JBL PLAYLIST 150 User manual

What’s in the box
x1
x1
2Buttons
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

3Wi-Fi Setup
Step 1: Download the JBL Wireless Setup app., scan QR code needed for both iOS App
Store and Google Play Store downloading
Step 2: Power on the speaker, then press and hold the “Play” to enter Wi-Fi
Step 3: Find Stream in the app, and follow the guide
Step 4: Select network and input password, till the indication of Wi-Fi
connected shown
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

4Google Cast play music procedure
Step 2: Play musicStep 1: Open Google Cast supported app
Step 3: Tap the cast icon and select “JBL GC150”
** Google Cast support app - refer to link - https://www.google.com/cast/apps/
5Spotify play music procedure
Step 1: Open Spotify app Step 2: Play music
Step 3: Tap the Spotify connect icon and select “JBL GC150”
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

6Bluetooth
1. Bluetooth connection setup process
PLAYLIST 150
2. Music control process
x1 x2
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

8LED behavior
9Warning
Standby Power on Bluetooth
Pairing
Speaker
Connecting
Speaker
Connected NA NA
Bluetooth
Connected
(White) (White) (Blue) (Blue)
Care on Passive radiator
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150
7Connections
Reset

EN
• Bluetooth version: 4.1
• Support: A2DP V1.2, AVRCP V1.0
• Transducer: 2 x 50mm
• Rated Power: 2 x 15W
•Frequency Response: 60 – 20KHz
• Maximum SPL: 92dB
• Power supply: 19VDC, 2.0A
• Power consumption in sleep mode: <2.0 Watts
• Dimension: 316 x 131 x 147 mm
• Weight: 1200g
• Bluetooth transmitter power: <4 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz
(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)
• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)
• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n
• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: <20dBm (EIRP)
• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

FR
• Bluetooth version: 4.1
• Support: A2DP V1.2, AVRCP V1.0
• Transducer: 2 x 50mm
• Rated Power: 2 x 15W
•Frequency Response: 60 – 20KHz
• Maximum SPL: 92dB
• Power supply: 19VDC, 2.0A
• Power consumption in sleep mode: <2.0 Watts
• Dimension: 316 x 131 x 147 mm
• Weight: 1200g
• Bluetooth transmitter power: <4 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz
(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)
• Weight: 16.3kg
• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)
• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n
• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: <20dBm (EIRP)
• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

ES
• Bluetooth version: 4.1
• Support: A2DP V1.2, AVRCP V1.0
• Transducer: 2 x 50mm
• Rated Power: 2 x 15W
•Frequency Response: 60 – 20KHz
• Maximum SPL: 92dB
• Power supply: 19VDC, 2.0A
• Power consumption in sleep mode: <2.0 Watts
• Dimension: 316 x 131 x 147 mm
• Weight: 1200g
• Bluetooth transmitter power: <4 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz
(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)
• Weight: 16.3kg
• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)
• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n
• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: <20dBm (EIRP)
• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

PT
• Bluetooth version: 4.1
• Support: A2DP V1.2, AVRCP V1.0
• Transducer: 2 x 50mm
• Rated Power: 2 x 15W
•Frequency Response: 60 – 20KHz
• Maximum SPL: 92dB
• Power supply: 19VDC, 2.0A
• Power consumption in sleep mode: <2.0 Watts
• Dimension: 316 x 131 x 147 mm
• Weight: 1200g
• Bluetooth transmitter power: <4 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz
(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)
• Weight: 16.3kg
• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)
• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n
• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: <20dBm (EIRP)
• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac
Quick Start Guide
Guide de démarrage rapide
PLAYLIST 150

DE
• Bluetooth version: 4.1
• Support: A2DP V1.2, AVRCP V1.0
• Transducer: 2 x 50mm
• Rated Power: 2 x 15W
•Frequency Response: 60 – 20KHz
• Maximum SPL: 92dB
• Power supply: 19VDC, 2.0A
• Power consumption in sleep mode: <2.0 Watts
• Dimension: 316 x 131 x 147 mm
• Weight: 1200g
• Bluetooth transmitter power: <4 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz
(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)
• Weight: 16.3kg
• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)
• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n
• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: <20dBm (EIRP)
• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac
