Jonsered GC2126C Guide

SERVICE
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
IPL, GC2126 C, 2008-06, 545 01 43-96
GC2126C
545 01 43-96

Replaced
545014396 - 9/28/07 NOTE : Illustration may differ from actual model due to design changes.
545014396
2/08/08 Page:
PARTS LIST
R
GC2126C
1
Parts List No.
Date
MODEL
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by Qualified Service
Personnel.
4
1
10
3
2
5
6
16
12
20
21
13
19
17
14
15
18
22
11
30
31
33
32
34
24
23
78 9
25 27
26
28
29
36
37
38
545096801 Decal-Warning (upper)
545143401 Decal-Warning (lower)
1. 545125301 Assy-Cable/Wire Harness
2. 545072001 Trigger
3. 545024202 Housing-Throttle (RH)
4. 530016448 Screw
5. 530016449 Screw
6. 530016454 Spring-Trigger
7. 545072102 Throttle-Lockout
8. 545045601 Spring-Lockout
9. 545071801 Housing-Throttle (LH)
10. 545030601 Kit-Switch
11. 545006070 Kit-Upper Driveshaft
(Incl. flex & 22)
12. 545056601 Clamp-Harness (lower)
13. 530015940 Screw
14. 545113301 Clamp-Harness (upper)
15. Screw
16. Nut - Square M6
17. Screw
18. Knob
19. Assy - Loop Handle w/J handle
20. Handle - J - Plastic
21. Spacer
22. 503200725 Screw-Clamp
23. 545006071 Kit-Lower Driveshaft
(Incl. flex, 28,29,31,33)
24. 537216201 Harness-Shoulder
25. 545081703 Kit-Shield
(Incl. 26,27,30)
26. 530052286 Limiter-Line
27. 530015814 Screw
28. 530016014 Screw
29. 545003902 Screw
30. 530015771 Screw
31. 530057554 Bracket-Shield
32. 502285901 Pin-Locking
33. 530096295 Assy-Gearbox
34. 537234901 Driver Disc
36. 503890101 Cup-Support
37. 537285601 Support - Flange
38. 503856301 Locknut - Blade
Ref. Part No. Description Ref. Part No. Description
= New Part Number For This IPL = Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
Ref. Part No. Description
Not Shown

545014396
2/08/08
Replaced
545014396 - 9/28/07 Page:
PARTS LIST
R
GC2126C
2
Parts List No.
Date
MODEL
NOTE : Illustration may differ from actual model due to design changes.
1
2
3
18
17
16
1514
13
11
61 60
64
65
66
67
6869
62
63
10
9
8
7
6
5
4
20
19
21
22
24 23
25
27
26
32
28
29
30
33
34
35
39
40
41
43
46 47
50 51
53
55
70
Gasket
Kit
56
57
58
59
52
54
44 45
42
36
37
38
12
31
48
49
Ref. Part No. Description Ref. Part No. Description
Ref. Part No. Description
1. 530150253 Filter
2. 530016101 Nut-Carb. Screw
3. 545071701 Air Box
4. 530057844 Lever - Choke
5. 545050402 Kit-Carb. Gasket (Incl 7,65)
6. 530035596 Adaptor-Carb.
7. 545030101 Kit-Gasket (foam)
8. 530016400 Bolt
9. 545001001 Cylinder
10. 952030201 Plug-Spark (RCJ-8Y)
11. 545050403 Kit-Crankshaft seal
12. 530016475 Washer-Starter
13. 545160301 Spring-Starter Cup
14. 545102302 Assy-Starter Cup
15. 530059800 Coupling-Starter
16. 530095646 Assy-Fuel Filter
17. 545081897 Kit-Fuel Line
18. 545073101 Assy-Cap w/ret.(Incl. 19)
19. 530019293 O-ring - Fuel Cap
20. 545105107 Assy-Fuel Tank
(Incl. 16,17,18,19)
21. 545065201 Shroud-Rear
22. 530016448 Screw
23. 545029901 Kit-Rope
24. 545043201 Handle-Starter
25. 530016426 Screw
51. 530016470 Screw
52. 530015768 Nut
53. 530016456 Screw
54. 545072901 Assy-Fan Housing
55. 530150039 Assy-Clutch Drum
56. 545050405 Kit-Clutch Assy.
57. 530057852 Spacer
58. 530039242 Flywheel
59. 545054601 Crankcase
60. 545013401 Bearing
61. 545030001 Kit-Crankshaft
62. 530015162 Retainer-Piston Pin
63. 530019283 Ring-Piston
64. 545030301 Kit-Piston (Incl. 62,63)
65. 545030101 Kit-Gasket (adaptor seal)
66. 530015897 Screw
67. Kit-Carb. (Incl. 4,5)
68. 545071901 Cover-Air Box
69. 545072201 Assy-Knob
70. 545030101 Kit-Gasket
(Incl. 5,7,11,19,41,65)
530058709 Bulb-Purge
= New Part Number For This IPL = Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
26. 530016449 Screw
27. 545104401 Starter Hsg. w/eyelet
28. 545029801 Kit-Starter Spring
29. 545029701 Kit-Starter Pulley
30. 530016468 Screw
31. 545102701 Assy-Starter Hsg.(Incl.
23,24,27,28,29,30)
32. 545071601 Plate-Wear
33. 530059780 Isolator-Tank
34. 530058982 Bolt-Muffler
35. 530015496 Screw
36. 530150440 Shield-Heat
37. 530016449 Screw
38. 545065401 Guard-Muffler
39. 545030501 Kit-Spark (Incl. 35)
40. 545057501 Assy-Muffler
41. 530057848 Gasket-Paper Metal
42. 530015897 Screw
43. 545046701 Module
44. 530039227 Assy-Leadwire
45. 530016456 Screw
46. 530016463 Washer
47. 530094189 Washer-Clutch
48. 545173401 Bearing - Thrust
49. 530016420 Washer - Thrust
50. 530016469 Screw
Not Shown

Replaced
545014396 - 9/28/07 NOTE : Illustration may differ from actual model due to design changes.
545014396
2/08/08 Page:
PARTS LIST
R
GC2126C
3
Parts List No.
Date
MODEL
Service Reference
Note : Due to product improvements, your unit may have a different assist handle.
Please refer to the serial number on your unit and order the parts below.
Serial Number - 07202N and lower, please use the following parts:
Ref.# 1 - 530015820 - Bolt
Ref.# 2 - 545180810 Kit - Loop Handle w/”J” Handle (Includes hardware)
Ref.# 3 - 530059185 Handle Clamp
Ref.# 4 - 530016152 Wingnut
Serial Number - 07203N and higher, please use the following parts:
Page 1, Ref.# 15 - 503217516 Screw
Page 1, Ref.# 16 - 502197101 Nut - Square M6
Page 1, Ref.# 17 - 725238051 Screw
Page 1, Ref.# 18 - 503879001 Knob
Page 1, Ref.# 19 - 545144302 Assy - Loop Handle w/”J” Handle
Page 1, Ref.# 20 - 503997802 Handle “J” Plastic
Page 1, Ref.# 21 - 503940302 Spacer
1
2
15 16
17
18
19
20
21
Service Reference
Note : Due to product improvements, your unit may have a different carburetor.
Please refer to the serial number on your unit and order the parts below.
Serial Number - 07202N and lower, please use the following parts:
Page 2, Ref.# 67 - 545006060 Kit - Carburetor
Serial Number - 07203N and higher, please use the following parts:
Page 2, Ref.# 67 - 545081850 Kit - Carburetor
3
4
