Jimmy Styks Puffer User manual

OWNERS GUIDE

2
FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTACT US THROUG H O U R WE B S I T E , WWW.J I M M YST YK S . COM
3
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
READ THIS IMPORTANT INFORMATION BEFORE USING YOUR PUFFER INFLATABLE PADDLE BOARD
DISREGARDING ANY OF THE SAFETY PRECAUTIONS AND INSTRUCTIONS CONTAINED IN
THE OWNER’S MANUAL AND/OR ON THE PRODUCT MAY RESULT IN INJURY... INCLUDING THE
POSSIBILITY OF DEATH.
- REVIEW THE WEIGHT CAPACITY LIMITATIONS OF THIS BOARD AND NEVER EXCEED IT.
- ALWAYS WEAR A COAST GUARD APPROVED PERSONAL FLOTATION DEVICE (PFD).
- NEVER GO PADDLE-BOARDING IN SEVERE WEATHER OR WATER CONDITIONS THAT MIGHT
AFFECT YOUR ABILITY TO STEER THE BOARD OR RETURN TO SHORE.
- NEVER ALLOW MINORS TO USE THIS BOARD WITHOUT ADULT SUPERVISION.
- NEVER CONSUME ALCOHOL OR ANY OTHER SUBSTANCE THAT MAY IMPAIR YOUR
COORDINATION, JUDGEMENT OR ABILITY TO SAFELY PADDLE THE BOARD.
- NEVER USE THIS BOARD BEYOND YOUR SKILLS OR ABILITY.
- NEVER USE THIS PRODUCT AFTER SUNSET, BEFORE DAWN OR AT ANY TIME IN POOR LIGHTING.
- CHECK LOCAL LAWS AND REGULATIONS REGARDING PROPER AND SAFE USE OF THIS PRODUCT.
- NEVER LEAVE BOARD EXPOSED TO DIRECT SUNLIGHT WHEN OUT OF THE WATER.
- NEVER LEAVE A DECK PAD EXPOSED TO DIRECT SUNLIGHT.
- DO NOT STORE PADDLE BOARD IN A BOARD BAG FOR EXTENDED PERIODS OF TIME.
- TIGHTEN AIR VALVE BEFORE TAKING BOARD INTO THE WATER. LOOSEN AIR VALVE AFTER USE TO
RELEASE AIR PRESSURE.
- REGULARLY INSPECT AIR VALVE FOR TEARS AND/OR DAMAGE BEFORE USE.
Section 1
Section 2
Page 6
Page 7
Section 3
Page 8
Page 9
Page 9
Page 10
Section 4
Page 11
Page 12
Section 5
Page 13
Section 6
Page 14
Page 15
Section 7
Page 16
Page 17
Page 18
Page 19
Identifying PUFFER Parts & Accessories
PUFFER Care & Maintenance
Paddle Board Care
Pump Maintenance
Inating & Deating PUFFER
PUFFER Ination
Inner Valve Positioning
PUFFER Deation
Valve Tightening
Fin & Leash Installation
Fin Installation
Leash Installation
JS ADJUSTABLE TRAVEL PADDLE
Paddle Assembly
Carry & Transport Guidelines
Tips for Transporting
Tips for Carrying
Repair Kit Contents & Application
Repair Kit Contents
Repairing Leaks & Tears
Water Safety Guidelines
Limited Warranty Information
TABLE OF CONTENTS

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
4
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
5
SECTION 1
IDENTIFYING PUFFER PARTS & ACCESSORIES
PUFFER Paddle Board
Bungee Ties
Traction Pad
Carry Handle
Air Valve
Leash D-Ring
Fin Clamp
JS ADJUSTABLE TRAVEL PADDLE
HP1 High Pressure Pump
Pressure Gauge
Air Hose
Fin
RK1 Repair Kit
CL6 Coil Leash
Board Tote
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
A
B
H
I
L
M
N
O
J
K
C
D
E
F
G

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
6
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
7
IMPORTANT
IMPORTANT
DIRECT SUNLIGHT MAY DESTROY YOUR
PADDLE BOARD.
Even mild sunlight can damage a board if
left in the direct sunlight for a period of time.
On a mild day at 21°C (mid-to-high 70°F), the
inside of a car can reach 77°C (170° F).
Always keep in the shade when not in
the water. If you must expose your board
to direct sunlight during transport or
temporary storage, it is safest to keep the
white (bottom) facing up.
Max pressure is 12 psi. If inated cold to 12
psi, pressure will increase in the sun causing
potential damage to seams.
Damage resulting from heat is not covered
by manufacturer’s warranty!
Never leave paddle board exposed to
direct sunlight when out of the water.
Max pressure is 12 psi.
Sun, sand and saltwater will degrade
any man-made material over time.
Rinse o sand and saltwater deposits
from your paddle board with
fresh water and store in a cool, dry
environment after each use.
BOARD MAINTENANCE
Please be sure that before and during
use, the pump is fully lubricated with oil.
To lubricate, open the top and spread a
thin layer of oil or grease on the gasket
and tube.
Regularly clean the air filter located
inside the top.
PUMP MAINTENANCE
SECTION 2
PUFFER CARE & MAINTENANCE
AIR FILTER
LUBRICATE

