jbc FAE030 User manual

FAE030
Collector Flange
for Stand Aspiration Ducts
INSTRUCTION MANUAL

Packing List
The following items should be included:
Collector Flange for Stand Aspiration Ducts ...................................................................................... 1 unit
Ref. FAE030
Main Aspiration Duct
Collector Flange
FAE030 comes with 4 caps
Replacement:
Caps for FAE Collector Flange
Ref. 0019101 (includes 2 caps)
O-Ring ......................................................... 2 units
53x2.5 - NBR70
Screws ......................................................... 6 units
DIN7982 - ø3.5x16 - black burnished
Screws ......................................................... 3 units
DIN965 - M4x50 - black burnished
Washers ...................................................... 3 units
DIN9021 - ø4.3 - black burnished
Nuts .............................................................. 3 units
DIN985 - M4 self-locking
Manual ........................................................... 1 unit
Ref. 0019182
This manual corresponds to the following reference:
FAE030
2

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Assembly Example
Connect FAE010 Flexible
Hose to the Fume Extractor
FAE030
Collector Flange for
Stand Aspiration Ducts
or use alternatively
FAE040
Collector Flange with
Clamp for Stand
Aspiration Ducts
FAE020
Flexible Arm ø50mm
or use alternatively
FAE070
Flexible Arm ø50mm with Clamp
FAE010
Flexible Hose ø50 mm
Total length: ~1.6m / ~63in
FAE2
Fume Extractor
for 2 Workbenches
or use alternatively
FAE1
Fume Extractor
for 1 Workbench
Connect FAE010 Flexible Hose to
- Flexible Arm (FAE020/FAE070) or to
- Accessory for Stand Aspiration
(FAE030/FAE040)
Connect up to four
stand aspiration ducts
3

Assembly
Workbench thickness:
Up to a maximum of 32mm/1.26in
- First make the large central hole in your
workbench as shown in the drawing below.
- Place the FAE030 flange over the central hole
and mark the points for the three pilot holes.
- Take off the flange and drill the three pilot
holes at the marked spots. The hole diameter
can be found in the dimension scheme below.
- Fix the flange onto your workbench with the
supplied o-rings (2x), screws (3x) washers
(3x) and nuts (3x).
Screws (3x)
DIN965
M4x50
Workbench
thickness:
max. 32 mm /
1.26 in
Nuts (3x)
DIN985 - M4
Washers (3x)
DIN9021
ø4.3mm
O-Ring
max. ø5.5mm
max. ø0.217in
~ ø50mm
~ ø1.969in
~ ø74mm
~ ø2.913in
Work bench
Drilled central
hole
Pilo hole
(3x)
O-Ring
Dimension Scheme
4

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Workbench thickness:
From 32mm/ 1.26in and more
- First make the large central hole in your
workbench as shown in the drawing below.
- Place the FAE030 flange over the central hole
and mark the points for the three pilot holes.
- Take off the flange and drill the three pilot
holes at the marked spots. The hole diameter
can be found in the dimension scheme below.
- Fix the flange onto your workbench with the
supplied o-rings (2x) and screws (6x).
Workbench
thickness:
32 mm / 1.26 in
and thicker
O-Ring
max. ø2mm
max. ø0.079in
~ ø50mm
~ ø1.969in
~ ø74mm
~ ø2.913in
Work bench
Drilled central
hole
Pilo hole
(3x)
O-Ring
Screws (3x)
DIN7982
ø3.5x16mm
Screws (3x)
DIN7982
ø3.5x16mm Dimension Scheme
Assembly
5

Notes
6

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Notes
7

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Specifications
FAE030
Collector Flange for Stand Aspiration Ducts
Ref. FAE030
- Outer Flange Diameter: 90 mm / 3.54 in
- Total Net Weight: 0.130kg / 0.287 lb
- Package Dimensions / Weight: 135 x 100 x 100 mm / 0.198 kg
(L x W x H) 5.31 x 3.94 x 3.94in / 0.437 lb
Complies with CE standards.
ESD safe.
0019182-260523
