Jenn-Air 740-0165 (LP) User manual

STAINLESS STEEL BUILT-IN GAS GRILL
MODEL #s: 740-0165 (LP) / 750-0165 (NG) LOWE’S ITEM #s: 144510/157618
Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe’s Companies, Incorporated.
FOR OUTDOOR USE ONLY
PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE

TABLE OF CONTENTS
SECTIONONE
Safety Instructions…………………………….
Placement of the Grill…………………………
SECTIONTWO
Model Specifications………………………….
Island Construction……………………………
Front View for Built-In Opening………………
Side View for Built-In Opening……………….
SECTION THREE
Battery Installation…………………………….
LP Gas Hook-Up………………………………
Propane Regulator Hook-Up………………..
Installation of NG Regulator…………………
Natural Gas Hook-Up………………………..
SECTION FOUR
Leak Testing…………………………………
Installer Final Checklist……………………
Operating Instructions…………………….
Lighting Instructions………………………..
Lighting Illustrations………………………..
To Match Light the Grill…………………….
Care and Maintenance……………………
Troubleshooting…………………………….
SECTION FIVE
Exploded View Model 740-0165…………..
Parts List Model 740-0165………………..
Exploded View Model 750-0165…………..
Parts List Model 750-0165………………..
SECTION SIX
Grilling Hints………………………………..
Grill Cooking Chart…………………………
Grill Recipes…………………………………
SECTION SEVEN
Warranty Information………………………
1-4
4
5
6
7
8
9
10
11
12
13
14
15
16-17
18
19
20
21
22
WARNING
To reduce the risk of fire, burn hazard or other
injury, read this Care and Use Manual carefully
and completely before using your grill.
23
24
25
26
27
27-29
30-31
32

SAFETY INSTRUCTIONS
RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS
SAFETY SYMBOLS
WARNING
Hazardous or unsafe practices that
could result in severe personal injury or
death.
CAUTION
Hazardous or unsafe practices that
could result in minor personal injury.
COMMON CAUTIONS AND WARNINGS
INSECT WARNING
Spiders and insects can nest inside the burners of
this and other grills, which could disrupt gas flow.
This dangerous condition could cause a fire
behind and beneath the valve panel, damaging the
grill and making it unsafe to operate.
Inspect the grill at least twice a year.
WARNING
Do not use the grill if gas odor is present. Contact
customer service at 1-800-554-5799.
WARNING
Do not try lighting this appliance without first
reading the “LIGHTING INSTRUCTIONS” section
of this manual.
ELECTRICAL GROUNDING WARNING
The rotisserie motor should be plugged directly
into a properly grounded receptacle.
Do not cut or remove the grounding prong from
this plug.
Keep the rotisserie motor electric cord away from
the heated surfaces of the grill.
When not in use, remove and store the motor in a
dry location.
WARNING
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
gas supplier or your fire department.
LP GAS CYLINDER WARNING
The LP Gas Cylinder must be fitted with an Overfill
Protection Device (OPD).
For Your Safety:
1. Do not store spare LP-gas cylinders under or
near this appliance.
2. Never fill the cylinder beyond 80 percent
capacity.
3. If the information above is not followed exactly,
a fire resulting in death or serious injury could
occur.
WARNING
Cylinder must be stored outdoors out of the
reach of children and must not be stored in a
building, garage or any other enclosed area.
1

SAFETY INSTRUCTIONS
WARNING
Do not attempt to use damaged or obstructed
equipment. See your local LP gas dealer for
repair.
WARNING
Do not install this unit into combustible
enclosures. There should be a minimum
clearance of at least 24 in. from all sides to
combustible materials.
WARNING
Do not use the grill until all connections have
been checked and do not leak.
Do not smoke while leak testing.
Never leak test with an open flame.
WARNING
Always check for leaks after every LP tank
change.
CAUTION
Do not leave the grill unattended while
cooking.
CAUTION
Remove the warming rack when using the
rotisserie burner. High heat from the burner
may cause the warming rack to bend.
WARNING
While lighting, keep your face and body as far
from the grill as possible.
CAUTION
Before cleaning make sure the burners are
cool, and the gas supply and knobs are in the
“OFF” position.
CAUTION
Failure to ensure proper placement of the
burner over the valve assembly can cause a
fire to occur behind and beneath the valve
panel, thereby damaging the grill and making
it unsafe to operate.
WARNING
Storage of an outdoor cooking gas
appliance indoor is permissible only if the
cylinder is disconnected and removed from
the outdoor cooking gas appliance.
Model 750-0165 Natural gas Grill
WARNING
1. The outdoor cooking gas appliance and its
individual shutoff valve must be disconnected
from the gas supply piping system during any
pressure testing of that system at test pressure in
excess of ½ psi (3.5 kpa).
2. The outdoor cooking gas appliance must be
isolated from the gas supply piping system by
closing its individual manual shutoff valve during
any pressure testing of the gas supply piping
system at test pressures equal to or less ½ psi
(3.5 kpa).
CAUTION
Burner adjustments should only be
performed after the burners have cooled.
WARNING
Model 740-0165 LP Gas Grill
1. Do not store spare LP gas cylinders
under or near this appliance.
2. Never fill the cylinder beyond 80 percent
capacity.
3. If the information above is not followed
exactly, a fire resulting in death or
serious injury could occur.
2

