jobmate 99-2973-8D User manual

18 V Cordless
Wet/Dry Hand Vacuum
(Part of 4 in 1 Combo 99-2973-8)
99-2973-8D
Instruction Manual
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
PRODUCT SPECIFICATIONS
Motor:
Single speed
Switch:
Lock-on
Filter:
Cleanable filter fabric
Battery:
18 V
Charger input:
120 V AC, 60 Hz
Charger output:
25 V DC, 500 mA
Battery charging time:
3–5 Hours
Replacement battery:
54-3099-0
TOLL FREE HELPLINE 1-866-JOBMATE

2
Product specifications ………….…………………………………………………….
1
Table of contents ……………………………………………………………………...
2
General safety warnings ……………………………………………………………..
3–4
Eye, ear & lung protection …………………………………………………
3–4
Electrical safety …………………………………………………………….
4
Power tool safety ……………………………………………………………………...
5–6
General safety rules ………………………………………………………..
5
Work area …………………………………………………………………...
5
Electrical safety …………………………………………………………….
5
Personal safety …………………………………………………………….
5–6
Tool use and care ………………………………………………………….
6
Service ………………………………………………………………………
6
Specific safety rules …………………………………………………………………..
7
Battery & charger safety ……………………………………………………….…….
7–8
Symbols ………………………………………………………………………………..
9
Know your vacuum ……………………………………………………………………
10
Accessories and contents ……………………………………………………………
11–12
Assembly and operation ……………………………………………………………..
13–19
Charging the battery pack …………………………………………………
13-14
Installing battery in vacuum ……………………………………………….
14
Dust container & filter ……………………………………………………...
14–16
Attachments ………………………………………………………………...
16–17
Operation ……………………………………………………………………
18
Maximum fill line ……………………………………………………………
19
Maintenance …………………………………………………………………………..
19–21
General warnings …………………………………………………………..
19
Cleaning ……………………………………………………………………..
19
Lubrication …………………………………………………………………..
19
Battery pack removal and preparation for recycling ……………………
20
Battery maintenance ……………………………………………………….
20
How to exercise a nickel-cadmium battery ………………………………
21
Parts diagram ………………………………………………………………………….
22
Parts list ………………………………………………………………………………..
23
Warranty ……………………………………………………………………….………
24
TABLE OF CONTENTS

3
EYE, EAR & LUNG PROTECTION
This instruction manual includes the following:
General Safety Rules
Specific Safety Rules and Symbols
Functional Description
Assembly
Operation
Maintenance
Accessories
!
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during operation of a power tool.
SAVE THESE INSTRUCTIONS FOR REFERENCE
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool or if the operation is noisy.
!
GENERAL SAFETY WARNINGS
CAUTION: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions.
!

4
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 110–120 V operation. It must be
connected to a 110–120 V 15 A time delayed fuse or circuit breaker. To
avoid shock or fire, replace power cord immediately if it is worn, cut or
damaged in any way.
ALWAYS WEAR A DUST MASK DESIGNED FOR USE WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING: Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contains chemicals known to cause
cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
Lead from lead-based paints
Crystalline silica from bricks, cement and other masonry products
Arsenic and chromium from chemically-treated lumber
Your level of risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals, work in a
well-ventilated area and work with approved safety equipment such as dust
masks that are specially designed to filter out microscopic particles.
!
GENERAL SAFETY WARNINGS

5
GENERAL SAFETY RULES
WARNING: Read and understand
all instructions. Failure to follow all
instructions listed below may result in
electric shock, fire and/or serious personal
injury.
WORK AREA
Keep your work area clean and well lit.
Cluttered benches and dark areas invite
accidents.
Do not operate power tools in potentially
explosive environments, such as in the
presence of flammable liquids, gas or dust.
Power tools create sparks which may
ignite the dust or fumes.
Keep bystanders, children and visitors
away while operating the tool. Distractions
can cause you to lose control.
ELECTRICAL SAFETY
Double insulated tools are equipped with a
polarized plug (one blade is wider than the
other). This plug will fit in a polarized plug
only one way.
If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install a
polarized outlet. Do not alter the plug in
any way. Double insulation eliminates the
need for the three-prong grounded power
cord and grounded power supply system.
Avoid body contact with grounded surfaces
such as pipes, radiators, ranges and
refrigerators. There is increased risk of
electric shock if your body is grounded.
Do not expose power tools to rain or wet
conditions. Water entering the power tool
will increase the risk of electric shock.
Do not abuse the cord. Never use the cord
to carry the tool or pull the plug from an
outlet. Keep cord away from heat, oil,
sharp edges or moving parts. Replace
damaged cords immediately. Damaged
cords increase the risk of electric shock.
When operating a power tool outdoors,
use an outdoor extension cord marked “W-
A” or “W”. These cords are rated for
outdoor use and reduce the risk of electric
shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use the tool while tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Dress properly. Do not wear loose clothing
or jewellery.
Contain long hair. Keep your hair, clothing
and gloves away from moving parts. Loose
clothing, jewellery or long hair can be
caught in moving parts.
!
POWER TOOL SAFETY

