JENN-AIR® SIDE BY SIDE
BUILT-IN REFRIGERATOR
REFRIGERADOR EMPOTRADO
DE DOS PUERTAS JENN-AIR®
RÉFRIGÉRATEUR ENCASTRÉ
CÔTE À CÔTE JENN-AIR®
W10681397A
USE & CARE GUIDE
For questions about features, operation/performance, parts, accessories, or service,
call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.ca.
MANUAL DE USO Y CUIDADO
Si tiene preguntas respecto a las características, funcionamiento, rendimiento, partes, accesorios o servicio técnico,
llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En Canadá, llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.ca.
GUIDE D’UTILISATION ET D’ENTRETIEN
Au Canada, pour assistance, installation ou service, composez le 1-800-JENNAIR (1-800-536-6247)
ou visitez notre site Web à www.jennair.ca.
Table of Contents / Índice / Table des matières ...................................................................................2

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY........................................................................... 3
Proper Disposal of Your Old Refrigerator................................................. 3
BEFORE USE ............................................................................................... 4
Water Supply Requirements..................................................................... 4
Water System Preparation........................................................................ 4
REFRIGERATOR USE ................................................................................. 5
Power On/Off Switch ................................................................................ 5
Using the Controls .................................................................................... 5
Holiday Mode............................................................................................ 7
Ingredient Care Center ............................................................................. 7
Water and Ice Dispensers......................................................................... 8
Ice Maker and Storage Bin.......................................................................9
Water Filtration System .......................................................................... 10
REFRIGERATOR CARE ............................................................................ 11
Cleaning.................................................................................................. 11
Changing the Light Bulbs....................................................................... 12
Power Interruptions ................................................................................ 12
Vacation Care ......................................................................................... 12
TROUBLESHOOTING ............................................................................... 13
Refrigerator Operation............................................................................ 13
Temperature and Moisture..................................................................... 14
Ice and Water.......................................................................................... 14
ASSISTANCE OR SERVICE...................................................................... 15
In the U.S.A............................................................................................. 15
In Canada................................................................................................ 15
ACCESSORIES.......................................................................................... 16
WATER FILTER CERTIFICATIONS.......................................................... 16
PERFORMANCE DATA SHEETS ............................................................. 17
WARRANTY ............................................................................................... 19
ÍNDICE
SEGURIDAD DEL REFRIGERADOR........................................................20
Cómo deshacerse adecuadamente de su refrigerador viejo.................21
ANTES DE USAR .......................................................................................21
Requisitos del suministro de agua .........................................................21
Preparación del sistema de agua...........................................................22
USO DE SU REFRIGERADOR..................................................................22
Interruptor de encendido/apagado ........................................................22
Uso de los controles...............................................................................23
Holiday Mode (Modo de día de fiesta) ...................................................25
Ingredient Care Center
(Centro de cuidado de ingredientes)......................................................25
Despachadores de agua y hielo.............................................................26
Fábrica de hielo y depósito ....................................................................28
Sistema de filtración de agua.................................................................29
CUIDADO DE SU REFRIGERADOR ........................................................ 30
Limpieza.................................................................................................. 30
Cómo cambiar los focos ........................................................................ 31
Cortes de corriente................................................................................. 31
Cuidado durante las vacaciones............................................................ 31
SOLUCIÓN DE PROBLEMAS................................................................... 32
Funcionamiento del refrigerador ............................................................ 32
Temperatura y humedad........................................................................ 33
Hielo y agua ............................................................................................ 33
AYUDA O SERVICIO TÉCNICO................................................................ 35
En los EE.UU........................................................................................... 35
En Canadá .............................................................................................. 35
ACCESORIOS............................................................................................ 35
