Jimi JC800 User manual
User Manual
www.jimilab.com
JC800 3G Car DVR
Instructions before use
1. This device should be connected with a vehicle 12-24 volt power system (must be grounded).
2. Do not install the unit onto position that would block the vision or operation of the drivers.
3. For safe driving, the driver must not watch TV program or operate the unit while driving.
4. Do not replace the power fuse without professional guidance.
5. The device consists of high-precision components, please avoid strong impact. Do not
disassemble or adjust any inner part, if you have any questions, please turn off the power
immediately and notify your local vendors.
6. Do not scratch the mirror with sharp materials.
7. Do not use anything that contains alcoholic or corrosive dilution to clear the screen.
8. Prevent the device from places that is too hot or too cold. Storage temperature: –30℃～ 80℃，
operating temperature: –10℃～ 55℃.
9. Do not expose the unit to moisture, dust, vapors, fumes, direct sunlight or related environment.
Hints:
●Read all the instructions before installation, and we suggest bringing professionals in helping
the installation.
●Please note that when install 3rd party apk, due to compatibility difference the App might not
be working well. It might also cause the device to reboot. These errors have nothing to do
with the device itself.
●Turn off the device before taking out the TF card.
Interface descriptions
Mute
Volume down
Speaker
Power input
USB port
Power button
Bottom
Home
TF card slot
Sim card slot
Battery case
Volume up
HD Camera
Product Features
●CPU Dual-Core 1.3GHz
●Calling function
●Android 4.2 system
●G-Sensor
●5.5 inch IPS touch screen, QHD (960 * 540)
●140° wide-angle camera,1080P resolution
●WiFi, GSM/WCDMA, Bluetooth
●1500 mAh battery
●GPS tracking
●Magnetic base for easy installation
Specications
CPU MT8312
Frequency Dual-core 1.3G
Operating system Andriod 4.2
LCD 5.5"QHD, IPS
Lens 140° wide angle
Resolution 1080P
Frame 30FPS
Network GSM 800/900/1800/1900
WCDMA: 850/1900/2100
Memory 1GB
Internal storage 8GB
External storage TF card 32GB Max.
Bluetooth Bluetooth 4.0
FM Supported (headset antenna)
WIFI Supported
Speaker Highdenitionaudiospeaker
G-sensor Supported
Light sensor Supported
Battery 1500mAH
Dimensions 151(L)*51(W)*83(H)mm
Weight 360g
Basic operation
Turn on/off
Long press power button to turn on device; Long press power button again to turn off device. If
the device is on and shut off the engine directly, then next time the engine is on, the device will
automatically turn on.
Energy saving mode
When the device is on, short press power button to go into standby mode, the screen will close.
Short press the power button again to return.
Main screen introduction
The system provides GPS navigation, DVR, Google Play, Gmail, music, movie, etc. Press
button to return to main screen, button to return to last screen.
Navigation:
1. Press into Google Map for navigation.
2.3G/GSMnetworkorWishouldbeavailabletoactivatetheGooglemap.
3.StreamthelocalmapwithWibeforeinstallationintocarswouldbesuggested.
DVR:
1. When connect to external DC power, device and DVR function will turn on automatically.
When using battery, press in main screen to go into recording mode. Press at the bottom
to stop recording. Press top power button to close the screen, the recording will continue.
2. When the DC power is off and there is no car vibration detected for 2 minutes, device
will consider the car has stopped, and the DVR function will be switched off automatically.
3. Tap the left screen to set the storage space
and recording resolution for video record. When
TF card is available, video will be recorded into
TF card as default, when there is no TF card or
the space of TF card is running full, video will be
saved into internal storage automatically.
4. Tap to review video records, event videos, etc.
4.1 Default recording resolution is 720P. 3 minutes
recordingthelewillbearound75MB.Videole
will be saved every 3 minutes under folder “GENERAL”.
Old record will be overrun by the new when space
is running out.
4.2. G-Sensor. During accident or sudden brake,
videole(15seconds)willbesavedinaseparate
folder “EVENT” and will not be overrun until the
“EVENT” folder is full(500MB).
Set
Memory Space
Video Fomat
2G
16:9 1280*720(720P)
REC
File listREC
GENERAL
EVENT
SHARE
2G
4G
8G
16:9 1280*720(720P)
16:9 1920*1080(1080P)
Applications
Tap to go into APP list
Calling function:
1. Support GSM 850/900/1800/1900
WCDMA 2100/1900/850 frequency
2. Insert SIM and press to start
1
_
2
_
3
_
4
_
5
_
6
_
7
_
8
_
9
_
0
_
o
_
oABC
JKL
TUV
GHI
PQRS
*#
DEF
MNO
WXYZ
GPS tracking
1. Insert SIM card, when data connection is
successful, the device will start to send GPS
data to platform
2.Defaulttrackingfunctionison.Firstxafterturn
on will take around 2-5 minutes.
3. Please place the device in open air for accurate
positioning.
4. Tracking platform is www.jimitrack.com; detail
usage of the platform and APP please refer to
the instructions for Jimitrack.
System setting: You can set brightness, sound,
language, WIFI switch, navigation, etc.
Settings
SIM card control
WLAN
Bluetooth
Data usage
More settings
Storage
Application
OFF
OFF
Wire diagram
The device is equipped with two DC input, one is at the left, one is at the right. Users can
choose either one according to different cars.
2
1
