JR Home Paramount Quick start guide

FP-341-GY
FPT1879
Version B

Contact us for assistance: [email protected] | [phone] 2
TABLE OF CONTENTS
Table of Contents/Before You Begin Page 2
Package Contents Page 3
Safety Information Page 4
Assembly Page 5-8
Care and Maintenance Page 9
Warranty Information Page 10
BEFORE YOU BEGIN
Please read and understand this entire manual before attempting to assemble, operate or install
this appliance.
This manual contains important information about the assembly, operation and maintenance of this
appliance. General safety information is presented in the first few pages and is located throughout
this manual. Keep this manual for future reference and to educate new users of this appliance.

3
K
S Hook 1
1
E
G
H
K
I
J
Burner
Table Top
Front Door Panel
Side Panels
Back Panel
Gas Tank Support Bar
Gas Tank Support Ring
HARDWARE CONTENTS TOOLS
Wrench
S
Hex Key
R
Q
Plastic Cap (M8)
Qty: 4
L
Bolt 8x20mm
Qty: 5
(4 for assembly +1 extra)
M
Washer, Spring Washer 8mm
Qty: 5
(4 for assembly +1 extra)
N
Bolt 6x25mm
Qty: 9
(8 for assembly +1 extra)
O
Bolt 6x18mm
Qty: 4
(3 for assembly +1 extra)
P
Washer 6mm
Qty: 12
(11 for assembly +1 extra)

Contact us for assistance: [email protected] | [phone] 4
SAFETY INFORMATION
SAFETY INFORMATION
This appliance has been tested to and
complies with the ANS Z 21.97-2010, Outdoor
Decorative Gas Appliances CGA CR 97-003
Outdoor Gas Fireplaces. The installation must
conform to local codes or in the absence of
local codes to the National Fuel Gas Code.
ANS Z223.1. This manual contains important
information about the assembly, operation and
maintenance of this appliance. General
few pages and is also located throughout
the manual. Keep this manual for future
reference and to educate new users of this
product. This manual should be read in
conjunction with the labeling on the product.
Safety precautions are essential when any
mechanical or gas fueled equipment is
involved. These precautions are necessary
when using, storing, and servicing. Using
the equipment with the respect and caution
demanded will reduce the possibilities of
personal injury or property damage. The
following symbols shown below are used
extensively throughout this manual. Always
heed these precautions, as they are essential
when using any mechanical or gas fueled
equipment.
DANGER
EXPLOSION—FIRE HAZARD
• Keep solid combustibles, such as building
materials, paper, or cardboard a safe
distance away from the appliance as
recommended by the instructions.
• Provide adequate clearances around air
openings into the combustion chamber.
•Never use the appliance in spaces which
do or may contain volatile or airborne
combustibles, or products such as
gasoline, solvents, paint thinner, dust
particles, or unknown chemicals.
• During operation, this appliance can be a
source of ignition. Keep appliance area clear
and free from combustible materials,
gasoline, paint thinner, cleaning solvents
Do not use the appliance in areas with high dust
content. Minimum appliance clearances from
combustible materials: 2 feet (24 inches)
from the sides & 2 feet (24 inches) from
the rear, 6 feet (72 inches) from ceiling.
• Never store propane near high heat, open
ignition sources or where temperatures
exceed 120 degrees F (49 degrees C).
• Propane vapors are heavier than air and
can accumulate in low places. If you smell
gas, leave the area immediately.
• Never install or remove a propane cylinder
while the appliance is lighted, near flame,
pilot lights, or other ignition sources or
while the appliance is hot to the touch.
from top and 2 feet (24 inches) from sides.
• Store the propane cylinder outdoors in a
well ventilated space out of the reach of
children. Never store the propane cylinder
in an enclosed area (house, garage, etc.).
If the appliance is to be stored indoors, disconnect
the propane cylinder for outdoor storage.
WARNING
Failure to comply with the precautions and
instructions provided with this appliance can
result in death, serious bodily injury and
property loss or damage from hazards of
fire, explosion, burn, asphyxiation, and
of carbon monoxide poisoning. Only
persons who can understand and follow
the instructions should use or service
this appliance.
WARNING
We cannot foresee every use which may be
made of our appliance. Check with your local
fire safety authority if you have questions about
your appliance use, Other standards govern
the use of fuel gases and heat producing
authorities can advise you about these. If no
local codes exist, follow National Fuel Gas
Code, ANS Z223.1. In Canada, installation
must conform to local codes. If no local
codes exist, follow the current National
standards of CANADA CAN/CGA-B 149.2.
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause property damage, injury or death.
Read the installation, operation and
maintenance instructions thoroughly before
installing or servicing this equipment.
WARNING
Do not store or use gasoline or other
of this or any other appliance. An LP-cylinder
not connected for use shall not be stored in
the vicinity of this or any other appliance.
DANGER
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
3. If odor continues, keep away from the
appliance and immediately call your gas
WARNING / DANGER
WARNING/DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING:
FOR OUTDOOR USE ONLY
CARBON MONOXIDE HAZARD
This appliance is a combustion appliance.
All combustion appliances produce carbon
monoxide (CO) during the combustion
process. This product is designed to
produce extremely minute, non-hazardous
amounts of CO if used and maintained
in accordance with all warnings and
instructions. Do no block air flow into or
out of the appliance.
• Carbon Monoxide (CO) poisoning
headaches, dizziness, fatigue and possibly
death. You can’t see it and you can’t smell
it. It’s an invisible killer. If these symptoms
are present during operation of this
product get fresh air immediately!
• For outdoor use only.
• Never use inside house, or other
unventilated or enclosed area.
This appliance consumes air (oxygen) Do
not use in unventilated or enclosed areas
to avoid endangering your life.
This appliance is red hot during use and can
and vapors well away from the appliance.