HOJA DE DATOS DEL RENDIMIENTO................................................... 36
GARANTÍA ................................................................................................. 38
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ...........................................................40
Mise au rebut appropriée de votre vieux réfrigérateur...........................41
AVANT L’UTILISATION ............................................................................. 41
Spécifications de l’alimentation en eau..................................................41
Préparation du système d’eau................................................................42
UTILISATION DU RÉFRIGÉRATEUR.......................................................42
Interrupteur marche/arrêt........................................................................ 42
Utilisation des commandes ....................................................................43
Holiday Mode (mode vacances).............................................................45
Ingredient Care Center (Centre de soins des ingrédients)..................... 45
Distributeurs d'eau et de glaçons........................................................... 46
Machine à glaçons et bac d’entreposage..............................................48
Système de filtration d'eau.....................................................................49
ENTRETIEN DU RÉFRIGÉRATEUR......................................................... 50
Nettoyage ............................................................................................... 50
Remplacement des ampoules d’éclairage............................................. 51
Pannes de courant.................................................................................. 51
Entretien avant les vacances.................................................................. 51
DÉPANNAGE ............................................................................................. 52
Fonctionnement du réfrigérateur............................................................ 52
Température et humidité ........................................................................ 53
Glaçons et eau........................................................................................ 53
ASSISTANCE OU SERVICE...................................................................... 55
Au Canada .............................................................................................. 55
ACCESSOIRES.......................................................................................... 55
FEUILLES DE DONNÉES SUR LA PERFORMANCE ............................. 56
GARANTIE.................................................................................................. 58

3
REFRIGERATOR SAFETY
Proper Disposal of
Your Old Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous,
even if they will sit for “just a few days.” If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3 prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all parts and panels before operating.
■Remove doors from your old refrigerator.
■Use nonflammable cleaner.
■Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■Use two or more people to move and install refrigerator.
■Disconnect power before installing ice maker (on ice maker
kit ready models only).
■Use a sturdy glass when dispensing ice (on some models).
■Do not hit the refrigerator glass doors (on some models).
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.

4
BEFORE USE
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
■Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside of
your refrigerator before using it. See the cleaning instructions in
“Refrigerator Care.”
Water Supply Requirements
Read all directions before you begin.
IMPORTANT:
■When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see “Connect to Water Line” in the Installation
Instructions. If you have any questions about your water
connection, see “Troubleshooting” or call a licensed, qualified
plumber.
■If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF. See “Ice Maker and
Storage Bin.”
■All installations must meet local plumbing code requirements.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
“Troubleshooting” or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See “Water Filtration
System.”
If you have questions about your water pressure, call a licensed,
qualified plumber.
Water System Preparation
Please read before using the water system.
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, follow the steps below to make sure
that the water system is properly cleaned. This will flush air from
the filter and water dispensing system, and prepare the water filter
for use.
NOTE: If your model has a base grille filter system, make sure the
base grille filter is properly installed and the cap is in the horizontal
position.
1. Open the freezer door and turn off the ice maker. The On/Off
switch is located on the top right side of the freezer
compartment. Move the switch to the OFF (right) setting as
shown.
2. Use a sturdy container to depress and hold the water
dispenser lever for 5 seconds, then release it for 5 seconds.
Repeat until water begins to flow. Once water begins to flow,
continue depressing and releasing the dispenser lever
(5 seconds on, 5 seconds off) until a total of 3 gal. (12 L) has
been dispensed. This will flush air from the filter and water
dispensing system, and prepare the water filter for use.
Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
3. Open the freezer door and turn on the ice maker. Move the
switch to the ON (left) position.
NOTES:
■Allow 24 hours to produce the first batch of ice.
■Discard the first three batches of ice produced.
■Allow 3 days to completely fill ice container.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.

5
REFRIGERATOR USE
Power On/Off Switch
If you need to turn the power to your refrigerator On or Off, you
must remove the top grille assembly to access the power switch.
Turn the power to the refrigerator Off when cleaning your
refrigerator or changing light bulbs.
To Remove Top Grille:
1. Grasp both ends of the top grille.
2. Push the top grille straight up, then pull straight out. Lay the
grille on a soft surface.
To Replace Top Grille:
1. Insert top grille hooks (located on the back of the top grille)
onto mounting bolts on the side trim.
