jeri V4 User manual

Portable Power Station (PPS)
User Manual
Wh
403
V4
Wh
622
V6
Wh
1036
V10

Do not operate or store the jeri portable power station (jeri
PPS) in a wet environment such as rain, snow, high humidity
location or any place that could cause water ingress.
Do not clean the jeri PPS with direct water, wet towel, or
harsh chemicals.
Do not operate or store the jeri PPS close to a heat source
such as open flames, stoves or other devices, which can
produce heat.
Do not cover or wrap the jeri PPS while operating. Use the
product in a ventilated space.
Do not expose the product to mechanical shocks, such as
dropping, crushing, or puncturing the unit.
Do not disassemble or repair the jeri PPS by any
unauthorised person or organisation. Incorrect
disassembling may cause electrical jolts, electrocution,
explosion, or fire. Any damage caused by such unauthorised
action is not under warranty protection.
Do not insert foreign objects through the output ports, input
ports or ventilation holes.
Keep the device out of reach of children. If being used by
children, an adult must supervise the application.
Keep the product sitting at a stable horizontal position if it
is not operating or stored on the ground. Be mindful that
children and adults could get injured if the unit drops onto
the human body from a certain height.
Keep the unit dry and clean, especially for the charge and
discharge ports. Use a dry cloth to clean the units if needed.
Connect and operate the device according to the manual.
Misusing or incorrect connections to the jeri PPS may cause
electrical shock or damage to itself and other devices.
Your jeri PPS might become warm during its operation. It is
not advisable to use the product under direct sunlight when
it is over 40 degrees Celsius.
In the unlikely event of leakage or explosion, sand or a
chemical fire distinguisher could be used.
It is suggested to recycle or dispose of the jeri PPS, a battery
product, according to the local guidelines.
It is advisable only to use electrical loads at or below the
rated power of each output port. Loads beyond the rated
power will not operate due to safety functions built within.
IMPORTANT
SAFETY
INSTRUCTIONS
Read all instructions before
use of product to avoid
personal injury and property
damage.

3
User Manual / V2.0
- Portable Power Station (PPS) -
Index
Items Included
Product Information
The First Charge
Charging Methods
How to Use Your jeri
Storage and Optimal jeri PPS Care
Specifications
Troubleshooting
Warranty and Registration of Your jeri PPS
FAQ
4
5
5
6 - 7
8
9
10
11
12 - 15
16 - 18
Safety Signal – Activate SOS (Light)
Double-click the LED light ON/OFF Button to turn on the SOS light mode.
Press once more to turn off the SOS light mode.

- Portable Power Station (PPS) -
4User Manual / V2.0
Items Included
jeri - Portable Power Station V4
AC Power Adapter Car Charging Cable
User Manual
User Manual
V4
jeri - Portable Power Station V6
AC Power Adapter Car Charging Cable
User Manual
User Manual
V6
jeri - Portable Power Station V10
AC Power Adapter Car Charging Cable
User Manual
User Manual
V10

5
User Manual / V2.0
- Portable Power Station (PPS) -
Product Information
1. Input Power LED
2. DC Input Port
3. DC Output Ports ON/OFF Button
4. 12V DC Output Car Port
5. 12V DC 5525 Output Ports
6. Collapsible Handle
7. LCD Screen ON/OFF Button
8. LCD Screen
9. USB Output ON/OFF Button
10. USB-C PD Input/Output Port
11. USB A Output Ports
12. AC Output Ports ON/OFF Button
13. 230V AC Output Ports
14. LED light ON/OFF Button
15. LED Light
The First Charge
Note:
jeri V4 and V10 products will look different, but the buttons and functions are the same.
Ensure that your jeri PPS has been fully charged before using it for the first time.
Note (Charging):
When being charged, the battery sign on the LCD will flash, indicating the input power. When fully
charged, the battery sign on the LCD will show four solid green lines, and the battery state of charge
percentage will display 100%. The charger can then be removed as your jeri PPS is now fully charged.
67
8
91
2
3
4
5
10
11
12
13
14
15

- Portable Power Station (PPS) -
6User Manual / V2.0
Charging Methods
The jeri PPS can be charged through the following four methods.
AC Power Adapter
Connect the jeri PPS with an AC socket through the AC charging
adapter, as in the picture above.
Connect the jeri PPS to the 12V output in the car through the car
charging cable, as in the picture above.
Car Charger
Connect the jeri PPS to the USB-C PD port with a power source
through a USB-C cable. Charging can start in both ON and OFF
state of the USB button, as the USB-C PD port is always on and is
not governed by the USB button.
Note:
A USB-C cable is not included in this package as an accessory.
USB-C Cable
*A USB-C cable is required.

