Joyside Z01A Series User manual

1
INSTRUCTION MANUAL
Joyside FIRE PIT
Series Z01A（Black）
IF YOU PURCHASED THE GREENHOUSE ONLINE AND HAVE ANY
QUESTION OR CONCERNS
PLEASE CONTACT US WITH EMAIL OR WHATS APP
[e-mail]
WhatsApp QR Code

2
WARNINGS:
This fire bowl is intended for outdoor use only. Do not use on wooden decks.
This fire bowl is intended to burn wood logs only. Do not burn coal, leaves, or other combustible materials in the fire
bowl.
Not for use by children. Keep children and pets away from the fire bowl.
The fire bowl is hot. Use with caution. Do not touch the hot fire bowl with bare hands.
Never leave the burning fire bowl unattended, and always extinguish the fire completely before leaving the fire bowl.
Do not use near flammable or combustible objects or materials.
When the fire bowl is in use, the handle on the mesh screen can reach extreme temperatures that can cause serious
injury to an unprotected hand. Use a poker or an appropriate heat resistant glove or pad when handling.
Check local fire regulations and municipal by-laws for safe use.
Some parts may contain sharp edges—especially as noted in the manual. Wear protective gloves if necessary.
The metal may become very hot during and after use. Do not touch the metal or try to move the unit while hot.
Keep children away from the unit while in use until the fire is extinguished and the metal has cooled.
Do not use on a wooden surface, or on grass, near walls or flammable articles, or under overhead coverings.
Keep at least 2 feet away from all other articles during use.
Use only the fuel type(s) specified in the instructions. Using other fuel types is dangerous and could cause injury.
Do not overload the unit with fuel.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 10 minutes.

3
FIRE PIT PARTS LIST
No.
PARTS
Qty
A
Bowl
1
B
Leg
3
C
Outer ring
4
D
Extension Lever
1
E
Grill rack
1
F
Grill
1
G
Spark screen
1
J
Poker
1
K
PVC cover
1
HARDWARE LIST
No.
Hardware
Qty
S1
M8 Nut
（pre-assembled）
6
S2
M6 x 35mm Bolt
4
S3
M6 Nut
4
S4
M6 x 10mm Nut
4
S5
Butterfly Bolt
2
S6
Flat pad
(Pre- assembled)
6

4
Step By Step Assembly Instructions:
Step1: Attach Leg (B) to Fire bowl ( A ) using 6pcs pre-assembled M8 Nuts (S1) and 6pcs flat
pad (S6), then tighten all Bolts.
Step2: Attach four outer ring (C) onto the bowl outside using four M6 x 35mm Bolts (S2) and four
M6 Nuts (S3). Loosely tighten all bolts with Phillips Screwdriver and M6 wrench. Lastly attach
four M6 x 10mm bolts (S4) under the connector ,then tighten all bolts and nuts .

5
Step 3: Insert the extension lever (D) into the hole of bowl, tighten the butterfly screw (S5) to fix
the height, then insert the grill rack(E) into the extension lever on the suitable height using
butterfly screw (S5) to fix. Finally, put on a cooking grill (F) for cooking use at any time.
Step 4: For fire pit use, place spark screen (G) on top of fire bowl assembly.

6
Step 5: Place Poker (J) and PVC cover (K) beside fire pit for use as needed.
