Jinyoung Contech TU17VR User manual

TFT LCD Monitor : TU17VR 1/13
Issued Date :
Dec 23, 2002
TO : Jinyoung Contech Co., Ltd.
42-5 DAEWON B/D, JAMWON-DONG, SEOCHO-KU, SEOUL, KOREA
TEL : [phone] FAX : [phone]
HOME PAGE : http://www.jyct.com/ Page :
13pages
TFT LCD MONITOR 17”USER’
S MANUAL
TU17VR
-With Touch Screen (Optional)
1. Introduction
With an LCD Panel Monitor using a TFT Color LCD, you can use TU17VR a substitution of general PC
Monitor because it can receive the R.G.B input of PC VGA Signal. TU17VR has OSD Function in order to
display the best quality of the screen according to VGA Cards’features. Besides, DVI, NTSC/PAL, S-Video
Signals are available by option, and Touch Screen is also available by customer’s request, it can be usable
simultaneously with PS/2 Mouse
Safety Precautions
The safety recommendations outlined in this section are to be read, understood and followed before
operating the product. Keep this information in a safe place for future reference. Failure to comply with any of
the following safety procedures could result in serious hazard.
A. Do not operate product for any purposes other than its intended use.
B. This product is intended for indoor use only.
C. Do not operate product if power cord is damaged in any way.
D. Do not insert object into openings.
E. Do not immerse product in water or permit liquids to spill inside.
F. Turn off power when attended or not in use unplug product before moving it or when it is not
in use for an extended period of time.
Note : These specifications are subject to change for up-date without notification

TFT LCD Monitor : TU17VR 2/13
2. Specifications
-Screen Size : 17.1”, 1280 x 1024 dots
-Active Area(mm) : 337.92 x 270.336
-Supporting Resolutions : Full display by zooming out on VGA/SVGA/XGA/SXGA
-Aspect Ratio : 4:3
-Max .Colors : 16,777,216 color
-Pixel Pitch (H x W) : 0.264 x 0.264 mm
-Luminance(cd/m2) : Typ. 250
-Contrast Ratio : Typ. 350 : 1
-Backlight Lifetime : Typ. 50,000 Hrs
-Viewing Angle : Horizontal ; Typ. 75°/75°
Vertical ; Typ. 65°/60°
-Response Time(ms) : Typ. 20
-Screen Adjustment : OSD (On Screen Display)
-Mount Type : Rack Mount
-Supporting Analog R.G.B signal (Analog VGA) input
-Supporting Digital signal (DVI : Digital Video Interface) input –(optional)
-Supporting Video signal (NTSC/PAL) input –(optional)
-Supporting Video signal (S-Video) input –(optional)
-Chassis Material : Steel
-RGB Input : 0.7Vpp±10%, 75 Ohms
-Input Rating : AC 100-240V@ 1.3-0.65A, 50/60Hz
-Ampere requirement : AC 100V @ 1.3A, AC 200V @ 0.65A, DC 12V @ 3.75A
-Power requirement : 45W
-Power Consumption : Max. 45W
-Power Saving Mode : Less than 3W
-Storage Temperature : -20 ~ 60°C
-Operating Temperature : 0 ~ 50℃
-Dimensions (W x H x D) : 483 x 354.8 x 80 mm
-Weight : 8.8 Kg
-Frequency : Hor. 15~60 KHz, Ver. 56~75 Hz

TFT LCD Monitor : TU17VR 3/13
-Compatibility of Vertical Frequency
PC MODE Vertical Frequency (Hz)
640 x 480 60 / 72 / 75
800 x 600 56 / 60 / 72 / 75
1024 x 768 60 / 70 / 75
1280 x 1024 60 / 75
DOS 640 x 350 70 / 85
DOS 640 x 400 70 / 85
IBM
DOS 720 x 400 70 / 85
-Touch Screen -(Optional)
Touch Screen Type : Analog Resistive
5-Wire Type
Touch Screen Controller Interface : Serial (RS-232)
Touch Screen Drivers : MS-DOS, Windows 3.1/95/98/ME/NT/2000, Linux X Windows
3. OSD Functions
3.1 OSD KEY
* OSD Button : With pressing the button once, the OSD Screen is displayed. The button
is used for closing Menu after adjusting each parameter value. The parameter
values adjusted are automatically saved.
* SEL Button :The SEL button is used when selecting Menu or exiting from SUB Menu.
* RIGHT,LEFT Button
-UP/RIGHT :Used for moving BAR position to the rightside from Main Menu
or increasing parameter value from SUB Menu.
-DOWN/LEFT :Used for moving BAR position to the leftside from Main Menu
or decreasing parameter value from SUB Menu.

TFT LCD Monitor : TU17VR 4/13
3.2 OSD Items
* The following OSD screen is shown with pressing OSD button.
: Automatic adjustment for sharpening screen image.
With selecting “YES ”,the text “AutoAdjusting ”is displayed with black screen on the LCD.
: Adjusts the black level of the backlight.

TFT LCD Monitor : TU17VR 5/13
: Adjusts the contrast ratio of the image.
: Adjusts the screen position,ADC lock and phase.
-Horz. Position : Adjusts the screen position horizontally.
-Vertical Position : Adjusts the screen position vertically.
-Clock : Adjusts the value of clock per line.

TFT LCD Monitor : TU17VR 6/13
-Phase : Adjusts ADC Sample pixel Clock
: Adjusts the gain of each RGB
-Red : Adjusts the gain of Red.
-Green : Adjusts the gain of Green.
-Blue : Adjusts the gain of Blue.

TFT LCD Monitor : TU17VR 7/13
-Factory Preset :Initializes setting values.
-DOS/GFX :Selects DOS Mode only.
-ON : 640 x 400 -OFF : 720 x 400
-OSD Time : Selects OSD time out.
-OSD H-Position : Adjusts OSD position horizontally.

TFT LCD Monitor : TU17VR 8/13
-OSD V-Position : Adjusts OSD position vertically.
: Indicates display information about the system.
: The adjusted parameter value is saved.
: Selects the mode the display.(optional)
-Analog : Analog R.G.B Input Select
-Digital : DVI(Digital Video Interface) Input Select
-Video : NTSC/PAL Video input Select
-S-Video : S-Video Input Select

TFT LCD Monitor : TU17VR 9/13
* Video Menu : Adjusts and saves the parameter value related with video function from
Video Menu.
: Adjusts the black level of the backlight.
: Adjusts the contrast ratio of the video image.
: Adjusts the combination of the Hue.

TFT LCD Monitor : TU17VR 10/13
: Adjusts the saturation of the screen.
: Adjusts the screen position horizontally.
: Adjusts the screen position vertically.
3.3 Warning Message
No Sync Mode : If there is not Analog RGB or Video input signal,the message “No Sync ”
is displayed.
Input Not Supported Mode : In case of detecting the mode that cannot be supported by
LCD,the below message is displayed on black screen.In order to
remove the phenomenon,it should be switched into the mode that
can be supported by LCD.
