Jinyoung Contech SX1700 User manual

TFT LCD Monitor : SX1700 1/14
Issued Date :
Nov 07, 2003
To: Jinyoung Contech Co., Ltd.
42-5 DAEWON B/D, JAMWON-DONG, SEOCHO-KU, SEOUL, KOREA
TEL : [phone] FAX : [phone]
HOME PAGE : http://www.jyct.com/ Page :
14pages
TFT LCD MONITOR 17”With Sharpening Style USER’
S MANUAL
SX1700
-With Touch Screen (Optional)
1. Introduction
With an LCD Panel Monitor using a TFT Color LCD, you can use SX1700 a substitution of general PC
Monitor because it can receive the R.G.B input of PC VGA Signal. SX1700 has OSD Function in order to
display the best quality of the screen according to VGA Cards’features. Besides, DVI, NTSC/PAL, S-Video
Signals are available by option, and Touch Screen is also available by customer’s request, it can be usable
simultaneously with PS/2 Mouse.
Safety Precautions
The safety recommendations outlined in this section are to be read, understood and followed before
operating the product. Keep this information in a safe place for future reference. Failure to comply with any of
the following safety procedures could result in serious hazard.
A. Do not operate product for any purposes other than its intended use.
B. This product is intended for indoor use only.
C. Do not operate product if power cord is damaged in any way.
D. Do not insert object into openings.
E. Do not immerse product in water or permit liquids to spill inside.
F. Turn off power when attended or not in use unplug product before moving it or when it is not
in use for an extended period of time.
Note : These specifications are subject to change for up-date without notification

TFT LCD Monitor : SX1700 2/14
2. Specification
2.1 LCD Monitor Specifications
-Screen Size : 17.0”TFT Color LCD
-Active Area (H x W): 337.92 ×270.336 mm
-Supporting Resolutions : Full display by zooming out on VGA/SVGA/XGA/SXGA
-Driver Element : a-SI TFT active matrix
-Pixel Arrangement : RGB vertical stripe
-Display Mode : Normally White
-Surface treatment : Haze 25%, Anti-glare & Hard –Coating (3H)
-Resolution : 1280 x 1024 dots
-Aspect Ratio : 4:3
-Max .Colors : 16,777,216 color
-Pixel Pitch (H x W) : 0.264 x 0.264 mm
-Luminance(cd/m2) : Typ. 270
-Contrast Ratio : Typ. 350 : 1
-Backlight Lifetime : Min. Hrs
-Viewing Angle : Horizontal ; Typ. 70°/70°, Vertical ; Typ. 60°/60°
-Response Time(ms) : Typ. 5(R)/20(F)
-Screen Adjustment : OSD (On Screen Display) include Auto Adjustment compliant
-Mount Type : Panel Mount & Wall Mount & Stand Type & VESA Standard ARM Mount
-Supporting Analog R.G.B signal (Analog VGA) input
-Supporting Digital signal (DVI : Digital Visual Interface) input –(Optional)
-Supporting Video signal (NTSC/PAL) input –(Optional)
-Supporting Video signal (S-Video) input –(Optional)
-Chassis Material : Front -Aluminum, Rear –Steel
-RGB Input : 0.7Vpp±10%, 75 Ohms
-Input Rating : AC 100-240V@ 1.3-0.65A, 50/60Hz or DC 12V @ 3.5A
-Ampere requirement : AC 100V @ 1.3A, AC 200V @ 0.65A, DC 12V @ 3.5A
-Power requirement : 42W
-Power Consumption : Max. 42W
-Power Saving Mode : Less than 3W
-Storage Temperature : -20 ~ 60°C
-Operating Temperature : 0 ~ 50℃
-Dimensions(W x H x D) : With Power Type ; 397 x 330 x 63 mm,
Without Power Type ; 397 x 330 x 51 mm
-Weight : Net ; 6.0kg, Gross ; 8.3kg
-Refresh Rate : Max. 1280 x 1024 @ 75 Hz (60 Hz for optimal display)
-Main Frequency : Typ. 67.5 MHz

