Jefferson JEFPLAS40A-DV User manual

OLYMPUS
User Manual
v.1.1
JEFPLAS40A-DV
PLASMA
Dual Voltage 230V / 110V ~ 50Hz
CUTTER

3
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
CONTENTS
Contents 3
About This Document 3
Specications 4
Equipment Identication 4
Safety Guidelines 5
Operation Guide 8
Maintenance 10
Troubleshooting 11
Circuit / Wiring Diagram 12
Environmental Protection 13
WEEE (Waste Electrical and Electronic Equipment) Statement 13
RoHS Directive 2011/65/EU 13
Parts List 14
Parts Diagram 15
Limited Warranty Statement 16
EU Declaration Of Conformity 18
ABOUT THIS DOCUMENT
This manual has been compiled by Jefferson Tools and is an integrated part of the product with which it's enclosed
and should be kept with it for future reference. Please read all of the information supplied in this User Manual before
operating this product.
This manual describes the purpose for which the product has been designed and contains all the necessary
information to ensure its correct and safe use. We recommend that you read the information supplied before carrying
out any maintenance or repair. By following all the general safety instructions contained in this manual you will help
to ensure operator safety and extend the potential life span of the equipment.
All photographs and drawings in this manual are supplied by Jefferson Tools to help illustrate the operation of the
product. Whilst every effort has been made to ensure accuracy of information contained in this manual our policy of
continuous improvement determines the right to make modifications without prior warning.
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the equipment Some illustrations in this Instruction Manual may show details or attachments that differ from those
on your own model. Contact your nearest Jefferson Dealer if you are unsure about any information included in this
manual or require any additional information about the safe use, operation maintenance, or repair of this equipment.

4
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
SPECIFICATIONS
Model Number: JEFPLAS40A-DV
Input Voltage ~ Frequency: 230V / 110V ~50Hz
Maximum Amp Output: 40A (@230V) 20A (@110V)
Cutting Capacity: 25mm
Open Circuit Voltage: 300V
Duty Cycle: 230V: 40A @ 30% • 110V: 20A @ 60%
Working Pressure: 80-110psi
Display: Analogue
Cable / Plug: 4M x 2.5mm 3 core / 16A
Dimensions: 582 x 343 x 381mm
NW / GW: 9.6kg / 15kg
EQUIPMENT IDENTIFICATION
1. Thermal Overload
2. Cutting Indicator
3. Power Indicator
4. Carry Handle
5. Current Adjustment Knob
6. Air Vents
7. Torch Cable Socket
8. Earth Lead Socket
9. Front Panel
1
2
3
4
5
6
7
8
9
10. Power Switch
11. Power Cable
12. Air Inlet
13. Filter
14. Air Vents
15. Back Panel
12
10
11
13
14
15

5
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
SAFETY GUIDELINES
Please read and ensure that you understand all of the operating instructions, safety precautions
and warnings in this Instruction Manual before operating or maintaining this equipment. An
accident can often be avoided by recognizing a potentially hazardous situation before it occurs,
and by observing the appropriate safety procedures. Never use this equipment or modify it in
any way that has not been specically recommended by the manufacturer. Contact a qualied
electrician for advice on any issues relating to electrical safety in your working environment.
GENERAL EQUIPMENT SAFETY
• Do not operate the machine without reading and understanding the contents of this user manual.
• This equipment should only be used by competent trained operators.
• Do not operate under the inuence of medication or alcohol.
• Regularly inspect the plasma cutter for damage before use.
• Do not use the equipment if damage is detected.
• Replace any damaged parts before use (contact your dealer for Jefferson Tools approved replacement parts).
• Always use the machine for its intended purpose, do not modify the equipment for other uses.
• This equipment should only be repaired by fully-trained or approved engineers.
• Ensure that the plasma cutter is not connected to the mains power supply before removing the outer casings to
carry out repair or maintenance.
WORKING ENVIRONMENT
• Only use in clean, uncluttered environments with good ventilation and sufcient light.
• Do not operate in the vicinity of children or animals.
• Do not operate in explosive atmospheres, in the presence of ammable liquids, gases or excessive dust.
• Cutting sparks can ignite dust and fumes.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating this equipment.
• Never use a plasma cutter while you are tired or under the inuence of drugs, alcohol or medication.
• Arc rays and infrared radiation can injure eyes and burn skin. Always wear suitable Personal Protection Equipment
(PPE) that has been tested to the latest standards and rated for use with this equipment. This includes eye
protection such as arc shaded (with a DIN Shade 10 lens rating), impact safety full face shield, dust mask or
respirator, heavy-duty work gloves, non-skid safety shoes and hearing protection.
• Do not wear loose tting clothing or jewellery. Ensure long hair is tied back before operating this equipment.
• Avoid accidental starting. Always ensure the power switch is in the OFF position before plugging in.
• Do not overreach, ensure that you are working on a rm stable surface with proper footing and balance at all times.
• Ensure that the plasma cutter is suitably rated for the application before use.
• Store in a clean dry environment out of the reach of children.
• Ensure that the plasma cutter is kept clean and well-maintained to ensure safe use and longer working life.
• Use a qualied service engineer and contact your Jefferson Dealer for any advice required on the safe operation
and maintenance of this equipment.
WARNING:
No responsibility is accepted for incorrect use of this equipment. Incorrect use can result in damage to the equipment
and danger to the user. Warranty will be void in the event of incorrect use. The warnings, cautions and instructions
discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which cannot be built into this product, but must
be supplied by the operator.

