Jenn-Air JS42NXFXDE User manual

W10779525A
Table of Contents/Índice/Table des matières...................................................................................2
USE AND CARE GUIDE
For questions about features, operation/performance, parts, accessories, or service,
call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.ca.
MANUAL DE USO Y CUIDADO
Si tiene preguntas respecto a las características, funcionamiento, rendimiento, partes, accesorios o servicio técnico,
llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En Canadá, llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.ca.
GUIDE D’UTILISATION ET D’ENTRETIEN
Au Canada, pour assistance, installation ou service, composez le 1-800-JENNAIR (1-800-536-6247)
ou visitez notre site Web à www.jennair.ca.
JENN-AIR®SIDE BY SIDE
BUILT-IN REFRIGERATOR
REFRIGERADOR EMPOTRADO
DE DOS PUERTAS JENN-AIR®
RÉFRIGÉRATEUR ENCASTRÉ
CÔTE À CÔTE JENN-AIR®

2
TABLE OF CONTENTS
REFRIGERATION SAFETY ........................................................ 3
Proper Disposal of Your Old Refrigerator .......................... 3
BEFORE USE ............................................................................. 4
Water Supply Requirements ................................................ 4
Water System Preparation................................................... 4
Install Produce Preserver (on some models) ..................... 5
REFRIGERATOR USE................................................................ 6
Power On/Off Switch............................................................ 6
Using the Controls................................................................ 6
Water and Ice Dispensers (on some models) .................... 8
Sabbath Mode....................................................................... 8
Ice Maker and Storage Bin
(on some models - Accessory)............................................ 9
Water Filtration System...................................................... 10
REFRIGERATOR FEATURES................................................... 11
Refrigerator Shelves........................................................... 11
Temperature Controlled Deli Drawer ................................ 12
Crisper and Covers............................................................. 12
Wine Rack ........................................................................... 13
FREEZER FEATURES .............................................................. 13
Freezer Shelf ....................................................................... 13
Freezer Basket.................................................................... 13
DOOR FEATURES.................................................................... 13
Door Bins............................................................................. 13
REFRIGERATOR CARE ........................................................... 14
Cleaning............................................................................... 14
Lights ................................................................................... 14
Power Interruptions............................................................ 14
Vacation Care...................................................................... 14
TROUBLESHOOTING.............................................................. 15
Refrigerator Operation....................................................... 15
Temperature and Moisture................................................. 16
Ice and Water ...................................................................... 16
ASSISTANCE OR SERVICE..................................................... 18
In the U.S.A.......................................................................... 18
In Canada ............................................................................ 18
ACCESSORIES......................................................................... 18
PERFORMANCE DATA SHEETS............................................. 19
WARRANTY.............................................................................. 20
ÍNDICE
SEGURIDAD DEL REFRIGERADOR....................................... 21
Cómo deshacerse adecuadamente de
su refrigerador viejo ........................................................... 22
ANTES DE USAR ..................................................................... 22
Requisitos del suministro de agua.................................... 22
Preparación del sistema de agua...................................... 23
Instalación del preservador de alimentos frescos
(en algunos modelos) ......................................................... 24
USO DE SU REFRIGERADOR................................................. 25
Interruptor de On/Off (encendido/apagado) .................... 25
Uso de los controles........................................................... 25
Sabbath Mode (Modo de descanso)................................. 27
Despachadores de agua y hielo (en algunos modelos) .. 27
Fábrica de hielo y depósito
(en algunos modelos - Accesorio) .................................... 29
Sistema de ltración de agua............................................ 30
CARACTERÍSTICAS DEL REFRIGERADOR .......................... 31
Estantes del refrigerador ................................................... 31
Cajón para carnes frías con temperatura controlada..... 31
Cajones para verduras y tapas.......................................... 32
Portabotellas....................................................................... 32
CARACTERÍSTICAS DEL CONGELADOR ............................. 32
Estante del congelador...................................................... 32
Canastilla del congelador .................................................. 32
CARACTERÍSTICAS DE LA PUERTA...................................... 33
Recipientes de las puertas ................................................ 33
CUIDADO DE SU REFRIGERADOR........................................ 33