6
PERSONAL SAFETY –cont’d
Avoid accidental starting. Be sure the
switch is OFF before plugging in or
installing the battery. Carrying tools with
your finger on the switch, plugging in tools
or installing batteries in tools that have the
switch ON invites accidents.
Remove adjusting keys or wrenches
before turning the tool ON. A wrench or
key that is left attached to a rotating part of
the tool may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. Proper footing and
balance enables better control of the tool
in unexpected situations.
Use safety equipment. Always wear eye
protection.
Dust mask, non-skid safety shoes, hard
hat or hearing protection must be used for
appropriate conditions.
TOOL USE AND CARE
Use clamps or another practical way to
secure and support the workpiece to a
stable platform. Holding the work by hand
or against your body is unstable and may
lead to loss of control.
Do not force the tool. Use the correct tool
for your application. The correct tool will do
the job better and safer at the rate for
which it was designed.
Do not use the tool if the power switch
does not turn it ON or OFF. Any tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
or remove the battery before making any
adjustments, changing accessories or
storing the tool. Such preventive safety
measures reduce the risk of starting the
tool accidentally.
Store idle tools out of reach of children and
other untrained persons. Tools are
dangerous in the hands of untrained users.
Maintain tools with care. Keep cutting tools
sharp and clean. Properly maintained
cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the tool’s
operation. If damaged, have the tool
serviced before using. Many accidents are
caused by poorly maintained tools.
Use only accessories that are
recommended by the manufacturer for
your model. Accessories that may be
suitable for one tool may become
hazardous when used on another tool.
SERVICE
Tool service must be performed only by
qualified personnel. Service or
maintenance performed by unqualified
personnel could result in risk of injury.
When servicing a tool, use only identical
replacement parts. Follow instructions in
the Maintenance section of this manual.
Use of unauthorized parts or failure to
follow Maintenance instructions may
create a risk of electric shock or injury.
POWER TOOL SAFETY

7
WARNING: For your safety, do not
charge the battery or install the battery in
your vacuum until you have read and
understood this Owner’s Manual.
WARNING: Never use vacuum to
remove any flammable liquid such as
gasoline.
Never submerge the vacuum in water.
Severe damage to the vacuum will result.
Always make sure the vacuum filter is
clean, dry and properly installed in the dust
container. Running the vacuum with a dirty
or wet filter may cause the motor to
overheat.
Never run the vacuum without the filter in
place. Collected dust will enter the motor
and cause damage to the motor.
Never allow vacuum to be used if the
debris in the container is above the ‘MAX.”
level line on the side of the container.
Do not store or carry battery in a manner in
which metal objects could contact the
exposed metal end. Do not place battery in
aprons, pockets, drawers, etc. with loose
nails, screws, keys etc. The battery could
short circuit causing a fire, personal injury
or damage to the battery.
Never attempt to open the battery for any
reason. If the housing of the battery breaks
or cracks, immediately
discontinue use and do not recharge.
Do not charge the battery if it is wet or
shows any evidence of corrosion.
A small leakage from the battery may
occur under extreme usage, charging or
temperature conditions. This does not
indicate a failure. If however, the outer seal
is broken and this leakage gets on your
skin, follow these steps:
1. Wash immediately with soap and
water.
2. Neutralize with a mild acid such as
lemon juice or vinegar.
3. If liquid gets into your eyes, flush
immediately with clean water for a
minimum of 10 minutes and seek
medical attention.
NOTE: The battery liquid is a 20–35%
solution of potassium hydroxide.
Do not incinerate the battery. It can
explode in a fire.
Do not use an extension cord. Plug the
charger cord directly into an electrical
outlet.
Use the charger only in a standard
110–120 V 60 Hz electrical outlet.
Charge the battery only with the charger
supplied with the circular saw.
Do not use the charger in wet or damp
conditions. It is intended for indoor use
only. Do not use the charger near sinks or
tubs. Do not immerse the charger in water.
SPECIFIC SAFETY RULES
!
BATTERY & CHARGER
SAFETY
!

