JetChill Mini User manual

Quick Start Guide
Version M1.0

SPECIFICATIONS:
Operation: Manual
Material: Delrin Body, Steel Cover, Steel/Brass/Aluminium internal components
Size: 20cm x 15 x 5 (8" x 6" x 2")
Total Weight: 2kg (4.4 lb)
Body
Charge Button
Manual charge
button
Hose Connection
Adjustable
Nipple
Locates inside
Glass safety
chamber
Probe
JETCHILL PRODUCT SPEC - Mini Machine

Product Spec Image
CYLINDER HOSE
(Universal)
British Standard BS
341 Part 1 No. 8
USA CGA 320
POWER SUPPLY
(Universal)
100-240V
2.5A
CYLINDER STRAP 1M (3.3ft) Velcro
CYLINDER HOSE
CONNECTION
WRENCH &
SPANNERS
25mm (0.98”)
15mm (0.59”)
16mm (0.62”)
SPARE CYLINDER
HOSE PARTS
O RINGS
COPPER WASHERS
PLASTIC WASHERS
EPDM BS111
1/4" Copper
Flare Washer
JETCHILL PRODUCT SPEC - Mini Machine

Body
Durable and
scratch resistant
SPECIFICATIONS:
Material: Food grade polycarbonate (Wonderlite 110)
Size: 19cm x 4 x 5 (7.5” x 1.6” x 2.0”)
Volume: 200ml (7 oz)
Total Weight: 50g (0.04lb)
Warning: Not for use with Dry Ice pellets
Diffuser
Prevents Dry Ice escaping
Chill Chamber
Stores Dry Ice for 20 mins
Drink smokes for 4 mins
JETCHILL PRODUCT SPEC - Cocktail Glass
Delivery Pipe Centre Hole
Allows Machine to fill
Chill Chamber with Dry Ice

Body
Durable and
scratch resistant
SPECIFICATIONS:
Operation: Manual screw cap
Material: Food grade polycarbonate (Wonderlite 110)
Size: 19cm x 4 x 4 (7.5” x 1.6” x 1.6”)
Volume: 125ml (4 oz)
Total Weight: 80g (0.18lb)
Warning: Not for use with Dry Ice pellets
Diffuser
Prevents Dry Ice escaping
Safety Chamber
Stores Dry Ice for 20 mins
Drink smokes for 4 mins
Silicone Ring
Prevents
drink leaking
Cap
Simple 90 degree turn
Delivery Pipe Centre Hole
Allows Machine to fill
Chill Chamber with Dry Ice
JETCHILL PRODUCT SPEC –Shot-Tail Glass

Body
Durable and
scratch resistant
SPECIFICATIONS:
Material: Food grade polycarbonate (Wonderlite 110)
Size: 9cm x 4 x 4 (3.5” x 1.6” x 1.6”)
Volume: 50ml (2 oz)
Total Weight: 20g (0.04lb)
Warning: Not for use with Dry Ice pellets
Diffuser
Prevents Dry Ice escaping
Chill Chamber
Stores Dry Ice for 20 mins
Drink smokes for 4 mins
JETCHILL PRODUCT SPEC - Shot Glass
Delivery Pipe Centre Hole
Allows Machine to fill
Chill Chamber with Dry Ice

STEP
1
•
Ensure black Rubber O Ring/white Plastic
Washer is on the Cylinder End of the
Cylinder Hose
•
Replacement O Rings/Washers supplied
in Tool Kit, contact JetChill for additional
replacements
STEP
2
•
Hand screw UK Cylinder Hose clockwise
tight, onto Cylinder of Food Grade Liquid
Co2 (with Dip Tube)
•
Wrench screw USA Cylinder Hose
clockwise tight, onto Cylinder of Food
Grade Liquid Co2 (with Dip Tube)
STEP
3
•
Open Cylinder valve by hand turning
Valve 90 degrees anticlockwise
•
Ensure Connection not frosting or
making a hissing sound from Co2 Gas
leaking
STEP
4
•
Plug Power Lead into Mains and side of
Machine
•
Red LED on the Machine will light up
QUICK START GUIDE –Pre Use
UK USA
UK USA

STEP
5
•
Place one dry JetChill Glass on Machine
Probe and ensure Glass locates correctly
on Probe Nipple
•
Hold Glass in place and press and hold
Charge Button once to prime Gas
through Machine
STEP
6
•
Hold Glass in place and press and hold
Charge Button for 12 seconds to charge
Shot-Tail/Cocktail Glass and 6 seconds
for Shot Glass
STEP
7
•
Charged Glass Chamber should be 90%
full with Dry Ice leaving gap for Drink to
create smoking and chilling effect
STEP
8
•
Turn charged Glass upside down and tap
Glass to remove excess any Dry Ice above
Diffuser
•
Glass now ready to serve
QUICK START GUIDE –Use

STEP
9
•
To change Cylinder or at end of session
use, close Cylinder Valve by hand turning
valve 90 degrees clockwise
STEP
10
•
Press and hold Charge Button to purge
Gas through Machine
STEP
11
•
Unscrew Cylinder Hose from Cylinder
anti clockwise
•
Store Cylinders in safe place in
accordance with Cylinder Suppliers
Safety Data Sheet
UK USA
QUICK START GUIDE –Post Use
