Jenn-Air JS42NXFXDW10 User manual

JENN AIR®SIDE BY SIDE
BUILT IN REFRIGERATOR
REFRIGERADOR EMPOTRADO
DE DOS PUERTAS JENNA R®
RI2FRIGI2RATEUR ENCASTRFt
@
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_!!!!!!iiiiiiii
USE & CARE GUIDE
For questions about features, operation/performance, parts, accessories, or service,
call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.ca.
MANUAL DE USO Y CUIDADO
Si tiene preguntas respecto a las caracteristicas, funcionamiento, rendimiento, partes, accesorios o servicio tecnico,
Ilame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En Canada, Ilame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.ca.
GUIDE D'UTILISATIONET D'ENTRETIEN
Au Canada, pour assistance, installation ou service, composez le 1-800-JI=NNAIR (1-800-536-6247}
ou visitez notre site web & www.jennair.ca.
Table of Contents /[ndice /Table des matieres ................................................................................... 2
JENN-AIR °
W10681396A

TABLE OF
REFRIGERATOR SAFETY ........................................................................... 3
Proper Disposal of Your Old Refrigerator ................................................. 3
BEFORE USE ............................................................................................... 4
Water Supply Requirements ..................................................................... 4
Water System Preparation ........................................................................ 4
REFRIGERATOR USE ................................................................................. 5
Power On/Off Switch ................................................................................ 5
Using the Controls .................................................................................... 6
Water and Ice Dispensers ......................................................................... 8
Ice Maker and Storage Bin ....................................................................... 9
Water Filtration System .......................................................................... 10
REFRIGERATOR FEATURES ................................................................... 11
Refrigerator Shelves ............................................................................... 11
Temperature Controlled Dell Drawer ...................................................... 11
FREEZER FEATURES ............................................................................... 12
Freezer Shelf ........................................................................................... 12
Freezer Basket ........................................................................................ 13
CONTENTS
DOOR FEATURES ..................................................................................... 13
Utility Compartment ................................................................................ 13
Door Bins ................................................................................................ 13
REFRIGERATOR CARE ............................................................................ 13
Cleaning .................................................................................................. 13
Changing the Light Bulbs ....................................................................... 14
Power Interruptions ................................................................................ 14
Vacation Care ......................................................................................... 15
TROUBLESHOOTING ............................................................................... 15
Refrigerator Operation ............................................................................ 15
Temperature and Moisture ..................................................................... 16
Ice and Water .......................................................................................... 16
ASSISTANCE OR SERVICE ...................................................................... 18
In the U.S.A ............................................................................................. 18
In Canada ................................................................................................ 18
ACCESSORIES .......................................................................................... 18
WATER FILTER CERTIFICATIONS .......................................................... 19
PERFORMANCE DATA SHEETS ............................................................. 20
WARRANTY ............................................................................................... 22
[NDICE
SEGURIDAD DEL REFRIGERADOR ........................................................ 24
C6mo deshacerse adecuadamente de su refrigerador viejo ................. 25
ANTES DEL USO ....................................................................................... 25
Requisitos del suministro de agua ......................................................... 25
Preparaci6n del sistema de agua ........................................................... 26
USO DE SU REFRIGERADOR .................................................................. 26
Interruptor de On/Off (Encendido/Apagado) .......................................... 26
Uso de los controles ............................................................................... 27
Despachadores de agua y hielo ............................................................. 29
F_brica de hielo y dep6sito .................................................................... 30
Sistema de filtraci6n de agua ................................................................. 32
CARACTERISTICAS DEL REFRIGERADOR ........................................... 33
Estantes del refrigerador ........................................................................ 33
Caj6n para cames frias con temperatura controlada ............................ 33
CARACTERISTICAS DEL CONGELADOR .............................................. 35
Estante del congelador ........................................................................... 35
Canastilla del congelador ....................................................................... 35
CARACTERJSTICAS DE LA PUERTA ...................................................... 35
Compartimiento de uso general ............................................................. 35
Recipientes de la puerta ......................................................................... 35
CUlDADO DE SU REFRIGERADOR ........................................................ 36
Limpieza .................................................................................................. 36
C6mo cambiar los focos ........................................................................ 37
Cortes de corriente ................................................................................. 37
Cuidado durante las vacaciones ............................................................ 37
SOLUClON DE PROBLEMAS ................................................................... 38
Funcionamiento del refrigerador ............................................................ 38
Temperatura y humedad ........................................................................ 39
Hielo y agua ............................................................................................ 39
AYUDA O SERVIClO TI_CNICO ................................................................ 41
En los EE.UU ........................................................................................... 41
En Canad& .............................................................................................. 41
ACCESORIOS ............................................................................................ 41
HOJA DE DATOS DEL RENDIMIENTO ................................................... 42
GARANTIA ................................................................................................. 44
TABLE DES
SECURITE DU REFRIGERATEUR ........................................................... 46
Mise au rebut appropriee de votre vieux refrigerateur ........................... 47
AVANT UTILISATION ................................................................................ 47
Specifications de I'alimentation en eau.................................................. 47
Pr@aration du systeme d'eau ................................................................ 48
UTILISATION DU REFRIGERATEUR ....................................................... 48
Interrupteur d'alimentation On/Off (marche/arr_t) .................................. 48
Utilisation des commandes .................................................................... 49
Distributeurs d'eau et de glagons ........................................................... 51
Machine &glagons et bac d'entreposage .............................................. 53
Systeme de filtration d'eau ..................................................................... 54
CARACTERISTIQUES DU REFRIGERATEUR ........................................ 55
Tablettes du refrigerateur ....................................................................... 55
Bac pour specialit6s alimentaires &temperature contr61ee ................... 56
CARACTERISTIQUES DU CONGELATEUR ............................................ 57
Tablette de congelateur .......................................................................... 57
Panier de congelateur ............................................................................. 57
MATIERES
CARACTERISTIQUES DE LA PORTE ...................................................... 58
Compartiment utilitaire ........................................................................... 58
Balconnets de porte ............................................................................... 58
ENTRETIEN DU RI_FRIGI_RATEUR ......................................................... 58
Nettoyage ............................................................................................... 58
Remplacement des ampoules d'eclairage ............................................. 59
Pannes de courant .................................................................................. 59
Entretien avant les vacances .................................................................. 60
DEPANNAGE ............................................................................................. 60
Fonctionnement du refrig6rateur ............................................................ 60
Temperature et humidite ........................................................................ 61
Glagons et eau ........................................................................................ 61
ASSISTANCE OU SERVICE ...................................................................... 63
Au Canada .............................................................................................. 63
ACCESSOIRES .......................................................................................... 63
FEUILLES DE DONNEES SUP LA PERFORMANCE ............................. 64
GARANTIE .................................................................................................. 66
2

REFRIGERATORSAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Disconnect power before servicing.
• Replace all parts and panels before operating.
• Remove doors from your old refrigerator.
• Use nonflammable cleaner.
• Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
• Use two or more people to move and install refrigerator.
• Disconnect power before installing ice maker (on ice maker
kit ready models only).
• Use a sturdy glass when dispensing ice (on some models).
• Do not hit the refrigerator glass doors (on some models).
SAVE THESE INSTRUCTIONS
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
Proper Disposal of
Your Old Refrigerator
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous,
even if they will sit for "just a few days." If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.

BEFORE USE
Pinch Hazard
Installation of door panels with less than a 3/8"(0.95 cm) gap
between the door panel and the adjacent cabinet increases
the risk of potential pinching.
Remove the Packaging
Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see "Refrigerator Safety."
• Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside of
your refrigerator before using it. See the cleaning instructions in
"Refrigerator Care."
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
• Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
• Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See "Water Filtration
System."
If you have questions about your water pressure, call a licensed,
qualified plumber.
Ws Syste P yeps/ st
Please read before using the water system.
Immediately after installation, follow the steps below to make sure
that the water system is properly cleaned.
1. Open the freezer door and turn off the ice maker. For Style 1,
lift up the wire shutoff arm as shown. For Style 2, move the
switch to the OFF (right) setting as shown. The On/Off switch
is located on the top right side of the freezer compartment.
Style 1- Non-Dispenser Models
important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Style 2 - Dispenser Models
Read all directions before you begin.
IM PORTANT:
When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see "Connect to Water Line" in the Installation
Instructions. If you have any questions about your water
connection, see "Troubleshooting" or call a licensed, qualified
plumber.
• If you turn the refrigerator on before the water line is
connected, turn the ice maker OFE See "Ice Maker and
Storage Bin."
• All installations must meet local plumbing code requirements.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
"Troubleshooting" or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
NOTE: If your model has a base grille water filter, make sure the
water filter is properly installed so that the Eject button is out. See
"Water Filtration System."
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
2. Use a sturdy container to depress and hold the water
dispenser lever for 5 seconds, then release it for 5 seconds.
Repeat until water begins to flow. Once water begins to flow,
continue depressing and releasing the dispenser lever
(5 seconds on, 5 seconds off) until a total of 3 gal. (12 L) has
been dispensed. This will flush air from the filter and water
dispensing system, and prepare the water filter for use.
Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.

3. Open the freezer door and turn on the ice maker. For Style 1,
lower the wire shutoff arm. For Style 2, move the switch to the
ON (left) position.
• Allow 24 hours to produce the first batch of ice.
• Discard the first three batches of ice produced.
• Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
REFRIGERATORUSE
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
Standard Installation -Flush Grille
To remove the top grille panel:
1. Open the door(s).
2. Lift the top grille panel straight up, then pull straight out. Place
the panel on a soft surface.
To replace the top grille panel:
1. Hook the panel brackets onto the mounting bolts extending
from the top of the refrigerator.
2. Pull the grille panel down slightly to lock into place.
Integrated Installation -Full Height Grille
To install the grille panel to the refrigerator:
1. Slide the upper and lower slots in each bracket onto the
mounting pins extending upward from the top of the
refrigerator.
2. Push the grille panel forward to fully engage the spring clips
and fasten the grille panel.
To remove the grille panel from the refrigerator:
1. Open the door(s).
2. Place both hands under the grille panel, grasping the bottom
edge between your fingers and thumbs.
3. Pull the grille panel straight out until the grille stops. Then, lift
up on the grille panel to remove.
Power On or Off Switch
1. Remove the top grille panel.
2. Press power switch to the On or Off position.
3. Replace the top grille panel.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
/
[]
A
If you need to turn the power to your refrigerator On or Off, you
must remove the top grille panel to access the power switch. Turn
the power to the refrigerator Off when cleaning your refrigerator or
changing light bulbs.
B A B
A. Power switch
A. Top grille
B. Cabinet sides