Limpieza .............................................................................. 33
Luces ................................................................................... 34
Cortes de corriente ............................................................ 34
Cuidado durante las vacaciones....................................... 34
SOLUCIÓN DE PROBLEMAS.................................................. 35
Funcionamiento del refrigerador ...................................... 35
Temperatura y humedad .................................................... 36
Hielo y agua......................................................................... 36
AYUDA O SERVICIO TÉCNICO............................................... 38
En los EE.UU. ...................................................................... 38
En Canadá ........................................................................... 38
ACCESORIOS .......................................................................... 38
HOJA DE DATOS DEL RENDIMIENTO................................... 39
GARANTÍA................................................................................ 40
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR........................................... 42
Mise au rebut appropriée de votre vieux réfrigérateur ... 43
AVANT L’UTILISATION............................................................. 44
Spécications de l’alimentation en eau ........................... 44
Préparation du système d’eau........................................... 44
Installation du conservateur pour produits frais
(sur certains modèles)........................................................ 45
UTILISATION DU RÉFRIGÉRATEUR ...................................... 46
Interrupteur d’alimentation On/Off (marche/arrêt).......... 46
Utilisation des commandes ............................................... 46
Sabbath Mode (mode sabbat) ........................................... 48
Distributeurs d’eau et de glaçons
(sur certains modèles)........................................................ 49
Machine à glaçons et bac d’entreposage (sur certains
modèles - accessoire)........................................................ 51
Système de ltration d’eau................................................ 52
CARACTÉRISTIQUES DU RÉFRIGÉRATEUR........................ 53
Tablettes du réfrigérateur .................................................. 53
Centre de soins des ingrédients ....................................... 53
Bac à légumes et couvercles ............................................ 54
Casier à vin.......................................................................... 54
CARACTÉRISTIQUES DU CONGÉLATEUR ........................... 53
Tablette de congélateur ..................................................... 54
Panier du congélateur........................................................ 54
CARACTÉRISTIQUES DE LA PORTE..................................... 55
Compartiments dans la porte............................................ 55
ENTRETIEN DU RÉFRIGÉRATEUR ........................................ 55
Nettoyage ............................................................................ 55
Lampes ................................................................................ 56
Pannes de courant ............................................................. 56
Entretien avant les vacances............................................. 56
DÉPANNAGE ............................................................................ 57
Fonctionnement du réfrigérateur...................................... 57
Température et humidité.................................................... 58
Glaçons et eau .................................................................... 58
ASSISTANCE OU SERVICE..................................................... 60
ACCESSOIRES......................................................................... 60
FEUILLES DE DONNÉES SUR LA PERFORMANCE ............. 61
GARANTIE................................................................................ 62

3
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
REFRIGERATOR SAFETY
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3 prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all parts and panels before operating.
■Remove doors from your old refrigerator.
■Use nonflammable cleaner.
■Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■Use two or more people to move and install refrigerator.
■Disconnect power before installing ice maker (on ice maker
kit ready models only).
■Use a sturdy glass when dispensing ice (on some models).
■Do not hit the refrigerator glass doors (on some models).
Proper Disposal of Your Old Refrigerator
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned refrigerators are
still dangerous, even if they will sit for “just a few days.” If
you are getting rid of your old refrigerator, please follow these
instructions to help prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.

4
BEFORE USE
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your ngers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, ammable
uids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
■Dispose of/recycle all packaging materials.
After you remove all of the packaging materials, clean the inside
of your refrigerator before using it. See the cleaning instructions
in “Refrigerator Care.”
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Water Supply Requirements
Read all directions before you begin.
IMPORTANT:
■When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see “Connect to Water Line” in the Installation
Instructions. If you have any questions about your water
connection, see “Troubleshooting” or call a licensed, qualied
plumber.
■If you turn the refrigerator on before the water line is
connected, turn the ice maker Off. See “Ice Maker and
Storage Bin.”
