Joy-it RB-LCD10-2 User manual

RB-LCD10-2
10,1"-Touchscreen Display Manual
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product. In fol-
lowing, we will introduce you to what to observe while
starting up and using this product.
Should you encounter any unexpected problems dur-
ing use, please do not hesitate to contact us.

2. ASSEMBLY OF DISPLAY
2.1 Assembly of the Display
Take out the display, the foot and the socket neck from
the package. Insert the metallic rectangle of the socket
neck into the matching conduction on the display case
(near the USB imprint).
Fixate the socket neck by tightening the round washer,
which is located directly in front of the metallic rectan-
gle.
Now insert the socket neck into the foot and tighten it
with the provided screws.

2.2 Assembly of a Raspberry Pi
If you wish to operate the display with a Raspberry Pi ,
you can use the mounting platform provided for this
purpose. Remove the provided mounting platform and
attach your Raspberry Pi onto it.
Aer you have fixated your Raspberry Pi, place the
mounting plate on the back of the display and mount it
to it (screw holes 9 - Vesa).
The display is now completely assembled and should
correspond to the following picture.

2.3 Connection to a device
First, plug the power supply into the display. Then, con-
nect the display with the device, which should be used,
using the HDMI cable.
To use the Touch functions as well, the display must also
be connected with the device to be used with the pro-
vided USB cable.
!Caution! Do not confuse the USB ports! You
have to use the port with the imprint "touch" on
the display to be able to use the touch functions.

3. USAGE OF THE DISPLAY
3.1 Installation of soware
Install the LCD image on your SD card with the help of
the „Win32 Disk Imager“-program, which you can find
as preinstalled Raspbian system for your Raspberry Pi
as download by the following link:
hps://joy-it.net/de/products/RB-LCD10-2
3.2 Manual Installation & Calibration (experienced
user)
-Usage with a Raspberry Pi 4:
For the usage with a Raspberry Pi 4, a setting in „/boot/
config.txt“ must be edited. For this, please enter the
sudo nano /boot/config.txt
1. Choose Image 2. Choose
Device
3. Write SD card with

following command:
Below the Point [pi4], you have to comment out fol-
lowing command: dtoverlay=vc4-fkms-v3d. This
should look like the following:
If you do not want to use our prepared Image or inte-
grate the display into an existing system, you can also
install the display manually, of course.
First, connect the both devices with the provided HDMI
cable. Connect both the display and the Raspberry Pi
with the matching power supplies.
[pi4]
# Enable DRM VC4 V3D driver on top of the
dispmanx display stack
#
#dtoverlay=vc4-fkms-v3d
max_framebuffers=2
<- This setting has to
be commented out
with #
!Caution! When starting the display for the first
time, the Raspberry Pi has to be started AFTER
the Display! Otherwise, the transmission of pic-
ture data will not function.

In order to display the image correctly when the display
is started with the Raspberry Pi, the „config.txt“-file has
to be edited first. Open it with the following command:
Now enter the following lines at the end of the file.
Aerwards, you can save the file using the key combina-
tion CTRL+O and exit the file with the combination
CTRL+X.
Now install the Touchscreen driver with the following
command:
To ensure, that the installed drivers are always initial-
ised aer the existing drivers, please copy the configu-
ration file with the following command (please write
the command in one line !):
Next, the calibration tool can be installed and started
with the following command:
sudo nano /boot/config.txt
hdmi_force_hotplug=1
hdmi_group=2
hdmi_mode=27
sudo cp /usr/share/X11/xorg.conf.d/10-
evdev.conf /usr/share/X11/xorg.conf.d/45-
evdev.conf
sudo apt-get install xserver-xorg-input-evdev
sudo apt-get install xinput-calibrator

Then restart your Raspberry Pi:
Before your can start the calibration tool, you have to
create the file for the calibration settings (please write
the command in one line !):
Now enter the following settings in this file:
Restart your Raspberry Pi then:
Now you can start the calibration tool with the follow-
ing command (please write the command in one line !):
The display will now show four consecuting points that
you will have to press. Aer that, four calibration val-
ues will be outputted to you, which you must enter in
sudo reboot
sudo nano /usr/share/X11/xorg.conf.d/99-
calibration.conf
sudo reboot
Section "InputClass"
Identifier "calibration"
MatchProduct "eGalax Inc. USB TouchController"
Option "Calibration" "4094 -35 4026 10"
Option "SwapAxes" "1"
EndSection
xinput_calibrator --device "eGalax Inc.
USB TouchController"

the previously created file „99-calibration.conf“.
For this, please enter the following command (in one
line):
Enter the following content here and amend the four
values of the "calibration" option with those, which
have been outputted to you in the previous step:
Finally, you have to restart the Raspberry Pi for the last
time:
Now the Touch function is ready to use.
Section "InputClass"
Identifier "calibration"
MatchProduct "eGalax Inc. USB TouchController"
Option "Calibration" "4094 -35 4026 10"
Driver "evdev"
EndSection
sudo nano /usr/share/X11/xorg.conf.d/99-
calibration.conf
sudo reboot

3.3 Usage with a desktop PC
Connect the display with the provided power supply.
Then, connect your computer with the display, using
an HDMI– or VGA-cable, depending on your preference.
You can further connect your computer with the Touch
interface using the USB cable, if the operation via
Touchscreen is desired.
This requires an additional driver installation though.
The drivers for the Touch function can be found on this
website.
In order to ensure the touch function of the display
even when using several screens, the multiple moni-
tor function must be activated in the eGalax Touch
program.
For this, please first open the program:
!Attention! On some systems, it may happen that the the lastest drivers are not fully func-
tional. In this case, better results can be
achieved with older drivers. You can download
an older driver here.

Aerwards, choose the tab "Display" :

Now activate the multiple monitor function:
Aer activation, you will be prompter to perform anoth-
er calibration. If this does not take place automatically,
please proceed as follows:

Select the Tab "Tools" :

Now please click on 4-Point-Calibration, to perform a
new calibration:
If there is a problem arising with the detection of the
USB- touch screen drivers, the eGalax Touch driver
must be uninstalled and reinstalled.
During the installation, make sure that you have the
USB cable connected with the computer and the Touch
interface of the display.
Then you have finished the set-up.