Depending on your model, your refrigerator may have Style 1 or Style1
Style 2 controls. Follow the instructions specific to your model. OF -18C
IM PORTANT:
•Wait 24 hours after you turn on the refrigerator before you put
food into it. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster. Style 2
FROZEN FOOD FRESH FOOD
If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1_/2hours until the
refrigerator and freezer temperatures are below 48°F (9°C) and
15°F (-9°C), respectively, or until the alarm is turned off. To
turn off the audio alarm and indicator light, see "Master Alarm
Reset."
Turning Refrigerator On/Off and Viewing Set Points
The On/Off touch pad on the control panel shuts down refrigerator
functions such as cooling, some lighting, fans and compressors.
To turn the power off completely, use the power On/Off switch
located behind the top grille. See "Power On/Off Switch."
• Press and hold the ON/OFF touch pad for 3 seconds. The
LED will light up to indicate that cooling is Off. Press the touch
pad again to turn on cooling. The LED will turn off.
Viewing the Celsius Temperatures
Press F/C touch pad. To redisplay degrees Fahrenheit, press
F/C again.
NOTE: If the freezer temperature is below zero, the negative
sign next to the freezer display will light up. This is normal.
Adjusting Controls
IMPORTANT:
• The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
NOTE: Wait at least 24 hours between adjustments. Recheck
the temperatures before other adjustments are made.
Press the SET TO RECOMMENDED touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The factory recommended set points are 0°F (-18°C)
for the freezer and 37°F (2°C) for the refrigerator.
The actual temperature may differ from the display when a
door is open for an extended period of time.
To Adjust Set Point Temperatures:
The set point range for the freezer is -5°F to 3°F (-21°C to -16°C).
The set point range for the refrigerator is 34°F to 42°F
(1°C to 6°C).
• Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
SET TO RECOMMENDED 37"F 3c
E] ....... €1 E]
F1 ....... [] ..........F-1
CONDITION/REASON: TEMPERATURE
ADJUSTM ENT:
REFRIGERATOR too cold REFRIGERATOR Control
Not set correctly for conditions 1° higher
REFRIGERATOR too warm REFRIGERATOR Control
1o lower
High use or room very warm
FREEZER too cold FREEZER Control
Not set correctly for conditions 1° higher
FREEZER too warm/too little ice FREEZER Control
High use or heavy ice use 1° lower
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the current
condition that caused the alarm until a new condition occurs or
until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing ON/OFF
twice or by turning the power to the refrigerator off and on again.
See "Power On/Off Switch." After performing a Master Alarm
Reset, the indicator light will reactivate if the condition that caused
the alarm is still present. See "Over Temperature," "Call Service,"
or "Door Alarm."
Style 1
Door Alarm •
Over [emp AIsrm •
Call Service •
Style 2
Door Alarm _
Over lemp Alarm _'_
Door Alarm
The Door Alarm indicator light will flash, an alarm will sound and
the interior lights will turn off when a door has been open for
longer than 10 minutes. When the door is closed, the audio alarm
will reset and turn off, but the Door Open indicator light will
continue to flash until the temperature is equal to or below 45°F
(7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
"Master Alarm Reset."
6

Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your food
may spoil. See the "Power Interruptions." Minimize door openings
until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or the
freezer temperature rises above 15°F (-9°C) for longer than
1V2hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash until the Alarm is pressed to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 1V2hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: The audio alarm will be disabled for subsequent
occurrences of over temperature alarm condition. To enable the
audio alarm, see "Master Alarm Reset."
Call Service (on some models)
If the Call Service indicator light is flashing, call for service. See
the "Assistance or Service" section for information on calling for
service.
NOTE: The audio alarm will be disabled for subsequent
occurrences of the call service alarm condition. To enable the
audio alarm, see "Master Alarm Reset."
Max Cold
The Max Cold feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
• Press MAX COLD to turn on the Max Cold feature. The Max
Cold indicator light will remain on for 24 hours unless manually
turned off.
NOTE: The temperature display will remain at 34°F (1°C) and -5°F
(-21 °C) for the refrigerator and freezer compartments,
respectively, while the Max Cold feature is enabled. After
24 hours, the refrigerator returns to the previous temperature set
points.
Rest Mode (on some models)
The Rest Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Rest Mode when it is no longer
required.
• Press REST MODE to turn on this feature.
• Press REST MODE again to turn off this feature.
Rest Mode
Sabbath Mode (on some models)
The Sabbath Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Sabbath Mode when it is no longer
required.
• Press SABBATH MODE to turn on this feature.
• Press SABBATH MODE again to turn off this feature.
NOTES:
• If the refrigerator is operating in Sabbath mode and you press
SABBATH MODE to turn off the feature, close the doors to
reset the interior lighting.
If the Max Cold feature has been selected prior to turning on
the Sabbath Mode feature, then the set points will remain at
34°F (1°C) and -5°F (-21 °C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times
out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cold feature, but the lights and ice maker will remain off
until Sabbath Mode is pressed again.
Water Filter Status
Style 1-Reset
The Reset Filter control allows you to restart the water filter status
tracking feature each time you replace the water filter. See "Water
Filtration System."
• Press and hold RESET for 3 seconds, until the indicator
display changes to 99%.
%Remaining
WATER FILTERINDICATOR
Style 2-Reset Filter
The reset filter control allows you to restart the water filter status
tracking feature each time you replace you water filter. See "Water
Filtration System."
• Press and hold RESET FILTER for 3 seconds, until the Order
or Replace light turns off.
Water Filter Status
/_ Good
_ Order Filter
_} Replace Filter
NOTE: If the Max Cold feature has been selected prior to turning
on the Rest Mode feature, then the set points will remain at 34°F
(1°C) and -5°F (-21 °C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times out.
The refrigerator will then return to the previous temperature set
points chosen prior to the selection of the Max Cold feature, but
the lights and ice maker will remain off until Rest Mode is pressed
again.

