JPS RSP-Z2 User manual

INTEROPERABILITY NOW
Quick Start Guide
RSP-Z2
Dual Channel Analog-IP Interface
Designed and Manufactured by:
JPS Interoperability Solutions
5800 Departure Drive
Raleigh, NC 27616
919-790-1011
Email: [email protected]om / [email protected]
www.jpsinterop.com
Guide is JPS P/N 2740-516060 Revision Prelim A-1 ©December 2017

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 2 of 12 Interoperability Now
1General
All of the information necessary to install, configure, and operate the RSP-Z2 Channel Bank is
available within the unit. This Quick Start Guide’s basic purpose is to describe how to access
that information, which includes extensive context-sensitive help available on each page of the
unit’s browser-based Graphical User Interface. Some topics benefit from more in-depth
information; applicable documents can be accessed from the GUI’s Help tab pull-down menu.
The RSP-Z2 is standards-compliant and therefore supports standards-compliant web browsers,
including Internet Explorer (must be at least IE 10 or Edge), Firefox, Chrome, Opera, and Safari.
It’s always best to use the most current version of any web browser.
A brief overview of RSP-Z2 operation is also provided in Section Two of this QSG, providing
sufficient information to give a basic understanding of most RSP-Z2 functions.
1.1 Set up IP Address and Subnet Mask
As with any device with a static IP address, it will be necessary to set up the unit to operate on
the LAN where it is to be deployed. The RSP-Z2’s factory default IP address is 192.168.1.200,
with a default subnet mask of 255.255.255.0.
To reset to an address and subnet mask that work on your LAN, connect the RSP-Z2 via CAT-5
cable (need not be a cross-over cable, though a cross-over cable will work) directly to the
Ethernet Port of the computer that will be used to access and configure it.
Set the computer to a static IP address of 192.168.1.xxx (where xxx is a number between 2 and
199) and a subnet mask of 255.255.255.0. This will allow you to browse to the RSP-Z2 at its
default IP address following the instructions in the next section of this guide.
Plug in the unit’s power supply, and turn the unit on via its front panel power switch. The RSP-
Z2’s front panel LEDs will flash while the unit boots up (approximately 90 seconds). After
logging in, you can access the Installation and Operations Manual and use it to change the unit’s
IP address and subnet mask as necessary. Be sure to remember and write down this new IP
address; if you fail to do so or become otherwise unable to navigate to the login screen, see
Section 1.5 of this QSG.

RSP-Z2 Quick Start Guide
Interoperability Now Page 3 of 12 RSP-Z2 Quick Start Guide
1.2 Log In
Upon browsing to the unit’s IP address, the login screen above will appear.
Default name and password are both “su” for Super User with the Super User’s full-capability
permission set. Further explanation, including instructions for changing these defaults, is
provided in the Help Documents.
1.3 Accessing the Help Documents
The unit’s Help Documents, in PDF format, can be downloaded from the unit. Click on the Help
pull-down menu (as shown below), and select “Contents.”
Among the topics available are this Quick Start Guide, an Installation and Operations Manual,
and some helpful specific instructions on basic topics such as Channel Profiles, how the RSP-
Z2’s SIP Channels handle COR & PTT, and tips for basic system optimization and
troubleshooting.

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 4 of 12 Interoperability Now
1.4 Context-Sensitive Help
The RSP-Z2 also makes extensive use of context-sensitive help. On the upper right corner of
each of the unit’s web pages, click on the circular question mark to bring up page-specific
help text.
Further specific help is also available wherever appropriate. For example, the channel
configuration pages include context-sensitive help for each settings box.
The image below shows the pop-up window for the “Connection Maintenance” settings. Note
how the rest of the screen is darkened while the help text is being viewed.

RSP-Z2 Quick Start Guide
Interoperability Now Page 5 of 12 RSP-Z2 Quick Start Guide
1.5 IP Address Determination
If unable to access the RSP-Z2 because you’ve forgotten its IP address and other network
settings, the front panel USB port can be used to retrieve the needed information. Plug a thumb
drive into the port and cycle the power. After power-up, the unit will store several files on the
drive; these include diagnostic log files plus a short text file that lists the unit’s network
information. Most important will be its IP address and subnet mask. After the unit is fully
rebooted the USB drive will be unmounted and can be unplugged. Use the USB drive’s LED to
determine when it has completed downloading the log files.
On the USB drive, open the file named “networkinfo.txt”
It contains the desired information in this format:
address: 192.168.1.200
netmask: 255.255.255.0
gateway: 192.168.1.100
dns-nameservers: 209.18.47.61 209.18.47.62 8.8.8.8
broadcast: 192.168.1.255
Note this matches the unit’s Network Settings information that can be viewed or changed via the
web browser:
See Section 3 of the Installation and Operations Manual (located under the Help tab on the GUI)
for instructions related to changing these settings.