6
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
ELECTRICAL SAFETY
Ensure that you check the equipment thoroughly to ensure it is safe and t for purpose before each
use. It is important that you inspect all plugs, sockets, power cables and electrical ttings for wear and
damage and repair or replace any defective components. The risk of electric shock can be minimised
by the correct use of the appropriate electrical safety devices.
• We recommend that you t a Residual Current Circuit Breaker (RCCB) in the main distribution board and that a
Residual Current Device (RCD) is used when operating this equipment.
• The Electricity at Work Act 1989 includes legislation that places legal implications on employers to ensure
the safety of electrical devices in the workplace. The regulations dictate that all portable equipment must be
inspected regularly and tested to ensure that it is safe for use. 'Portable equipment' means any electrical item
that can be moved and this is often referred to as Portable Appliance Testing (PAT). PAT testing should be carried
out regularly on this equipment by trained, authorised personnel, as required by the legislation.
• The Health and Safety at Work Act 1974 states that it is the responsibility of the owner of electrical appliances to
ensure that both the equipment and working environments are maintained to ensure safe operation at all times.
• Check that all equipment cables are secure, correctly insulated, free from damage, and protected against short
circuit and overload before connecting to the power supply. Do not use worn or damaged cables, plugs, sockets
or other ttings.
• Ensure that the power supply matches voltage requirements specied on the equipment and that the plug is
wired correctly and tted with the correct fuse.
• If the electrical fuse blows, ensure it is replaced by an identical type of fuse with the same rating.
• Never pull or manoeuvre this equipment into position using the power cable.
• Ensure the power cable is kept away from heat, oil and sharp edges. Damaged or entangled cables increase the
risk of electric shock.
• We recommend that the equipment is connected directly to the power supply without the use of extension leads
as the resulting voltage drop can reduce motor performance.
• Always disconnect the equipment from the power source before servicing, inspecting, maintaining, cleaning,
replacing or checking any parts.
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is grounded.
• Do not expose the plasma cutter to rain or wet conditions. Any moisture entering a plasma cutter will increase
the risk of electric shock and will result in damage or corrosion.
• When operating the plasma cutter outdoors, use an extension cable that is designed and rated for outdoor use.
• This unit draws enough current to cause serious injury or death. Do not use the plasma cutter unless you are
insulated from the ground and the work piece.
• People with pacemakers should consult their physician(s) before use. Electromagnetic elds in close proximity to
pacemakers could cause interference or failure.
OPERATION SAFETY
• Move any ammable and explosive materials at least 10 meters from the cutting arc to prevent sparks or molten
metal from starting a re.
• Always keep a type ABC re extinguisher within easy reach as a re precaution.
• Thoroughly clean the object being cut of any paint, grease, or other foreign material.
• Avoid unintentional starting (ensure power switch is set to the OFF / “0” position before connecting to the mains
supply)
• Prepare and securely x the work piece before turning on the plasma cutter.
• Never leave the plasma cutter unattended when it is plugged into an electrical supply.
• Always turn off the plasma cutter, and unplug it from its electrical outlet before leaving the work environment.
• Use clamps or other practical ways to secure and support the work piece to a stable work surface.
• Wear an approved head covering to protect the head and neck. Use aprons, cape, sleeves, shoulder covers, and
bibs designed and approved for welding and cut¬ting procedures.
• When welding/cutting overhead or in conned spaces, wear ame resistant ear plugs or ear muffs to keep sparks
out of ears.
• Enclose the work area with portable re resistant screens where possible. Protect combustible walls, ceilings,
oors, etc., from sparks and heat with re resistant covers.

