exit Gas Check mode.

Page 18
6.7. Cutting current configuration
In the Continuous Cut or Mesh Cut page, the display window shows the current cutting
current. Enter the adjusted current by rotating the knob.
6.8. 2T/4T function settings
In the Continuous Cut page, enter the Function Settings menu to select 2T or 4T.
、
6.9. Cutting torch length and post-flow time configuration
In the Continuous Cut or Mesh Cut pages, enter the Parameter Settings menu to set torch
length and post-flow time.
、 、

Page 19
6.10. Help
In the Settings page, enter the Help menu to display the current machine information.
、
6.11. Language selection
In settings page, enter the Language Selection menu to select English or Simplified
Chinese.
、
6.12. Unit configuration
In the Settings page, enter the Unit Setting menu to select the Imperial or metric system.
、
6.13. Back-end configuration
Standby time: Set the machine standby time.
、
In the Settings page, enter the Back-end Settings menu to select overvoltage/undervoltage
protection switch and standby time, restore cutting parameters, or restore factory settings.
Overvoltage/undervoltage protection switch: Set to enable or disable
overvoltage/undervoltage protection.

Page 20
、 、
Parameter Reset: restore all cutting parameters of the machine.
、 、
Factory Reset: Restore all factory settings of the machine.
、 、
6.14. User manual
In the Home page, enter the User Manual to select Operation, Components, or
Maintenance.
Operation: Learn about the operations of the machine.
、
Components: Learn about the parts of the machine.
、
Maintenance: Learn about maintenance of the machine.
