Velleman MVR5 User manual

MVR5
DIGITAL VOICE AND VIDEO RECORDER (8 GB)
DIGITALE MEMO
-
EN VIDEORECORDER (8 GB)
DICTAPHONE ET ENREGISTREUR VIDÉO NUMÉRIQUE (8 Go)
DICTÁFONO Y GRABADOR DE VÍDEO DIGITAL (8 GB)
DIGITALES DI TIERGERÄT UND
VIDEORE ORDER (8 GB)
DICTAFONE DIGITAL E GRAVADOR DE VÍDEO (8 GB)
CYFROWY DY TAFON I AMERA (8 GB)
USER MANUAL
3
GEBRUIKERSHANDLEIDING 12
MODE D’EMPLOI 22
MANUAL DEL USUARIO 32
BEDIENUNGSANLEITUNG 42
MANUAL DO UTILIZADOR 52
INSTRUKCJA OBSŁUGI 62

MVR5
V. 1 – 24/ 1/2 13 2 ©Velleman nv

MVR5
V. 1 – 24/ 1/2 13 3 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that
disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a
specialized company for recycling. The device should be
returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly
before bringing the device into service. If the device was damaged in
transit, don't install or use it and contact your dealer.
Package content:
•1 x digital voice recorder
•1 x USB cable
•1 x earphones
•1 x user manual
2. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last
pages of this manual.
•Do not disassemble or repair this product.
•Indoor use only. Keep the device away from rain, moisture,
splashing and dripping liquids.
•Keep the device away from dust and extreme heat.
•Backup your important data frequently, damage or data loss
caused by malfunction or modification is not guaranteed.
•Do not subject the device to severe impact or drop it from high
position.
•Always use accessories provided or authorized by the vendor.
3. Features
•built-in mass storage, capacity 8 GB

MVR5
V. 1 – 24/ 1/2 13 4 ©Velleman nv
•microSD card slot (card max. 16 GB, not incl.)
•super long recording
•music playback
•1.44" colour LCD screen
•recording indicator
•AB repeat: repeat a specific part of the recording
•delete file: single file or all files
•voice recording
•video recording
•USB connection for file transfer
•built-in speaker
•built-in rechargeable battery
•auto power-off
4. Overview
Refer to the illustrations on page 2 of this manual.
1
USB Port
2
Record/
Play
button
(
record
= up
,
play =
down)
3
Audio/Video button
(
video =
up
,
audio
= down
)
4
Menu Button
5
Previous

6
Camera
7
Recording indicator
8
Display
9
A
-
B Repeat/Volume
10
Next

11
Play
►║
12
Decorative Mesh
13
Earphone jack
14
microSD
card slot
15
Power switch
(
unlocked =
up,
locked =
down)
5. Operation
5.1 Basic operations
Starting the device
The device has two modes: Record and Play. These modes are set
with the Record/Play button [2] on the side panel.

MVR5
V. 1 – 24/ 1/2 13 5 ©Velleman nv
•If the Record/Play button is set to record position (up), the device
will start recording when switched on.
•If the Record/Play button is set to play position (down), the device
will display the main menu when switched on.
To start the device:
1. Set the power switch button [15] to ON.
2. Set the mode you want with the Record/Play button [2].
3. Press and hold ►║ on the front panel to turn on the device.
Turning the device off
1. Press and hold ►║ to turn off the device.
Locking the device
To lock the device, set the power switch button [15] to OFF.
Charging the battery
To charge the battery:
•Connect the device to your computer with the included USB cable.
•The device itself cannot be used while connected to your
computer.
First use: setting the device time
The files on the device will be listed by time order. It is
recommended to set the system time on first use. See below.
5.2 Recording audio or video
To record:
1. Set the Audio/Video button on the side panel [3] to video (up)
or audio (down).
2. Set the Record/Play button [2] to record position (up).
3. Press and hold ►║on the front panel.
The device will start recording.
To pause:
1. While recording, press ►║to pause recording.
The recording indicator starts flashing.
2. Press ►║ again to continue recording.

MVR5
V. 1 – 24/ 1/2 13 6 ©Velleman nv
To save or exit
1. While recording, set the Record/Play button [2] to play position
(down).
The device will save the recording and enters play mode.
2. Press ►║ to play the recorded file.
Notes
The minimum memory space required for video recording is 12 Mb.
If the available space is less than 12 Mb, the system will save the
video file and automatically return to the main menu.
5.3 Playing files
1. Set the Record/Play button [2] to play position (down).
2. Press and hold ►║ on the front panel.
3. Press  or  to select the type of file:
- Select Audio for music files
- Select Audio Record for recorded audio
- Select Video Recorder for recorded video
4. Press [M] to view the list of files.
5. Press  or  to select a file.
6. Press ►║ to start playing the current file.
oPress ►║ again to pause file playing.
oLong press [M] to return to the main menu.
To play the next or previous file
While playing a file:
•Press  or  to play the previous or next file.
To select another file from the playlist
While playing a file:
1. Press ►║ to pause playback.
2. Press [M] to enter the playlist.
3. Press  or  to select the file you want to play.
4. Press ►║ button to play the file.
5.4 Playback Settings
Adjusting the volume
1. Make sure the device is in play mode.
2. Press A-B.
3. Press  or  to adjust the volume.