TFT LCD Monitor : SX1700 3/14
-Frequency : Hor. 31.5~80 kHz, Ver. 56 ~75 Hz
-Compatibility of Vertical Frequency
PC MODE Vertical Frequency (Hz)
640 x 480 60 / 72 / 75
800 x 600 56 / 60 / 72 / 75
1024 x 768 60 / 70 / 75
1280 x 1024 60 / 75
DOS 640 x 350 70
DOS 640 x 400 70
IBM
DOS 720 x 400 70
2.2 Touch Screen Specifications
-Touch Screen Type : Analog Resistive 5-Wire Type
-Touch Screen Controller Interface : Serial (RS-232)
-Touch Screen Drivers : MS-DOS, Windows 3.1/95/98/ME/NT/2000, Linux X Window
-Drift compensation for fluctuations in the temperature and humidity
-Antiglare scratch resistant finish
-Gloved or Ungloved finger or Stylus activation
-Chemically strengthened glass backing panel
-Optically bonded buffer layer
-Transmittance : Typ. >74%
-Durability : Point Activation Typ. 150,000
Gouge Hardness 3H or more

TFT LCD Monitor : SX1700 4/14
3. OSD Functions
3.1 OSD KEY
* OSD Button : With pressing the button once, the OSD Screen is displayed. The button
is used for closing Menu after adjusting each parameter value. The parameter
values adjusted are automatically saved.
* SEL Button :The SEL button is used when selecting Menu or exiting from SUB Menu.
* RIGHT,LEFT Button
-UP/RIGHT :Used for moving BAR position to the rightside from Main Menu
or increasing parameter value from SUB Menu.
-DOWN/LEFT :Used for moving BAR position to the leftside from Main Menu
or decreasing parameter value from SUB Menu.
3.2 OSD Items
* The following OSD screen is shown with pressing OSD button.

TFT LCD Monitor : SX1700 5/14
: Automatic adjustment for sharpening screen image.
With selecting “YES ”,the text “Auto Adjusting ”is displayed with black screen on the LCD.
: Adjusts the black level of the backlight.
: Adjusts the contrast ratio of the image.
: Adjusts the screen position,ADC lock and phase.

TFT LCD Monitor : SX1700 6/14
-Horz. Position : Adjusts the screen position horizontally.
-Vertical Position : Adjusts the screen position vertically.
-Clock : Adjusts the value of clock per line.
-Phase : Adjusts ADC Sample pixel Clock
: Adjusts the gain of each RGB
-Red : Adjusts the gain of Red.

TFT LCD Monitor : SX1700 7/14
-Green : Adjusts the gain of Green.
-Blue : Adjusts the gain of Blue.
-Factory Preset :Initializes setting values.
-DOS/GFX :Selects DOS Mode only.
-ON : 640 x 400 -OFF : 720 x 400

TFT LCD Monitor : SX1700 8/14
-OSD Time : Selects OSD time out.
-OSD H-Position : Adjusts OSD position horizontally.
-OSD V-Position : Adjusts OSD position vertically.
: Indicates display information about the system.
: The adjusted parameter value is saved.

TFT LCD Monitor : SX1700 9/14
: Selects the mode the display.(optional)
-Analog : Analog R.G.B Input Select
-Digital : DVI(Digital Video Interface) Input Select
-Video : NTSC/PAL Video input Select
-S-Video : S-Video Input Select
* Video Menu : Adjusts and saves the parameter value related with video function from
Video Menu.
: Adjusts the black level of the backlight.
: Adjusts the contrast ratio of the video image.

TFT LCD Monitor : SX1700 10/14
: Adjusts the combination of the Hue.
: Adjusts the saturation of the screen.
: Adjusts the screen position horizontally.
: Adjusts the screen position vertically.
3.3 Warning Message
No Sync Mode : If there is not Analog RGB or Video input signal,the message “No Sync ”
is displayed.
Input Not Supported Mode : In case of detecting the mode that cannot be supported by
LCD,the below message is displayed on black screen.In order to
remove the phenomenon,it should be switched into the mode that
can be supported by LCD.
