JohnDow Industries AFC-100-94 User manual

™
WARNING
This filte c ushe is designed to c ush one filte at a time.
Any attempt to c ush mo e than one filte may
esult in damage and is not cove ed in the wa anty.
WARNING
Do not ope ate the c ushe without a filte in the c ushing cambe .
PREVENTATIVE MAINTENANCE
1. Keep the in-line air lubricator filled with oil. (SAE 30 motor oil is recommended.)
2. Check the level of hydraulic fluid in the reservoir every 90 days. The fluid level
should be within 1/2” of the top. se only high grade hydraulic fluid.
3. Periodically check the hydraulic line connections for tightness.
4. Periodically check the pressing plate for tightness.
5. Inspect the drain holes at the bottom of the crushing chamber and remove any
debris or restrictions.
For Service
Phone Toll-Free
1-800-433-0708
JohnDow Industries, Inc.
151 Sn der Ave.
Barberton, OH 44203
Oil Filter Crushers
Models No.
AFC-100-94
HDC-150-94
Owners Manual
AFC-100-94
HDC-150-94
REV 9/16

Assembly Instructions
Checklist Of Components
Your filter crusher was shipped with the following components. Please be sure
you receive them as listed below. Contact us if anything is missing.
Item No. Desc iption Qty.
1 … … … … … … … …Top Cover Guard … … … … … … …1
2 … … … … … … …1” x 4” Drain Fitting … … … … … …1
3 … … … … … … …1” x 1ft. Drain Hose … … … … … …1
In addition, any air filter/regulator/lubricator is required in
order for the unit to o erate ro erly. Item no. FRL-1 is avail-
able from JohnDow.
IMPORTANT!
Good ai quality is impo tant fo optimum pe fo mance
and life of the ai /hyd aulic pump. An inline ai filte and
lub icato is equi ed and must be maintained. Failu e to
do so may esult in damage to the unit and is not cove ed
in the wa anty.
Ste 1. REMOVE THE SHIPPING PLUG AND
INSTALL THE BREATHER CAP BEFORE OPERATION.
The shipping plug must be replaced with the breather cap before operating the
crusher. Failure to do so may result in damage.
The shipping plug is located on the top of the hydraulic fluid reservoir inside the
top of the aluminum cabinet.
1. Remove the cabinet top.
2. The shipping plug is located to the right rear of the cabinet. Remove the
shipping plug by turning it counterclockwise.
3. Install the breather cap turning it clockwise until finger tight.
4. Replace the cabinet top.
Ste 2. Mounting Options
Floo Stand
1. Remove the floor stand from the shipping carton. No assembly is required.
2. Position the crusher on the stand lining up the four holes and secure with the
nuts and bolts provided.
Wall B acket
1. Install wall bolts (not included).
2. Mount bracket to the wall.
3. Position the crusher on the wall bracket lining up the four holes and secure
with the nuts and bolts provided.
Ste 3. Install drain fitting hos and catch
contain r
1. Thread the 1” x 4” drain fitting into the drain coupling on the underside of the
unit.
2. Push the 1” I.D. drain hose onto the fitting.
3. Position a catch container under the unit (not included). A 5-gallon bucket is
recommended.
Ste 4. Install th filt r/r gulator/lubricator and
conn ct air supply
1. Fill the lubricator bowl with SAE30 oil prior to installing the assembly on the
crusher.
2. Install the filter/regulator/lubricator assembly into the air inlet on the side of
the crusher.
3. Open the door to the crushing chamber prior to connecting the air supply.
4. Connect the air supply. It is recommended that the air regulator is to be set
at 85 psi but not to exceed 100 psi.
Ste 5. Op ration
1. Place one filter in the crushing chamber with the open end of the filter facing
downward within the area surrounded by the six centering posts.
2. Close the door to activate the crushing cycle. When the unit stops running or
runs noticeable slower, the crushing cycle is complete. (Note - the crusher
will not operate with the door open.)
3. Raise the door and carefully remove the crushed filter.

