JMA Wireless Weather Protection System WPS-DM-14S User manual

16175-01 rev. A
Page 1
©2019 JMA Wireless. All rights reserved. This document contains proprietary and confidential information. All products, company names,
brands, and logos are trademarks™ or registered® trademarks of their respective holders. All specifications are subject to change without
notice. Revised: January 29, 2020 +1 315.431.7100 [e-mail]
Installation Instructions
JMA Weather Protection System™
WPS-DM-14S, DM Connector to Port
Materials (all sold separately)
WPS-DF
(for antenna) WPS-DM-14S RDCUTTER
TQ-114-F18
torque wrench
Step 1: Install WPS-DM-14S and 1/4” connector
Prior to cable prep, slide the WPS-
DM-14S onto the 1/4” cable 6–12”
from the end.
Prep and install the 1/4” cable to install
the JMA 1/4” UXP compression
connector. Refer to the 1/4” corrugated
connector installation instructions.
Step 2: Cut WPS-DF
Measure the WPS-DF from the end
of the port to the beginning of the
threads as shown. Use your thumb to
mark a cut line.
Align the blade of the RDCUTTER to
the thumb mark indicating the cut
length. Using one firm cutting motion,
cut the WPS-DF to the proper length.
Step 3: Install WPS-DF
Place the cut WPS-DF onto the
antenna or device female port. Ensure that the WPS-DF is properly placed on the antenna or device port,
positioned just past the threads.
Properly measured WPS-DF.
Properly installed WPS-DF.

16175-01 rev. A
Page 2
©2019 JMA Wireless. All rights reserved. This document contains proprietary and confidential information. All products, company names,
brands, and logos are trademarks™ or registered® trademarks of their respective holders. All specifications are subject to change without
notice. Revised: January 29, 2020 +1 315.431.7100 [e-mail]
Installation Instructions
JMA Weather Protection System™
WPS-DM-14S, DM Connector to Port
Properly mated connector.
Step 5: Install WPS-DM-14S
Slide the WPS-DM-14S over the 1/4”
connector, making sure to overlap
the port seal.
Completed installation of the JMA
Weather Protection System.
Step 4: Connect and torque interface
Connect the 1/4” connector to the
antenna port or device, and hand
tighten
Torque the connection to 18 lbf∙ft
using TQ-114-F8 torque wrench.
Proper port seal alignment