IM PORTANT:
After connecting the refrigerator to a water source or replacing
the water filter, flush the water system. Use a sturdy container
to depress and hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water begins to
flow. Once water begins to flow, continue depressing and
releasing the dispenser lever (5 seconds on, 5 seconds off)
until a total of 3 gal. (12 L) has been dispensed. This will flush
air from the filter and water dispensing system and prepare
the water filter for use. Additional flushing may be required in
some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
Allow 24 hours for the refrigerator to cool down and chill
water.
Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
The dispensing system will not operate when the freezer door
is open.
Depending on your model, your water and ice dispensers may
have one or more of the following features: a water level
indicator in the dispenser tray, a light that turns on when you
use the dispenser, or a lock option to avoid unintentional
dispensing.
Water Dispenser
To dispense water:
1. Press a sturdy glass against the water dispenser pad.
NOTES:
While dispensing water and for 3 seconds after dispensing
has stopped, the digital display will show how many
ounces of water have been dispensed.
To switch from ounces to cups, press and hold ICE and
LOCK at the same time until the dispenser beeps after
3 seconds. To switch from cups to liters, press and hold
the buttons for another 3 seconds. To switch back to
ounces, repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-flavor if you do not use the
dispenser periodically. Dispense enough water every week to
maintain a fresh supply.
Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see "Ice Maker and Storage Bin."
Your ice maker can produce both crushed and cubed ice. The
display screen reads "CRUSHED" or "CUBED," indicating which
type is selected. To change the setting, press the ICE button
before dispensing ice.
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When the ice maker is changing from crushed to cubed, a few
ounces of crushed ice will be dispensed along with the first cubes.
To dispense ice:
1. Press the button to select the desired type of ice.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
2.
3.
Press a sturdy glass against the ice dispenser pad. Hold the
glass close to the dispenser opening so ice does not fall
outside of the glass.
IMPORTANT: You do not need to apply a lot of pressure to the
pad in order to activate the ice dispenser. Pressing hard will
not make the ice dispense faster or in greater quantities.
Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad. The dispenser may
continue to make noise for a few seconds after dispensing.
Dispenser Light (on some models)
When you use the dispenser, the light will automatically turn on.
If you want the light to be on continuously, you may choose either
ON or AUTO.
ON: Press LIGHT to turn the dispenser light on.
AUTO: Press LIGHT a second time to select AUTO mode. The
dispenser light will automatically adjust to become brighter as the
room brightens, dimmer as the room darkens.
OFF: Press LIGHT a third time to turn the dispenser light off.
The dispenser lights are LEDs that can not be changed. If it
appears that your dispenser lights are not working, be sure that
the light sensor is not blocked (in AUTO mode). See
"Troubleshooting" for more information.
Dispenser Lock (on some models)
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
NOTE: The lock feature does not shut off power to the product, to
the ice maker, or to the dispenser light. It simply deactivates the
ice and water dispensers. To turn off the ice maker, see "Ice
Maker and Storage Bin."
• Press and hold LOCK for 3 seconds to lock the dispenser.
While the dispenser is locking, "LOCKING" will appear on the
display screen and the blue indicator light around the LOCK
button will flash. When the dispenser is locked, the indicator
light will change to red for a few seconds, then turn off.
8

Press and hold LOCK a second time to unlock the dispenser.
While the dispenser is unlocking, "UNLOCKING" will appear
on the display screen and the red indicator light around the
LOCK button will flash. When the dispenser is unlocked, the
indicator light will change to blue for a few seconds, then turn
off.
IMPORTANT: Flush the water system before turning on the ice
maker. See "Water and Ice Dispensers." Allow 24 hours to
produce the first batch of ice. Discard the first three batches of ice
produced. Allow 3 days to completely fill the ice container.
Style 1
To Turn the Ice Maker On/Off:
The On/Oft switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1= To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
2. To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position and listen for the click to make sure
the ice maker will not continue to operate.
t
To Remove and Replace the Ice Bin:
1. Flip up the covering panel.
A..................._ ...............
[ J
A. Ice maker cover
2. Lift the wire shutoff arm so it clicks into the OFF (up)
position. Ice can still be dispensed, but no more can be made.
3. Lift up the front of the storage bin and pull the ice bin forward.
4. Replace the bin by pushing it in all the way or the dispenser
will not work. Push the wire shutoff arm down to the ON
position to restart ice production. Make sure the door is
closed tightly.
Style 2
To Turn the Ice Maker On/Off:
The On/Oft switch is located on the top right side of the freezer
compartment.
1. To turn the ice maker on, slide the control to the ON (left)
position.
NOTE: Your ice maker has an automatic shutoff. The ice
maker sensors will automatically stop ice production, but the
control will remain in the ON (left) position.
2. To manually turn the ice maker off, slide the control to the OFF
(right) position.
To Remove and Replace the Ice Storage Bin:
1. Hold the base of the storage bin with both hands and press
the release button to lift the storage bin up and out.
NOTE: It is not necessary to turn the ice maker control to the
OFF (right) position when removing the storage bin. The
sensor cover ("flipper door") on the left wall of the freezer
stops the ice maker from producing ice if the door is open or
the storage bin is removed.
2. Replace the storage bin on the door and push down to make
sure it is securely in place. J
/
Clean the Ice Storage Bin
NOTE: It is normal for ice to stick together inthe ice bin. Ice may
be dispensed or used more frequently which will break up the ice.
It is recommended that the ice container be emptied and cleaned
as needed.
To clean the ice storage bin:
1. Empty the ice container. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin or bucket. This can cause damage to the ice container and
the dispenser mechanism.
2. Wash ice bin with a mild detergent, rinse well and dry
thoroughly. Do not use harsh or abrasive cleaners or solvents.

Remember
• Allow 24 hours to produce the first batch of ice. Allow 3 days
to completely fill ice container.
Discard the first three batches of ice produced to avoid
impurities that may be flushed out of the system.
The quality of your ice will be only as good as the quality of the
water supplied to your ice maker.
Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
For Style 1 ice maker, do not force the wire shutoff arm up or
down.
• Do not store anything on top of the ice maker or in the ice
storage bin/bucket.
Depending on your model, there may be a water filter indicator or
water filter status lights on the control panel. Follow the
instructions specific to your model.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
Water Filter Indicator (dispenser models)
The water filter indicator, located on the control panel, will remind
you when it is time to order and replace the water filter.
A new water filter should display a reading of 99%. The reading in
the display will decrease as the filter life is used. A replacement
water filter should be ordered when "Order Filter" is displayed.
When "Change Filter" is displayed, a new water filter should be
installed.
The disposable water filter should be replaced every 6 months OR
earlier if the flow of water to the water dispenser or ice maker
decreases noticeably.
After changing the water filter, press and hold RESET for
2 seconds until the indicator display changes to 99%. See "Using
the Controls."
Water Filter Status Lights (non-dispenser models)
The water filter status lights will remind you when it is time to
order and replace the water filter. When the Order Filter light is on,
it is almost time to change the water filter. When the Replace Filter
light is on, a new water filter should be installed.
The disposable water filter should be replaced at least every
6 months OR earlier if the flow of water to the ice maker
decreases noticeably.
After replacing the water filter, press and hold RESET FILTER for
3 seconds. The Good light will turn on when the filter tracking
feature is reset. See "Using the Controls."
Changing the Water Filter
The water filter is located in the base grille below the freezer
compartment door. It is not necessary to remove the base grille to
remove the filter.
1. Remove the filter by pressing the eject button and pulling
straight out on the filter cap.
NOTES:
Avoid twisting the cap when removing the filter because
this could cause the cap to come off. If this occurs,
replace the cap and pull the filter straight out.
• There will be water in the filter. Some spilling may occur.
2.
3.
A. Eject button
B. Filter cap
Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
Align the ridge on the cap with the arrow on the new filter and
turn the cap until it snaps into place.
A. Cover
B. O-rings
4. Remove the covers from the O-rings. Be sure the O-rings are
still in place after the covers are removed.
5. Place the cap (removed in Step 2) on the new filter. Align the
ridge on the cap with the arrow on the filter. Turn the cap
clockwise until it snaps into place.
A
A. Eject button
B. Arrow on filter
C. Ridge on cap
10