MVR5
V. 1 – 24/ 1/2 13 7 ©Velleman nv
A-B Repeat
You can set the device to repeat a part of a track or recording.
The repeat function is not available for video files.
1. Make sure the device is in music playback mode.
2. Long press A-B to select the start point of A-B repeat
3. Long press A-B again to select the end point of A-B repeat.
4. To cancel the repeat function, long press A-B button.
5.5 Device settings
Accessing the system settings
To access system settings, you need to start the device in play
mode.
1. Set the Record/Play button [2] to play position (down)
2. Press and hold ►║ on the front panel to turn on the device.
3. Press  until System Settings appears.
4. Press [M] to enter the System Settings.
5. When done, long press [M] to return to the main menu.
Setting the language
1. Access the System Settings (see above).
2. Press  to select Language and press [M] to confirm.
3. Press  or  to select the language and press [M] to confirm.
Memory Space Information
1. Access the System Settings (see above).
2. Press  to select Memory Information and press [M] to confirm.
Disc D refers to the internal memory, Disc E refers to microSD
card.
3. Press [M] to exit.
Reset to factory settings
Restoring factory settings resets all default settings but does not
affect your files.
1. Access the System Settings (see above).
2. Press  to select Factory Settings and press [M] to confirm.
3. Press  to select Yes/No to reset to factory settings.
4. Press [M] to confirm.
Select the memory type
You can either use the internal memory or the microSD card
1. Access the System Settings (see above).

MVR5
V. 1 – 24/ 1/2 13 8 ©Velleman nv
2. Press  to select Memory Medium and press [M] to confirm.
The options are: Internal memory and microSD card.
3. Press  to select the memory you want and press [M] to
confirm.
4. If you select the microSD card option, the icon SD will be
displayed on the screen.
Set the time and date
1. Access the System Settings (see above).
2. Press  to select Time Settings and press [M] to confirm.
3. Press  to select the date or time and press [M] to confirm.
4. Press  or  to adjust the digit.
5. Press ►║ to go to the next digit.
6. When done, press [M] to confirm
Set the recording format
1. Access the System Settings (see above).
2. Press  to select Set Audio record mode and press [M] to
confirm.
The recording formats are: AMR, WAV, MP3 and AAC.
3. Press  to select a recording format and press [M] to confirm.
Note: The default recording format for this device is WAV.
Set the sampling rate
1. Access the System Settings (see above).
2. Press  or  to select Sampling rate and press [M] to confirm.
3. Select from 8K, 16K, 24K, 32K and 48K
4. Press [M] to confirm.
Set the screensaver delay
1. Access the System Settings (see above).
2. Press  to select Screen Save Timer and press [M] to confirm.
3. Press  or  to select the delay: off or 1 -2 -3 or 6 sec.
4. Press [M] to confirm.
Turn the LED recording indicator on or off
1. Access the System Settings (see above).
2. Press  to select the LED option.
3. Press [M] to change the setting.
When Off is selected, the LED indicator will remain off during
audio/video recording.

MVR5
V. 1 – 24/ 1/2 13 9 ©Velleman nv
Display backlight setting
1. During video recording, you can turn off the backlight by long
pressing M.
2. Long press [M] again to turn on the backlight.
5.6 Copying music files to the device
Note
The device can only play files stored in the MUSIC folder on the
device. Copy all of your music files to the MUSIC folder and do not
use subfolders.
1. Make sure the device contains a microSD card.
2. Connect the device to the computer with the USB cable
provided.
3. Two removable disk icons will be displayed on your computer:
oone is the built-in memory disc
othe other is the card memory disc.
4. You can now copy files from your computer to the device.
Note
If the device is connected to your computer without microSD card,
you will not be able to open the card memory disc icon.
5.7 Deleting files
Note
A file cannot be restored once it is deleted, please back up any
important data before deletion. Do not power off the device while
deleting files.
To start the device:
1. Set the Record/Play button [2] to play position (down)
2. Press and hold ►║ on the front panel to turn on the device.
3. Press  to select the type of file you want to delete.
- Select Audio for music files
- Select Audio Record for recorded audio
- Select Video Recorder for recorded video
4. Press [M] to enter the playlist.
5. Press  to select the file you want to delete.
6. Press [M] again to view options. The options are:
o[Delete from list]: deletes the current file;
o[Delete all from list]: deletes all files.
7. Press  to select Yes and press [M].

MVR5
V. 1 – 24/ 1/2 13 1 ©Velleman nv
8. Long press [M] to return to the main menu.
6. Technical Specifications
memory
8 GB (built
-
in flash memory)
works with
Windows®2 /XP/Vista/7/8
USB cable
USB 2. full speed
voice recording
format: MP3, WAV, AAC, AMR
time: AMR format: 1824 min
WAV format: 114 min
video recording
format: AVI
resolution: 64 x 48 pixels
time: 16 min
output (max.)
earphones: stereo earphones, 32 ohm
speaker: dynamic 3 x 5 mm / 1 W ~ 8
ohm
frequency response
2 Hz ~ 2 kHz
operating temperature
°C ~ +4 °C
power supply
Li
-
ion rechargeable battery 3.7 ~ 4.2 V,
6 mAh
operating time :video recording: ± 4
hours
voice recording: ± 16 hours
play :± 13 hours (using earphones)
dimensions
98 x 38 x 13 mm
weight
93 g (with battery)
Use the device with original accessories only. Velleman nv
cannot be held responsible in the event of damage or injury
resulting from (incorrect) use of the device. For more info
concerning this product and the latest version of this manual,
please visit our website www.velleman.eu. The information in
this manual is subject to change without prior notice.
All registered trademarks and trade names are properties of their
respective owners and are used only for the clarification of the
compatibility of our products with the products of the different
manufacturers. Windows, Windows XP, Windows 2 , Windows
Vista, Windows Aero, Windows 7, Windows 8, Windows Mobile,
Windows Server are registered trademarks of Microsoft Corporation