7
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
• If working on a metal wall, ceiling, etc, prevent ignition of combustibles on the other side by moving the objects
to a safe location. If relocation of combustibles is not possible, designate someone to serve as a re watch,
equipped with a re extinguisher, during the cutting process and for at least one half hour after the cutting is
completed.
• Do not weld or cut on materials having a combustible coating or combustible internal structure, as in walls or
ceilings, without an approved method for eliminating the hazard.
• Do not dispose of hot slag in containers holding combustible materials. Keep a re extinguisher nearby and know
how to use it.
• After cutting, make a thorough examination for evidence of re. Be aware that easily-visible smoke or ame
may not be present for some time after the re has started. Do not weld or cut in atmospheres containing
dangerously reactive or ammable gases, vapours, liquids, and dust. Provide adequate ventilation in work areas
to prevent accumulation of ammable gases, vapours, and dust. Do not apply heat to a container that has held
an unknown substance or a combustible material whose contents, when heated, can produce ammable or
explosive vapours.
• Clean and purge containers before applying heat.
• Vent closed containers, including castings, before preheating, welding, or cutting.
• Do not touch live electrical parts. Wear dry, insulating gloves.
• Do not touch electrode or conductor tong with bare hand. Do not wear wet or damaged gloves.
• Protect yourself from electric shock. Always insulate yourself from the work piece and ground. Use
nonammable, dry insulating material if possible, or use dry rubber mats, dry wood or plywood, or other dry
insulating material big enough to cover your full area of contact with the work or ground.
• Never remove the grounding prong or modify the Power Cord Plug in any way. Do not use adapter plugs with this
product.
• Ensure that the unit is placed on a stable location before use. If this unit falls while plugged in, severe injury,
electric shock, or re may result.
• Avoid overexposure to fumes and gases. Always keep your head out of the fumes. Do not breathe the fumes.
Use enough ventilation or exhaust, or both, to keep fumes and gases from your breathing zone and general area.
• Use only compressed air at between 80-110psi. Never use oxygen, carbon dioxide, combustible gases or any
bottled gas as an air source for the plasma cutter. Such gases are capable of explosion and serious injury to
people.
• The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and caution
are factors which cannot be built into this product, but must be supplied by the operator.
• Familiarise yourself with the specications, rated duty cycles and operating instructions of this equipment.
• The duty cycle denes the number of minutes, within a 10 minute period, during which a given plasma cutter can
safely produce a particular current as shown on the information label shown on the underside of the equipment:

8
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
OPERATION GUIDE
BEFORE USE
• Unpack and make sure all the items in good condition before use. Occasionally equipment can be damaged
in transit. All damage should be noted and reported. Do not use the equipment if any damage is detected. If
abnormal noise or vibration occurs, have the problem corrected before further use.
• Ensure the power switch is set to the OFF / “0” position and check the power source for correct input before
connecting the plasma cutter to the mains supply.
• Connect the gas line to the compressed air inlet port at a suitable pressure. Use only compressed air at between
80-110psi. Never use oxygen, carbon dioxide, combustible gases or any bottled gas as an air source for the
plasma cutter.
• Ensure you are wearing the correct Personal Protection Equipment (PPE) before using this equipment. Contact
your Jefferson dealer for advice on protection and equipment requirements. A full range of safety equipment is
available with full details on our website and latest catalogue.
• You will require arc shaded eye protection (DIN Shade 10 recommended), a full face shield, heavy-duty work
gloves, a welding apron, respirator, and heavy-duty work clothes without pockets should be worn when using
this product.
• Do not look at the ignited arc without eye protection. Light from the arc can cause permanent damage to the
eyes. Light from the arc can burn the skin. Do not breathe arc fumes.
• Designate a work area that is clean, well-lit and well-ventilated. The work area must not allow access by children
or pets to prevent injury and distraction.
• Position the power cable along a safe route to reach the work area without creating a tripping hazard or exposing
the cable to possible damage.
• The power cable must reach the work area with enough extra length to allow free movement while working.
• Ensure there are no hazardous objects, such as utility lines or foreign objects, nearby that will present a hazard
while working.
• A barrier, such as a welding curtain or welding shroud should be put up to protect others in the work area and
limit the spray of sparks.

