jeri JER-120-SP-AG User manual

SolarPortable Panel
U
se
r
Manual
r
W
120
JER-120-SP-A
Power Your Freedom
www.jerifreedom.com.au
G

3
User Manual / V1.0
- -
I
MP
O
R
T
AN
T
T
T
S
AFETY
IN
S
T
R
U
C
T
I
O
N
S
Read all instructions
before using this product
to avoid personal injury
and property damage.
Do not bend the solar panel.
Do not immerse the solar panel into water or any other liquid.
Do not use or store your jeri solar panel near fire or heater.
Do not scratch the solar panel with sharp objects.
Do not step or place heavy objects on your jeri solar panel.
Do not put corrosive substance on your jeri solar panel.
Do not drop your jeri solar panel from heights or expose it to
physical impact.
The output of the solar panel must be correctly connected to
the equipment.
For safety purpose, check the status of each component,
including cables, wires and plugs before connection.
To maximize the output power from your jeri portable solar
panel, use it at a place where can face direct sunlight and
away from shadows.
Note:
While charging your jeri portable power station through
the portable solar panel, please keep the portable power station
away from heat or direct sunlight to extend its life span.
Do not allow the disassembling of the solar panel by
unauthorised individuals or repair centres.
Items Included 4
Product Information 5 - 6
Specifications 6
FAQ 7
Warranty and Registration 8 - 11
Index

3
User Manual / V1.0
- -
I
MP
O
R
T
AN
T
T
T
S
AFETY
IN
S
T
R
U
C
T
I
O
N
S
Read all instructions
before using this product
to avoid personal injury
and property damage.
Do not bend the solar panel.
Do not immerse the solar panel into water or any other liquid.
Do not use or store your jeri solar panel near fire or heater.
Do not scratch the solar panel with sharp objects.
Do not step or place heavy objects on your jeri solar panel.
Do not put corrosive substance on your jeri solar panel.
Do not drop your jeri solar panel from heights or expose it to
physical impact.
The output of the solar panel must be correctly connected to
the equipment.
For safety purpose, check the status of each component,
including cables, wires and plugs before connection.
To maximize the output power from your jeri portable solar
panel, use it at a place where can face direct sunlight and
away from shadows.
Note:
While charging your jeri portable power station through
the portable solar panel, please keep the portable power station
away from heat or direct sunlight to extend its life span.
Do not allow the disassembling of the solar panel by
unauthorised individuals or repair centres.
Items Included 4
Product Information 5 - 6
Specifications 6
FAQ 7
Warranty and Registration 8 - 11
Index

- -
4User Manual / V1.0
5
User Manual / V1.0
Items Included
Portable Solar Panel JER-120-SP-AG
How to Use Your jeri Portable Solar Panel
User ManualSolarPanel
MC4 to 5525 Plug cable
U
se
r
Manual
r
Unbuckle the
portable solar panel.
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Unfold the portable
solar panel.
Two adjustable
angles available for
support legs.
Step 1
Step 2
Step 3
53°C
48°C

- -
4User Manual / V1.0
5
User Manual / V1.0
Items Included
Portable Solar Panel JER-120-SP-AG
How to Use Your jeri Portable Solar Panel
User ManualSolarPanel
MC4 to 5525 Plug cable
U
se
r
Manual
r
Unbuckle the
portable solar panel.
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Unfold the portable
solar panel.
Two adjustable
angles available for
support legs.
Step 1
Step 2
Step 3
53°C
48°C

- -
6User Manual / V1.0
7
User Manual / V1.0
How to Use Your jeri Portable Solar Panel
FAQ
Model JER-120-SP-AG
Cell Type Monocrystalline Silicon
Solar Cell Efficiency 22%
Rated Power 120W
Open Circuit Voltage 21.85V
Short Circuit Current 6.67A
Operation Temperature -10°C ~ 65°C
Folding Number 4
Dimension (unfolded) 493 * 1486 * 25mm
Dimension (folded) 493 * 364 * 54mm
Weight 4.63 kg
Warranty 12 Month
Certification PSE, RCM
Does the charging speed of jeri portable solar panel vary?
jeri portable solar panel charging speeds could vary with different operating and environmental
conditions as below:
Weather: Solar panel could have lower outputs in a cold, cloudy, and rainy environment.
Can the solar panel be used in any weather?
Would that be an issue if my solar panel get a bit wet?
How to clean the panel surface?
Specifications
Use the MC4 to 5525
Plug cable to
connect the MC4
plug from the portable
solar panel and the DC
input from the portable
power station.
Positioning: Solar panel could have lower outputs when they are not directly facing the sun.
Obstructions: Solar panel could have lower outputs when placed under shade, behind other
objects, or behind a window.
Dirts: Solar panel could have lower outputs when dust, dirt or guano is covering the surface.
Physical damage: Solar panel could have lower output when the panel is damaged due to
external pressure, scratch, or mechanical shocks.
No, please use the solar panels in stable weather conditions. The optimal temperature range for
normal use and storage of solar panels is -4°F to 149°F (-20°C to 65°C).
Warning:
DO NOT use solar panels during severe weather conditions, such as thunderstorms, strong winds,
and hailstorms.
No, but to maximize the lifespan of the solar panel, please avoid getting it wet. You can use it again
when it is fully dried.
Dust and dirt on the surface should be removed by using a soft brush. The remaining dust or dirt
could be wipe by a damp cloth . If there is any guano or other adhesive on the panel, it should be
removed as soon as possible from the surface to avoid a reduction in performance.
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Step 4
*Rated Power is tested under Standard Test Conditions: 1000W/m2, AM1.5, 25°C.