2. Pull grille down slightly to lock into place.
Turn Power On or Off:
1. Remove top grille.
2. Press power switch to the On or Off position.
3. Replace top grille.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
Using the Controls
Depending on your model, your refrigerator may have Style 1 or
Style 2 controls. Follow the instructions specific to your model.
IMPORTANT:
■Wait 24 hours after you turn on the refrigerator before you put
food into it. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
■If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
■After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1¹⁄₂ hours until the
refrigerator and freezer temperatures are below 48°F (9°C) and
15°F (-9°C), respectively, or until the alarm is turned off. To
turn off the audio alarm and indicator light, see “Master Alarm
Reset.”
Turning Refrigerator On/Off and Viewing Set Points
The On/Off touch pad on the control panel shuts down refrigerator
functions such as cooling, some lighting, fans and compressors.
To turn the power off completely, use the power On/Off switch
located behind the top grille. See “Power On/Off Switch.”
■Press and hold the ON/OFF touch pad for 3 seconds. The
LED will light up to indicate that cooling is Off. Press the touch
pad again to turn on cooling. The LED will turn off.
Viewing the Celsius Temperatures
■Press F/C touch pad. To redisplay degrees Fahrenheit, press
F/C again.
NOTE: If the freezer temperature is below zero, the negative
sign next to the freezer display will light up. This is normal.
A. Top grille
B. Cabinet side trims
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
B BA
A. Power switch
A

6
Adjusting Controls
IMPORTANT:
■The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
NOTE: Wait at least 24 hours between adjustments. Recheck
the temperatures before other adjustments are made.
■Press the SET TO RECOMMENDED touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The factory recommended set points are 0°F (-18°C)
for the freezer and 37°F (2°C) for the refrigerator.
■The actual temperature may differ from the display when a
door is open for an extended period of time.
To Adjust Set Point Temperatures:
The set point range for the freezer is -5°F to 3°F (-21°C to -16°C).
The set point range for the refrigerator is 34°F to 42°F (1°C
to 6°C).
■Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
Style1
Style 2
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the current
condition that caused the alarm until a new condition occurs or
until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing ON/OFF
twice or by turning the power to the refrigerator off and on again.
See “Power On/Off Switch.” After performing a Master Alarm
Reset, the indicator light will reactivate if the condition that caused
the alarm is still present. See “Over Temperature,” “Call Service,”
or “Door Alarm.”
Style 1
Style 2
Door Alarm
The Door Alarm indicator light will flash, an alarm will sound and
the interior lights will turn off when a door has been open for
longer than 10 minutes. When the door is closed, the audio alarm
will reset and turn off, but the Door Open indicator light will
continue to flash until the temperature is equal to or below 45°F
(7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your food
may spoil. See the “Power Interruptions.” Minimize door openings
until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or the
freezer temperature rises above 15°F (-9°C) for longer than
1¹⁄₂ hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash until the Alarm is pressed to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 1¹⁄₂ hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: The audio alarm will be disabled for subsequent
occurrences of over temperature alarm condition. To enable the
audio alarm, see “Master Alarm Reset.”
Call Service (on some models)
If the Call Service indicator light is flashing, call for service. See
the “Assistance or Service” section for information on calling for
service.
NOTE: The audio alarm will be disabled for subsequent
occurrences of the call service alarm condition. To enable the
audio alarm, see “Master Alarm Reset.”
Max Cold
The Max Cold feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
■Press MAX COLD to turn on the Max Cold feature. The Max
Cold indicator light will remain on for 24 hours unless manually
turned off.
NOTE: The temperature display will remain at 34°F (1°C) and -5°F
(-21°C) for the refrigerator and freezer compartments,
respectively, while the Max Cold feature is enabled. After
24 hours, the refrigerator returns to the previous temperature set
points.
CONDITION/REASON: TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold
Not set correctly for conditions
REFRIGERATOR Control
1°higher
REFRIGERATOR too warm
High use or room very warm
REFRIGERATOR Control
1°lower
FREEZER too cold
Not set correctly for conditions
FREEZER Control
1°higher
FREEZER too warm/too little ice
High use or heavy ice use
FREEZER Control
1°lower

7
Rest Mode (on some models)
The Rest Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Rest Mode when it is no longer
required.