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
8
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
9
Attach pressure gauge to pump. Begin
with pressure gauge dial facing the
ground and twist clockwise 180 degrees
until dial is securely fastened and facing
upward.
Fasten air hose to pressure gauge.
Open valve cover.
Depress inner valve and turn clockwise
to lock in the open or“down” position.
Allow air to freely escape PUFFER for a
few minutes.
Beginning at the nose, tightly roll up
PUFFER to force remaining air through
the air valve.
Locate the air valve on tail section of the
board deck.
Open valve cover.
Make sure the inner valve is disengaged
in the “up” position (See opposite
illustration).
Connect air hose to air valve.
Inate PUFFER to 10-12 psi.
Disconnect air hose from valve. Inner
valve will prevent air from escaping
when disengaged in the “up” position.
Close valve cover.
PUFFER INFLATION
PUFFER DEFLATION
STEP 1: PUMP SET UP
STEP 2: INFLATING PUFFER
INNER VALVE POSITIONING
The inner valve will prevent air from
escaping when disengaged (“Up”
position).
The inner valve will allow air to
escape freely when engaged
(“Down” position).
SECTION 3
INFLATING & DEFLATING PUFFER
PUMP ASSEMBLY
INNER VALVE DISENGAGED (UP POSITION)
AIR PREVENTED FROM LEAVING SUP
LOCATING AIR VALVE
INNER VALVE ENGAGED (DOWN POSITION)
AIR ESCAPES FREELY FROM SUP
IMPORTANT

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
10
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
11
SECTION 4
FIN INSTALLATION
Completely remove screw and barrel from
n clamp.
Insert fin, front first then lower into place
until flush against bottom of fin clamp.
Reset screw and barrel. Tighten securely.
FIN INSTALLATION
TIGHTENING VALVE
Occasionally, the valve on your
inatable SUP may become loose. If the
valve ange freely spins when opening
the valve cover or you detect air leaking
from the valve area, tightening will be
required. Using the included valve
wrench, tighten valve in a clockwise
motion until hand tight.
PUFFER INFLATION
IMPORTANT
VALVE WRENCH

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
12
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
13
SECTION 5
JS ADJUSTABLE TRAVEL PADDLE
PADDLE ASSEMBLY
When connecting the two shafts of
the paddle, make sure that the “Jimmy
StyksTM” logo side of the blade is
aligned with the adjustable clamp
lever.
Be careful to not pinch nger tips when
connecting the two paddle shafts.
The PUFFER paddle board includes our
JS ADJUSTABLE TRAVEL PADDLE. For
carrying convenience, the paddle can
be separated into two smaller halves.
Our JS WATER GEAR adjustable clamp
allows for non-permanent sizing on
the go.
JIMMY STYKSTM
LOGO PADDLE FRONT
ADJUSTABLE
CLAMP LEVER
IMPORTANT
Pull leash loop through eyelet.
Pull knot through loop and pull tight
Open Velcro board cu and attach leash to leash loop
Jimmy StyksTM recommends that you
remove your leash after use to prevent
unintentional snagging.
STANDARD LEASH
LEASH LOOP
LEASH INSTALLATION

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
14
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
15
SECTION 6
CARRY & TRANSPORT GUIDELINES
PUFFER is designed to compact for
convenient storage & travel. Due to
a lack of weight when inated, they
will travel poorly if strapped to a
vehicle rooftop. Damages incurred by
improper transport are not covered
by the manufacturer’s warranty!
When transporting PUFFER, be
sure to clear any sharp objects.
Punctures are not covered by the
manufacturer’s warranty!
Keep PUFFER clear of any heat
producing items such as camp
stoves, propane lamps, etc. Damages
resulting from heat are not covered by
the manufacturer’s warranty!
Allow PUFFER to completely dry before
tightly rolling for packing. Excess
moisture may cause mildew and/or
mold damage.
The board tote included with PUFFER
is intended for PUFFER and PUFFER
accessories only. Additional items
added to the board tote may exceed
weight capacity and result in damages
to the tote, shoulder straps and/or carry
handle.
For maximum comfort when carrying
PUFFERinboardtote, wearbothshoulder
straps to evenly distribute the carry
weight. Tighten the shoulder straps to
reduce slack and to avoid tote contents
from resting on the back of the legs.
When completely packed, PUFFER
and PUFFER accessories can get rather
heavy. Make sure to never carry more
than is comfortable for you in one trip.
Always use proper lifting and carrying
techniques to avoid straining muscles.
TIPS FOR TRANSPORTING TIPS FOR CARRYING
Do not transport an inated
paddle board on top of a vehicle.
Never carry more than you can
handle comfortably.

FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
16
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
17
SECTION 7
REPAIR KIT CONTENTS & APPLICATION
The PUFFER comes equipped with an
RK1 emergency repair kit for small leaks
and/or tears.
The included kit may not be adequate
for larger tears or along seams. Contact
Jimmy StyksTM online at jimmystyks.
com for further assistance.
Prepare the following items:
Latex Gloves (Pair)
Isopropyl Alcohol (Rubbing Alcohol)
Clean Cloth
Cement Applicator (Brush, Popsicle® stick, etc.)
RK1 Emergency Repair Kit Contents
To avoid cement irritation of skin, it
is recommended to wear latex gloves
when attempting to make repairs.
1. Completely deate PUFFER paddle board.
2. Thoroughly clean the surface around the
leak and the matte side of the PVC/Polyester
patch with rubbing alcohol. Both surfaces
must be free of moisture, oil and debris.
3. Open the cement tube by breaking the
tube seal using the outside of the tube cap.
4. Apply cement carefully and evenly to both
paddle board surface and matte side patch
surface. Avoid contact with skin & eyes.
Avoid breathing cement vapors.
5. Allow cement on both board and patch
to dry to the touch. Once dry, reapply a very
thin layer of cement around the perimeter of
the patch.
6. Once cement on both board and patch
becomes tack-free, apply patch to board
and rmly work out any trapped air bubbles.
7. Allow 8 hours for cement to cure before
inating paddle board.
REPAIRING LEAKS & TEARS
THE REPAIR KIT
BEFORE YOU START
DIRECTIONS FOR USE
REPAIR KIT CONTAINER CEMENT
PVC/POLYESTER PATCHES X 2
IMPORTANT

18
FOR WARRANTY INFORMATION, PARTS/ACCESSORIES, CALL 1-800-370-0745
OR CONTAC T US THROUG H O U R WE B S I T E , WWW.JI M M YST YK S . COM
19
QUESTIONS/COMMENTS:
1-800-370-0745
jimmystyks.com
WATER SAFETY GUIDELINES JIMMY STYKSTM 365 DAY LIMITED WARRANTY
Jimmy StyksTM oers a limited 365 Day Warranty Against Defects in Materials andWorkmanship.
Terms of Warranty:
Your Jimmy StyksTM product is guaranteed to be free of defects in material and workmanship for
a period of no more than 365 days from the date of purchase. If the product does not conform
to the warranty, Jimmy StyksTM, at its discretion will issue a new, like new, or similar model
product, excluding any shipping charges. Warranty extends to original purchaser only and is
non-transferable. Sales receipt and original packaging materials are required.
Warranty:
Jimmy StyksTM will make every eort to produce boards to the highest quality and standards
in the industry. We do quality checks in our factories in Asia and in our warehouses in North
America in an eort to guarantee each boards’ quality before shipping. Because of the nature
of surng and paddle boarding we can not warranty the performance of any board or shape
for individual riders and varying levels of skills and abilities. Furthermore, we can not guarantee
against damage or breakage and cannot protect or warranty against circumstances outside of
our control. In the event of a new board being removed from a box and not in good condition,
please contact the oce for resolution.You will be asked for a copy of a sales receipt and photos
of the damage in question, as well as original packaging material to verify if damage was due
to shipping. If it is deemed a manufacturing or material aw, we will issue an RMA number. This
number along with the damaged product will need to be returned to the closest warehouse
(Vancouver or Huntington Beach) at customer’s expense. Upon physical review, Jimmy StyksTM
will make it’s nal determination as to the nature of the damage or aw and issue a replacement
product (model depends on availability), or store credit. Shipping will be the responsibility of
the customer. We are not responsible for damage or defects once the board has been used.
Damage is dened as impact with any object or material, punctures, abrasions, over-ination,
damage due to dropping, loading, unloading, or transport, alterations or modications, repairs,
natural disasters, res, temperatures below 40 degrees F, or above 110 degrees F, any further
use of a board once a claim has been reported, transport or storage of a board with a closed air
valve, use of a board in the water with a loose or removed air valve, failure to clean and service
air vent valve, storage of a board in extremely hot or humid conditions including a wet or damp
board bag.
Returns and exchanges:
Jimmy StyksTM will exchange any new, unused product for company credit providing it is
accompanied by original sales receipt and all original packaging. This will not include any
shipping charges or expenses. Product must be in new condition and will be subject to the
inspection of sta.
ALWAYS WEAR A COAST GUARD APPROVED PERSONAL
FLOTATION DEVICE (PFD).
NEVER GO PADDLE-BOARDING IN SEVERE WEATHER OR WATER
CONDITIONSTHAT MIGHT AFFECT YOUR ABILITY TO STEER THE
BOARD OR RETURN TO SHORE.
NEVER ALLOW MINORS TO USE THIS BOARD WITHOUT ADULT
SUPERVISION.
NEVER CONSUME ALCOHOL OR ANY OTHER SUBSTANCE THAT
MAY IMPAIR YOUR COORDINATION, JUDGEMENT, OR ABILITY
TO SAFELY PADDLE THE BOARD.
NEVER USE THIS BOARD BEYOND YOUR SKILLS OR ABILITY.
NEVER USE THIS PRODUCT AFTER SUNSET, BEFORE DAWN OR
AT ANY TIME IN POOR LIGHTING.
CHECK LOCAL LAWS AND REGULATIONS REGARDING PROPER
AND SAFE USE OF THIS PRODUCT.
LIMITED WARRANTY

1-800-370-0745 | www.jimmystyks.com
TM