- -
6User Manual / V1.0
7
User Manual / V1.0
How to Use Your jeri Portable Solar Panel
FAQ
Model JER-120-SP-AG
Cell Type Monocrystalline Silicon
Solar Cell Efficiency 22%
Rated Power 120W
Open Circuit Voltage 21.85V
Short Circuit Current 6.67A
Operation Temperature -10°C ~ 65°C
Folding Number 4
Dimension (unfolded) 493 * 1486 * 25mm
Dimension (folded) 493 * 364 * 54mm
Weight 4.63 kg
Warranty 12 Month
Certification PSE, RCM
Does the charging speed of jeri portable solar panel vary?
jeri portable solar panel charging speeds could vary with different operating and environmental
conditions as below:
Weather: Solar panel could have lower outputs in a cold, cloudy, and rainy environment.
Can the solar panel be used in any weather?
Would that be an issue if my solar panel get a bit wet?
How to clean the panel surface?
Specifications
Use the MC4 to 5525
Plug cable to
connect the MC4
plug from the portable
solar panel and the DC
input from the portable
power station.
Positioning: Solar panel could have lower outputs when they are not directly facing the sun.
Obstructions: Solar panel could have lower outputs when placed under shade, behind other
objects, or behind a window.
Dirts: Solar panel could have lower outputs when dust, dirt or guano is covering the surface.
Physical damage: Solar panel could have lower output when the panel is damaged due to
external pressure, scratch, or mechanical shocks.
No, please use the solar panels in stable weather conditions. The optimal temperature range for
normal use and storage of solar panels is -4°F to 149°F (-20°C to 65°C).
Warning:
DO NOT use solar panels during severe weather conditions, such as thunderstorms, strong winds,
and hailstorms.
No, but to maximize the lifespan of the solar panel, please avoid getting it wet. You can use it again
when it is fully dried.
Dust and dirt on the surface should be removed by using a soft brush. The remaining dust or dirt
could be wipe by a damp cloth . If there is any guano or other adhesive on the panel, it should be
removed as soon as possible from the surface to avoid a reduction in performance.
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Step 4
*Rated Power is tested under Standard Test Conditions: 1000W/m2, AM1.5, 25°C.

- -
8User Manual / V1.0
Warranty and Registration of Your jeri 120W Portable Solar Panel
jeri 120W Portable Solar Panel
Our goods come with guarantees under the Australian Consumer Law. You are entitled to a replace
-
ment or refund for a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
The benefits given by this warranty are separate to any other rights and remedies you may have under
laws in relation to the goods or services to which this warranty relates.
12 Months Limited Product Warranty
Warranty Registration and Terms and Conditions
Congratulations on choosing your jeri by Clenergy. To ensure that you get the best performance from
your purchase please read the following warranty terms and conditions, complete the registration form
and keep it for your records.
Alternatively, Please go to www.clenergy.com.au/solution-centre/service-centre/ and create your
profile and attach purchase details to your account.
If any problems arise, please contact the company or outlet you purchased your product from.
Please retain a copy of the warranty registration form and proof of payment for any future warranty
claim.