9
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
PLASMA CUTTING
• Mount the metal to be cut to the metal welding/cutting table. It should be mounted so that the cutting debris falls
onto a non-ammable or cement oor.
• Place the plasma cutter unit no closer than 2 meters from the workpiece to be cut.
• Fix the earth / grounding clamp to a part of the workpiece or metal table that is clean of paint, oil, or dirt. Clamp
as close as possible to the workpiece but far enough away to avoid damaging the cable during cutting.
• Set the desired current for the type of metal being cut with the current adjustment knob. Generally and
depending on the material, thin metals use low current and heavy metals require higher current.
• Ensure the power switch is set to the OFF / “0” position, then plug the Plasma Cutter’s Power Cord into a
dedicated, 230V electrical supply (or a 110V supply with a suitable adaptor mounted on the power cable) with
delayed action type circuit breaker.
• Hold the cutting torch rmly. Please Note: The torch is “live” when its trigger is pressed.
• Keep the torch away from people and ammables before touching the trigger.
• When everything is in place for cut, press the Power Switch to its ON / “1” position. The GREEN “Power
Indicator” will illuminate and machine is ready to cut.
• WARNING! TO PREVENT SERIOUS INJURY: point torch away from your body when triggering the torch.
• Once the torch is triggered, the arc will ignite. This unit provides a pilot arc, so the cutting torch does not need to
contact the workpiece before the cutting arc ignites.
• Trigger the torch and the RED “Cutting Indicator” will illuminate.
• Make sure not to touch anything else with the Torch except the workpiece to be cut.
• Slowly move the cutting torch at a slight angle along the cutting line with the torch tip trailing.
• The air causes the molten metal to fall away from the workpiece being cut.
• The machine is equipped with 20 seconds of nozzle air cooling after torch trigger is released.
• When nished cutting, release the trigger on the cutting torch and lift the torch away from the workpiece.
• Press the Power Switch to its OFF position “0” and set the cutting torch down on the metal workbench.
• Turn off the air supply and unplug the power cord from the power supply
• Allow all components of the Plasma Cutter to completely cool before storing the plasma cutter in a cool dry
indoor environment - out of the reach of children.
THERMAL CUTOUT
This plasma cutter is equipped with an internal thermal protection system to help prevent damage to the unit. If the
cutter exceeds the rated duty cycle it may overheat . In this state, the thermal overload indicator light will illuminate
on the front panel display, the plasma cutter will automatically shut down. The cutter will return to operation when it
cools down sufciently.

10
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
MAINTENANCE
Ensure all repair and replacement of parts is carried out by a qualied technician using only Jefferson approved
replacement parts. A list spare parts and a parts diagram are supplied later in this document. Contact your nearest
Jefferson dealer for any information or advice required.
WARNING: To prevent serious injury from accidental operation:
Turn the Power Switch of the Plasma Cutter to its “OFF” / "O" position and unplug the plasma cutter from its
electrical outlet before performing any inspection, maintenance, or cleaning procedures.
CLEANING, MAINTENANCE, AND LUBRICATION PROCEDURE
1. Before each use, inspect the general condition of the plasma cutter. Check for loose screws, cracked or broken
parts, damaged electrical wiring, and any other condition that may affect its safe operation.
2. Maintain the air supply according to the component manufacturers' instructions.
3. Drain the dryer regularly. Performing routine air supply maintenance will allow the tool to operate more safely and
will also reduce wear on the tool.
4. After Use, clean external surfaces of the plasma cutter with clean cloth.
5. Periodically, using compressed air, blow out all dust and debris from the interior.
6. If the unit repeatedly shuts down from thermal overload, stop all use. Have the Plasma Cutter inspected and
repaired by a qualied service technician.
7. Store the plasma cutter and accessories in a clean and dry location out of reach of children.