7
User Manual / V2.0
- Portable Power Station (PPS) -
Solar Panel
*Optional accessory
Connect the jeri PPS to the jeri portable solar panel, an optional
accessory (see jeri website), using the charging cable from the jeri
solar panel, as in the picture above.
Fast Charge
You can hybrid charge your jeri PPS by using a combination of charging ports to boost the input power
to your jeri PPS.
Please see the hybrid charging methods below,
• USB-C + AC power adapter
• USB-C + Car charger
• USB-C + Solar panel

- Portable Power Station (PPS) -
8User Manual / V2.0
How to Use Your jeri
The jeri PPS can be used to power up a variety of electrical appliances through its DC and AC output
ports. It will start to power up your device after depressing the ON/OFF button to an ON state, as
shown in the pictures below. By doing so, the button will be backlit. It is advisable to keep your jeri PPS
connected to a power source when not in use. During all stages of charging, your jeri PPS can be used
to power your freedom.
DC and AC Output
AC Port Output USB Port Output Car Port Output
Notes:
The jeri PPS has a default 3-hour sleep timer that is designed to conserve power when no output is connected. It will
turn off automatically if no output is connected for three hours.
The input and output of the USB-C are not controlled by the USB button. The USB-C port can work in both ON and
OFF state of the USB button.
AC Button USB Button DC Button
Press the LED light ON/OFF Button once, twice, or thrice to adjust the brightness from 20%, 50% to
100%. Press the LED light ON/OFF Button for the fourth time to turn off the LED light.
LED Light

9
User Manual / V2.0
- Portable Power Station (PPS) -
Storage and Optimal jeri PPS Care
Connect your jeri PPS to a power source when not in use. It will prolong the battery life and ensure the
power station is always in standby mode. Store it in a cool and dry environment and avoid any place
close to an open flame.
For Daily Use and Short Trips
Charging your jeri PPS every three months will ensure that the battery life of the PPS remains in
optimal condition. Please note that keeping the PPS’s battery at a low or empty level for an extended
period will most likely cause permanent damage to the battery life and its peak capacity.
For Best Care of Your jeri PPS

- Portable Power Station (PPS) -
10 User Manual / V2.0
Specifications
Product Name V4 V6 V10
Model No. JER-400-PP-A1 JER-600-PP-A1 JER-1000-PP-A1
Capacity 403Wh 622Wh 1036Wh
Input Ports
DC5525 1*120W 12~24V 1*120W 12~24V 1*180W 12~24V
USB-C PD 1*100W 1*100W 1*100W
Output Ports
Car Port 1*13.3V 10A 1*13.3V 10A 1*13.3V 10A
DC 5525 2*13.3V 10A 2*13.3V 10A 2*13.3V 10A
USB-A 3*5V 2.4A 3*5V 2.4A 3*5V 2.4A
USB-C PD 1*100W 1*100W 1*100W
AC Output 2*230V 400W 2*230V 600W 3*230V 1000W
Protection
Over Voltage Protection
Overload Protection
Over Temperature Protection
Short Circuit Protection
Low Temperature Protection
Low Voltage Protection
Overcurrent Protection
Basic Info
Weight 4.8kg 6.8kg 11.2kg
Dimensions 244.5*188*200mm 290*210*205mm 377.5*232*230mm
LED light 3W (Max) 3W (Max) 3W (Max)
Certification FCC, UL2743, UN38.3,
PSE, RCM
FCC, UL2743, UN38.3,
PSE, RCM
FCC, UL2743, UN38.3,
PSE, RCM
Warranty 12 months 12 months 12 months
Charge
AC port 4.5 Hours 7 Hours 6 Hours
USB-C PD 4 Hours 6.5 Hours 10.5 Hours
Car Port 3.5 Hours 5.5 Hours 8.5 Hours
Solar Panel (120W) *14~8 Hours 6~10 Hours 9~13 Hours
Dischagre
DC
Output
Car Fridge (60W) 6 Hours 9 Hours 15 Hours
Drone (50Wh) 7 Recharges 11 Recharges 19 Recharges
AC
Output
32-inch TV (40W) 9 Hours 14 Hours 24 Hours
Laptop (62Wh) 6 Recharges 9 Recharges 15 Recharges
USB A
Output
Smartphone (4352mAh) 22 Recharges 35 Recharges 55 Recharges
DSLR Camera (1600mAh) 26 Recharges 40 Recharges 67 Recharges
USB C
Output
Smartphone (3227mAh) 30 Recharges 48 Recharges 80 Recharges
Laptop (49.9Wh) 7 Recharges 12 Recharges 19 Recharges
The charging time may vary depending on the weather. Charging time might be longer on cloudy or rainy days.*1

