Welcome

Thank you for purchasing the Control Center™ 540C.

Before using this product please familiarize yourself thor-

oughly with this User Guide so you fully understand the

setup procedure and functions of the product.

Note: Read your Xbox 360™ console Instruction Manual

for important safety information and health warnings. Please

retain both documents for future reference.

Package contents

Check that you have the following items:

1) Control Center 540C™

2) AV Interconnect Cable

3) Ethernet Cable

4) Remote Control

5) User Guide

6) Power Adapter

Features

Part names

1) IR Receiver

2) (On/Standby) Button and Indicator

3) Input Channel Button

4) Display Screen

5) A/V Input Channel 6

6) Recess for removing Control Centre™ 540C Faceplate

7) Display Navigation Buttons

8) Cancel / Back Button

9) Confirm / Accept Button

10) Xbox 360™ A/V Input Channel

11) A/V input Channel 2

12) A/V input Channel 3

13) A/V input Channel 4

14) A/V input Channel 5

15) A/V Multi output Channel

16) DC IN 12V power connector

17) 5 Port 10/100 Hub

1ENGLISH

123 4 5 6

789

10 11 12 13 14 15 16

Control Center™ 540C Front with Faceplate

With faceplate removed

Rear

Control Center™ 540C A/V Input Channels

and Connectors

The Control Center™ 540C has six A/V input channels

which can be used to connect an Xbox 360™ console and

up to five other AV devices to one TV.

Input Channel 1

Dedicated for use with the Xbox 360™ console as this uses

a propriety connection for carrying both audio and video

signals.

Input Channels 2 - 5

A/V connections are provided for:

composite video, component video, left and right audio, S-

video and digital optical audio.

Input Channel 6

This channel is located on the Faceplate under a

drop down panel. A/V connections are provided for:

composite video, left and right audio and S-video.

Using a composite A/V cable to connect to

your TV

Follow the diagram on the right to connect the Xbox 360™

console and Control Center™ 540C using a composite

video cable with stereo audio to your TV.

1) Connect the AV Interconnect Cable (supplied) to the A/V

connector on the rear of the Xbox 360™ console and to the

Input Channel 1 connector of the Control Center™ 540C.

2) Connect a composite AV cable (sold separately) to the

Control Center™ 540C A/V multi output and then to the TV.

A/V Multi Output Channel

The A/V multi output channel connects all of the input

channels to a TV and provides connections for:

composite video, left and right audio, component video, S-

video and digital optical audio.

About Picture Quality

TV picture quality will differ depending on the type of input

connections used. Refer to your TV instruction manual and

use the information below to determine the best connec-

tion method.

HD (High Definition) resolutions such as 480p, 720p and

1080i are only supported with the component video con-

nections.

Match the color-coded connectors of the composite AV

cable to the corresponding connectors on the rear panel of

the Control Center™ 540C and to the TV.

Note: For monaural TV’s with only one audio input con-

nector, connect either white or red connector to the audio

input of the TV.

3) Select the appropriate video input on your TV (refer to

your TV instruction manual for connection details).

2 ENGLISH

Composite S-Video Component

Best

quality picture

Standard

quality picture

XBOX360 Console 540C Control Center

TV Audio and

Video inputs

Composite AV Cable

Do not use when

connecting to a mono TV

Yellow White Red

AV Interconnect

Cable (supplied)

Using an S-video cable to connect

to your TV

Follow the diagram below to connect the Xbox 360™

console and Control Center™ 540C using an S-video

cable with stereo audio to your TV.

1) Connect the AV Interconnect Cable (supplied) to the A/V

connector on the rear of the Xbox 360™ console and to the

Input Channel 1 connector of the Control Center™ 540C.

2) Check the Control Center™ 540C is set to output an S-

video signal from input 1 (Xbox 360™ console)

Note: If you choose to connect the Control Center™ 540C

to the S-video input on your TV, you must select the S-video

setting on the Control Center™ 540C in order to display the

picture correctly. If you are connecting via S-video and you

see no picture on your TV, check the Control Center™

540C is set to output S-V. For set-up details, see the sec-

tion on Control Center™ 540C settings.

IMPORTANT: The AV output settings only need to be

adjusted for Input 1 (Xbox 360™ console). AV signals from

inputs 2 to 6 pass directly through the Control Center™

540C and are output through their corresponding connec-

tions in the multi output channel.

3) Connect an S-video cable (sold separately) to the

Control Center™ A/V multi output and then to the TV.

REMEMBER: S-video does not carry audio signals so it

must be combined with a right and left audio cable or a digi-

tal optical cable (both sold separately).

4) Select the appropriate video input on your TV (refer to

your TV instruction manual for connection details).

