JLG E300AJ Use and care manual

Operation and Safety Manual
ANSI
®
Original Instructions - Keep this manual with the machine at all times.
Boom Lift Models
E300AJ
E300AJP
S/N 0300138358 to Present
3121252
January 5, 2015

FOREWORD
3121252 – JLG Lift – a
FOREWORD
This manual is a very important tool! Keep it with the machine at all times.
The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating
procedures essential for the safe and proper machine operation for its intended purpose.
Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without
prior notification. Contact JLG Industries, Inc. for updated information.

FOREWORD
b– JLG Lift – 3121252
SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
INDICATES AN IMMINENTLY HAZARDOUS SITUATION. IF NOT AVOIDED, WILL
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE A RED BACK-
GROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, COULD
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE AN ORANGE BACK-
GROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, MAY RESULT
IN MINOR OR MODERATE INJURY. IT MAY ALSO ALERT AGAINST UNSAFE PRACTICES.
THIS DECAL WILL HAVE A YELLOW BACKGROUND.
INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY OR INDI-
RECTLY TO THE SAFETY OF PERSONNEL OR PROTECTION OF PROPERTY.
This is the Safety Alert Symbol. It is used to alert you to the potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury or
death

FOREWORD
3121252 – JLG Lift – c
THIS PRODUCT MUST COMPLY WITH ALL SAFETY RELATED BULLETINS. CONTACT JLG
INDUSTRIES, INC. OR THE LOCAL AUTHORIZED JLG REPRESENTATIVE FOR INFORMA-
TION REGARDING SAFETY-RELATED BULLETINS WHICH MAY HAVE BEEN ISSUED FOR
THIS PRODUCT.
JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF
RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT THE
CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE.
JLG INDUSTRIES, INC. MUST BE NOTIFIED IMMEDIATELY IN ALL INSTANCES WHERE
JLG PRODUCTS HAVE BEEN INVOLVED IN AN ACCIDENT INVOLVING BODILY INJURY
OR DEATH OF PERSONNEL OR WHEN SUBSTANTIAL DAMAGE HAS OCCURRED TO PER-
SONAL PROPERTY OR THE JLG PRODUCT.
Contact:
Product Safety and Reliability Department
JLG Industries, Inc.
13224 Fountainhead Plaza
Hagerstown, MD 21742
USA
or Your Local JLG Office
(See addresses on inside of manual cover)
In USA:
Toll Free: 877-JLG-SAFE (877-554-7233)
Outside USA:
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
For:
• Accident Reporting
• Product Safety Publica-
tions
• Current Owner Updates
• Questions Regarding
Product Safety
• Standards and Regulations
Compliance Information
• Questions Regarding Special
Product Applications
• Questions Regarding Prod-
uct Modifications

FOREWORD
d– JLG Lift – 3121252
REVISION LOG
Original Issue - June 26, 2009
Revised - September 29, 2009
Revised - October 28, 2009
Revised - November 19, 2009
Revised - November 8, 2010
Revised - February 6, 2012
Revised - August 9, 2012
Revised - January 5, 2015

3121252 – JLG Lift – i
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
TABLE OF CONTENTS
SECTION - 1 - SAFETY PRECAUTIONS
1.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Operator Training and Knowledge . . . . . . . . . . . . . . . . . 1-1
Workplace Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Machine Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.3 OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Trip and Fall Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Electrocution Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Tipping Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Crushing and Collision Hazards . . . . . . . . . . . . . . . . . . 1-10
1.4 TOWING, LIFTING, AND HAULING. . . . . . . . . . . . . . . . . . . . 1-11
1.5 MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Maintenance Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Battery Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
SECTION - 2 - USER RESPONSIBILITIES, MACHINE PREPARATION,
AND INSPECTION
2.1 PERSONNEL TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Operator Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Training Supervision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Operator Responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 PREPARATION, INSPECTION, AND MAINTENANCE . . . . . 2-2
Pre-Start Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Function Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
SkyGuard Function Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
SECTION - 3 - MACHINE CONTROLS AND INDICATORS
3.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 CONTROLS AND INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Ground Control Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Platform Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Platform Control Indicator Panel . . . . . . . . . . . . . . . . . 3-13
SECTION - 4 - MACHINE OPERATION
4.1 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 BOOM OPERATING CHARACTERISTICS AND
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 MOTOR OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Power/Emergency Stop Switch . . . . . . . . . . . . . . . . . . . . 4-6
Platform/Ground Select Switch . . . . . . . . . . . . . . . . . . . . 4-6
Motor Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.4 TRAVELING (DRIVING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Traveling Forward and Reverse . . . . . . . . . . . . . . . . . . . . 4-9
4.5 STEERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.6 PLATFORM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Platform Level Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Platform Rotation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

