JOMISE G812 User manual

G812
User Manual
Notice: To avoid product loss caused by improper operation, please read the safety
information of all operating instructions in this manual before using this product.
123
45678
9 10 11 12 13
14 15 16 17 19
20
Version: V1.0

CATALOG
123
45678
9 10 11 12 13
14 15 16 17 19
20
PRECAUTIONS 1
SPECIFICATION 2
PACKAGE CONTENTS 3
INSTALLATION 4-10
PRODUCT OVERVIEW 11-12
SETTINGS 13-19
TROUBLESHOOTING 20

PRECAUTIONS
● Please read this manual carefully before operation and
keep it for future reference. It will be helpful should you
encounter any operational problem.
● Improper installation will void the manufacturer's warranty.
The installation instructions do not apply to all types of
vehicles and are written as guidelines to assist in installing the
system.
● Consult an experienced technician if you are not comfort-
able installing the product.
● Please make sure to read and understand call local laws
and regulations regarding cameras and their use in a vehicle.
Laws vary by state.
● Do not obscure the view of the road ahead or impede the
deployment of any airbags in the event of an accident.
● When not in use, please disconnect the car adaptor from
both the12/24V DC outlet in your vehicle and the device itself.
● Only clean the device with a soft dry cloth, for tough dirt,
apply some neutral detergent diluted in 5 to 6 parts water to a
soft cloth.
● Note that alcohol, thinner, benzene, etc could cause
damage to the paint or coatings.
● Avoid making contact with the Lens as damage may be
caused.
● The video recordings made by this Digital Video Recorder
are intended for personal use only.
● Whilst driving, do not adjust the controls of your device as
this is a distraction to driving.
11 2 3
45678
9 10 11 12 13
14 15 16 17 19
20

SPECIFICATION
Item Name 11″ Stream Media Mirror Dash Camera
Model JOMISE G812
Screen Size 11″ IPS Touch Screen
Display Resolution 1920 x 480P
Recording Resolution Front Camera: 1920 x 1080P
Rear Camera: 1920 x 1080P
Lens Front Camera: F1.8 170°
Rear Camera: F2.0 150°
Recording Format TS
Photo Format JPG
Memory Card 32G~128G U1 Micro SD card
Storage Temperature -40℉~176℉
Operating Temperature -4℉~158℉
Product Weight
Item Dimension
2.31 lb
10.1 x 2.9 x 1.7 (in)
Power Interface Type-C 5V/3A
123
45678
9 10 11 12 13
14 15 16 17 19
20

PACKAGE CONTENTS
JOMISE G812 Mirror Dash Cam
Backup camera
cable (21ft) *1
GPS Receiver
1 2 3
45678
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
WARNING
● Please MAKE SURE to connect all cameras and wires BEFORE power
ON the Mirror Screen, otherwise, the camera cannot work properly.
● Please follow the instructions below for the first-time installation of the
Stream Media Mirror Dash Camera. lt is designed to be fitted to the
existing rear-view mirror using the straps.
Insert Micro SD Card
Insert the Micro SD Card into the stream media mirror dash camera,
taking care that the gold contacts are facing towards the backside of the
stream media mirror dash camera. Push the memory card until it clicks
into the slot.
123
45678
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Insert Micro SD Card
● Use the edge of a small coin ( or similar object ) to push the memory
card into slot if required. Take care that the card has clicked into slot, a
second push inwards will release the memory card.
● Do not remove or insert the memory card when the Mirror Dash Cam
is turned on. This may damage the memory card.
● Take care when removing the SD card from the Mirror Dash Cam
when it is installed in the vehicle. Due to the card slot mechanism, the
card will spring from the slot when released.
● Periodically reformat the memory card. Every 2-3 weeks we
recommend that you reformat the memory card. This will wipe any files
from the card and set it up afresh for continued use with your Mirror
Dash Cam.
● Of course, you should only do this after you've downloaded any files
from the SD card that you may want to keep, as formatting the card will
remove all content.
● Format your memory card using the Mirror Dash Cam. This will make
sure that the card is structured specifically for your camera.
● Press to enter into the setting and choose the Format Card option
to follow the on-screen instructions accordingly.
Notice:
123
45 6 7 8
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Mount the Mirror Dash Cam
Step 1: Attach the upper end of the straps to the retaining hooks on the
top of the rear-view mirror.
Step 3: Extend the straps around the back of the rear-view mirror and
attach them to the bottom retaining hooks.
Step 2: Pull out the front lens of the JOMISE G812 to match the
rearview mirror of the vehicle.
123
4 5 6 7 8
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Rear Camera Installation
Use the provided double-sided tape or screws to fix rear camera. The
angle can be adjusted, so be sure to find a perfect viewing angle for
your camera before fix it.
▼ Install inside the vehicle
▼ Install outside the vehicle
123
4567 8
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Rear Camera Installation
● Make the connection first and ensure the machine work well before
installing.
● Keep away with the driving operation and the active part of the car.
Do not get caught by screws or seat gaps.
● When drilling holes in car, please do not break the vibrator, tank and
wires.
● Before attaching the double-sided tape, please remove stain or oil
with alcohol cleaner from the surface.
● When temperature is low, please warm up the mounting surface with
dryer, in order to improve the adhesion before sticking.
● The provided 3M sticker cannot be reused, or the adhesion will not
be strong enough.
● Do not disassemble or change any part of this product, this will not
be covered by warranty.
Notice:
123
45678
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Wiring Images
GPS Receiver
Car Charger
Red wire Connected to
the reversing lamp positive
Rear Camera
Backup Camera
Connecting Wiring
123
45678
9 10 11 12 13
14 15 16 17 19
20