■All installations must meet local plumbing code requirements.
Clean Before Using
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
“Troubleshooting” or call a licensed, qualied plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of
a reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water ltration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
■Check to see whether the sediment lter in the reverse
osmosis system is blocked. Replace the lter if necessary.
■Allow the storage tank on the reverse osmosis system to rell
after heavy usage.
■If your refrigerator has a water lter, it may further reduce
the water pressure when used in conjunction with a reverse
osmosis system. Remove the water lter. See “Water Filtration
System.”
If you have questions about your water pressure, call a licensed,
qualied plumber.
Water System Preparation
Please read before using the water system. Follow the directions
specic to your model.
Style 1 (Dispenser Models)
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water lter, follow the steps below to make sure
that the water system is properly cleaned. This will ush air from
the lter and water dispensing system, and prepare the water
lter for use.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
NOTE: If your model has a base grille lter system, make sure
the base grille lter is properly installed and the cap is in the
horizontal position.
1. Open the freezer door and turn off the ice maker. The On/
Off switch is located on the top right side of the freezer
compartment. Move the switch to the OFF (right) setting as
shown.
2. Use a sturdy container to depress and hold the water
dispenser lever for 5 seconds, and then release it for
5 seconds. Repeat until water begins to ow. Once water
begins to ow, continue depressing and releasing the
dispenser lever (5 seconds on, 5 seconds off) until a total
of 3 gal. (12 L) has been dispensed. This will ush air from
the lter and water dispensing system and prepare the water
lter for use. Additional ushing may be required in some
households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
3. Open the freezer door and turn on the ice maker. Move the
switch to the ON (left) position.
NOTES:
■Allow 24 hours to produce the rst batch of ice.
■Discard the rst three batches of ice produced.
■Allow 3 days to completely ll ice container.

5
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
NOTE: If your model has a base grille lter system, make sure
the base grille lter is properly installed and the cap is in the
horizontal position.
1. Turn on the ice maker. Lower the wire shutoff arm as shown.
Please refer to “Ice Maker and Storage Bin” for further
instructions on the operation of your ice maker.
NOTES:
■Allow 24 hours to produce the rst batch of ice.
■Allow 3 days to completely ll ice container.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
Install Produce Preserver
(on some models)
The produce preserver absorbs ethylene to slow the ripening
process of many produce items. As a result, certain produce
items will stay fresh longer.
Ethylene production and sensitivity varies depending on the type
of fruit or vegetable. To preserve freshness, it is best to separate
produce with sensitivity to ethylene from fruits that produce
moderate to high amounts of ethylene.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
Style 2 (Non-Dispenser Models)
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water lter, ll and discard two full containers of
ice to prepare the water lter for use, before using the ice.
Sensitivity to
Ethylene Ethylene Production
Apples High Very High
Asparagus Medium Very Low
Berries Low Low
Broccoli High Very Low
Cantaloupe Medium High
Carrots Low Very Low
Citrus Fruit Medium Very Low
Grapes Low Very Low
Lettuce High Very Low
Pears High Very High
Spinach High Very Low
Installing the Produce Preserver (on some models)
CAUTION: IRRITANT
MAY IRRITATE EYES AND SKIN. DANGEROUS FUMES
FORM WHEN MIXED WITH OTHER PRODUCTS.
Do not mix with cleaning products containing ammonia,
bleach or acids. Do not get in eyes, on skin or clothing. Do
not breathe dust. Keep out of reach of children.
FIRST AID TREATMENT: Contains potassium
permanganate. If swallowed, call a Poison Control Center or
doctor immediately. Do not induce vomiting. If in eyes, rinse
with water for 15 minutes. If on skin, rinse with water.
1. Wash the interior of a crisper drawer with a solution of mild
dish soap and warm water, and dry thoroughly.
2. Find the package containing the Produce Preserver inside the
refrigerator, and install the Produce Preserver into the crisper
drawer according to the instructions provided in the package.