11
User Manual / V2.0
- Portable Power Station (PPS) -
Troubleshooting
Check if the charging cable is connected properly to the jeri PPS and if the power source is
connected correctly to the original power source switch and switched to the ON state.
An alternative charging method may help verify whether the problem is from the charging cable or
is with the jeri PPS. For example, if you are using an AC adapter to charge your jeri PPS and the PPS
does not charge, try using a USB-C cable to charge the jeri PPS via the USB-C PD port to test
whether the PPS can be charged.
Refer to the table below if you encounter an error code on the LCD.
Charging issue with the jeri (Input)
Check if the cable is connected correctly.
Ensure that the corresponding ON/OFF button is in the ON state.
Check if the jeri PPS still has power. If not, please charge your jeri. You can still use it while charging.
Check if the power rating of the connected device is higher than the rated output of the jeri PPS.
If yes, the jeri PPS is unable to power up the device.
jeri power (Output)
Error Codes
Input Overvoltage Protection:
The symbol will flash for 5 seconds when
an input overvoltage condition is
detected. In this situation, please
disconnect all cables. Reconnect them
when the jeri PPS returns to normal
operating conditions.
Low Power Alarm:
The symbol will flash when the jeri PSS
battery charge is less than 3%. In this
situation, please connect the jeri PPS to a
power source immediately. Doing so will
help preserve the battery life.
Low Temperature Alarm:
The low-temperature symbol will be
displayed if the jeri PPS is used outside its
allowable operating temperature. Please
only use your jeri PPS within its operating
temperature range.
(Please refer to page 10).
Output Overload Protection: The symbol will flash for 5 seconds when an AC output overload
condition is detected. In this situation, please disconnect all cables and reduce the number of devices
connected to your jeri PPS.
High Temperature Alarm:
This high-temperature symbol will be
displayed if the jeri PPS is used outside
its allowable operating temperature.
Please only use your jeri PPS within the
specified operating temperature range.
Please contact our technical team via the below email if you are experiencing an issue with your jeri PPS.
E: [e-mail] | T: [phone] (Menu > Service)

- Portable Power Station (PPS) -
12 User Manual / V2.0
Warranty and Registration of Your jeri PPS
Our goods come with guarantees under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
The benefits provided by the warranty are in addition to any other rights and remedies you may have
under laws relating to the goods or services to which the warranty applies.
12-Month Limited Product Warranty
Warranty Registration and Terms and Conditions
Congratulations on choosing the jeri PPS. To ensure that you get the best performance from your
purchase, please read the following warranty terms and conditions, complete the registration form and
keep it for your records.
Alternatively, please go to www.clenergy.com.au/solution-centre/service-centre/ to create your
profile and attach purchase details to your account.
If any problems arise, please contact the company or outlet from which you purchased your product.
Please retain a copy of the warranty registration form and proof of payment for any future warranty
claims.