3ENGLISH

S-video

Video

XBOX360 Console 540C Control Center

TV Audio and

Video inputs

S-video Cable

S-Video White Red

AV Interconnect

Cable

(supplied)

Using a component video cable to connect

to your TV

Follow the diagram below to connect the Xbox 360™ con-

sole and Control Center™ 540C using a component video

cable with stereo audio to your TV.

1) Connect the AV interconnect cable to the A/V connector

on the rear of the Xbox 360™ console and the input channel

1connector on the Control Center™ 540C.

2) Slide the switch on the AV Interconnect Cable to the SD

or HD position.

The HD position should be selected if your TV supports

High Definition resolutions such as 480p, 720p and 1080i

3) Check the Control Center™ 540C is set to output a

component video signal from input 1 (Xbox 360™ console).

Note: If you choose to connect the Control Center™ 540C

to the component video input on your TV, you must select

the component video setting on the Control Center™ 540C

in order to display the picture correctly. If you are connecting

via component video and you see no picture on your TV,

check the Control Center™ 540C is set to output YUV or Y,

Pb/Cb, Pr/Cr. For details, see the section on Control

Center™ 540C settings.

4) Connect a component cable (sold separately) to the AV

multi output and the TV. Match the color-coded connectors

of the component cable to the corresponding connectors on

the rear panel of the Control Center™ 540C and to the TV.

REMEMBER: Component video does not carry audio sig-

nals so it must be combined with a right and left audio cable

or a digital optical cable (both sold separately).

5) Select the appropriate video input on your TV (refer to

your TV instruction manual for connection details).

4 ENGLISH

Pr/Cr

Pb/Cb

XBOX360 Console 540C Control Center

TV Component

Video inputs

Component Cable

Green Blue Red

AV Interconnect

Cable

(supplied)

Using a digital optical cable to connect to your

sound system

To listen to digital optical sound from the Xbox 360™ con-

sole, connect a digital optical cable to the digital optical

audio output connector at the rear panel of the Control

Center™ 540C.

Using more than one AV device with the

Control Center™ 540C

The Control Center™ 540C is designed to allow additional

connection of up to five other AV devices to one TV. Input

Channels 2 - 6 are provided for these additional devices.

The AV devices shown in the illustration are for reference

only. Any suitable AV device may be connected to Input

Channels 2 - 6. The display screen is pre-programmed with

the abbreviated names of common AV devices, such as

DVD, VCR etc. These pre-programmed channel input

names can be easily edited to suit your setup. For details

see the section on Control Center™ 540C settings. Refer

to the AV output channels on your device and TV then

select the connection method of your choice.

NOTE: Additional cables may be required to connect

all of your AV devices.

IMPORTANT:

Each input connection will only output to the same style

output connection (pass-through system). For example, a

component video cable attached to component video on

Input Channel 2 – 6 can only be viewed via the component

video output and CAN NOT be displayed via the S-video,

composite video or stereo audio outputs.

REMEMBER: Component video and S-video connections

do not carry audio signals, so it must be combined with a

right and left audio cable or a digital optical cable.

Connecting the Power Adapter

1) Connect the Power Adapter to the DC 12V input connec-

tor located on the rear of the Control Center™ 540C.

2) Plug the Power Adapter into a power outlet.

NOTE: In some territories your Power Adapter may include

additional regional adapters designed to comply with your

local domestic power outlets.

If these are supplied, slide the appropriate regional adapter

into the Power Adapter as shown:

5ENGLISH

Xbox TM

360

Câble/Satellite

VCR

Camcorder/

Caméscope

DVD

Typical multi device setup:

Control Center™ 540C settings

It is possible to change individual settings on the Control

Center™ 540C. Settings that can be adjusted include the

following:

CH1 OUT - output configuration

LIGHT – changes backlight

INVERT - display text color invert

BRIGHT - display brightness

SPEAKER - audible bleep

RESTORE - restore factory default settings.

CH NAME - channel input names

To change settings:

1) Ensure the Control Center™ 540C is switched ON.

2) Carefully remove the Control Center™ 540C Faceplate.

3) Using the display navigation buttons (< / >) cycle through

the setting options.

4) At the desired setting, press the green button to access

options. Adjust the settings by using the navigation buttons

(< / >). Confirm and store the desired setting with the green

button or cancel with the red button.

Setting 1: CH1 OUT

The Xbox 360™ console outputs many different AV signals

and the Control Center™ 540C must be adjusted to output

the correct signal for your chosen method of connection to

a TV. The default setting is “YUV” for displaying component

video. Set to “S-V” to output an S-video signal by following

these steps:

Use the display navigation buttons (< / >) to cycle through

the settings to “CH1 OUT”. Press the green button to

access options. Use the display navigation buttons (< / >) to

select either “S-V” or “YUV”. Save the setting by pressing

the green button.

NOTE: If you see no picture on your TV, check CH1 output

is set correctly for your method of connection.

Setting 2: LIGHT

Three different back light settings are available: (OFF always

/ ON always / AUTO)