Installing the Status Indicator (on some models)
The Produce Preserver comes with a status indicator, which
should be activated and installed at the same time the pouch
is installed.
1. Place the indicator face-down on a rm, at surface.
2. Apply pressure to the bubble on the back of the indicator
until the bubble pops to activate the indicator.
3. Slide open the cap on the Produce Preserver housing.
4. Place the indicator in the top of the housing facing outward.
5. Slide the cap closed, and check that the indicator is visible
through the rectangular hole in the cap.
NOTE: The cap will not easily close if the indicator’s rear
bubble has not been popped.
Replacing the Produce Preserver
The disposable packets should be replaced every 6 months or
when the status indicator changes completely from white to red.
To order replacements, see “Accessories” in the User Instructions
or User Guide.
1. Remove the used packets from the produce preserver
housing.
2. Remove the used status indicator.
3. Install the replacement packets and status indicator using
the instructions included in the package.

6
A
A. Power switch
Using the Controls
IMPORTANT:
■The refrigerator control adjusts the refrigerator compartment
temperature. The freezer control adjusts the freezer
compartment temperature.
■Wait 24 hours after you turn on the refrigerator before you put
food into it. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
■If the temperature is too warm or too cold in the refrigerator
or freezer, rst check the air vents to be sure they are not
blocked before adjusting the controls.
■The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is rm.
■The actual temperature may differ from the display when a
door is open for an extended period of time.
NOTE: The factory recommended set points are 0°F (-18°C) for
the freezer and 37°F (3°C) for the refrigerator.
REFRIGERATOR USE
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
Power On/Off Switch
If you need to turn the power to your refrigerator On or Off,
you must remove the top grille assembly to access the power
switch. Turn the power to the refrigerator Off when cleaning your
refrigerator.
Standard Installation - Flush Grille
To remove the top grille panel:
1. Open the door(s).
2. Lift the top grille panel straight up, and then pull straight out.
Place the panel on a soft surface.
To replace the top grille panel:
1. Hook the panel brackets onto the mounting bolts extending
from the top of the refrigerator.
2. Pull the grille panel down slightly to lock into place.
Integrated Installation - Full Height Grille
To install the grille panel to the refrigerator:
1. Slide the upper and lower slots in each bracket onto
the mounting pins extending upward from the top of the
refrigerator.
2. Push the grille panel forward to fully engage the spring clips
and fasten the grille panel.
To remove the grille panel from the refrigerator:
1. Open the door(s).
2. Place both hands under the grille panel, grasping the bottom
edge between your ngers and thumbs.
3. Pull the grille panel straight out until the grille stops. Then, lift
up on the grille panel to remove.
Turn Power On or Off:
1. Remove top grille.
2. Press Power switch to the ON or OFF position.
3. Replace top grille.
IMPORTANT: Be sure the power switch is set to the ON position
after cleaning refrigerator or changing light bulbs.

7
Turning Refrigerator On and Viewing Set Points
■Press the Cooling (ON/OFF) touch pad.
NOTE:
■After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1¹⁄₂ hours until the
refrigerator and freezer temperatures are below 48°F (9°C) and
15°F (-9°C), respectively, or until the alarm is turned off. To
turn off the audio alarm and indicator light, see “Master Alarm
Reset.”
■The Cooling ON/OFF touch pad on the control panel shuts
down refrigerator functions such as cooling, lighting, fans and
compressors. To turn the power off completely, use the power
ON/OFF switch located behind the top grille. See “Power On/
Off Switch.”
Viewing the Celsius Temperatures
■Press the F/C touch pad. To redisplay degrees Fahrenheit,
press F/C again.
NOTE: If the freezer temperature is below zero, the negative sign
next to the freezer display will light up. This is normal.
Adjusting Controls
NOTE: Wait at least 24 hours between adjustments. Recheck the
temperatures before other adjustments are made.
To Adjust Set Point Temperatures:
■Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
■Press the Set To Recommended touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The set point range for the freezer is -5°F to 3°F (-21°C
to -16°C). The set point range for the refrigerator is 34°F to
42°F (1°C to 6°C).
