JingYan JED100 User manual

1
Revision Date：202004
JED100
User Manual for JED100
Electrostatic Meter

6
Product Introduction
Thanks for using JED100 portable electrostatic meter. JED100 portable
electrostatic meter is a non - contact electrostatic qualitative testing instrument.
JED100 has three indicator lights, green for power, red for positive charge and
blue for negative charge. This product can be used in the qualitative
measurement of whether there is static electricity on the surface of the target
object. It is widely used in the measurement of static electricity on the surface
of masks, non-woven fabrics, plastics, films, rubber, fiber composite plates and
other products.
Function Introduction
1. Power Indicator -- This light will be on when the machine is started and
working normally.
2. On /OFF Switch -- NO is power on /OFF is power off.
3. Positive Charge Indicator -- This light will light up when positive charge
voltage is detected
4. Negative Charge Indicator -- This light will light up when negative charge
Testing Area
4
6
3
5
1
2

7
voltage is detected
5. Positive Charge Reset -- Press this button to reset the positive charge
voltage before measurement
6. Negative Charge Reset -- Press this button to reset the negative charge
voltage before measurement
Working Instruction
1. Open the package, remove the four screws on the back of the instrument,
open the instrument case, install the two 3V CR2030 batteries, and then lock
the fixing screws.
2. Switch the "ON"/" off "button to" ON "and the power indicator will light up.
3. Zero+, Zero- to reset the positive and negative voltage.
4. Aim the testing area at the surface of the measured object, and the optimal
measuring distance is 10mm. When the positive charge indicator light is on,
the positive charge electrostatic is detected; when the negative charge
indicator light is on, the negative charge electrostatic is detected; if neither light
is on, the surface of the measured object is not detected.
5. Press the "on/OFF" button to "OFF" after use.
Product Specification
Product Name
Electrostatic Meter
Product Model
JED100
Power
Double 3V CR2030 batteries
Size
80mmX60mmX25mm
Weight
76g
Operate Temperature
0~50℃
Sensing range
100V~20KV
Measurement Mode
Handhold non-contact measurement

8
Cautions
1. Please take out the internal battery when it is not used for a long time.
2. Please make sure that the positive load voltage is reset before testing.
Press "ZERO" to reset.
3. Do not drop the product on the floor.
4. Place the product away from water or other liquids.
Warranty
The after-sales service of this product is implemented in strict accordance
with the law of the People's Republic of China on the protection of consumers'
rights and interests and the quality law of the People's Republic of China on
Chinese people's names.
1. The main body of the machine is guaranteed for one year, and the battery
is a consumable, which needs to be purchased by itself after use. During the
warranty period, the company will guarantee for free any fault caused by the
quality problem of the product itself.
2. Please read the instructions carefully before using the product. If the
product fails due to improper operation, improper storage or unauthorized
disassembly, it will not be covered by the free warranty.
3. Please contact your seller before the product repair, so as to arrange the
repair more quickly.
Measuring Distance
10mm（Best）
Response Time
1S~3S