6. Push the new filter into the opening in the base grille. As the
filter is inserted, the eject button will depress. The eject button
will pop back out when the filter is fully engaged.
7. Pull gently on the cap to check that the filter is securely in
place.
8. Flush the water system. See "Water and Ice Dispensers."
Using the Ice Maker Without a Water Filter
You can operate the ice maker without a water filter. Your ice will
not be filtered.
1. Remove the filter by pressing the eject button and pulling on
the cap. See "Changing the Water Filter" earlier in this section.
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3, With the cap in a horizontal position, insert the cap into the
base grille until it stops.
4, Turn the cap counterclockwise until the cap slips into the
attachment slot. Then, turn the cap clockwise until it is in a
horizontal position.
NOTE: The cap will not be even with the base grille.
REFRIGERATOR FEATURES
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
The shelves in your refrigerator are adjustable to meet your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Shelves
Style 1
To remove and replace a shelf/frame:
1. Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports. Pull shelf straight out.
2. Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until the rear
shelf hooks drop into the shelf supports.
3, Lower the front of the shelf and check to make sure that the
shelf is securely in position.
Style 2
To remove and replace a shelf/frame:
1. Remove the shelf by tilting it up at the front and lifting it out of
the shelf supports. Pull shelf straight out.
2. Reposition the shelf supports in the desired location. Check
that they are level and firmly inserted inthe support rails.
3. Place the back of the shelf in the shelf supports.
4. Lower the front of the shelf and make sure that it is in position.
The control for the dell drawer adjusts the temperature of the
drawer. Cold air flows into the drawer through the air duct
between the freezer and the refrigerator. Adjusting the control
allows more or less cold air through the air duct.
Adjust the Temperature
There are three temperature settings: Dell, Produce, Meats (Cold
to Coldest) and the Quick Chill setting. Select the appropriate
setting for the food being stored.
1. Choose a setting based on the item to be stored in the drawer.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to let you
know that the drawer is ready to be loaded.
Quick Chill Setting (on some models)
Each dell drawer has a Quick Chill setting. Selecting Quick Chill
lowers the temperature of the dell drawer for a one-hour period.
NOTE: The dell drawer temperature will be lower than the freezing
point for liquids. Remove items that may freeze, before setting the
drawer to Quick Chill.
Style 1
A
A. Deft drawer
B. Crisper
11

Style 2
AiA
2. To replace the crisper drawer or deli drawer, pull out the
drawer slides until they are fully extended and set the drawer
on the slides. Be sure the small bracket on the side of the
crisper drawer is behind the pin on the side.
A. Crisper
B. Deft drawer
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish ........................ use same day as purchased
Chicken, ground beef, variety meat (liver, etc.) ................ 1-2 days
Cold cuts, steaks/roasts .................................................. 3-5 days
Cured meats .................................................................. 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Crisper and Deli Drawers
The larger drawers are the crispers for your larger produce items.
To remove and replace the top cover:
1. Remove food from the top cover. Pull drawer out about 4"
(10.16 cm). Reach under the glass shelf with both hands and
lift gently upward until back of shelf is free. Tilt the shelf at an
angle and remove the shelf from the refrigerator. Do not bump
the glass.
3.
1.
2.
_B
A. Bracket
B.Pin
Push the drawer in toward the back until it is in closed
position. Reopen the crisper drawer or deli drawer to make
sure it has been replaced properly.
FREEZERFEATURES
Remove the shelf by lifting it up and pulling it straight out.
Replace the shelf by putting it over the supports and lowering
it into place.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
To remove and replace the crisper and deli drawers:
1. Slide the crisper drawer or deli drawer, straight out to the stop.
Lift the front of the drawer with one hand while supporting the
bottom with the other hand. Slide the drawer out the rest of
the way.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside a
sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating ice
crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 Ibs of food per cubic foot
[907-1,350 g per 28 L] of freezer space). Leave enough space in
the freezer for air to circulate around packages. Be sure to leave
enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
12

Bas et
The freezer basket can be used to store bags of frozen fruits and
vegetables that may slide off freezer shelves.
Remove and Replace the Freezer Basket
1. Pull the basket forward out to the stop.
2. Lift the front of the basket and slide it out the rest of the way.
Door Bins
1. Remove the bin by lifting it up and pulling it out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
REFRIGERATORCARE
3. Replace the basket by positioning it on the side wall guide
rails. Lift the basket front slightly while pushing it past the
guide rail stops and slide basket in the rest of the way.
DOOR FEATURES
The utility compartment can be placed in any position on the
refrigerator door.
Remove and Replace the Utility Bin
1. Remove utility compartment by grasping both ends and lifting
compartment up and out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Dees" BBss
Large door bins hold gallon containers and the smaller door bins
hold 2-liter bottles. The door bins are adjustable and removable
for easy cleaning and adjusting.
Gallon Door Bin
NOTE: The gallon door bin can only be placed on the lower
support.
1. Insert the attachment brackets into the adjustment slots on
the door.
2. Push down on the bin to secure tabs.
3. If necessary, adjust interior shelves to allow for milk jugs and
tall beverage containers stored in the gallon door bin.
E×plosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to avoid
buildup of odors. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Remove the top grille. See "Power On/Oft Switch."
2. Press power switch to OFF.
3. Remove all removable parts from inside, such as shelves,
crispers, etc.
4. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
• Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
• To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
13