Assembly Instructions
Checklist Of Components
Your filter crusher was shipped with the following components. Please be sure
you receive them as listed below. Contact us if anything is missing.
Item No. Desc iption Qty.
1 … … … … … … … …Top Cover Guard … … … … … … …1
2 … … … … … … …1” x 4” Drain Fitting … … … … … …1
3 … … … … … … …1” x 1ft. Drain Hose … … … … … …1
In addition, any air filter/regulator/lubricator is required in
order for the unit to o erate ro erly. Item no. FRL-1 is avail-
able from JohnDow.
IMPORTANT!
Good ai quality is impo tant fo optimum pe fo mance
and life of the ai /hyd aulic pump. An inline ai filte and
lub icato is equi ed and must be maintained. Failu e to
do so may esult in damage to the unit and is not cove ed
in the wa anty.
Ste 1. REMOVE THE SHIPPING PLUG AND
INSTALL THE BREATHER CAP BEFORE OPERATION.
The shipping plug must be replaced with the breather cap before operating the
crusher. Failure to do so may result in damage.
The shipping plug is located on the top of the hydraulic fluid reservoir inside the
top of the aluminum cabinet.
1. Remove the cabinet top.
2. The shipping plug is located to the right rear of the cabinet. Remove the
shipping plug by turning it counterclockwise.
3. Install the breather cap turning it clockwise until finger tight.
4. Replace the cabinet top.
Ste 2. Mounting Options
Floo Stand
1. Remove the floor stand from the shipping carton. No assembly is required.
2. Position the crusher on the stand lining up the four holes and secure with the
nuts and bolts provided.
Wall B acket
1. Install wall bolts (not included).
2. Mount bracket to the wall.
3. Position the crusher on the wall bracket lining up the four holes and secure
with the nuts and bolts provided.
Ste 3. Install drain fitting hos and catch
contain r
1. Thread the 1” x 4” drain fitting into the drain coupling on the underside of the
unit.
2. Push the 1” I.D. drain hose onto the fitting.
3. Position a catch container under the unit (not included). A 5-gallon bucket is
recommended.
Ste 4. Install th filt r/r gulator/lubricator and
conn ct air supply
1. Fill the lubricator bowl with SAE30 oil prior to installing the assembly on the
crusher.
2. Install the filter/regulator/lubricator assembly into the air inlet on the side of
the crusher.
3. Open the door to the crushing chamber prior to connecting the air supply.
4. Connect the air supply. It is recommended that the air regulator is to be set
at 85 psi but not to exceed 100 psi.
Ste 5. Op ration
1. Place one filter in the crushing chamber with the open end of the filter facing
downward within the area surrounded by the six centering posts.
2. Close the door to activate the crushing cycle. When the unit stops running or
runs noticeable slower, the crushing cycle is complete. (Note - the crusher
will not operate with the door open.)
3. Raise the door and carefully remove the crushed filter.

™
WARNING
This filte c ushe is designed to c ush one filte at a time.
Any attempt to c ush mo e than one filte may
esult in damage and is not cove ed in the wa anty.
WARNING
Do not ope ate the c ushe without a filte in the c ushing cambe .
PREVENTATIVE MAINTENANCE
1. Keep the in-line air lubricator filled with oil. (SAE 30 motor oil is recommended.)
2. Check the level of hydraulic fluid in the reservoir every 90 days. The fluid level
should be within 1/2” of the top. se only high grade hydraulic fluid.
3. Periodically check the hydraulic line connections for tightness.
4. Periodically check the pressing plate for tightness.
5. Inspect the drain holes at the bottom of the crushing chamber and remove any
debris or restrictions.
For Service
Phone Toll-Free
1-800-433-0708
JohnDow Industries, Inc.
151 Sn der Ave.
Barberton, OH 44203
Oil Filter Crushers
Models No.
AFC-100-94
HDC-150-94
Owners Manual
AFC-100-94
HDC-150-94
REV 9/16