F
G
Locate 4 Panels D/E/F. NOTE: There is a hole at the bottom of
each Side Panel E . The hole should face DOWN.
Place a Washer P on each of 8 Bolts N and insert through holes
in sides of Side Panels into the holes in sides of Leg Panels D/F.
Tighten all Bolts N with Hex Key S.
X 1
X 8
X 8
NBolt（6*25mm）
PWasher(M6)
SHex Key
D
N
P
X 1
X 2
X 2
OBolt（6*18mm）
PWasher(M6)
SHex Key
Once all Panels are bolted together, carefully turn the table
base upside-down. Attach Gas Tank Support Bar G to Side
Panels E by aligning holes in Gas Tank Support Bar with
holes in the bottom of Side Panels. Insert Bolt O through
Washer P into holes and tighten with Hex Key S.
O
P

3
4
M
M
L
D
D
Q
O
P
Gas Tank Support Ring H over Gas Tank
Support Bar G and align hole on front of Gas Tank Support
Ring with holes at the bottom of Front Door Panel D. Insert
Bolt O through Washer P and then through hole. Tighten with
Hex Key S.
Turn the assembled table base over, then place Table Top C
over Legs, and align the holes on Table Top with holes on the
top of Legs. Insert Bolt L through Spring Washer M then
through Washer M into the hole. Tighten with Wrench R then
cover bolt heads with Plastic Caps Q.
X 1
X 1
X 1
OBolt（6*18mm）
PWasher(M6)
SHex Key
Bolt（8*20mm）
Washer(M8)
X 4
X 4
L
M
X 4
X 1
MSpring Washer(M8)
Q Plastic Cap (M8)
RWrench
X 4

6
D
D
J
E
I
K
6
Gently place the Burner B into the hole in the Table Top C ,
allowing the hose and regulator to drop into the fire pit base.
Make sure the Control Panel on the Burner faces the Front
Door Panel D
Hang the S hook J into the hole of Side Panel’s vertical pipe,
then the pipe of the Burner to the hook.
Pour the Fire Glass K around the Burner. Be careful not to
obstruct pilot light housing. Put the Removable Burner
Cover A on the Burner.
When the fire pit is NOT in use, or after use, when the fire
pit has cooled COMPLETELY, cover it with the Protective
Cover I. DO NOT PUT THE PROTECTIVE FIRE PIT COVER
ON A HOT FIRE PIT.

7
7
7
7

Contact us for assistance: [email protected] | [phone] 9
CARE & MAINTENANCE
WARNING
FOR YOUR SAFETY
•
at least 45 minutes after use.
• Burner is hot to the touch.
• Allow burner to cool before
touching.
perform the following maintenance activities on a regular basis:
cleaning agents.
2. While cleaning your unit, be sure to keep the area around the burner and
control compartment dry at all times. Do not submerge the control valve
assembly. If the gas control is submerged in water, do NOT use it. It must
covering with a cover.
A. Keep the appliance area clear and free from combustible materials,
C. Keep the ventilation opening(s) of the cylinder enclosure free and clear
from debris.
air passageways clean. Signs of possible blockage include:
• Fire pit does NOT reach the desired temperature.
• Fire pit glow is excessively uneven.
• Fire pit makes popping noise.
burner holes by using a heavy-duty pipe cleaner. Compressed air
may help clear away smaller particles.
warm soapy water if any carbon deposits develop.
Note: In a salt-air environment (such as near an ocean), corrosion
occurs more quickly than normal. Frequently check for corroded areas
and repair them promptly.
SERVICE:
repair gas passages and associated
components.
Caution:
before attempting service.
STORAGE:
Between uses:
• Turn control knob OFF.
• Disconnect LP source.
from direct contact with
inclement weather (such
as rain, sleet, hail, snow, dust
and debris).
protect exterior surfaces and
to help prevent build-up in air
passages.
During periods of extended
inactivity or when transporting:
• Turn control knob OFF.
• Disconnect LP source and move
to a secure, well-ventilated
location outdoors.
from direct contact with
inclement weather (such as
rain, sleet, hail, snow dust and
debris).
protect exterior surfaces and
to help prevent build-up in
air passages. Never leave LP
cylinder exposed to direct
sunlight or excessive heat.
Note:
cool before covering.