9
User Manual / V1.0
- -
jeri 120W Portable Solar Panel
Your Details
Name
Street Address
Suburb
Post Code
State
Contact Number
Email
Retailer’s Details
Name
Street Address
Suburb
Post Code
State
Contact Number
Email
Note:

- -
10 User Manual / V1.0
11
User Manual / V1.0
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Clenergy warrants to the original purchaser (“Purchaser”) of product(s) that the Product shall be free
from defects in material and workmanship for a period of twelve (12) months from the date of
purchase.
Clenergy will replace or repair the product during the warranty period and
subject to the following conditions:
The product does not perform in accordance with its design specifications.
The product fails during the warranty period as long as it is used correctly as per the user manual.
During the warranty period, Clenergy will replace the faulty product if this is considered to be the
most appropriate course of action.
Any and all costs for repair or replacement outside the warranty period are the responsibility of the
Customer.
Clenergyholds stock in Australia expressly for the purpose of warranty repairs or replacements.
If there are any questions or concerns regarding the conditions of this warranty, please write or
email us at the address below.
The warranty does not apply if:
The warranty period is expired.
Damage is caused by incorrect use including dropping or placement in water or exposure to
excessive precipitation.
The product has been altered or damaged.
The product has been repaired or altered by non-accredited or unauthorised person.
Found to have unauthorised modifications.
If the product is suspected of having a defect that needs to be attended to, you should follow the
process to make a claim as laid out below, if you are out of warranty, please contact Clenergy directly
for assistance the contact details are the same regardless:
From the paperwork that was originally provided by your retailer, you will be able to determine if you
are still covered by warranty and who to contact in case of a defect to the product.
Once you have identified who supplied the product you should contact them directly and they will
arrange for an inspection of the unit and whether the product should be returned to Clenergy for an
assessment.
How to make a warranty claim
If however you are unsure how to make a claim, or are out of the Warranty period or don’t know who
you purchased your Clenergy product through, then you can contact us at Clenergy Australia for sup-
port as detailed below.
Enquiries can be made by phone, letter, email or website portal as below.
Note:
To claim through website portal, please register an online account and then you can submit, manage
and view your claim from the account.
Phone: [phone]
Email: [e-mail]
www.clenergy.com.au/solution-centre/service-centre/

- -
10 User Manual / V1.0
11
User Manual / V1.0
jeri 120W Portable Solar Panel
- -
jeri 120W Portable Solar Panel
Clenergy warrants to the original purchaser (“Purchaser”) of product(s) that the Product shall be free
from defects in material and workmanship for a period of twelve (12) months from the date of
purchase.
Clenergy will replace or repair the product during the warranty period and
subject to the following conditions:
The product does not perform in accordance with its design specifications.
The product fails during the warranty period as long as it is used correctly as per the user manual.
During the warranty period, Clenergy will replace the faulty product if this is considered to be the
most appropriate course of action.
Any and all costs for repair or replacement outside the warranty period are the responsibility of the
Customer.
Clenergyholds stock in Australia expressly for the purpose of warranty repairs or replacements.
If there are any questions or concerns regarding the conditions of this warranty, please write or
email us at the address below.
The warranty does not apply if:
The warranty period is expired.
Damage is caused by incorrect use including dropping or placement in water or exposure to
excessive precipitation.
The product has been altered or damaged.
The product has been repaired or altered by non-accredited or unauthorised person.
Found to have unauthorised modifications.
If the product is suspected of having a defect that needs to be attended to, you should follow the
process to make a claim as laid out below, if you are out of warranty, please contact Clenergy directly
for assistance the contact details are the same regardless:
From the paperwork that was originally provided by your retailer, you will be able to determine if you
are still covered by warranty and who to contact in case of a defect to the product.
Once you have identified who supplied the product you should contact them directly and they will
arrange for an inspection of the unit and whether the product should be returned to Clenergy for an
assessment.
How to make a warranty claim
If however you are unsure how to make a claim, or are out of the Warranty period or don’t know who
you purchased your Clenergy product through, then you can contact us at Clenergy Australia for sup-
port as detailed below.
Enquiries can be made by phone, letter, email or website portal as below.
Note:
To claim through website portal, please register an online account and then you can submit, manage
and view your claim from the account.
Phone: [phone]
Email: [e-mail]
www.clenergy.com.au/solution-centre/service-centre/

Global Contact Numbers
CN: [phone] | AU: [phone] | JP: [phone]
DE: [phone] | TH: [phone] | PH: [phone]
0
Global Partners
UK: [phone]
A
Clenergy Technolog
i
es Company
1/10 Duerdin St Clayton VIC 3168 Australia
MADE IN CHINA | DESIGNED IN AUSTRALIA
@ClenergyClub / @ClenergyAus @Clenergy@ Clenergy_global
@jeri.clenergy @jeri.clenergy @jeri.clenergy
W: www.jerifreedom.com.au E: [e-mail]
Power Your Freedom