INSTALLATION
Wire Layout in the Vehicle
Step 1: The car charger is connected to the cigar socket.
Step 2: Connect JOMISE G812 to the car charger.
Step 3: Connect the rear camera cable with the mirror dash cam along the
car body, by joining the pillar inside to the rear camera.
123
45678
910 11 12 13
14 15 16 17 19
20

PRODUCT OVERVIEW
Appearance Description
123
45678
9 10 11 12 13
14 15 16 17 19
20
Front Camera
Rear Camera Port
GPS Port
Micro SD Card Slot
Power Supply Port
Screen 11 inch IPS touch screen
Short press to turn off the screen, long press to turn off the power.
Power Button
Fasteners
Record the front view of the vehicle.
Connect the GPS receiver.
Connect the car charger.
Please use the silicone strap that comes with the
Insert a Micro SD card (maximum support 128G).
Connect the rear view camera.
⑧
⑦

PRODUCT OVERVIEW
①Recording
②Date & Time
④ Playback
③ Settings
⑤ Start / Pause Recording
⑥ Snapshot
⑦ Front / Rear Image Switch
⑧ Lock / Unlock
⑨ Speed
⑩ Driving Direction
⑪ Screen Brightness Adjustment
Notice: You need to pause recording before entering into settings.
123
45678
9 10 11 12 13
14 15 16 17 19
20
N
0 mph
12:25
2021-04-16Fri
1
BL
01:39
⑨
⑩
⑪

SETTINGS
● Loop Time: Set the video recording loop time.
- 1 Min
- 2 Mins
- 3 Mins
● Resolution: Adjust the resolution of the video recording.
- 1080P
- 720P
● Audio Recording: Turn on/off audio recording.
● Power Off: Automatic shut-down.
- Off
- 1 Min
- 2 Mins
- 3 Mins
● Clock Settings: Set the current time and date. This function allows
for manual time setting if GPS is not available. Once a GPS signal is
received, the time and date will be updated automatically.
● Time format: Set the 12H/24H time display format according to
usage habits.
- 12-Hour Time
- 24-Hour Time
● Language: Set the language.
123
45678
9 10 11 12 13
14 15 16 17 19
20
12:25
2021-04-16Fri
Power Off
Clock Settings
Time format
Language English
Off
12-Hour Time
12:25
2021-04-16Fri
Loop Time
Resolution
Audio Recording
Power Off
1 Min
1080P
ON
Off

SETTINGS
● Volume setting: Turn on/off the volume.
● Frequency: Set the screen refresh frequency.
- 50 Hz
- 60 Hz
● Screen Saver: Set the screen saver time.
- Off
- Display Off
- Low brightness
- Time and Date
● G-Sensor: Select the sensitivity of the G-Sensor or turn it off. The
locked files will not be overwritten. Please copy important locked files to
your computer for storage, and format the SD card regularly.
- Off
- High
- Middle
- Low
● Parking Monitoring: Start the parking guard function (according to
the preset G-Sensor sensitivity, the emergency video recording is
automatically started after the vehicle is shaken, this function requires a
hard-wired kit to be used normally).
- Off
- High
- Middle (Recommend preset level).
- Low
123
45678
9 10 11 12 13
14 15 16 17 19
20
12:25
2021-04-16Fri
Volume setting
Frequency
Screen Saver
G-Sensor
60Hz
Off
Off
ON
12:25
2021-04-16Fri
Parking Monitoring
Time Zone
Volume setting
GPS Information
GMT-08:00
Off

SETTINGS
● Time Zone: Select the time zone of your location. The system will set
a date and time according to the GPS location.
● Volume setting: Set the volume.
● GPS Information: Show the Longitude, Latitude, and other GPS
information.
● GPS Disp: Turn on/off the display of GPS information on the recording
interface.
● Speed Unit
- MPH
- KM/H
● Over speed remind: You can set 20mph-100mph Overspeed warning,
when the speed reaches the preset speed, JOMISE G812 will beep to
remind the driver (this function needs to be connected to the GPS module).
● Vertical Flip: Vertically flip the view of the rear camera.
● Rear Cam Mirror Image: Mirror flip the rear camera view.
● Show reversing line: To display the reversing guideline, you need to
connect the trigger wire (red wire) at the end of the rear camera to the
positive pole of the reverse lamp.
● Reversing auxiliary line calibration: You can adjust the reversing
guideline according to the actual environment.
● Reset Setup: Restore the initial settings.
123
45678
9 10 11 12 13
14 15 16 17 19
20
12:25
2021-04-16Fri
GPS Disp
Speed Unit
Over speed remind
Vertical Flip
MPH
OFF
ON
ON
12:25
2021-04-16Fri
Rear Cam Mirror Image
Show reversing line
Reversing auxiliary line calibration
Reset Setup
ON
ON

SETTINGS
● Format SD-Card: Clear all data files on the Micro SD card (please
save important video files before formatting, and format the Micro SD
card regularly).
● FW Version: View the firmware version information.
123
45678
9 10 11 12 13
14 15 16 17 19
20
12:25
2021-04-16Fri
Reversing auxiliary line calibration
Reset Setup
Format SD-Card
FW Version JOMISE_G810_53_20220228G

SETTINGS
Brightness Adjustment
Touch the pointed area first, a scrollbar will come out, then slide to left or
right (+/-) to adjust the brightness.
123
45678
9 10 11 12 13
14 15 16 17 19
20

Data Playback
To select a video or photo for playback, press the button.
Slide to select the desired file form the list and then press the file name
to start playback.
123
45678
9 10 11 12 13
14 15 16 17 19
20
SETTINGS
18
00:00 03:00
1/25
00:00 01:00
JOMISE
2020-04-21 18:11:05