■Press REST MODE to turn on this feature.
■Press REST MODE again to turn off this feature.
NOTE: If the Max Cold feature has been selected prior to turning
on the Rest Mode feature, then the set points will remain at 34°F
(1°C) and -5°F (-21°C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times out.
The refrigerator will then return to the previous temperature set
points chosen prior to the selection of the Max Cold feature, but
the lights and ice maker will remain off until Rest Mode is pressed
again.
Sabbath Mode (on some models)
The Sabbath Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Sabbath Mode when it is no longer
required.
■Press SABBATH MODE to turn on this feature.
■Press SABBATH MODE again to turn off this feature.
NOTES:
■If the refrigerator is operating in Sabbath mode and you press
SABBATH MODE to turn off the feature, close the doors to
reset the interior lighting.
■If the Max Cold feature has been selected prior to turning on
the Sabbath Mode feature, then the set points will remain at
34°F (1°C) and -5°F (-21°C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times
out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cold feature, but the lights and ice maker will remain off
until Sabbath Mode is pressed again.
Water Filter Status
Style 1 - Reset
The Reset Filter control allows you to restart the water filter status
tracking feature each time you replace the water filter. See “Water
Filtration System.”
■Press and hold RESET for 3 seconds, until the indicator
display changes to 99%.
Style 2 - Reset Filter
The reset filter control allows you to restart the water filter status
tracking feature each time you replace you water filter. See “Water
Filtration System.”
■Press and hold RESET FILTER for 3 seconds, until the Order
or Replace light turns off.
Holiday Mode
The Holiday Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Holiday Mode when it is no longer
required.
Control Panel
In Holiday Mode, the temperature set points remain unchanged
and the interior lights turn off.
■Press Holiday Mode to turn on this feature.
■Press Holiday Mode again to turn off this feature.
Ingredient Care Center
The control for the Ingredient Care Center adjusts the temperature
of the storage drawer. Cold air flows into the drawer through the
air duct between the freezer and the refrigerator. Adjusting the
control allows more or less cold air through the air duct.
Adjust the Temperature
1. Choose a setting based on the item to be stored in the drawer.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to verify that
the drawer is ready to be loaded.
Style 1–Dispenser models
Style 2–Non-dispenser Models

8
Remove and Replace the Ingredient Care Center
Cover
1. Remove food from Ingredient Care Center cover. Pull drawer
out about 4" (10.16 cm). Reach under the glass shelf with both
hands and lift gently upward until back of shelf is free. Tilt the
shelf at an angle and remove the shelf from the refrigerator. Do
not bump the glass.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish ........................ use same day as purchased
Chicken, ground beef, variety meat (liver, etc.)................ 1-2 days
Cold cuts, steaks/roasts .................................................. 3-5 days
Cured meats .................................................................. 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Water and Ice Dispensers
(on some models)
IMPORTANT:
■After connecting the refrigerator to a water source or replacing
the water filter, flush the water system. Use a sturdy container
to depress and hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water begins to
flow. Once water begins to flow, continue depressing and
releasing the dispenser lever (5 seconds on, 5 seconds off)
until a total of 3 gal. (12 L) has been dispensed. This will flush
air from the filter and water dispensing system, and prepare
the water filter for use. Additional flushing may be required in
some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
■Allow 24 hours for the refrigerator to cool down and chill
water.
■Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
■The dispensing system will not operate when the freezer door
is open.
■Depending on your model, your water and ice dispensers may
have one or more of the following features: a dispenser tray, a
special light that turns on when you use the dispenser, or a
lock option to avoid unintentional dispensing.
Water Dispenser
To Dispense Water:
1. Press a sturdy glass against the water dispenser pad.
NOTES:
■While dispensing water and for 3 seconds after dispensing
has stopped, the digital display will show how many
ounces of water have been dispensed.