ii – JLG Lift – 3121252
TABLE OF CONTENTS
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
4.7 BOOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Swinging the Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Raising and Lowering the Upper Boom. . . . . . . . . . . . 4-11
4.8 FUNCTION SPEED CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 4-11
4.9 MACHINE SAFETY SYSTEM OVERRIDE (MSSO)
(CE ONLY). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.10 SKYGUARD OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.11 SHUT DOWN AND PARK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
4.12 LIFTING AND TIE DOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Lifting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Tie Down. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
SECTION - 5 - EMERGENCY PROCEDURES
5.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 INCIDENT NOTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.3 EMERGENCY OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Operator Unable to Control Machine. . . . . . . . . . . . . . . 5-1
Platform or Boom Caught Overhead . . . . . . . . . . . . . . . 5-2
5.4 EMERGENCY TOWING PROCEDURES. . . . . . . . . . . . . . . . . . 5-2
5.5 MANUAL DESCENT SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.6 MANUAL SWING OVERRIDE . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.7 MACHINE SAFETY SYSTEM OVERRIDE (MSSO)
(CE ONLY). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
SECTION - 6 - GENERAL SPECIFICATIONS & OPERATOR
MAINTENANCE
6.1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 OPERATING SPECIFICATIONS AND PERFORMANCE
DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Operating Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Capacities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Major Component Weights . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6.3 OPERATOR MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
6.4 BATTERY MAINTENANCE AND CHARGING . . . . . . . . . . . 6-13
Battery Maintenance, Quarterly . . . . . . . . . . . . . . . . . . . 6-13
Battery Charging, Daily . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6.5 TIRES & WHEELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Tire Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Wheel and Tire Replacement . . . . . . . . . . . . . . . . . . . . . 6-15
Wheel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
6.6 SUPPLEMENTAL INFORMATION . . . . . . . . . . . . . . . . . . . . . 6-16
SECTION - 7 - INSPECTION AND REPAIR LOG

3121252 – JLG Lift – iii
LIST OF FIGURES
FIGURE NUMBER - TITLE PAGE FIGURE NUMBER - TITLE PAGE
2-1. Basic Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2-2. Daily Walk-Around Inspection - Sheet 1 of 3 . . . . . . . . . . 2-8
2-3. Daily Walk-Around Inspection - Sheet 2 of 3 . . . . . . . . . . 2-9
2-4. Daily Walk-Around Inspection - Sheet 3 of 3 . . . . . . . . . 2-10
3-1. Ground Control Station - E300AJ . . . . . . . . . . . . . . . . . . . . . 3-3
3-2. Ground Control Station - E300AJ with Machine Safety
System Override (MSSO) (CE Only) . . . . . . . . . . . . . . . . . 3-4
3-3. Ground Control Station - E300AJP . . . . . . . . . . . . . . . . . . . . 3-5
3-4. Ground Control Station - E300AJP with Machine Safety
System Override (MSSO) (CE Only) . . . . . . . . . . . . . . . . . 3-6
3-5. Platform Control Console . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3-6. Platform Control Indicator Panel. . . . . . . . . . . . . . . . . . . . . 3-14
4-1. Position of Least Forward Stability . . . . . . . . . . . . . . . . . . . . 4-3
4-2. Position of Least Backward Stability - E300AJ . . . . . . . . . 4-4
4-3. Position of Least Backward Stability - E300AJP . . . . . . . . 4-5
4-4. Grade and Side Slopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4-5. Lifting and Tie Down Chart . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
4-6. Decal Location Sheet 1 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
4-7. Decal Location Sheet 2 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
4-8. Decal Location Sheet 3 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
4-9. Decal Location Sheet 4 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
4-10. Decal Location Sheet 5 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
5-1. Manual Descent Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
6-1. Operator Maintenance and Lubrication Diagram. . . . . . 6-8

iv – JLG Lift – 3121252
LIST OF FIGURES
FIGURE NUMBER - TITLE PAGE FIGURE NUMBER - TITLE PAGE
This Page Left Blank Intentionally.