8
Do not allow the cord to hang over the
edge of a table or counter or touch hot
surfaces. The charger should be placed
away from sinks and hot surfaces.
Do not use charger to charge any batteries
other than the circular saw batteries. Other
batteries may explode.
Do not operate charger if cord or plug is
damaged. Replace damaged cord and
plug immediately.
Do not operate charger if it has received a
sharp blow, been dropped or otherwise
damaged in any way. Have a qualified
technician examine the charger and repair
it if necessary. Do not disassemble the
charger.
For best results, only charge the battery
when the temperature range of the battery
or work area is between 10–40°C (50–
105°F).
Unplug the charger when not in use and
before cleaning or maintenance.
Do not abuse the cord. To reduce the risk
of damage to the electric cord or plug,
never carry the charger by the cord or
yank the cord to pull the plug. Always
grasp the plug and pull to disconnect.
Always keep the cord away from heat, oil
and sharp edges.
BATTERY & CHARGER SAFETY
NOTE: See Pages 20 & 21 for
detailed information on disposal of
defective batteries and exercising the
battery for peak performance.

9
V
volts
A
amperes
Hz
hertz
W
watt
kW
kilowatts
microfarads
L
liters
kg
kilograms
H
hours
N/cm2
newtons per square
centimeter
Pa
pascals
Min
minutes
S
seconds
alternating current
three-phase alternating
current
three-phase alternating
current with neutral
direct current
no load speed
alternating or direct
current
class II construction
splash proof
construction
watertight construction
protective earthing at
earthing terminal, Class I
tools
revolutions or
reciprocations per
minute
diameter
off position
arrow
warning symbol
WARNING: Some of the symbols below may be used on your tool.
Please study them and learn their meaning. Proper interpretation of
these symbols will allow you to operate the tool better and safer.
!
SYMBOLS
This symbol designates that
this tool is listed with both
Canadian and U.S.
requirements by Underwriters
Laboratories.

10
KNOW YOUR CORDLESS VACUUM
Maximum fill
line
Dust container
release button
ON/OFF button
Battery release
button
Dust container
Battery
Charger
stand
Battery
charger

11
AVAILABLE ACCESSORIES
WARNING: Use only vacuum
filters recommended for this vacuum.
Follow instructions that accompany the
filters. Improper use of filters may
cause injury to the operator or damage
to the vacuum.
Do not use any accessory unless you have
completely read the instructions or
Owner’s Manual for that accessory.
Vacuum filters
WARNING: If any part is missing
or damaged, do not plug the battery
charger into the power source or insert
the battery into the vacuum until the
missing or damaged part is replaced.
CONTENTS
Carefully unpack the vacuum. Compare
against the “Vacuum Components” at
right.
NOTE: See illustration of components on
Page 12.
WARNING: To avoid fire or toxic
reaction, never use gasoline, naphtha,
acetone, lacquer thinner or similar
highly volatile solvents to clean the
tool.
NOTE: This vacuum is part of a
4-piece tool kit. The following accessories
are packed in a separate carton within the
master carton. The batteries are to be
used with any of the tools contained within
this kit. The charger and charging stand
are to be used to charge the 18 V
batteries.
!
!
!
ACCESSORIES & CONTENTS
VACUUM COMPONENTS
KEY
DESCRIPTION
QTY
A
Wet/dry hand
vacuum
1
B
Crevice tool
1
C
Brush
1
D
Squeegee
1
Owner’s manual
1
ACCESSORIES
KEY
DESCRIPTION
QTY
E
Battery
2
F
Charging stand
1
G
Charger
1
Tote for kit
1

12
CONTENTS

13
CHARGING THE BATTERY PACK
1. Place the battery (1) in a dry location
near a 110–120 V 60 Hz electrical
outlet (Fig. 1)
2. Place the charger base (2) over the
matching slots (3) of the battery.
NOTE: Make sure the charger stand is
pressed fully onto the battery until the
battery latches (4) “click” into place.
3. Insert small charger plug (5) into
charger stand receptacle (6) and plug
the battery charger (7) into the
110–120 V 60 Hz wall receptacle.
NOTES:
a) The green indicator light (8) will turn
ON indicating the charger is “live”.
b) The red indicator light (9) will come
ON when the battery pack is properly
inserted into the charger stand.
c) If red indicator light does not come
ON, check to make sure battery pack
is inserted fully into the charger and
the electrical outlet is working
properly.
d) Both the red and green indicator
lights will remain ON as long as the
charger is plugged into the power
source and the battery is plugged
into the charging stand.
NOTES:
a) A new battery pack or one that is
completely run down should be charged
for 5 hours. After normal use, a battery
pack should be fully charged in about 3
hours.
b) It is normal for the battery charger to
hum and be warm to the touch during
operation.
ASSEMBLY AND OPERATION
Fig. 1

