JastecM von Series User manual

Warning Statement
FCC Part 15.19 Statements:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
FCC Part 15.105 statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reason
able protection against harmful interference
in a residential installation. This equipment
generates, uses and can radiate radio freque
ncy energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communicatio
ns. However, there is no guarantee that inte
rference will not occur in a particular instal
lation. If this equipment does cause harmful
interference to radio or television reception,
which can be determi ned by turning the
equipment off and on, the user is encourag
ed to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
FCC Part 15.21 statement
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority
to operate this equipment.
RF Exposure 주의 문구
This equipment should be installed and
operated with minimum 20 cm between the
radiator and your body. This transmitter
must not be collocated or operating in
conjunction with any other antenna or
transmitter unless authorized to do so by
the FCC.
1. Device Info
1) Model :JTLC-5000
2) FCC Certification :
2. Warranty Period
1 year after purchase
3. Coverage
1) Immediately and effectively notify Guarantor
about determined device’s defects and cease any
using of it.
2) The Warranty does not cover: Damages due to
the user's fault or lack of knowledge
4. Return and change
1) Returns are only accepted within a week. It must
also be in the original packaging.
2) For the change of mind return, shipping fee will
be charged
5. Miscellaneous
1) For those who cannot confirm purchase date,
warranty start date will be correspondent to
activation date.
2) Repair fee will be charged for the following
cases
- Damage due to the user's fault or lack of
knowledge
- The device that has been tempered with
reconfiguration, repair, willful constructional
variations, modifications and adjustments
- Damages caused by acts of God, floods, fires,
lighting or other natural disasters, wars,
unexpected events, inappropriate voltage,
defective supply materials or other external
factors;
- Defects resulting from the usage of improper or
non-genuine supply materials;
6. Contact
82-1599-8439
von-U61

Processor 32-bit ARM Cortex-M4(1024KB Flash, 192KB SRAM)
Memory Internal Memory 8MB
Status 3-LEDs (ECU,GPS,NETWORK)
Protocol ISO 9141-2, ISO 14230-4(KWP-2000),
ISO 15765-4(CAN)
Support SAE J1979 Mode $01~$0A
Interface SAE J1962 Standard OBD-II 16 PIN Connector
Network
LTE Cat.4 Quectel EC25-AF(D)
LTE FDD - B2/B4/B5/B12/B13/B14/B66/B71
UMTS - B2/B4/B5
SIM Type MFF2, Embedded SIM
WiFi IEEE 802.11 a/b/g/n/ac (Hotspot Support)
GPS U-Blox, EVA-M8E
GPS, Glonass, Galileo, QZSS
Sensor 9-axis (Accelerometer/Gyroscope/Magnetometer)
BMX160
External Port Key Fob, RS-485 (H.D), CAN2
USB Port USB 2.0, VCP Supported
Voltage DC 12V ~ 24V
Consumption Max Power : ≤4000mW, Sleep : ≤60mW
Dimensions 52.7mm(W) x 25mm(D) x 73.3mm(H)
Weight 54g
Operating Temp -20 ~ +70 ℃
Storage Temp -40 ~ +80 ℃