13
User Manual / V2.0
- Portable Power Station (PPS) -
Your Details
Name
Street Address
Suburb
Post Code
State
Contact Number
Email
Serial Number
Retailer’s Details
Name
Street Address
Suburb
Post Code
State
Contact Number
Email
*You will find your jeri PPS serial number on the right bottom side of your PPS under the product sticker.

- Portable Power Station (PPS) -
14 User Manual / V2.0
Clenergy warrants to the original purchaser (“Purchaser”) of the product(s) that the product will be
free from defects in material and workmanship for a period of twelve (12) months from the date of
purchase.
Clenergy will replace or repair the product during the warranty period
subject to the following conditions:
The product does not perform in accordance with its design specifications.
The product fails during the warranty period while being used correctly as per the user manual.
During the warranty period, Clenergy will replace the faulty product if it is deemed the most
appropriate course of action.
Any repair or replacement costs outside the warranty period are the responsibility of the
Customer.
Clenergy holds stock in Australia expressly for the purpose of warranty repairs or replacements.
If there are any questions or concerns regarding the conditions of this warranty, please write or
email us at the address below.
The warranty does not apply if:
The warranty period has expired.
Damage is caused by incorrect use, including dropping or placement in water or exposure to
excessive precipitation.
The product has been altered or damaged.
The product has been repaired or altered by a non-accredited or unauthorised person.
Found to have unauthorised modifications.
If you believe there is a defect with the product, you should follow the process to make a claim as
below. If you are out of warranty, contact Clenergy directly for assistance. Contact details are as below.
Review the paperwork provided by your retailer originally. It should indicate whether you are still
covered by warranty and who to contact in case of a defect.
Once you have identified the retailer who supplied the product, you should contact them directly.
The retailer will arrange for an inspection of the unit to determine whether the product should be
returned to Clenergy for an assessment.
How to make a warranty claim

15
User Manual / V2.0
- Portable Power Station (PPS) -
If you are unsure how to make a claim, are out of the warranty period or don’t know from whom you
purchased your Clenergy product, you can contact us at Clenergy Australia for support. Contact details
are as below.
Enquiries can be made by phone, letter, email or website portal as below.
Note:
If you wish to make a warranty claim through the website portal, please register an online account with
Clenergy Australia. Once you have registered an account, you can then submit, manage and view your
warranty claim from the account.
Phone: [phone]
Email: [e-mail]
www.clenergy.com.au/solution-centre/service-centre/

- Portable Power Station (PPS) -
16 User Manual / V2.0
FAQ
Where is the serial number location of my jeri PPS?
You will find your jeri PPS serial number on the right bottom side of your PPS under the product
sticker.
What type of battery does my jeri PPS V series use?
The jeri PPS V series uses a high-quality lithium-ion battery.
How do I turn on or turn off a power port (AC, USB or CIG / 525)?
1. To turn on a power port, depress the green button above the desired port.
2. By doing so, the port will be backlit, indicating that the port is on.
3. To turn off the port, depress the green button above the desired port.
4. By doing so, the port’s backlight will turn off, indicating that the port is now turned off.
What loads can be powered via the AC outlet (power socket) and total
summary of ports on my jeri PPS?
The rated power of the AC output port of the jeri PPS is as follows:
1. V10: 1000W, V6: 600W and V4: 400W (as shown on the technical specifications page).
2. It is essential to verify the power requirements of the device before attempting to operate it via
the jeri PPS.
3. It is essential to ensure that the load of any particular device or the sum of the total loads of all
devices plugged into your jeri’s outlets (AC, USB-C PD, USB-A, 12V and 525 jacks) is less than
the total rated power (e.g V10, 1000w) of the jeri PPS model that you desire to power your
devices from.