11
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
TROUBLESHOOTING
Symptom Possible Causes Solution
All LEDs are OFF when
equipment.
1. No electrical supply to the
equipment
Check supply voltage.
Check / replace power cable fuse.
Verify that circuit breaker hasn’t been tripped.
Contact your service technician
Arc does not ignite 1. Improper ground connection Make certain that the work piece is contacted properly
by the Earth Clamp and that the work piece is properly
cleaned near the Earth Clamp and the cutting location
2. Improperly sized or excessively
worn nozzle
Verify that Nozzle is the proper size for the cutting torch
used. Check that the hole in the tip is not deformed,
enlarged, or dirty. If needed, replace Nozzle with proper
size and type
Insufficient cutting
penetration
1. Output current is too low Increase output current by turning the current
adjustment knob in a clockwise direction. Make sure
proper input power is supplied
2. Material being cut is too thick Refer to equipment specications and choose a
suitable material to cut or switch to a more powerful
plasma cutter for the task
3. Cutting speed is too fast Reduce torch travel speed
4. Incorrect cutting angle Adjust cutting angle and make sure torch head is
vertical to the workpiece
5. Consumables are worn out Check the condition of the consumables and replace
the worn parts if necessary
Excessive slag formation 1. Consumables are worn out Replace worn consumables, then reassemble the torch
ensuring all connections are secure
2. Improper cutting speed Increase cutting speed if slag formed at the bottom, or
decrease if slag formed at the top of workpiece
No gas flow 1. Nozzle plugged Clean the nozzle. If damaged, replace
2. Air supply hose blocked Check, replace air supply hose
Cutting arc is not stable 1. Loose torch cable or earth / ground
clamp cable
Check to ensure that all connections are tight
2. Unstable line voltage Check the line voltage and, if there are problems with
the wires, have a licensed electrician remedy the
situation
3. Cutting current is too low Increase cutting current through turning the knob
clockwise
4. Torch travels too fast Slow down the cutting speed
5. Torch consumables worn out Check nozzle, shield cup, or electrode, replace if
needed

12
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
CIRCUIT / WIRING DIAGRAM

13
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
ENVIRONMENTAL PROTECTION
Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools, accessories and packaging
should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable, reaches the end of its working life and requires disposal, drain off any
uids (if applicable) into approved containers and dispose of the product and the uids according to local regulations.
WEEE (Waste Electrical and Electronic Equipment) STATEMENT
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT
This symbol on the product(s) and / or accompanying documents means that used electrical and electronic products should
not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to
designated collection points where it will be accepted free of charge.
FOR PRIVATE HOUSEHOLDS:
Dispose of this product at the end of its working life and in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). Contact your local solid waste authority for recycling information for this equipment.
Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with you national legislation.
FOR BUSINESS USERS IN THE EUROPEAN UNION:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
INFORMATION ON DISPOSAL IN OTHER COUNTRIES OUTSIDE THE EUROPEAN UNION:
This symbol is only valid in the European Union. If you wish to discard this product please contact your local authorities or dealer and ask for the
correct method of disposal.
RoHS Directive 2011/65/EU
We hereby declare that this equipment has been tested and found to be compliant to RoHS Directive 2011/65/EU of the European Parliament and
the Council from 08/06/2011 on restriction of the use of certain hazardous substances in electrical and electronic appliances.
Screening Test by XRF Spectroscopy Cadmium, Lead, Chromium (VI), Mercury, Polybrominated biphenyls (PBB) and Polybrominated diphenyl
ethers (PBDE) BBP, DBP, DEHP, DIBP content Reference to RoHS (recast): Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronic Equipment, 2011/65/EU Annex II and its amendment Directive (EU) 2015/863

14
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
PARTS DIAGRAM

15
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
PARTS LIST
# Description Quantity
1Front Plastic Cover 1
2Knob 1
3Tube Connector 1
4Plasma Cutter Connector 1
5Tube Connector 1
6Cassette Mechanism Holder 1
7Tube Connector 1
8Solenoid Valve 1
9Tube Connector 1
10 Pressure Reducing Valve 1
11 Inductor 1
12 Rubber 1
13 Tube Connector 1
14 Barometric Switch 1
15 Tube Connector 1
16 Filter 1
17 Tube Connector 1
18 Cable Clip 1
19 Power Cable 1
20 Switch 1
21 Back Plastic Cover 1
22 Rear Cover Assembly 1
23 DC Fan 2
24 Handle 1
25 Top Cover 1
26 Beam 1
27 Main PCB 1
28 Bottom 1
29 Control PCB 1
30 Control Panel 1

