JMC UB570 PRO UVC User manual

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
UB570 PRO UVC
User Manual
101-UB570-PRO-UVC

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
TABLE OF CONTENTS
3. PRODUCT INTRODUCTION ............................................................................................................3
3.1. PRODUCT BRIEF.................................................................................................................................3
3.2. SPECIFICATION...................................................................................................................................3
4. HARDWARE INSTALLATION ..........................................................................................................4
4.1. PACKAGE CONTENTS .........................................................................................................................4
4.2. PRECAUTION......................................................................................................................................5
4.3. USB UVC DONGLE ...........................................................................................................................5
5. SOFTWARE INSTALLATION............................................................................................................6
5.1. SUPPORT OS ......................................................................................................................................6
5.2. DRIVER INSTALLATION ......................................................................................................................6

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
3. PRODUCT INTRODUCTION
3.1. Product Brief
UB570 PRO UVC is a high-quality, high-performance capture device which is specially designed for
high-definition video capture applications. It supports up to 1 channel of high-definition,
1920x1200p60 video from HDMI source and alternatively one 3G SDI input.
3.2. Specification
Model
UB570 Pro
Max. FPS
1920×1080p@60/50fps
Recording
Mode
Software Compression, Real-Time Mode
Interface
USB3.0 ( SuperSpeed ) UVC / USB2.0 ( High-Speed )
UVC
Video Input
1×SDI, 1×HDMI, 1×DVI-I, 1×YPbPr, 1×CVBS, 1×S-
Video
Video RAW
Data Format
YUY2
Video Input
Resolution
USB2.0/3.0 Support Resolution
All resolution below
1920×1200p@60fps
Recording
Video
Format
YUY2 ( USB2.0/3.0 )
UVC Video
Output
Resolution
USB3.0 Support Resolution
1920×1200p@60/50/30/25/24fps
1920×1080p@60/50/30/25/24fps
1280×1024p@60/50/30/25/24fps
1280×720p@60/50/30/25/24fps
1024×768p@60/50/30/25/24fps
800×600p@60/50/30/25/24fps
640×480p@60/50/30/25/24fps
720×576p@60/50/30/25/24fps
720×480p@60/50/30/25/24fps
USB2.0 Support Resolution
640×480p@30/25/24fps
720×576p@25/24fps
720×480p@25/24fps

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
Audio Input
SDI Embedded Audio
HDMI Embedded Audio
2×RCA ( Audio L/R Through Component Cable )
Audio
Format
Stereo / 16-bit / 48000Hz
System Requirement
OS Support
Windows 7 / Windows 8.1 / Windows 10 ( 32-bit and
64-bit )
Linux / MAC OS / Android
4. HARDWARE INSTALLATION
4.1. Package Contents
Item
Amount
UB570 PRO UVC
1
USB3.0 Cable
1
2 x RCA to 3.5mm stereo analog audio cable
1
4.2 Signal Source Connection Diagram
Front Side
Rear Side

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
4.2. Precaution
Before proceed, make sure touch a safely grounded object or metal object before touching the device.
Please follow below chapter for installation operations
4.3. USB UVC Dongle
⚫Connect USB3.0 cable to computer
USB Type B Connector
USB 3.0 Type A Connector
⚫Connect USB Type B connector to UB570 PRO UVC
⚫Connect signal source

JMC Systems Engineering AB www.jmc.se [phone] [email protected]
5. SOFTWARE INSTALLATION
5.1. Support OS
Windows based system
Windows 7
Support
Windows 8/8.1
Support
Windows 10
Support
Android
Support
MAC OS
Support
Linux
Support
5.2. Driver Installation
For UVC devices, there is no need to install drivers. The driver will activate automatically when the
device is attached.
Utility (Win) for UVC settings can be downloaded from
http://jmc.se/Download/2020/UVC.UTILITY.X86_V1.50.EXE