CONDITION/REASON: TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold
Not set correctly for conditions
REFRIGERATOR Control
1° higher
REFRIGERATOR too warm
High use or room very warm
REFRIGERATOR Control
1° lower
FREEZER too cold
Not set correctly for conditions
FREEZER Control
1° higher
FREEZER too warm/too little ice
High use or heavy ice use
FREEZER Control
1° lower
Water Filter Indicator and Reset
See “Water Filter Indicator” section.
Max Cool
The Max Cool feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
■Press MAX COOL to turn on the Max Cool feature. The Max
Cool indicator light will remain on for 24 hours unless manually
turned off.
NOTE: The temperature display will remain at 34°F (1°C) and
-5°F (-21°C) for the refrigerator and freezer compartments,
respectively, while the Max Cool feature is enabled. After 24
hours, the refrigerator returns to the previous temperature set
points.
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the
current condition that caused the alarm until a new condition
occurs or until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing Cooling
(ON/ OFF) twice or by turning the power to the refrigerator off and
on again. See “Power On/Off Switch.” After performing a Master
Alarm Reset, the indicator light will reactivate if the condition that
caused the alarm is still present. See “Over Temperature,” “Call
Service,” or “Door Open.”
Door Open
The Door Open indicator light will ash, an alarm will sound
and the interior lights will turn off when a door has been open
for longer than 10 minutes. When the door is closed, the audio
alarm will reset and turn off, but the Door Open indicator light
will continue to ash until the temperature is equal to or below
45°F (7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your
food may spoil. See the “Power Interruptions.” Minimize door
openings until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or
the freezer temperature rises above 15°F (-9°C) for longer than
1¹⁄₂ hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to ash until the Alarm is pressed to let you know that an over
temperature condition has occurred.

8
■Press SABBATH MODE again to turn off Sabbath Mode.
Dispenser Panel Holiday Mode (on some models)
In Holiday Mode, the dispenser levers are disabled and the
dispenser lights turn off.
■To turn on Holiday Mode, press and hold ICE, LIGHT and
LOCKOUT at the same time for 3 seconds. When the feature
turns on, the indicator light around the LOCKOUT button will
blink and “HOL” will appear on the dispenser display.
■To turn Holiday Mode off, press and hold ICE, LIGHT and
LOCKOUT at the same time for 3 seconds again.
NOTE: If the Max Cool feature has been selected prior to
turning on the Holiday Mode feature, then the set points will
remain at 34°F (1°C) and -5°F (-21°C) for the refrigerator and
freezer compartments, respectively, until the Max Cool feature
times out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cool feature, but the lights and ice maker will remain off
until the Holiday Mode is pressed again.
Water and Ice Dispensers
(on some models)
IMPORTANT:
■After connecting the refrigerator to a water source or replacing
the water lter, ush the water system. Use a sturdy container
to depress and hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water begins to
ow. Once water begins to ow, continue depressing and
releasing the dispenser lever (5 seconds on, 5 seconds off)
until a total of 3 gal. (12 L) has been dispensed. This will ush
air from the lter and water dispensing system, and prepare
the water lter for use. Additional ushing may be required in
some households.
NOTES:
■While dispensing water and for 3 seconds after
dispensing has stopped, the digital display will show how
many ounces of water have been dispensed.
■To switch from ounces to cups, press and hold ICE and
LOCK at the same time until the dispenser beeps after 3
seconds. To switch from cups to liters, press and hold the
buttons for another 3 seconds. To switch back to ounces,
repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-avor if you do not use the
dispenser periodically. Dispense enough water every week to
maintain a fresh supply.
Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see “Ice Maker and Storage Bin.”
Your ice maker can produce both crushed and cubed ice. The
display screen reads “CRUSHED” or “CUBED,” indicating which
type is selected. To change the setting, press the ICE button
before dispensing ice.
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When changing from crushed to cubed, a few ounces of crushed
ice will be dispensed along with the rst cubes.
