jbc DR560-A User manual

DR560
Desoldering Iron
INSTRUCTION MANUAL

Desoldering
Iron .................... 1 unit
Tip Ref. C560003
Through-Hole Desold. Ø 1
already inserted
Union
Flanges ........... 2 units
R ef. 0 0113 5 6
Tip Cleaning
Rods .................. 1 unit
Ref. 0965970*
Internal
Gasket Set ....... 1 pair
Ref. 0019208
contains 2 gaskets
Filter box .......... 1 unit
Ref. 0780840
Ref. contains 10 filters
Spanner ............ 1 unit
Ref. 0780550*
Spiral Filter ...... 1 unit
Ref. 0812330*
Drilled Tip Cleaning
Rods ................. 1 unit
Ref. 0965760*
Cleaning
stick ................... 1 unit
Ref. 0786640
Metal Solder
Collector ......... 1 unit
Ref. 0812630*
Glass Solder
Collector .......... 1 unit
Ref. 0812620*
Manual .............. 1 unit
Ref. 0008867
*included in Ref. 0022820 DR560-A Desoldering Iron Accessories Set
Packing List
The following items are included:
This manual corresponds to the following references:
DR560-A
Tip
Ref. C560003
2

DS360
DR560
DR560
DR560
DR560
DR560
Features and Connections
Desoldering Iron
Ref. DR560-A
Tip
Ref. C560003
to Desoldering Module
to Stand
Suction Filter
Ref. 0821830
Supplied with desoldering module
Desoldering Process
Use a tip with a larger diameter than the pad to achieve maximum aspiration and thermal efficiency.
Place the tip with the
component terminal in
the hole.
After pressing the desoldering key there is a slight delay until the self-contained vacuum pump
stops. This makes sure that the vacuum circuit is completely empty. If any solder remains are left
on a terminal after desoldering it, resolder it with fresh solder and repeat the desoldering operation.
When the solder liquefies,
gently rotate the tip so
that the component
terminal can be lifted off.
Press the vacuum pump
button long enough to
remove the solder.
3. Aspirating1. Placing 2. Rotating
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
Changing Tips
This operation should be done while the tip is hot and at a minimum temperature of 250°C, so that
any tin left inside is still molten.
1. Removing
Use the special spanner to unscrew the tip.
2. Inserting
Fit the new tip and tighten with the spanner
to make sure it is air tight.
Compatible Tips
DR560 uses C560 tips. Different sizes are
available for through-hole desoldering and for
pad cleaning. Find the model that best suits
your soldering needs at: www.jbctools.com
Tip Temp.
min 250ºC
Remove
Insert
c
a
c
Changing the Heating Element (Ref. DSV-DR)
1. Removing
Loosen the deposit lid (a),
remove the screw (b)
and withdraw the heating
element (c).
For this operation, turn off the station or disconnect the tool and wait until the tool temperature
drops to room temperature.
2. Placing
Insert the new heating
element (a), tighten the screw
(b) and then the deposit lid (c).
Before inserting, make sure
the internal gasket is inserted
into the glass solder collector.
b
b
a
DS360
DR560
DR560
DR560
DR560
DR560
Through-Hole
Desoldering
Pad Cleaning
!
!
4

DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
Coil Filter
Glass Solder
Collector
Cleaning Stick
washer
Compatibility
The DSV-DR also works with
the previous version DR5600
Desoldering Iron (Ref. 5600010).
In this case, you must take out
the washer with a pliers.
3. Connection
For a proper connection
it is essential to insert the
cartridge by lining it up to
the mark .
Lid
Glass Solder Collector Cleaning
1. Removing the Lid 2. Cleaning
Clean the inside of the glass solder collector with
the cleaning stick.
Remove the coil filter, check the filter and replace
it if it is dirty or damaged.
The lid must be unscrewed with the DR560 in a
vertical position.
Check Coil Filter
Check
Internal Joint
5
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
Tip Cleaning
Rod
Drilled Tip
Cleaning Rod
3. Inserting the Glass Solder Collector
The glass solder collector must be inserted
with the coil filter in place, positioned between
the 2 lines marked.
Then the whole unit must be closed by
onscrewing the lid.
Marks
Coil Filter
Maintenance
Before carrying out maintenance or storage, always unplug the tool.
- Check periodically that the metal parts are clean to ensure it is detected when on the stand.
Always use a damp cloth or alcohol.
- Periodically check all cables and tubes connections.
- Replace any defective or damaged pieces. Use original JBC spare parts only.
- Repairs should only be performed by a JBC authorized technical service.
The intake tube should be periodically cleaned by the largest possible rod.
Tip Care
Do not press the vacuum pump button while tinning the desoldering tip, as the fumes
given off by the flux would quickly block the ducts and the air filter.
6

Safety
- Do not use the tool for any purpose other than soldering or rework. Incorrect use may cause fire.
- The mains cable must be plugged into approved bases. Make sure that it is properly grounded
before use. When unplugging it, hold the plug, not the wire.
- The temperature of accessible surfaces may remain high after the unit is turned off.
Handle with care.
- Do not leave the appliance unattended when it is on.
- It is necessary to turn the station off before changing tips.
- Heat can cause inflamable products to ignite even when out of sight.
- Be careful with the remains of liquid tin. In contact with skin, it can cause burns.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when
working to avoid personal harm.
- This appliance can be used by children over the age of eight as well as persons with reduced
physical, sensory or mental capabilities or lacking of experience provided that they have been
given adequate supervision or instruction concerning use of the appliance and understand the
hazards involved. Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
It is imperative to follow safety guidelines to protect health and prevent electric
shock, injury, fire or explosions.
7
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Specifications
DR560
Desoldering Iron
Ref.: DR560-A
- Total Net Weight: 413 g / 0.91 lb
- Package Dimensions / Weight: 230 x 24 x 48 mm / 559 g
- (L x W x H) 10.43 x 8.78 x 6.30 in / 1.23 lb
Complies with CE standards
ESD safe
0 0 2 8 05 7- 012 2