5. Clean the exterior surfaces.
Broken Glass Hazard
Do not hit refrigerator glass doors.
Protect glass surface and edges during installation or
removal of doors.
Failure to do so can result in serious eye injury or
minor cuts.
Glass door panels: Wash glass door panels with a clean
sponge or soft cloth and a mild detergent in warm water.
NOTE: Do not hit the glass with pots, pans, furniture, toys, or
other objects. Scratching, hitting, jarring or stressing the glass
may weaken its structure, causing an increased likelihood of
breakage at a later date.
Stainless steel panels: Wash stainless steel with a clean
sponge or soft cloth and a mild detergent in warm water.
To keep your stainless steel refrigerator looking like new
and to remove minor scuffs or marks, it is suggested that
you use the manufacturer's approved Stainless Steel
Cleaner and Polish.
IMPORTANT: This cleaner isfor Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come
into contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If unintentional contact
does occur, clean plastic part with a sponge and mild
detergent in warm water. Dry thoroughly with a soft cloth. To
order the cleaner, see "Accessories."
6. Press the power switch to ON.
7. Replace the top grille. See "Power On/Off Switch."
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with one of the same size and shape. All lights
require a 40-watt maximum appliance bulb. Replacement bulbs
are available from your dealer or appliance store.
1. Remove the top grille. See "Power On/Off Switch."
2. Press the power switch to OFE
3. Remove light shield when applicable as shown.
NOTE: To clean a light shield, wash it with warm water and a
liquid detergent. Rinse and dry the shield well.
4. Remove light bulb and replace with one of the same size,
shape and wattage.
5. Replace light shield when applicable as shown.
6. Press the power switch ON.
7. Replace the top grille. See "Power On/Off Switch."
Refrigerator Control Panel Lights
There are two or three light bulbs located in the top front of the
refrigerator compartment behind a light shield.
• Open the light shield. Grasp the light shield by the openings.
Gently push back and pull down, as shown, to access the
light bulbs.
A.Light shield
Remove the light bulb and replace it with one of the same
size, shape and wattage.
Close the light shield by raising it up into place.
NOTE: If needed, clean the light shield with a damp soft cloth.
Freezer and Crisper Lights
Remove the light shield by grasping the sides and squeezing
in toward the center. Once the side hooks of the shield are free
from the freezer or crisper lining, pull down the shield.
Replace the light shield by squeezing the top and bottom
toward the center and inserting the hooks into the slotted
holes. Once the hooks are in place, snap the front tab into the
slotted hole.
If the power will be out for 24 hours or less, keep the door or
doors closed (depending on your model) to help food stay cold
and frozen.
If the power will be out for more than 24 hours, do one of the
following:
• Remove all frozen food and store it in a frozen food locker.
• Place 2 Ibs (907 g) of dry ice in the freezer for every cubic foot
(28 L) of freezer space. This will keep the food frozen for 2 to
4 days.
• If neither a food locker nor dry ice is available, consume or can
perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. If you see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
14

4 ¸ , ,_ _ _ _% _ ,_ _
Your refrigerator is equipped with either a Rest Mode or Sabbath
Mode feature, which is designed for the traveler who wishes to
turn off the lights and ice maker. By selecting this feature, the
temperature set points remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, it is recommended to exit Rest Mode or
Sabbath Mode when it is no longer required.
If You Choose to Leave the Refrigerator On While
You're Away:
1. Use up any perishables and freeze other items.
2. Press REST MODE or SABBATH MODE touch pad.
3. If your refrigerator has an automatic ice maker, shut off water
supply to the ice maker.
4. Empty the ice bin.
5. When you return from vacation, press REST MODE or
SABBATH MODE to return to normal operation.
If You Choose to Turn the Refrigerator Off Before You
Leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
• Turn off the water supply to the ice maker at least one day
ahead of time.
• When the last load of ice drops, raise the wire shutoff arm
to the OFF (up) position.
3. Depending on your model, turn the Thermostat Control
(or Refrigerator Control) to OFR See "Using the Controls."
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of both doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
The refrigerator will not operate
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Power cord unplugged? Plug into a grounded 3 prong outlet.
Is outlet working? Plug in a lamp to see if the outlet is
working.
Household fuse blown or circuit breaker tripped? Replace
the fuse or reset the circuit breaker. If the problem continues,
call an electrician.
Are controls on? Make sure the refrigerator controls are on.
See "Using the Controls."
Is refrigerator defrosting? Your refrigerator will regularly run
an automatic defrost cycle. Recheck in 30 minutes to see if it
is operating.
New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
NOTE: Adjusting the temperature controls to coldest setting
will not cool either compartment more quickly.
The motor seems to run too much
Your new refrigerator may run longer than your old one due to its
high-efficiency compressor and fans. The unit may run even
longer if the room is warm, a large food load is added, doors are
opened often, or if the doors have been left open.
The refrigerator is noisy
Refrigerator noise has been reduced over the years. Due to this
reduction, you may hear intermittent noises from your new
refrigerator that you did not notice from your old model. Below are
listed some normal sounds with an explanation.
•Buzzing - heard when the water valve opens to fill the ice
maker
Pulsating - fans/compressor adjusting to optimize
performance
Rattling - flow of refrigerant, water line, or from items placed
on top of the refrigerator
Sizzling/Gurgling - water dripping on the heater during
defrost cycle
Popping - contraction/expansion of inside walls, especially
during initial cool-down
Water running - may be heard when water melts during the
defrost cycle and runs into the drain pan
Creaking/Cracking - occurs as ice is being ejected from the
ice maker mold.
There is no audible door open alarm
Has the door been open less than 10 minutes? The door open
alarm will only flash when the door has been open for 10 minutes.
The audible alarm will sound the first time the door is left open for
more than 10 minutes. Subsequent door open alarms will only
flash. You must reset the audible alarm each time. See "Using the
Control(s)."
15