SAFETY INSTRUCTIONS
WARNING
Do not try lighting this appliance without first reading
the “LIGHTING INSTRUCTIO

When using the grill, do not touch the grill rack,
burner grate or immediate surroundings as these
areas become extremely hot and could cause
burns. Use only dry potholders. Moist or damp
potholders on hot surfaces may cause steam burns.
Do not use a towel or bulky cloth in place of
potholders. Do not allow potholders to touch hot
portions of the grill rack.
Grease is flammable. Let hot grease cool before
attempting to handle it. Do not allow grease
deposits to collect in the grease tray at the bottom
of the grill’s firebox. Clean the grease tray often.

GRILL SPECIFICATIONS
Description 740-0165 and 750-0165
Cutout Width 38 3/4 in. (98.43 cm)
Cutout Depth 21 3/4 in. (55.25 cm)
Cutout Height 10 7/8 in. (27.63 cm)
Natural Gas: Standard residential 1/2 in. (1.3 cm) ID gas service
line. Natural gas hose/regulator assembly included with quick-
connect fitting for attachment to house natural gas line.
Gas Requirements Liquid Propane: Supplied with hose/regulator assembly for
connection to standard 5 gal, 20 lb. liquid propane gas cylinder
with Type 1, QCC-1 connection.
Grill Burners 4 Cast brass main burners. Infra-red rear rotisserie burner.
1 Sear burner.
Main burners 52,000 BTU/Hr.
Rear burners 16,000 BTU/Hr.
BTU Ratings Sear burners 23,000 BTU/Hr.
Total 91,000 BTU/Hr.
Approximate Shipping
Weight 196 lbs.
5

ISLAND CONSTRUCTION
5 in.(12.70cm)
WARNING
Do not install this unit into combustible enclosures.
There should be a minimum clearance of at least
24 in.(60.96cm) from all sides to combustible
materials.

FRONT VIEW FOR BUILT-IN OPENING
1 7/8 in.(4.76cm)
9 in.(22.86cm)
10 7/8 in.(27.63cm)
3 in.(7.62cm) 100
200
300 400 500
600
700F
¡ã
C¡ã
50
100
150 200 250
300
350
8 in.(20.32cm) 6 in.(15.24cm)
38 1/4 in.(97.16cm)
The following are minimum dimensions necessary to install the 4 burner + 1 sear burner built-in grills:
Width of grill head: 38 1/4 in.
Depth for grill control panel: 10 7/8 in.
Combustion Gap below control panel: 1 7/8 in.
A minimum of 6 in. clearance is needed from the right side of the grill firebox to non-combustible
materials. The rotisserie motor is located on the left side of the grill firebox.
A minimum of 8 in. clearance is required between the grill lid and any surrounding material to
allow for proper functioning of the rotisserie motor.
7

SIDE VIEW FOR BUILT-IN OPENING
To ensure proper combustion.1 7/8 in.(4.76cm)
space is needed between the bottom of the
qrease tray andthe island material.
A minimum of 7.875 in.(20.00cm) is
required between the back of the grill
and any non-combustible material.
A minimum of 24 in.(60.96cm)is
required between the back of the grill
and any combustible material.
9 in.(22.86cm)
8 3/8 in.(21.27cm)
26 3/8 in.(66.99cm)
24 3/4 in.(62.87cm)
12 3/4 in.(32.38cm)
25 3/8 in.(64.45cm)
10 7/8 in.(27.63cm)
The following are minimum clearances necessary around the Jenn-Air built-in 4 burner +1 sear burner grills:
Rear Clearance: 3 in. to non-combustible materials
24 in. to combustible materials
Combustion gap below control panel: 1 7/8 in.
8
