Jensen Marine MWR150 User manual

1
INTRODUCTION
Thank you for choosing a Jensen product. The MWR150
Marine Wired Remote Control allows you to control basic
funcons of most Jensen Marine MS series radios, including
power, mode, volume, tuning and CD, iPod and satellite radio
operaon.
FEATURES
• Compable with JENSEN Marine MS Series radios with
remote control capability ONLY
• Waterproof design (IPX6 Rated)
• Conformal Coated circuit boards
• White LED backlit controls and LCD
• Full funcon sunlight readable display (posive type LCD)
• UV resistant nish (meets ASTMD4329 standards) resists
yellowing in sunlight
• Corrosion resistant materials (meets ASTMB117)
• Panel mount with removable trim ring
• 20 . extension cable included
• FCC/CE cered
INSTALLATION
1. Choose a mounng locaon on the instrument panel
that will allow enough room behind the panel to run the
wired remote cables to the exisng radio.
2. Cut a hole in the instrument panel using the supplied
template (See “Mounng Template” on page 2). At least
1” depth is needed to mount the remote control.
IMPORTANT! Do not mount unit where it can be
submerged.
3. Insert the remote control into the hole and then secure
with two #6 Pan Head Screws, at least 3/4” long,
illustrated in Figure A.
WIRING
Once the remote has been mounted, route the cable from
the remote and connect the cable to the radio. Note the
connector polarity on the extension cable. The 18 foot
extension cable may be used to connect the remote to the
radio. Up to two addional extension cables (MWREXT) may
be purchased and used to extend the reach of the remote up
to 54 feet.
IMPORTANT! When connecng the cables, be sure to
route the extension cable away from sharp objects,
corners, and places where it might get pinched, as this
could aect performance and cause damage to the unit.
Up to two more remote controls can be added with a “Y”
cable adapter (MWRYCBLS).
#6 Pan Head Screw
3/4” Min. Length
Trim ring
Figure A - Installation
MWR150 Wired
Remote Installaon
and Operaon
Instrucons

2
OPERATION
AM/FM Tuner CD MP3 Playback
Mode
iPod Satellite Radio
Control Acon Default Mode Mode Main Mode Main Mode Main Mode
POWER Press Power On/O Power On/O Power On/O Power On/O Power On/O
MODE Press Select Next Mode Select Next Mode Select Next Mode Select Next Mode Select Next Mode
BAND Press Preset Band Change --- --- --- Preset Band Change
VOL /\ UP Press Volume Increase Volume Increase Volume Increase Volume Increase Volume Increase
VOL \/ DN Press Volume Decrease Volume Decrease Volume Decrease Volume Decrease Volume Decrease
INFO Press Clock Display Toggle --- Display/ Toggle Arst/
Song/Etc.
Display/ Toggle Arst/
Song/Etc.
Display/ Toggle Arst/
Song/Etc.
>/||
MUTE
Press Mute Pause Pause Pause Mute
<< Press Tune Down Track Down Track Down Song Down Channel Down
Hold Tune Seek Down Rewind Rewind Rewind ---
>> Press Tune Up Track Up Track Up Song Up Channel Up
Hold Tune Seek Up Fast Forward Fast Forward Fast Forward ---
iPhone, iPod nano and iPod touch are trademarks of Apple Inc. registered in U.S.A. and other countries. “Made for iPod” and “Made
for iPhone” mean that an electronic accessory has been designed to connect specically to iPod or iPhone, respecvely, and has
been cered by the developer to meet Apple performance standards. Apple is not responsible for the operaon of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may aect wireless
performance.
MOUNTING TEMPLATE
www.asaelectronics.com