■To switch from ounces to cups, press and hold ICE and
LOCK at the same time until the dispenser beeps after
3 seconds. To switch from cups to liters, press and hold
the buttons for another 3 seconds. To switch back to
ounces, repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-flavor if you do not use the
dispenser periodically. Dispense enough water every week to
maintain a fresh supply.
Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see “Ice Maker and Storage Bin.”
Your ice maker can produce both crushed and cubed ice. The
display screen reads “CRUSHED” or “CUBED,” indicating which
type is selected. To change the setting, press the ICE button
before dispensing ice.
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When changing from crushed to cubed, a few ounces of crushed
ice will be dispensed along with the first cubes.
To Dispense Ice:
1. Press the button to select the desired type of ice.
2. Press a sturdy glass against the ice dispenser pad. Hold the
glass close to the dispenser opening so ice does not fall
outside of the glass.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING

9
IMPORTANT: You do not need to apply a lot of pressure to the
pad in order to activate the ice dispenser. Pressing hard will
not make the ice dispense faster or in greater quantities.
3. Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad. The dispenser may
continue to make noise for a few seconds after dispensing.
Dispenser Tray (on some models)
Some models have a tray at the bottom of the dispenser area. The
tray is designed to catch small spills and is removable for easy
emptying and cleaning.
NOTE: There is no drain in the tray.
Dispenser Light (on some models)
When you use the dispenser, the light will automatically turn on.
If you want the light to be on continuously, you may choose either
ON or AUTO.
ON: Press LIGHT to turn the dispenser light on.
AUTO: Press LIGHT a second time to select AUTO mode. The
dispenser light will automatically adjust to become brighter as the
room brightens, dimmer as the room darkens.
OFF: Press LIGHT a third time to turn the dispenser light off.
The dispenser lights are LEDs that cannot be changed. If it
appears that your dispenser lights are not working, be sure that
the light sensor is not blocked (in AUTO mode). See
“Troubleshooting” for more information.
Dispenser Lock (on some models)
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
NOTE: The lock feature does not shut off power to the product, to
the ice maker, or to the dispenser light. It simply deactivates the
ice and water dispensers. To turn off the ice maker, see “Ice
Maker and Storage Bin.”
■Press and hold LOCK for 3 seconds to lock the dispenser.
While the dispenser is locking, “LOCKING” will appear on the
display screen and the blue indicator light around the LOCK
button will flash. When the dispenser is locked, the indicator
light will change to red for a few seconds, then turn off.
■Press and hold LOCK a second time to unlock the dispenser.
While the dispenser is unlocking, “UNLOCKING” will appear
on the display screen and the red indicator light around the
LOCK button will flash. When the dispenser is unlocked, the
indicator light will change to blue for a few seconds, then turn
off.
Water Filter Status Light (on some models)
The water filter status light and display screen help you know
when to change your water filter. Press the FILTER button to
check the status of your water filter.
If the filter is new:
You must press FILTER to view the filter’s status. For a few
seconds, the status light will be blue and the display screen will
show what percentage of your filter’s life remains.
If it is almost time to change the filter:
The status light will automatically illuminate and will remain on,
appearing yellow. The words “ORDER FILTER” will appear on the
display screen. Press FILTER to see what percentage of your
filter’s life remains. You should order the appropriate replacement
filter. See “Accessories.”
If it is time to change the filter:
The status light will remain on, changing to red. The words
“REPLACE FILTER” and “HOLD BUTTON TO RESET” will appear
on the display screen until the filter has been changed and the
status light has been reset.
To reset the water filter status light:
After changing the filter, reset the status light by pressing and
holding the FILTER button for 3 seconds. The status light will blink
red and change to blue, then turn off when the system is reset.
Ice Maker and Storage Bin
(on some models - Accessory)
IMPORTANT: Flush the water system before turning on the ice
maker. See “Water and Ice Dispensers.” Allow 24 hours to
produce the first batch of ice. Discard the first three batches of ice
produced. Allow 3 days to completely fill the ice container.