16
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
LIMITED WARRANTY STATEMENT
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be free of defects in workmanship
or material. Jefferson shall, upon suitable notication, correct any defects, by repair or replacement, of any parts or components of this product
that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal operations, improper care, service
or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is unavailable from the end user, then
the date of purchase will be deemed to be 3 months after the initial sale to the distributor.
1 Year
JEFPLAS40A-DV - 40A Plasma Cutter - Dual Voltage ~ 50Hz
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be subject to a minimum of 90 days cover or the
remaining duration of the warranty period from the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the following address:
www.jeffersontools.com/warranty and completing the online form. Online warranty registration is recommended as it eliminates the need to
provide proof of purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will be corrected by repair or replacement at an
authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for collection. Jefferson will arrange collection and
transportation of any equipment returned under warranty. Upon inspection of the equipment, if no defect can be found or the equipment is not
covered under the terms of the Jefferson warranty, the customer will be liable for any labour and return transportation costs incurred. These costs
will be agreed with the customer before the machine is returned.
*Jefferson reserve the right to void any warranty for damages identified as being caused through misuse
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers. Jefferson's liability under this
warranty will not exceed the cost of correcting the defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business or hire of substitute equipment etc.) caused by
the defect or the time involved to correct the defect. This written warranty is the only express warranty provided by Jefferson with respect to its
products.
Any warranties of merchantability are limited to the duration of this limited warranty for the equipment involved.
Jefferson is not responsible for cable wear due to flexing and abrasion. The end user is responsible for routine inspection of cables for possible
wear and to correct any issues prior to cable failure.

17
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment (Tel: [phone]) or their nearest authorised Jefferson dealer where
final determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
• Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form. You can complete the form online and submit it
to us directly or download the form to print out and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of your nearest authorised Jefferson
repair centre. On receipt of this form Jefferson will arrange to collect the equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer's responsibility to ensure that the equipment is appropriately and securely packaged for collection, together with a copy of
the original proof of purchase. Please note that Jefferson cannot assume any responsibility for any damage incurred to equipment during
transit. Any claims against a third party courier will be dealt with under the terms & conditions of their road haulage association directives.
NOTE: Jefferson will be unable to collect or process any warranty requests without a copy of the original proof of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if the equipment is defective and in need
of repair and any repairs needed are covered by the warranty policy. In order to qualify for warranty cover all equipment presented must have been
used, serviced and maintained as instructed in the user manual.
Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the customer (normally within 7
working days).
NOTE: If the repair quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour time at £30 per hour plus
return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the equipment is identified as the cause of the problem, a
minimum of 1 hour labour at £30 per hour plus carriage costs will be required before the equipment will be despatched back to the customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to the customer within 7 working days upon receipt
of the equipment at an authorised Jefferson Repair centre (subject to part availability). Where parts are not immediately available Jefferson will
contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call [phone] or send your enquiry
via email to [email protected]
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are made without
guarantee. Since the conditions of use are beyond their control, Jefferson Tools® disclaim any liability for loss or damage suffered from the use of
this data or suggestions. Furthermore, no liability is accepted if use of any product in accordance with this data or suggestions infringes any patent.
Jefferson Tools® reserve the right to change product specifications and warranty statements without further notification. All images are for
illustration purposes only.

18
USER MANUAL v1.1
40A Plasma Cutter - Dual Voltage ~50Hz
JEFPLAS40A-DV
www.jeffersontools.com
EU DECLARATION OF CONFORMITY
We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer, declare
that the following equipment conforms to the requirements of the following:
Directive / Standard / Regulation Description:
EN 60974-1:2012 Arc welding equipment. Welding power sources
2014/35/EU Low Voltage Directive
2014/30/EU EMC Directive
2011/65/EU Restriction of Hazardous Substances (RoHS) Directive
Equipment Category: Plasma Cutter
Notified Testing Body: Intertek
Model Number(s): JEFPLAS40A-DV - 40A Plasma Cutter - Dual Voltage ~ 50Hz
Signed by: Stephen McIntyre
Position in the company: Operations Director
Date: 02 November 2020
Technical file holder's address as shown below
Name and address of manufacturer
or authorised representative:
Jefferson Tools, Herons Way, Chester Business Park,
Chester, United Kingdom, CH4 9QR
Telephone: [phone] Fax: [phone]
Email: [email protected]

Jefferson Tools,
Herons Way,
Chester Business Park,
Chester,
United Kingdom,
CH4 9QR
Tel. [phone]
Email: [email protected]
IMPORTANT! SAFETY FIRST!
Before attempting to use this product please read
all the safety precautions and operating instructions
outlined in this manual to reduce the risk of fire,
electric shock or personal injury.
www.jeffersontools.com