14
CHARGING THE BATTERY PACK –cont’d
c) If the battery pack does not charge
properly, check to make sure the electrical
outlet is “live”.
d) The battery pack should only be
charged in an area where the temperature
is between 10–40°C (50–105°F).
INSTALLING BATTERY IN VACUUM
1. Remove the discharged battery (1)
from the tool by pressing on the
battery release buttons (2) on each
side of the battery and pulling the
battery out of the tool handle (3)
(Fig. 2).
2. Slide the fully-charged battery into the
matching slots in the tool handle
where the discharged battery has
been removed.
NOTE: Make sure the battery is fully
engaged with the mounting slots in the
tool handle. The battery release
buttons will “click” into place when the
battery is fully installed.
WARNING: Do not immerse
battery pack in water. Sudden cooling
could cause hot battery to explode or
leak.
DUST CONTAINER & FILTER
1. Press down on dust container release
button (1) (Fig. 3).
2. Tip dust container (2) downward and
remove from motor housing (3).
ASSEMBLY AND OPERATION
!
Fig. 2
Fig. 3

15
DUST CONTAINER & FILTER –cont’d
3. Rotate filter assembly (4) clockwise a
few degrees until the round portion of
the slots (5) are placed behind the
mounting pins (6) (Fig. 4).
4. Pull filter assembly (6) out of the filter
retainer (7) (Fig. 5).
5. Pull the filter retainer (7) out of the
dust container (8).
NOTE: Do NOT remove any other
component inside the dust container.
6. Empty dust & debris from the dust
filter into a garbage container.
7. Clean filter and filter retainer.
NOTE: If filter is dry, it can be cleaned
by carefully brushing the dust from the
outside of the filter bag. Care must be
taken not to damage the filter fabric. If
fabric is damaged in any way or
cannot be cleaned, it must be
replaced with a new filter.
8. Re-insert the filter assembly into the
filter retainer and lock into position by
reversing the procedure described in
item #3 above.
NOTE: The filter assembly will only fit
properly one way.
9. Insert filter retainer and filter assembly
into the into the dust container.
NOTE: The filter assembly will only fit
onto the dust container one way.
Make sure it fits into the retainer
properly.
ASSEMBLY AND OPERATION
Fig. 4
Fig. 5

16
DUST CONTAINER & FILTER –cont’d
10. With dust container tipped downward,
slide it onto the bottom of the motor
housing until the holes in the dust
container engage with the tabs (9) in
the motor housing (Fig. 6).
11. Tip dust container upward until it
snaps into place.
ATTACHMENTS
This hand vacuum kit includes three
attachments. For general vacuuming they
are not required, however, they may be
required for special applications.
Attachments include:
Crevice tool
Brush
Squeegee
Crevice Tool
Use this tool for reaching into small
spaces.
To install the crevice tool, push the large
end (1) into the dust container (2) (Fig. 7).
NOTE: The crevice tool is friction fit. Do
NOT force it into the dust container too
hard or you may damage the dust
container.
Brush
Use this tool for cleaning up loose debris
from fabric.
Install the brush (1) on the small end of the
crevice tool (2) (Fig. 8).
NOTE: Make sure the hole (3) in the brush
tab locks onto the button in the small end
of the crevice tool.
ASSEMBLY AND OPERATION
Fig. 6
Fig. 7
Fig. 8

17
ATTACHMENTS –cont’d
Squeegee
Use this tool for cleaning up small liquid
spills.
DANGER: Never use this hand
vacuum to clean up any volatile or
flammable material. Explosion and
serious injury may result.
To install the squeegee, push the small
end (1) directly into the dust container
(Fig. 9).
NOTES:
a) Make sure the arrow (2) on the
squeegee is facing upward
b) DO NOT use the squeegee attachment
unless the dust container and filter are
clean. Liquid mixing with other debris will
make the filter and dust container difficult
to clean.
c) Make sure the dust container and filter
are DRY before using the hand vacuum for
dry materials. Moisture will cause the dust
container and filter to plug extremely
quickly.
d) When hand vacuum has been used to
clean up a liquid, carefully wash and dry
the filter and dust container.
!
WARNING: Have you read “GENERAL SAFETY WARNINGS”, “POWER
TOOL SAFETY”, “SPECIFIC SAFETY RULES”, “BATTERY & CHARGER
SAFETY” and “SYMBOLS” on pages 3, 4, 5, 6, 7, 8 & 9 of this Manual? If not,
please do it now before you operate this vacuum. Your safety depends on it!
Every time you use the vacuum you should verify the following:
1. Dust container is clean and dry.
2. Filter is clean, dry and in good condition.
Failure to adhere to these safety rules can greatly increase the chances of
injury.
!
ASSEMBLY AND OPERATION
Fig. 9