To Dispense Ice:
1. Press the button to select the desired type of ice.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 1¹⁄₂ hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: The audio alarm will be disabled for subsequent
occurrences of over temperature alarm condition. To enable the
audio alarm, see “Master Alarm Reset.”
Sabbath Mode
The Sabbath Mode feature is designed for the traveler or for
those whose religious observances require turning off the lights
and ice maker. By selecting this feature, the temperature set
points and Deli Pan settings remain unchanged, the ice maker
will be disabled and the interior lights will turn off. For most
efcient refrigerator operation, it is recommended to exit the
Sabbath Mode when it is no longer required.
To fully activate Sabbath Mode, you must follow the instructions
below for both the control panel and dispenser panel (on some
models).
IMPORTANT: If you do not activate Sabbath Mode in both ways
listed below, some functions you wish to disable will remain
active.
Control Panel
In Sabbath Mode, the temperature set points remain unchanged
and the interior lights turn off.
■Press SABBATH MODE to turn on Sabbath Mode.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
■Allow 24 hours for the refrigerator to cool down and chill
water.
■Allow 24 hours to produce the rst batch of ice. Discard the
rst three batches of ice produced.
■The dispensing system will not operate when the freezer door
is open.
■Depending on your model, your water and ice dispensers may
have one or more of the following features: a dispenser tray,
a special light that turns on when you use the dispenser, or a
lock option to avoid unintentional dispensing.
Water Dispenser
To Dispense Water:
1. Press a sturdy glass against the water dispenser pad.

9
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING
2. Press a sturdy glass against the ice dispenser pad. Hold
the glass close to the dispenser opening so ice does not fall
outside of the glass.
IMPORTANT: You do not need to apply a lot of pressure to
the pad in order to activate the ice dispenser. Pressing hard
will not make the ice dispense faster or in greater quantities.
3. Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad. The dispenser may
continue to make noise for a few seconds after dispensing.
Dispenser Tray (on some models)
Some models have a tray at the bottom of the dispenser area.
The tray is designed to catch small spills and is removable for
easy emptying and cleaning.
NOTE: There is no drain in the tray.
Dispenser Light (on some models)
When you use the dispenser, the light will automatically turn on.
If you want the light to be on continuously, you may choose either
ON or AUTO.
ON: Press LIGHT to turn the dispenser light on.
AUTO: Press LIGHT a second time to select AUTO mode. The
dispenser light will automatically adjust to become brighter as the
room brightens and dimmer as the room darkens.
OFF: Press LIGHT a third time to turn the dispenser light off.
The dispenser lights are LEDs that cannot be changed. If it
appears that your dispenser lights are not working, be sure
that the light sensor is not blocked (in AUTO mode). See
“Troubleshooting” for more information.
Dispenser Lock (on some models)
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
NOTE: The lock feature does not shut off power to the product,
to the ice maker, or to the dispenser light. It simply deactivates
the ice and water dispensers. To turn off the ice maker, see “Ice
Maker and Storage Bin.”
■Press and hold LOCK for 3 seconds to lock the dispenser.
While the dispenser is locking, “LOCKING” will appear on the
display screen and the blue indicator light around the LOCK
button will ash. When the dispenser is locked, the indicator
light will change to red for a few seconds, and then turn off.
■Press and hold LOCK a second time to unlock the dispenser.
While the dispenser is unlocking, “UNLOCKING” will appear
on the display screen and the red indicator light around the
LOCK button will ash. When the dispenser is unlocked, the
indicator light will change to blue for a few seconds, and then
turn off.
Water Filter Status Light (on some models)
The water lter status light and display screen help you know
when to change your water lter. Press the FILTER button to
check the status of your water lter.
If the filter is new:
You must press FILTER to view the lter’s status. For a few
seconds, the status light will be blue and the display screen will
show what percentage of your lter’s life remains.
If it is almost time to change the filter:
The status light will automatically illuminate and will remain on,
appearing yellow. The words “ORDER FILTER” will appear on
the display screen. Press FILTER to see what percentage of your
lter’s life remains. You should order the appropriate replacement
lter. See “Accessories.”