17
User Manual / V2.0
- Portable Power Station (PPS) -
How long can my jeri PPS power the products I wish to power?
It depends on the sum of all the products plugged into your jeri PPS. When all products are
plugged into the jeri PPS, and the ports are turned on,
1. The right side of the LCD screen on your jeri PPS will display the power draw of all devices
connected to the jeri PPS. The number displayed represents the total watts being drawn by all
devices.
2. If the total number of watts being used to power your products is 100 watts, your jeri PPS is
fully charged and it is a jeri V4 with 403 watt hours of storage capacity, you will be able to
power your products for up to 4 hours (this may vary depending on the environmental
temperature).
How do I clean my jeri PPS?
It is recommended to wipe down your jeri PPS with a dry, soft, clean cloth or paper towel.
How do I know if my jeri PPS is on charge?
When power is inputted to charge your jeri PPS from the AC/DC power brick, the USB-C PD port,
the 12V CIG adaptor or via a jeri solar panel, the left side of the LCD will illuminate, indicating the
total power inputted to charge your jeri PPS.
How do I store my jeri PPS?
1. Before storing the product, it is essential that all outlets are turned off.
2. Store your jeri PPS in a dry and well-ventilated area that is at room temperature.
3. Do not store your jeri PPS near water sources (e.g under a cupboard where there is a sink, water
pipe or any water source that may leak and damage your jeri PPS).
4. For long-term storage, it is recommended to discharge the battery to 70% of its capacity. It is
also recommended to remove your jeri from storage every three months and top up the charge
to 70%. Doing so helps prevent battery degradation and prolongs the life of the battery.

- Portable Power Station (PPS) -
18 User Manual / V2.0
Can my jeri PPS be checked in as luggage or carried on as hand luggage
onboard a plane?
jeri PPS cannot be checked in as luggage or carried on as hand luggage onboard any commercial
or non-commercial aircraft.
Do I need to turn on the USB port when I am charging a product via the
USB-C PD port?
1. Turning on the USB port will not turn on the USB-C PD port, as the USB-C port is always on.
2. This port is bi-directional, which means that it will both charge your jeri PPS and discharge
it.
Occasionally I have difficulty plugging my device into the AC port (GPO)
on my jeri PPS. What do I do?
If you can’t plug your device into an AC port (GPO) on your jeri PPS easily, it is advisable to adjust
the prongs on the plug end slightly, as the power requirements of devices vary, as do the plug
ends of devices. This adjustment will help you plug in your device smoothly and avoid damage to
the AC board, which can occur if the plug end is forced into the AC port.
My jeri PPS is drawing power from my laptop instead of charging it
when using the USB-C PD port. Why?
a) As the USB-C PD port is bi-directional, it is possible for the jeri PPS to draw power from your
device. If this occurs, it is recommended that you remove the USB-C cable from the port
immediately.
b) Wait for 10 seconds before reconnecting the USB-C cable to the USB-C PD port to resume
charging your device.
c) If the charge is still being drained from your device, repeat the process of removing the USB-C
cable from the jeri PPS USBC-PD port, and reconnecting it to your jeri PPS. The process
may take a few attempts to allow the power to flow in the direction of your product from your
jeri PPS.

19
User Manual / V2.0
- Portable Power Station (PPS) -
Enquiries can be made by phone, letter, email or website portal as below.
Phone: [phone]
Email: [e-mail]
www.clenergy.com.au/solution-centre/service-centre/
Note:
If you wish to make a warranty claim through the website portal, please register an online account with
Clenergy Australia. Once you have registered an account, you can then submit, manage and view your
warranty claim from the account.
Notes:
What can I do if my jeri PPS shuts down or performs erratically?
If your jeri PPS shuts down or performs erratically at any time, a system reset can help to solve this
issue generally. To reset, depress the button above the screen for 20 seconds. Release the button.
The jeri PSS will turn black and reconfigure. It will be ready to operate once the screen turns bright.
If the issue persists, please contact us for help.

Global Contact Numbers
CN: [phone] | AU: [phone] | JP: [phone]
DE: [phone] | TH: [phone] | PH: [phone]
Global Partners
UK: [phone]
A Clenergy Technologies Company
1/10 Duerdin St Clayton VIC 3168 Australia
MADE IN CHINA | DESIGNED IN AUSTRALIA
@ClenergyClub / @ClenergyAus @Clenergy @Clenergy_global
@jeri.clenergy @jeri.clenergy @jeri.clenergy
Power Your Freedom
W: www.jerifreedom.com.au E: [e-mail]