3121252 – JLG Lift – v
LIST OF TABLES
TABLE NUMBER - TITLE PAGE TABLE NUMBER - TITLE PAGE
1-1 Minimum Approach Distances (M.A.D.) . . . . . . . . . . . . . . . 1-6
1-2 Beaufort Scale (For Reference Only). . . . . . . . . . . . . . . . . . . 1-9
2-1 Inspection and Maintenance Table . . . . . . . . . . . . . . . . . . . 2-3
4-1 Skyguard Function Table . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12
6-1 Operating specifications - E300AJ. . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Operating specifications - E300AJP . . . . . . . . . . . . . . . . . . . 6-2
6-3 Dimensional Data - E300AJ . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6-4 Dimensional Data - E300AJP. . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-5 Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-6 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-7 Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6-8 Mobil DTE 11M Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6-9 DTE 10 Excel 15 Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6-10 Mobilfluid 424 Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6-11 Mobil EAL 224H Specs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-12 Mobil EAL Envirosyn H Specs . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-13 Quintolubric 888-46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-14 Critical Stability Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-15 Lubrication Specifications.. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
6-16 Wheel Torque Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-16
7-1 Inspection and Repair Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

vi – JLG Lift – 3121252
LIST OF TABLES
TABLE NUMBER - TITLE PAGE TABLE NUMBER - TITLE PAGE
This Page Left Blank Intentionally.

SECTION 1 - SAFETY PRECAUTIONS
3121252 – JLG Lift – 1-1
SECTION 1. SAFETY PRECAUTIONS
1.1 GENERAL
This section outlines the necessary precautions for proper and
safe machine usage and maintenance. It is mandatory that a daily
routine is established based on the content of this manual to pro-
mote proper machine usage. A maintenance program, using the
information provided in this manual and the Service and Mainte-
nance Manual, must also be established by a qualified person and
must be followed to ensure that the machine is safe to operate.
The owner/user/operator/lessor/lessee of the machine must not
accept operating responsibility until this manual has been read,
training is accomplished, and operation of the machine has been
completed under the supervision of an experienced and quali-
fied operator.
This section contains the responsibilities of the owner, user, oper-
ator, lessor, and lessee concerning safety, training, inspection,
maintenance, application, and operation. If there are any ques-
tions with regard to safety, training, inspection, maintenance,
application, and operation, please contact JLG Industries, Inc.
(“JLG”).
FAILURE TO COMPLY WITH THE SAFETY PRECAUTIONS LISTED IN THIS MANUAL
COULD RESULT IN MACHINE DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.
1.2 PRE-OPERATION
Operator Training and Knowledge
• The Operation and Safety Manual must be read and under-
stood in its entirety before operating the machine. For clarifi-
cation, questions, or additional information regarding any
portions of this manual, contact JLG Industries, Inc.

SECTION 1 - SAFETY PRECAUTIONS
1-2 – JLG Lift – 3121252
• An operator must not accept operating responsibilities until
adequate training has been given by competent and autho-
rized persons.
• Allow only those authorized and qualified personnel to oper-
ate the machine who have demonstrated that they under-
stand the safe and proper operation and maintenance of the
unit.
• Read, understand, and obey all DANGERS, WARNINGS, CAU-
TIONS, and operating instructions on the machine and in this
manual.
• Ensure that the machine is to be used in a manner which is
within the scope of its intended application as determined by
JLG.
• All operating personnel must be familiar with the emergency
controls and emergency operation of the machine as specified
in this manual.
• Read, understand, and obey all applicable employer, local, and
governmental regulations as they pertain to your utilization
and application of the machine.
Workplace Inspection
• Precautions to avoid all hazards in the work area must be
taken by the user before and during operation of the machine.
• Do not operate or raise the platform from a position on trucks,
trailers, railway cars, floating vessels, scaffolds or other equip-
ment unless the application is approved in writing by JLG.
• Before operation, check work area for overhead hazards such
as electric lines, bridge cranes, and other potential overhead
obstructions.
• Check operating surfaces for holes, bumps, drop-offs, obstruc-
tions, debris, concealed holes, and other potential hazards.
• Check the work area for hazardous locations. Do not operate
the machine in hazardous environments unless approved for
that purpose by JLG.
• Ensure that the ground conditions are adequate to support
the maximum tire load indicated on the tire load decals
located on the chassis adjacent to each wheel. Do not travel
on unsupported surfaces.

