JENN-AIR®DETAILED PLANNING DIMENSIONS 1 of 4
9211AdZw817
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air®appliances are appropriately UL, CUL or CSA approved.
42" FULLY INTEGRATED SIDE-BY-SIDE REFRIGERATOR
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM PANELS AND HANDLES)
JS42NXFXDE – 413⁄4" x 831⁄8" x 24" (without door/handles)
PRODUCT DIMENSIONS (including stainless steel door panel kit dimensions)
MODEL # JS42NXFXDE
in cm
A* Width of freezer door 1713⁄16 45.2
B* Width of refrigerator door 2313⁄16 60.5
CSpace between doors 1⁄80.3
DOverall width (including vinyl side trim) 413⁄4106.0
E
Height of door handles
Pro-Style®Stainless 63 160.0
Euro-Style Stainless 50 127.1
F
Height to top of door handles
Pro-Style®Stainless 67 170.3
Euro-Style Stainless 665⁄8169.1
GHeight of doors 81 205.7
HHeight of bottom grille 3 7.6
IWidth of recessed refrigerator 41 104.1
J
Width from side of refrigerator
to freezer door handle – door fully
open 110°
Pro-Style®Stainless 71⁄8 18.1
Euro-Style Stainless 63⁄417.1
K
Width from side of refrigerator
to handle – doors open 90°
Pro-Style®Stainless 2 5.1
Euro-Style Stainless 11⁄23.9
L
Width from side of refrigerator
to refrigerator door handle – door fully
open 110°
Pro-Style®Stainless 95⁄824.4
Euro-Style Stainless 91⁄823.1
MDepth without door panel kit 24 61.0
N
Depth with doors
Pro-Style®Stainless panel kit 243⁄462.9
Euro-Style Stainless panel kit 243⁄462.9
Custom panel (3⁄4"/1.9 cm) 243⁄462.9
O
Depth with handles
Pro-Style®Stainless 273⁄869.5
Euro-Style Stainless 267⁄868.3
PDepth with refrigerator door open 90° 463⁄4118.7
* Door width dimensions are for stainless steel panel kit only.
JS42NXFXDW
D
A* B*
C
F
H
I
K
JL
K
O
M
N
F
E
D
C
B
G
A*
P
110º 110º
E
FRONT VIEW
TOP VIEW
JS42NXFXDW
D
A* B*
C
F
H
I
K
JL
K
O
M
N
F
E
D
C
B
G
A*
P
110º 110º
E

JENN-AIR®DETAILED PLANNING DIMENSIONS 2 of 4
9211AdZw817
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air®appliances are appropriately UL, CUL or CSA approved.
DIMENSIONS AS INSTALLED
JS42NXFXDW
D
A* B*
C
F
H
I
K
JL
K
O
M
N
F
E
D
C
B
G
A*
P
110º 110º
E
SIDE VIEW
MODEL # JS42NXFXDE
in cm
A* Height of recessed refrigerator (min.) 831⁄8211.1
BDepth with refrigerator door open 90° (min.) 471⁄4120.0
C
Depth with handles (min.)
Pro-Style®Stainless 273⁄869.5
Euro-Style Stainless 267⁄868.3
D
Depth with doors (min.)
Pro-Style®Stainless panel kit 243⁄462.9
Euro-Style Stainless panel kit 243⁄462.9
Custom panel (3⁄4"/1.9 cm) 243⁄462.9
EDepth without door panel kit (min.) 24 61.0
FDepth of compressor (min.) 197⁄850.5
*Add 11⁄4" (3.2 cm) to the height dimension when leveling legs are fully extended.
42" FULLY INTEGRATED SIDE-BY-SIDE REFRIGERATOR
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM PANELS AND HANDLES)
JS42NXFXDE – 413⁄4" x 831⁄8" x 24" (without door/handles)

JENN-AIR®DETAILED PLANNING DIMENSIONS 3 of 4
9211AdZw817
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air®appliances are appropriately UL, CUL or CSA approved.
42" FULLY INTEGRATED SIDE-BY-SIDE REFRIGERATOR
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM PANELS AND HANDLES)
JS42NXFXDE – 413⁄4" x 831⁄8" x 24" (without door/handles)
ARMOIRE-STYLE INSTALLATION*
FRONT VIEW – OPEN TO CEILING
(OPTION 1)
FRONT VIEW – FALSE FRONT
(OPTION 2)
DOOR PANEL INSTALLATION
Side Trim
Door Panel
6" (15.2 cm) min.
Grille Bracket
Assembly
Airflow
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
Side Trim
Door Panel
6" (15.2 cm) min.
Grille Bracket
Assembly
Airflow
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
• Attach the grille bracket assembly and grille panel provided in the
armoire-style panel kit
• Requires a minimum of 6" (15.2 cm) of open space above the
refrigerator, which must not be blocked in any way, including soffits
* Refer to the Armoire Kit installation instructions for additional dimensions and installation
details.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
6" (15.2 cm) min.
False Front
False Front
False Front
Side Trim
Full Height
Door Panel
Grille Bracket
Assembly
False Front
(Option 2)
Airflow
84"
(213.4 cm)
84"
(213.4 cm)
84"
(213.4 cm)
84"
(213.4 cm)
84"
(213.4 cm)
84"
(213.4 cm)
SIDE VIEW – CUSTOM PANEL
DOOR PANEL INSTALLATION

JENN-AIR®DETAILED PLANNING DIMENSIONS 4 of 4
9211AdZw817
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air®appliances are appropriately UL, CUL or CSA approved.
OPENING/CLEARANCE DIMENSIONS
JF42NFXDW
42" FRENCH DOOR BOTTOM MOUNT
AA
B
D
H
G
F
E
I
L
K
J
C
M
O
NN
OR
P
Q
I
H
G
F
E
110º 110º
D*
A*
B*
Floor
C*
Wall
S
BACK VIEW
FRONT VIEW
w
D
A*
F
C
C
B
E
e
Water
Shutoff
MODEL # JS42NXFXDE
in cm
A* Width (min.) 42 106.7
BWidth of recommended electrical
location 71⁄219.1
C
Distance from side of cabinet to
recommended water connection
location
6 15.2
DHeight (min.) 84 213.4
EHeight to recommended electrical
location 77 195.6
FDepth of recommended water
connection location (max.) 1 2.5
eRecommended electrical connection location
wRecommended water connection location
*A minimum 2" (5.1 cm) furniture return must extend behind the face
of the cabinet on all sides.
ELECTRICAL REQUIREMENTS
115 volt, 60 Hz, AC only, 15- or 20-amp fused, grounded circuit is
required. A dedicated circuit is recommended. Use an outlet that cannot
be turned off by a switch. Do not use an extension cord.
WATER PRESSURE REQUIREMENTS
A cold water supply with water pressure between 30 and 120 psi (207
and 827 kPa) is required to operate the ice maker. Call a licensed,
qualified plumber with any questions about the water pressure.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water coming out of a reverse osmosis
system going to the water inlet valve of the refrigerator needs to be
between 30 and 120 psi (207 and 827 kPa).
If a reverse osmosis water filtration system is connected to the cold water
supply, the water pressure to the reverse osmosis system needs to be a
minimum of 40 to 60 psi (276 to 414 kPa).
LOCATION REQUIREMENTS
Floor must be able to support refrigerator (more than 600 lb [272 kg]),
door panels and contents of the refrigerator and must be at the same
level as flooring in the room.
42" FULLY INTEGRATED SIDE-BY-SIDE REFRIGERATOR
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM PANELS AND HANDLES)
JS42NXFXDE – 413⁄4" x 831⁄8" x 24" (without door/handles)
