Jaycar XC-5410 User manual

Pen Style Presenter
With Laser pointer
XC-5410
User Manual

1
Instruction
Features:
1. Store device conveniently.
The transmitter and receiver are
integrated into one unit for easy
storage.
2. Control pace of your presentation.
Uses radio frequency (RF) technology
and operates up to 10-metres away
from receiver.
3. Multifunctional presenter
This device combines the functions of
a laser pointer, slide changer and
blank screen display selector for
PowerPoint presentations.
4. Plug and Play wireless receiver
There’s no software to install. Just
plug the receiver into a USB port to
begin. When the presentation is over,
you can store the receiver in the
presenter.
I. Operation System
Compatible with Windows 2000 &
above, Windows XP, Vista, Win 7,
MAC.

2
II. Operating Hints
For optimal performance and RF
reception, please place the receiver at
least 15cm away from all electrical
devices, such as your monitor,
speakers or external storage devices.
III. Functions
Pointer
light
Press any button, the red
LED will turn on
Page Up
Page Down

3
Keep pressing this button
to emit laser beam, release
your hand, the laser will
disappear
Blank Screen Display
selector (for PowerPoint
only), press again to exit
Receiver Also has SD card reader
function.
IV. Replacing Battery
●Powered by 1x AAA battery.
●Push and remove the battery
compartment cover.
●Remove “OLD” AAA Battery and
dispose of battery accordingly.
●Insert “NEW” 1x AAA battery into
the battery holder.
●Put back in to position the battery
compartment cover.
IMPORTANT NOTES:

4
1. Ensure battery polarity is correct
(+) (-)
2. Do not leave bad or exhausted
battery in the device.
3. Please remove battery if device
is not used for long periods,
4. If the device does not function
correctly or if the operating range is
reduced, replace the battery with a
new one.
V. Specifications
Transmitter
Control technology 2.4GHz RF
RF Output power 0dBm
Control distance Up to 10M
Laser distance Up to 200M
Laser wavelength 650nm
Max output <1mW or <5mW
Battery 1 x AAA
Working voltage 1.2~1.5V
Sleep current <50uA
Dimension 13.3*2.2*1.7cm
Weight 21.4g(no battery)
Receiver
Sensitivity -90dBm
Operation
system Windows 2000 and above,
Windows XP, Vista，Win 7

5
Interface USB1.1 , Compatible with
USB2.0
Working
voltage USB electricity supply (4.5-5.5V)
Dimension 3.2*1.46*0.73cm
Weight 2g
VI. Safety Measures
To avoid possible eye damage,
never point the presenter at people,
especially their faces, or look directly
into the presenter’s laser beam.
Avoid pointing the presenter’s
laser beam at a mirror or other highly
reflective surface.
Keep the presenter away from
children.
Never view the presenter’s laser
beam using telescopic devices, such
as a microscope or binoculars.
Any attempt to disassemble,
adjust or repair the presenter may
result in exposure to laser light or
other safety hazards.

6
Note
The product adopts RF technology,
the USB receiver will identify the first
transmitter which is used. If you want
to use different transmitters with the
same receiver, please remove the
receiver and plug it in again, after 6
seconds, press any key on the
transmitter.