SECTION 1 - SAFETY PRECAUTIONS
3121252 – JLG Lift – 1-3
Machine Inspection
• Do not operate this machine until the inspections and func-
tional checks as specified in Section 2 of this manual have
been performed.
• Do not operate this machine until it has been serviced and
maintained according to the maintenance and inspection
requirements as specified in the machine’s Service and Main-
tenance Manual.
• Ensure all safety devices are operating properly. Modification
of these devices is a safety violation.
MODIFICATION OR ALTERATION OF AN AERIAL WORK PLATFORM SHALL BE MADE
ONLY WITH PRIOR WRITTEN PERMISSION FROM THE MANUFACTURER.
• Do not operate any machine on which the safety or instruction
placards or decals are missing or illegible.
• Check the machine for modifications to original components.
Ensure that any modifications have been approved by JLG.
• Avoid accumulation of debris on platform floor. Keep mud, oil,
grease, and other slippery substances from footwear and plat-
form floor.
1.3 OPERATION
General
• Machine operation requires your full attention. Bring the
machine to a full stop before using any device, i.e. cell phones,
two-way radios, etc. that will distract your attention from
safely operating the machine.
• Do not use the machine for any purpose other than position-
ing personnel, their tools, and equipment.
• Before operation, the user must be familiar with the machine
capabilities and operating characteristics of all functions.
• Never operate a malfunctioning machine. If a malfunction
occurs, shut down the machine. Remove the unit from service
and notify the proper authorities.
• Do not remove, modify, or disable any safety devices.
• Never slam a control switch or lever through neutral to an
opposite direction. Always return switch to neutral and stop
before moving the switch to the next function. Operate con-
trols with slow and even pressure.
• Do not allow personnel to tamper with or operate the
machine from the ground with personnel in the platform,
except in an emergency.

SECTION 1 - SAFETY PRECAUTIONS
1-4 – JLG Lift – 3121252
• Do not carry materials directly on platform railing unless
approved by JLG.
• When two or more persons are in the platform, the operator
shall be responsible for all machine operations.
• Always ensure that power tools are properly stowed and never
left hanging by their cord from the platform work area.
• When driving, always position boom over rear axle in line with
the direction of travel. Remember, if boom is over the front
axle, steer and drive functions will be reversed.
• Do not assist a stuck or disabled machine by pushing or pull-
ing except by pulling at the chassis tie-down lugs.
• Fully lower platform and shut off all power before leaving
machine.
• Remove all rings, watches, and jewelry when operating
machine. Do not wear loose fitting clothing or long hair unre-
strained which may become caught or entangled in equip-
ment.
• Persons under the influence of drugs or alcohol or who are
subject to seizures, dizziness or loss of physical control must
not operate this machine.
• Hydraulic cylinders are subject to thermal expansion and con-
traction. This may result in changes to the boom and/or plat-
form position while the machine is stationary. Factors
affecting thermal movement can include the length of time
the machine will remain stationary, hydraulic oil temperature,
ambient air temperature, and boom and platform position.
Trip and Fall Hazards
• During operation, occupants in the platform must wear a full
body harness with a lanyard attached to an authorized lanyard
anchorage point. Attach only one (1) lanyard per lanyard
anchorage point..
• Enter and exit only through gate area. Use extreme caution
when entering or leaving platform. Ensure that the platform
assembly is fully lowered. Face the machine when entering or
leaving the platform. Always maintain “three point contact”
with the machine, using two hands and one foot or two feet
and one hand at all times during entry and exit.