If it is time to change the filter:
The status light will remain on, changing to red. The words
“REPLACE FILTER” and “HOLD BUTTON TO RESET” will appear
on the display screen until the lter has been changed and the
status light has been reset.
To reset the water filter status light:
After changing the lter, reset the status light by pressing and
holding the FILTER button for 3 seconds. The status light will
blink red and change to blue, and then turn off when the system
is reset.
Ice Maker and Storage Bin
(on some models - Accessory)
IMPORTANT: Flush the water system before turning on the
ice maker. See “Water and Ice Dispensers.” Allow 24 hours to
produce the rst batch of ice. Discard the rst three batches of
ice produced. Allow 3 days to completely ll the ice container.
Style 1
To Turn the Ice Maker On/Off:
The On/Off switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1. To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will ll the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
2. To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position, and listen for the click to make sure
the ice maker will not continue to operate.

10
To Remove and Replace the Ice Bin:
1. Flip up the covering panel.
A
A. Ice maker cover
2. Lift the wire shutoff arm so it clicks into the OFF (up) position.
Ice can still be dispensed, but no more can be made.
3. Lift up the front of the storage bin and pull the ice bin forward.
4. Replace the bin by pushing it in all the way or the dispenser
will not work. Push the wire shutoff arm down to the ON
position to restart ice production. Make sure the door is
closed tightly.
Style 2
To Turn the Ice Maker On/Off:
The On/Off switch is located on the top right side of the freezer
compartment.
1. To turn the ice maker on, slide the control to the ON (left)
position.
NOTE: Your ice maker has an automatic shutoff. The ice
maker sensors will automatically stop ice production, but the
control will remain in the ON (left) position.
2. To manually turn the ice maker off, slide the control to the OFF
(right) position.
To Remove and Replace the Ice Storage Bin:
1. Hold the base of the storage bin with both hands and press
the release button to lift the storage bin up and out.
NOTE: It is not necessary to turn the ice maker control to
the OFF (right) position when removing the storage bin. The
sensor cover (“ipper door”) on the left wall of the freezer
stops the ice maker from producing ice if the door is open or
the storage bin is removed.
2. Replace the storage bin on the door and push down to make
sure it is securely in place.
Clean the Ice Storage Bin
NOTE: It is normal for ice to stick together in the ice bin. Ice may
be dispensed or used more frequently which will break up the ice.
It is recommended that the ice container be emptied and cleaned
as needed.
To clean the ice storage bin:
1. Empty the ice container. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin or bucket. This can cause damage to the ice container
and the dispenser mechanism.
2. Wash ice bin with a mild detergent, rinse well and dry
thoroughly. Do not use harsh or abrasive cleaners or solvents.
Remember
■Allow 24 hours to produce the rst batch of ice. Allow 3 days
to completely ll ice container.
■Discard the rst three batches of ice produced to avoid
impurities that may be ushed out of the system.
■The quality of your ice will be only as good as the quality of
the water supplied to your ice maker.
■Avoid connecting the ice maker to a softened water supply.
■Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
■It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
■For Style 1 ice maker, do not force the wire shutoff arm up or
down.
■Do not store anything on top of the ice maker or in the ice
storage bin/bucket.
Water Filtration System
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
Water Filter Indicator (on some models)
The water lter indicator, located on the control panel, will help
you know when to change the water lter.
A new water lter should display a reading of 99%. The reading
in the display will decrease as the lter life is used. A replacement
water lter should be ordered when “Order Filter” is displayed. It
is recommended that you replace the lter when “Change Filter”
is displayed or when water ow to your water dispenser and/or
ice maker decreases noticeably. See “Changing the Water Filter”
later in this section.
NOTE: Dispenser models have a lter reset on the freezer
compartment door. Non-Dispenser models have a Good/Order
Filter/Replace Filter indicator.
After changing the water lter, press and hold RESET for
2 seconds until the status display changes to 99%.
