Jonsered GT21 L Guide

SERVICE
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
I0200084
IPL, GT21 L, 2002-08, 106 29 60-61
GT21 L
106 29 60-61

WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
RR
POULAN PRO PARTS LIST
PARTS LIST 1
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
530084489 GT21L
DATE
8/07/02 REPLACES
530084489--1/31/02
=NEW PART NUMBER FOR THIS IPL
n
All repairs, adjustments
and maintenance not de-
scribed in the Operator’s
Manual must be performed
by qualified service per-
sonnel.
WARNING
14
6
5
12
10
3
8
7
23
22
26
20
13
15
16
17
18
19
11
1. 530402025 Throttle Housing (Right)
2. 530402028 Throttle Lock
3. 530069572 Kit--Switch
4. 530015886 Screw
5. 530402026 Throttle Housing ( Left)
6. 530094673 Handle
7. 530016118 Wingnut
8. 530094742 Clamp--Assist Handle
9. 530015820 Bolt
10. 530047307 Assy--Throttle Leadwire
11. 530042093 Spring--Lever Return
12. 530402027 Lever--Throttle
13. 530071423 Kit--Drive Shaft Hsg. Assy.
14. 530095176 Flex--Drive Shaft
15. 530049760 Assy--Cutting Head
(Incl. 16--19)
16. 530049761 Assy--Hub
17. 530401958 Spring--Return
18. 530401957 Retainer--Spool
19. 530095434 Assy--Spool w/Line
20. 530069666 Kit--Shield Ass’y.
(Incl. 22,23,24 & 26)
21. 530031159 Hex Wrench (5/32)
22. 530052286 Line Limiter
23. 530015814 Screw
24. 530015820 Bolt--Shield
25. 530094543 Dust Cup
26. 530016118 Wingnut
-- Operator’s Manual
530088139 Europe
530088140 Scandinavia
530054766 Decal--Shaft Warning
530038070 Instruction Decal
Ref. Part No. Description Ref. Part No. Description
Not Shown
24
9
21
24 1
25

WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
RR
POULAN PRO PARTS LIST
PARTS LIST 2
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
530084489 GT21L
DATE
8/07/02 REPLACES
530084489--1/31/02
1. 530042085 Spring--Starter
2. 530016224 Screw
3. 530053985 Retainer
4. 530015934 Screw
5. 530027569 Handle--Starter
6. 530015810 Screw
7. 530069616 Gasket--Cyl/Carb (kit)
8. 952030249 Spark Plug(RCJ--6Y)
9. 530069616 Gasket--Carb. (kit)
10. 530015941 Retain. Ring--C’shaft
11. 530015675 Screw (Used with old
style muffler guard )
12. -- -- -- Muff l er Guard
530037045 old style
530054536 new style
13. 530069886 Assy--Flywheel
14. 530039163 Ignition Module
15. 530036145 Spacer--Ignition Mod.
16. 530015954 Screw
17. 530015828 Washer--Flat
18. 530027953 Coupling--Drive
19. 530054753 Assy--Crankshaft
20. 530069615 Kit--Conn. Rod Assy
21. 530036404 Piston Ring
22. 530012414 Assy--Crankcase
23. 530032125 Inner Bearing
24. 530032124 Outer Bearing
25. 530019179 C’case Seal
26. 530015945 Retain. Ring C’case
27. 530036578 Muffler Body
28. 530036577 Muffler Cover
29. 530038602 Muffler Baffle--Exit
30. 530036579 Muffler Baffle--First
31. 530042088 Muffler Spring
32. 530047491 Assy--Fan Housing/
Rear Shroud
33. 530069616 O--ring--C’case (kit)
34. 530069619 Kit--Cylinder
35. 530047659 Carb. Adaptor
36. 530016014 Screw
37. 530069616 Gasket--Cylinder (kit)
38. 530069665 Kit--Carburetor Assy
w/ Limiter Cap
39. 530054554 Air Box
40. 530037326 Choke Mounting Plate
41. 530038102 Choke Shutter
42. 530015254 Washer
43. 530015852 Choke Spacer
44. 530015887 Screw
45. 530037413 Filter Plate
46. 530037331 Air Filter Foam
47. 530037292 Air Box Cover
48. 530015957 Screw
49. 530071548 Assy--Throttle Cable
50. 530015780 Screw
51. 530069862 Assy--Fuel Tank
52. 530036793 Isolator--Shroud
53. 530036792 Isolator--Crankcase
54. 530069599 Kit--Line
55. 530014347 Assy--Fuel Cap
56. 530095646 Assy--Fuel Pickup
57. 530069616 Kit--Engine Gasket
58. 530014729 Assy--C’case & C’shaft
(Incl. 10,19,22--26)
59. 530047278 Assy--Switch Wire
60. 530015953 Screw
61. 530015767 Screw
62. 530015768 Locknut
63. 530038874 Bulb Ass’y.--Air Purge
64. 530069232 Kit--Rope
65. 530016080 Screw
66. 530069400 Kit--Starter Pulley
67. 530071391 Kit--Spark Arrestor
68. 530015162 Piston Pin Retainer
69. 530069621 Kit--Piston
(Incl. 21,68 & Pin)
70. 530071396 Kit--Muffler
71. 530069571 Kit--Fuel Line
1
23
4
5
6
7
8
9
10
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
2728 29 30
31
32
33
35 36
37
38 39
40 41
42
43
44
45
46 47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
=NEW PART NUMBER FOR THIS IPL
n=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
6
Spark
Arrestor
Kit
67
69
70
Engine
Gasket
Kit
71
68
34
32
54
70
New Style
11
n

WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
RR
POULAN PRO PARTS LIST
PARTS LIST 3
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
530084489 GT21L
DATE
8/07/02 REPLACES
530084489--1/31/02
1. 530069838 Carburetor Repair Kit
( KIT=Indicates Contents)
2. 530038403 Limiter Cap
3. 530069844 Gasket/Diaphragm Kit
(DIndicates Contents)
4. 530035341 Needle
5. 530035342 Spring
Ref. Part No. Description
=NEW PART NUMBER FOR THIS IPL
n=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
D
K
=THESE PARTS ARE ILLUSTRATED FOR CLARITY. ORDER COMPLETE ASSEMBLY.
1
Carb.
Repair
Kit
Carburetor Assembly #530069665 --- WA227
2
Gasket/
Diaph.
Kit
3
KIT
KIT
KIT KIT
KIT
KIT D
KIT D
KIT D
KIT D
4
5
n