18
DANGER: Never use this hand
vacuum to clean up any volatile or
flammable material. Explosion and
serious injury may result.
1. Check the hand vacuum to make sure
the dust container and filter are clean
and dry.
2. Install the appropriate accessory if
required.
3. Install a fully-charged battery.
4. Slide the ON/OFF switch (1) forward
to turn hand vacuum ON (Fig. 10).
5. Hand vacuum up debris by moving the
hand vacuum forward and backward
in slow steady strokes.
NOTES:
a) Using slow even strokes will allow
the hand vacuum to pick up the debris
more effectively.
b) When using the squeegee
attachment, only hand vacuum when
pulling the tool toward you. Lift the tool
up when reaching forward to begin
another stroke. This action will allow
the squeegee to pull the liquid toward
the hand vacuum for more effective
cleaning.
WARNING: Never tilt hand vacuum
handle down when there is liquid in the
dust container. This will allow liquid to
run back into the hand vacuum motor
and damage the motor.
!
!
ASSEMBLY AND OPERATION
Fig. 10

19
MAXIMUM FILL LINE
WARNING: Do not allow the dust
container to get too full when
vacuuming up liquids.
See the maximum fill line (1) on the left
side of the dust container (Fig. 11). Always
empty the container before the liquid
reaches the maximum level. An over-filled
dust container will damage the motor.
WARNING: When servicing, use
only identical replacement parts. Use of
any other part may create a hazard or
cause product damage.
DO NOT abuse power tools. Abusive
practices can damage the tool as well as
the workpiece.
WARNING: DO NOT attempt to
modify tools or create accessories. Any
such alteration or modification is
misuse and could result in a hazardous
condition leading to possible serious
injury. It will also void the warranty.
CLEANING
DO NOT use solvents when cleaning
plastic parts. Most plastics are susceptible
to damage from various types of
commercial solvents and may be damaged
by their use. Use a clean cloth to remove
dirt, dust, oil, grease, etc.
WARNING: Do not at any time
allow brake fluids, gasoline, petroleum-
based products, penetrating oils, etc. to
come in contact with plastic parts. They
contain chemicals that can damage,
weaken or destroy plastic.
LUBRICATION
All of the bearings in this vacuum are
lubricated with a sufficient amount of high-
grade lubricant for the life of the unit under
normal conditions. Therefore, no further
lubrication is required.
!
MAINTENANCE
!
!
!
ASSEMBLY AND OPERATION
Fig. 11

20
BATTERY PACK REMOVAL AND
PREPARATION FOR RECYCLING
To preserve our natural resources, please
recycle or dispose of batteries properly.
This product contains nickel-cadmium
batteries. Never dispose of nickel-cadmium
batteries in your normal household
garbage or in landfill sites as they will add
to the pollution of the environment.
Consult your local waste authority for
information regarding available recycling
and disposal options.
WARNING: Upon removal of the
battery pack, cover the terminals of the
battery pack with electrical or heavy-
duty adhesive tape. Never touch both
terminals with metal objects or body
parts as a short circuit may result. Keep
away from children. Do not attempt to
destroy or disassemble battery pack or
remove any of its components. Nickel-
cadmium batteries must be recycled or
disposed of properly. Failure to comply
with these warnings could result in fire
and serious injury.
BATTERY MAINTENANCE
For power, long operational life and light
weight your tool is powered by a Nickel-
cadmium battery pack.
Nickel-cadmium batteries are powerful,
rugged and will provide hundreds of
charge/discharge cycles if properly
maintained and periodically ‘exercised’.
Exercising is required to recover most of
the capacity lost during usage. This
process reduces the size of the active
cadmium hydroxide crystals on the anode,
to expose all surface area and restore
capacity.
How to care for your Nickel-cadmium
battery
1. Never allow a battery to freeze.
2. Never charge a battery that has been
stored at or below 5° or above 40° C.
Allow it to sit at room temperature for
at least 30 minutes before charging.
3. Do not charge a battery if it feels
warm to the touch.
4. Never charge a battery after a short
use. Let it sit until it is needed again.
5. Never charge the battery until the tool
in which it is being used can not
produce useful work.
6. Do not leave a battery on the charger
after charging time has expired;
usually 3 to 5 hours. Your charger will
not damage the battery. However, the
heat it produces shortens the battery
operational life.
!
MAINTENANCE