Style 1
To Turn the Ice Maker On/Off:
The On/Off switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1. To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
2. To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position and listen for the click to make sure
the ice maker will not continue to operate.
To Remove and Replace the Ice Bin:
1. Flip up the covering panel.
2. Lift the wire shutoff arm so it clicks into the OFF (up)
position. Ice can still be dispensed, but no more can be made.
3. Lift up the front of the storage bin and pull the ice bin forward.
4. Replace the bin by pushing it in all the way or the dispenser
will not work. Push the wire shutoff arm down to the ON
position to restart ice production. Make sure the door is
closed tightly.
A. Ice maker cover
A

10
Style 2
To Turn the Ice Maker On/Off:
The On/Off switch is located on the top right side of the freezer
compartment.
1. To turn the ice maker on, slide the control to the ON (left)
position.
NOTE: Your ice maker has an automatic shutoff. The ice
maker sensors will automatically stop ice production, but the
control will remain in the ON (left) position.
2. To manually turn the ice maker off, slide the control to the OFF
(right) position.
To Remove and Replace the Ice Storage Bin:
1. Hold the base of the storage bin with both hands and press
the release button to lift the storage bin up and out.
NOTE: It is not necessary to turn the ice maker control to the
OFF (right) position when removing the storage bin. The
sensor cover (“flipper door”) on the left wall of the freezer
stops the ice maker from producing ice if the door is open or
the storage bin is removed.
2. Replace the storage bin on the door and push down to make
sure it is securely in place.
Clean the Ice Storage Bin
NOTE: It is normal for ice to stick together in the ice bin. Ice may
be dispensed or used more frequently which will break up the ice.
It is recommended that the ice container be emptied and cleaned
as needed.
To clean the ice storage bin:
1. Empty the ice container. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin or bucket. This can cause damage to the ice container and
the dispenser mechanism.
2. Wash ice bin with a mild detergent, rinse well and dry
thoroughly. Do not use harsh or abrasive cleaners or solvents.
Remember
■Allow 24 hours to produce the first batch of ice. Allow 3 days
to completely fill ice container.
■Discard the first three batches of ice produced to avoid
impurities that may be flushed out of the system.
■The quality of your ice will be only as good as the quality of the
water supplied to your ice maker.
■Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
■It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
■For Style 1 ice maker, do not force the wire shutoff arm up or
down.
■Do not store anything on top of the ice maker or in the ice
storage bin/bucket.
Water Filtration System
Depending on your model, there may be a water filter indicator or
water filter status lights on the control panel. Follow the
instructions specific to your model.
Water Filter Indicator (dispenser models)
The water filter indicator, located on the control panel, will remind
you when it is time to order and replace the water filter.
A new water filter should display a reading of 99%. The reading in
the display will decrease as the filter life is used. A replacement
water filter should be ordered when “Order Filter” is displayed.
When “Change Filter” is displayed, a new water filter should be
installed.
The disposable water filter should be replaced every 6 months OR
earlier if the flow of water to the water dispenser or ice maker
decreases noticeably.
After changing the water filter, press and hold RESET for
2 seconds until the indicator display changes to 99%. See “Using
the Controls.”
Water Filter Status Lights (non-dispenser models)
The water filter status lights will remind you when it is time to
order and replace the water filter. When the Order Filter light is on,
it is almost time to change the water filter. When the Replace Filter
light is on, a new water filter should be installed.
The disposable water filter should be replaced at least every
6 months OR earlier if the flow of water to the ice maker
decreases noticeably.
After replacing the water filter, press and hold RESET FILTER for
3 seconds. The Good light will turn on when the filter tracking
feature is reset. See “Using the Controls.”
Changing the Water Filter
The water filter is located in the base grille below the freezer
compartment door. It is not necessary to remove the base grille to
remove the filter.
1. Remove the filter by pressing the eject button and pulling
straight out on the filter cap.
NOTES:
■Avoid twisting the cap when removing the filter because
this could cause the cap to come off. If this occurs,
replace the cap and pull the filter straight out.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