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 6 of 12 Interoperability Now
2RSP-Z2 Basic Overview
2.1 Basic Information
This section provides some essential background information that will assist in understanding
the capabilities of the RSP-Z2.
JPS Interoperability Solutions has several decades of experience with voice communications
interoperability, fielding their first devices in 1989. Over this time the company has encountered
and resolved a wide array of problems that can hamper or complicate communications when
disparate devices are patched together into interoperability nets.
The RSP-Z2 incorporates all this experience, in the form of a suite of sophisticated DSP
algorithms that operate at its interfaces with any connected communications devices, as well as
many custom radio interface cables, covering well over 300 different radio makes and models.
JPS interoperability devices are also known for simplicity and ease-of-use. The RSP-Z2’s
browser-based Graphical User Interface is carefully designed to make these sophisticated
capabilities available when necessary. When the simple setup and configuration works well, an
installer and operator need only be concerned with these elements. However, if the
communications system includes any problematic elements, a JPS interoperability device (such
as this RSP-Z2) has thefeatures necessary to resolve the problems and optimize communications.
2.2 Important definitions:
COR: A signal that indicates when a radio (or other type of communications
device, such as an RSP-Z2) is receiving a valid audio signal.
PTT: A signal that tells a radio (or other communications device) to transmit the
audio signal being sent to it.
Full Duplex Communication System: Users can simultaneously talk to and
listen (for example, a standard telephone call).
Simplex or Half Duplex Communication System: Only one system user can
be heard at a time.
Interoperability Net: Communications link consisting of disparate devices (such
as radios of different frequencies, telephones, VoIP phones, etc.) connected
together, similar to a conference call.
These definitions are essential in understanding the basic operation of an interoperability device,
such as a JPS ACU Gateway or this RSP-Z2. That is: If multiple communications devices are
engaged in an interoperability net, whenever one device detects active COR (valid audio input),
that audio, along with a PTT signal, is sent to all other devices in the net to be transmitted. Also,
if any device in an interoperability net is half duplex (such as are almost all radio systems), then
all communications must be half-duplex. For this reason, the RSP-Z2 is a half-duplex device.
Among the unit’s sophisticated features are various methods for determining active COR (such
as VOX or VMR, which are optimal or necessary for some types of devices), and adjustable
audio delays to meet the timing requirements of the connected communications systems.

RSP-Z2 Quick Start Guide
Interoperability Now Page 7 of 12 RSP-Z2 Quick Start Guide
2.3 Possible RSP-Z2 Configurations
This RSP-Z2 provides a pair of analog-to-IP channels, along with a Headset Channel. The non-
headset channels can be configured in multiple ways, best illustrated below by this partial screen
shot from the Configuration Page of the unit’s browser-based Graphical User Interface. It shows
the three basic configurations; the first step in setting up the unit is selecting one. All three are
explained in the following sections.
2.3.1 Independent Passthrough
This configuration provides two separate Analog to IP converters. For each, active COR on the
analog side will send incoming audio out the IP backhaul interface, and vice-versa. Active COR
occurs when the channel determines that “Valid” audio input has been detected. Available COR
types (methods of determining valid audio) vary by channel type.

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 8 of 12 Interoperability Now
Note that four separate channels are depicted for this configuration –two local audio channels
each tied to its own IP backhaul channel. A USB Headset can also be included, and connected to
any communications channel.
Once a configuration is selected, right-clicking on any channel icon will bring up the Settings
Page for that channel; this allows the channel to be set to a variety of Channel Types, with
appropriate settings options for the selected type.
For this RSP-Z2, the analog options are Radio (appropriate also for other types of four-wire
devices), and Headset (among other applications, the headset allows the unit to be used as a small
IP dispatch station). Future versions will include a PSTN analog channel.
Backhaul options include RTP, SIP (BSI compliant), RoIP (the JPS-proprietary Radio over IP
protocol), VIA (for connection to the JPS VIA Smartphone PoC app), and Bridge Channels (for
future applications when used in a system with other JPS devices).
Note that, if desired, the analog channels can also be configured as either of the RoIP, RTP, or
SIP channel types.
Because the RSP-Z2 is a half-duplex device, the first channel with active COR is in control until
its COR status goes back to inactive - unless another channel is configured to allow preemption.
If so, that channel’s incoming audio will take over. See the related context-sensitive help below,
from the Settings Page for a Radio channel:

RSP-Z2 Quick Start Guide
Interoperability Now Page 9 of 12 RSP-Z2 Quick Start Guide
2.3.2 Cross-Connected
This configuration patches the two analog interfaces together, with no IP backhaul. When one of
the two channels detects a valid audio input, the other will transmit this audio. See block diagram
below. RSP-Z2 Channel 01 is connected to a VHF repeater system for the State Highway Patrol,
and Channel 02 to the local Fire Department’s 800 MHz trunked system. A channel/talkgroup
on each system is set aside for emergencies when the two agencies need to talk to each other.
Whenever any user from either system transmits on the designated channel/talkgroup, all other
users on both channels can hear. Because the donor radios interface the radio systems identically
to all other radios in either system, the RSP-Z2 installation has minimal impact.
A note about the need for sophisticated radio interface algorithms: Any time a handheld radio on
the 800 MHz trunked system keys up, that user needs to wait until a channel acquisition
confirmation tone is heard before speaking; only then is the trunked system ready to transmit that
user’s audio.
When a patrolman in the vehicle in the upper left keys up, he will begin talking without any
concern for a tone.
Now consider the two systems cross-connected. When that VHF user keys up, his radio will of
course be in transmit mode, so there is no way to provide any feedback regarding the channel
acquisition tone that the 800 MHz donor radio will receive. Further, the interoperability system
doesn’t want to alter normal operation of either system in any way. Instead, the RSP-Z2 deals
with this through the TX audio Delay feature in the Radio Channel Settings. The RSP-2 stores
the audio temporarily in an internal buffer and sends it out after the trunked system is ready to
receive and retransmit it.

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 10 of 12 Interoperability Now
2.3.3 Cross-Connected with Backhaul
This is a combination of the Independent Passthrough and Cross-Connected configurations. Only
a single backhaul interface is needed, because it is interfaced to the combined (cross-connected)
audio of the two local channels.
The diagram above shows one of the many ways the backhaul channel can be used, as a SIP
channel allowing a supervisor to dial in by a VoIP phone. All three channels are connected
together, so the caller will hear anything on either channel, and the supervisor’s speech will be
retransmitted in both radio systems.
2.4 Front Panel Level Indicator
The RSP-Z2 has a set of audio level indicating LEDs on the front panel; the LEDs can be applied
to any one of the unit’s channels. The level is measured after the channel's audio adjustment, that
is, the measurement point includes the changes made by the channel’s “Receive Input” audio
adjustment. This allows the level indicator to give visual evidence of optimal adjustment. When
properly set, a standard voice signal (a person on this channel speaking at a typical volume level)
will flash red on occasional voice peaks.
Click on the icon with the rising bars in the upper right of each interface to select (only visible
after configuration is set, see figures that follow). After selection, the level icon will turn green.
See the Field Setup Guide, available via the Help pulldown menu, for further tips on proper use
of the Level Meter.

RSP-Z2 Quick Start Guide
Interoperability Now Page 11 of 12 RSP-Z2 Quick Start Guide
2.5 USB Headset
If a JPS-approved USB headset is plug in at power-up, an icon will appear in the upper right
corner of CH1 and CH2. Click on one of these headset icons to select what audio source it will
be connected to. This selection makes a difference only for the Independent Passthrough
configuration, because with all other configurations, all the channels are tied together.
Figure above: Home Screen –a Headset was plugged in at power up but has not yet been
associated with either channel. Level Indicator association also not yet selected.
In the next screen shot, the operator has connected the headset to the interoperability net made
up of Channel One and its RoIP backhaul channel. The operator has also connected the RSP-
Z2’s front panel audio level meter to Channel 2’s backhaul channel. These selections are made
clear by the green shading.
Also, the operator is currently talking into the headset. Active COR by the headset is indicated
by the green circle at the lower left corner of the headset icon. Because this is an active
interoperability net, this active COR causes the headset operator’s speech to be retransmitted by
the radio channel and also the RoIP backhaul channel.

RSP-Z2 Quick Start Guide
RSP-Z2 Quick Start Guide Page 12 of 12 Interoperability Now
More about Headsets:
•If the headset becomes unplugged, a red exclamation point will be displayed on its icon.
•If none of the channels is selected to use the front panel level meter, it will indicate the
headset audio level.
•When installed, the headset has its own settings page. Settings options include VOX
sensitivity, changing to COR rather than VOX (useful in noisy environments) and
applying higher priority to the headset channel relative to other system channels.
•The system can also be configured so that the USB Headset acts as one of the local analog
channels, rather than being connected to the local/backhaul pair. See the Installation and
Operations manual for further instructions.
2.6 Configuration and Control Methodology
The unit is configured via its web-based GUI. There are no physical potentiometers or switches
related to the analog interface configuration.
To allow a lower price when only a single radio is needed, the RSP-Z2 may be purchased with a
single active analog channel. If the second analog channel is desired later, it may be purchased
from JPS Interoperability Solutions and activated via a firmware update.
End of Document