The doors will not close completely
•Door blocked open? Move food packages away from door.
• Bin or shelf in the way? Push bin or shelf back in the correct
position.
The doors are difficult to open
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Are the gaskets dirty or sticky? Clean gaskets with mild
soap and warm water.
The lights do not work
Is alight bulb loose in the socket or burned out? See
"Changing the Light Bulbs."
Is the refrigerator in Sabbath Mode or Rest Mode? See
"Using the Controls."
Has the door been open more than 10 minutes? See "Using
the Controls."
Temperature is too warm
New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
Door(s) opened often or left open? Allows warm air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
Large load of food added? Allow several hours for
refrigerator to return to normal temperature.
Controls set correctly for the surrounding conditions?
Adjust the controls a setting colder. Check temperature in
24 hours. See "Using the Controls."
Refrigerator not cooling? For models with digital controls,
turn the refrigerator OFF and then ON to reset. If this does not
correct the problem, call for service.
Air vents blocked? Remove any item from in front of the air
vents.
There is interior moisture buildup
NOTE: Some moisture buildup is normal.
• Humid room? Contributes to moisture buildup.
• Door(s) opened often or left open? Allows humid air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
The ice maker is not producing ice or not enough ice
•Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
•Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
•Ice maker turned on? Make sure wire shutoff arm or switch
(depending on model) is in the ON position.
•New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
•Large amount of ice recently removed? Allow 24 hours for
ice maker to produce more ice.
•Ice cube jammed in the ice maker ejector arm?
Remove ice from the ejector arm with a plastic utensil.
Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements" in either the Installation
Instruction booklet or the Use & Care Guide.
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
• Water shutoff valve not fully open? Turn the water shutoff
valve fully open.
• Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
• Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements."
• Questions remain regarding water pressure? Call a
licensed, qualified plumber.
Ice is sticking together in the ice storage bin
• It is normal for frost to be on top of the ice storage bin due to
normal opening and closing of the freezer.
It is normal for ice to stick together when it is not dispensed or
used frequently. It is recommended that the ice storage bin be
emptied and cleaned as needed. See "Ice Maker and Storage
Bin."
Off-taste, odor or gray color in the ice
New plumbing connections? New plumbing connections
can cause discolored or off-flavored ice.
Ice stored too long? Discard ice. Wash ice bin. Allow
24 hours for ice maker to make new ice.
Odor transfer from food? Use airtight, moisture proof
packaging to store food.
Are there minerals (such as sulfur) in the water? A water
filter may need to be installed to remove the minerals.
Is there awater filter installed on the refrigerator? Gray or
dark discoloration in ice indicates that the water filtration
system needs additional flushing.
16

The ice dispenser will not operate properly
•Freezer door closed completely? Close the door firmly. If it
does not close completely, see "The doors will not close
completely."
Ice bin installed correctly? Be sure the ice bin is firmly in
position.
New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
Ice stuck in the delivery chute? Use a plastic utensil to clear
the delivery chute.
Has the wrong ice been added to the bin? Use only cubes
produced by the current ice maker.
Has the ice melted around the auger (metal spiral) in the
ice bin? Empty the ice container. Use warm water to melt the
ice if necessary.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
Is the ice dispenser stalling while dispensing "crushed"
ice? Change the ice button from "crushed" to "cubed." If
cubed ice dispenses correctly, depress the button for
"crushed" ice and begin dispensing again.
Has the dispenser arm been held in too long? Ice will stop
dispensing when the arm is held in too long. Wait 3 minutes
for dispenser motor to reset before using again.
The water dispenser will not operate properly
•Freezer door closed completely? Close the door firmly. If it
does not close completely, see "The doors will not close
completely."
Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
Is the water pressure at least 30 psi (207 kPa)? The water
pressure to the home determines the flow from the dispenser.
See "Water Supply Requirements."
Kink in the home water source line? Straighten the water
source line.
New installation? Flush and fill the water system.
Water filter installed on the refrigerator? The filter may be
clogged or incorrectly installed.
Is areverse osmosis water filtration system connected to
your cold water supply? See "Water Supply Requirements"
in either the Installation Instructions or the Use & Care Guide.
Water is leaking from the dispenser
NOTE: One or two drops of water after dispensing is normal.
• Glass not being held under the dispenser long enough?
Hold the glass under the dispenser 2 to 3 seconds after
releasing the dispenser lever.
New installation? Flush the water system. See "Prepare the
Water System" or "Water and Ice Dispensers."
Recently changed water filter? Flush the water system. See
"Prepare the Water System" or "Water and Ice Dispensers."
The dispenser water is not cool enough
NOTE: Water from the dispenser is chilled to only 50°F (10°C).
• New installation? Allow 24 hours after installation for the
water supply to cool completely.
Recently dispensed large amount of water? Allow 24 hours
for water supply to cool completely.
Water not been recently dispensed? The first glass of water
may not be cool. Discard the first glass of water.
Refrigerator connected to a cold water pipe? Make sure
the refrigerator is connected to a cold water pipe. See "Water
Supply Requirements."
17