SECTION 1 - SAFETY PRECAUTIONS
3121252 – JLG Lift – 1-5
• Before operating the machine, make sure all gates are closed
and fastened in their proper position.
• Keep both feet firmly positioned on the platform floor at all
times. Never position ladders, boxes, steps, planks, or similar
items on unit to provide additional reach for any purpose.
• Keep oil, mud, and slippery substances cleaned from footwear
and the platform floor.
Electrocution Hazards
• This machine is not insulated and does not provide protection
from contact or proximity to electrical current.

SECTION 1 - SAFETY PRECAUTIONS
1-6 – JLG Lift – 3121252
• Maintain distance from electrical lines, apparatus, or any ener-
gized (exposed or insulated) parts according to the Minimum
Approach Distance (MAD) as shown in Table 1-1.
• Allow for machine movement and electrical line swaying.
• Maintain a clearance of at least 10 ft. (3m) between any part of
the machine and its occupants, their tools, and their equip-
ment from any electrical line or apparatus carrying up to
50,000 volts. One foot additional clearance is required for
every additional 30,000 volts or less.
Table 1-1. Minimum Approach Distances (M.A.D.)
Voltage Range
(Phase to Phase)
MINIMUM APPROACH DISTANCE
in Feet (Meters)
0to50KV 10(3)
Over50KVto200KV 15(5)
Over200KVto350KV 20(6)
Over350KVto500KV 25(8)
Over500KVto750KV 35(11)
Over750KVto1000KV 45(14)
NOTE: This requirement shall apply except where
employer, local or governmental regulations are
more stringent.

SECTION 1 - SAFETY PRECAUTIONS
3121252 – JLG Lift – 1-7
• The minimum approach distance may be reduced if insulating
barriers are installed to prevent contact, and the barriers are
rated for the voltage of the line being guarded. These barriers
shall not be part of (or attached to) the machine. The mini-
mum approach distance shall be reduced to a distance within
the designed working dimensions of the insulating barrier.
This determination shall be made by a qualified person in
accordance with the employer, local, or governmental require-
ments for work practices near energized equipment
DO NOT MANEUVER MACHINE OR PERSONNEL INSIDE PROHIBITED ZONE (MAD).
ASSUME ALL ELECTRICAL PARTS AND WIRING ARE ENERGIZED UNLESS KNOWN OTH-
ERWISE.
Tipping Hazards
• The user must be familiar with the surface before driving. Do
not exceed the allowable sideslope and grade while driving.
• Do not elevate platform or drive with platform elevated while
on or near a sloping, uneven, or soft surface. Ensure machine is
positioned on a firm, level and smooth surface before elevat-
ing platform or driving with the platform in the elevated posi-
tion.
• Before driving on floors, bridges, trucks, and other surfaces,
check allowable capacity of the surfaces.

SECTION 1 - SAFETY PRECAUTIONS
1-8 – JLG Lift – 3121252
• Never exceed the maximum work load as specified on the
platform. Keep all loads within the confines of the platform,
unless authorized by JLG.
• Keep the chassis of the machine a minimum of 2 ft. (0.6m)
from holes, bumps, drop-offs, obstructions, debris, concealed
holes, and other potential hazards at the ground level.
• Do not push or pull any object with the boom.
• Never attempt to use the machine as a crane. Do not tie-off
machine to any adjacent structure. Never attach wire, cable, or
any similar items to platform.
• Do not operate the machine when wind conditions exceed 28
mph (12.5 m/s). Refer to Table 1-2, Beaufort Scale (For Refer-
ence Only).
• Do not increase the surface area of the platform or the load.
Increase of the area exposed to the wind will decrease stabil-
ity.
• Do not increase the platform size with unauthorized deck
extensions or attachments.
• If boom assembly or platform is in a position that one or more
wheels are off the ground, all persons must be removed before
attempting to stabilize the machine. Use cranes, forklift trucks,
or other appropriate equipment to stabilize machine.