ASSISTANCE
If You Need Service
Please refer to the warranty page in this manual.
If You Need Replacement Parts
If you need to order replacement parts, we recommend that you
use only factory specified parts. Factory specified parts will fit
right and work right because they are made with the same
precision used to build every new Jenn-Air_appliance.
To locate factory specified parts in your area, call us or your
nearest designated service center.
Call the JennmAir Customer eXperience Center toll free at
1-800-JENNAIR (1-800-536-6247), or visit our website at
www.jennair.com.
Our consultants provide assistance with:
• Features and specifications on our full line of appliances.
• Referrals to local Jenn-Air brand dealers.
• Installation information.
• Use and maintenance procedures.
• Accessory and repair parts sales.
• Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
For Further Assistance
If you need further assistance, you can write to Jenn-Air with any
questions or concerns at:
Jenn-Air Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
OR SERVICE
Call the Jenn-Air Canada Customer eXperience Centre toll free
1-800-JENNAIR (1-800-536-6247} or visit our website at
www.jennair.ca.
Our consultants provide assistance with:
• Scheduling of service. Jenn-Air ®appliances designated
service technicians are trained to fulfill the product warranty
and provide after-warranty service, anywhere in Canada.
Features and specifications on our full line of appliances.
Referrals to local Jenn-Air brand dealers.
Use and maintenance procedures.
Accessory and repair parts sales.
For Further Assistance
If you need further assistance, you can write to Jenn-Air Canada
with any questions or concerns at:
Jenn-Air Brand Home Appliances
Customer eXperience Centre
200 - 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
ACCESSORIES
To order accessories, call 1-800-442-9991 and ask for the
appropriate part number listed below or contact your authorized
Jenn-Air dealer. In Canada, call 1-800-807-6777.
affresh®Stainless Steel Cleaner:
In U.S.A., order Part #W10355016
In Canada, order Part #W10355016B
affresh ®Stainless Steel Wipes:
In U.S.A., order Part #W10355049
In Canada, order Part #W10355049B
affresh ®Kitchen & Appliance Cleaner:
In U.S.A., order Part #W10355010
In Canada, order Part #W10355010B
Replacement Water Filter:
In U.S.A., order Part #4396841 (T2RFWG2)
In Canada, Order Part #4396841 B (T2RFWG2)
18

WATER FILTER CERTIFICATIONS
Stale of Calitornia
Department of ttealth Services
Water Treatment Device
Certificate Number
05 - 1703
Date Issued: April 6, 2005
Date Revised: September 7, 20(15
Trademark/Model Designation .....
Manufactureg_
116830 ofthe to Section
None
()re
":_:!i_A,!!II:_iiIiii!!!¸::,<7¢¸¸¸
Rated Service Capacily: 200gals RatedServiceFlo-3: 085gpm
Conditions of Certification:
Do not use with water that is micmbiok_gicalIy unsal) or ot unknown quaIity, without adequate disinf_tion before or
after tile system
l'radelnark/Model Designation
Whirlr _ot Deluxe T1WG2
_Vhi_l- )oi DehlxeT1WG2L
KitchenAid DeluxeTI WG2
J
KiwhenAld DeluxeT1 @_2L
Manufacturer: Whidpool C:mporauon
Slate of California
Deparlment of Health Services
Water Treatment Device
Cerlificate Number
05- 1702
Date Issued: April 6.2(/05
Da_e Revised Sep/emb:/7, 2005
Replacement Elements
None
Organic Contaminants
o-Dicl/otoben/ene
Toxapherlc
Rated Service Capacity: 200gals RatedServlceFlow: 05gpln
Conditioas of Certification:
Do not use with water that is microbiologically unsal_ or of unknown quail/y, without adcquate disinfection before or
after the system
19

PERFORMANCE DATA SHEETS
Base Grille Water Filtration System
Model T2WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T2WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
System tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of Chlorine Taste and Odor, Particulate
Class I1";and against NSF/ANSl Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
This system has been tested according to NSF/ANSl Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSl Standards 42 and 53.
Substance Reduction NSF Reduction Average Influent Challenge Maximum Average Minimum %Average %
Aesthetic Effects Requirements Influent Concentration Effluent Effluent Reduction Reduction
Chlorine Taste/Odor 50% reduction 2.0182 mg/L 2.0 mg/L + 10% 0.06 mg/L 0.0536 mg/L 97.03 97.34
Particulate Class I1" 85% reduction 1333333 #/mL At east 10,000 part c es/mL 6600 #/mL** 2325 #/mL 99.51 99.83
Contaminant NSF Reduction Average Influent Challenge Maximum Average Minimum %Average %
Reduction Requirements Influent Concentration Effluent Effluent Reduction Reduction
Lead: @ pH 6.5*** 0.010 mg/L 0.1533 mg/L 0.15 mg/L + 10% 0.0005 mg/L 0.0005 mg/L 99.67 99.67
Lead: @ pH 8.5*** 0.010 mg/L 0.1400 mg/L 0.15 mg/L _+10% 0.0007 mg/L 0.0006 mg/L 99.50 99.57
Mercury: @ pH 6.5 0.002 mg/L 0.0058 mg/L 0.006 mg/L + 10% 0.0002 mg/L 0.0002 mg/L 96.54 96.54
Mercury: @ pH 8.5 0.002 mg/L 0.0059 mg/L 0.006 mg/L _+10% 0.0005 mg/L 0.0003 mg/L 91.57 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L _+10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L _+10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L _+10% 0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L _+10% 0.0400 mg/L 0.0213 mg/L 51.13 74.00
Test Parameters: pH = 7.5 + 0.5 unless otherwise noted. Flow = 0.85 gpm (3.2 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
• It is essential that operational, maintenance, and filter •
replacement requirements be carried out for the product to
perform as advertised.
• Use replacement filter T2RFWG2, part #4396841.
Model T2WG2L: Style 1 - When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 - When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 - When the water filter status display changes from
"GOOD" to "ORDER," order a new filter. When the filter indicator
reads "REPLACE," it is recommended that you replace the filter.
Style 4 - Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T2WG2: Change the water filter cartridge every 6 months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6 months have passed, replace the water filter
cartridge more often.
• These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
• The product is for cold water use only.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
• Refer to the "Warranty" section for the Manufacturer's name,
address and telephone number.
• Refer to the "Warranty" section for the Manufacturer's limited
warranty.
Application Guidelines/Water Supply Parameters
Water Supply City or Well
Water Pressure 30 - 120 psi (207 - 827 kPa)
Water Temperature 33° - 100°F (0.6° - 37.8°C)
Service Flow Rate 0.85 gpm (3.2 Lpm) @60 psi
*Class II particle size: 1 um to <5 um
**Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
***Compliant for Lead reduction requirements under NSF/ANSl Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.
20