Contact us for assistance: [email protected] | [phone] 17
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Burner will
not light
Propane cylinder is frosted over Wait until the propane cylinder warms up and becomes
unfrosted
Clear blockage
Control knob is not in ON position Turn control knob to ON
is low
Gas pressure is low Turn cylinder valve OFF and replace cylinder
Outdoor temperature is less than
40°F and tank is less than 1/4 full Use a full cylinder
Control knob fully ON
Carbon build-up
Thick Black Smoke
Clean burner screen
Blockage in burner Remove blockage and clean burnerscreen inside and
outside.
TROUBLESHOOTING
Warranty And Reviews
Extend Your Warranty By Leaving A Review
We want your opinion about your purchase...and we want you to tell everyone about it!
Just leave a review for the product on the retailers website where you made your purchase, or at
www.jrhome.com, and ll in the online warranty at www.jrhome.com/warranty-registration within 30
days of purchase to receive a complimentary extra year of warranty protection.
Faites Part de Votre Évaluation et Prolongez Votre Garantie
Nous désirons connaître votre opinion sur nos produits … et nous vous invitons à la partager!
Laissezsimplementvotreopinionconcernantleproduitsurlesiteinternetdudétaillantoùvousavezfait
votre achat ou au www.jrhome.com et remplissez la che de garantie en ligne au https://www.jrhome.com/
warranty-registration an de recevoir gratuitement une prolongation d’un an de la garantie de protection.
Follow us on/ Suivez-nous sur:
www.jrhome.com #jrhome #paramount
JR HOME
COLLECTION
une touche d’innovation à toutes les pièces de votre maison

IMPORTANT
For questions, concerns or problems with our product please
email our customer service department:
[email protected]
DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE
WARRANTY
This product is inspected, tested and carefully packaged to minimize
the chance of damage during shipment. If a part (excluding light
bulbs, glass and fuses*) within one year from the date of purchase
proves to be defective in material or fabrication under normal use,
the part will be repaired or replaced. The Company’s obligation under
the warranty is to replace or repair defective parts at our discretion.
Any expenses or damage resulting from the installation, removal or
transportation of the product will be the responsibility of the owner
and are not covered by this warranty. The owner assumes all other
risks arising from the use or misuse of the product. The warranty will
be void if the product damage or failure is deemed by the Company
to be caused by accident, alteration, misuse, abuse, incorrect
installation or removal, or connection to an incorrect power source
by the owner. The Company neither assumes, nor authorizes any
person or entity to assume for it any obligation or liability associated
with its products. Light bulbs and fuses are not covered under this
warranty. If you have any questions regarding the warranty or
service, please contact us at [email protected].
Customer Service :
JR Home Products
Unit 306 - 19100 Airport Way, Pitt Meadows, BC V3Y 0E2
Toll Free : 1-800-561-5550
E-mail : [email protected]
Warranty Registration Information Form / Formulaire d’enregistrement de la garantie
Registration can be completed online at
www.jrhome.com or by mailing this form.
Name / Nom :
Street / Adresse :
City / Ville :
Province / Province :
Postal Code / Code postal :
Daytime Phone # / No téléphone jour :
Evening Phone # / No téléphone soir :
E-Mail Address / Courriel :
Product/Produit :
Place of Purchase / Lieu de l’achat :
Date of Purchase / Date de l’achat :
Model # / No de modèle :
Serial # / Numéro de série :
You MUST register your product to receive
warranty service.
For warranty service, contact J&R Home
Products at the address, phone numbers listed
below within 30 days of purchase. Be sure to
have your sales receipt and original date of
purchase. All warranty service will be
coordinated by
J&R Home Products service center.
Vous DEVEZ enregistrer votre produit pour vous
prévaloir de la garantie.
Afin de faire valoir la garantie, communiquez
avec J&R Home Products à l’adresse et aux
numéros indiqués ci-dessous dans les 30 jours
suivant la date d’achat. Ayez en main votre reçu
et la date d’achat. Toutes les demandes liées
aux garanties seront traitées par le centre de
service de J&R Home Products.
Please mail to / Veuillez poster le tout à : Parts & Service Department, J&R Home Products Ltd. Unit 306 - 19100 Airport Way, Pitt Meadows, BC V3Y 0E2
You MUST register your product within 30 days of
purchase to receive warranty service.
Si vous éprouvez si vous avez des questions ou des
préoccupations, prière de faire parvenir un courriel à notre service à la clientèle
[email protected]
UNE PREUVE D’ACHAT DATÉE EST REQUISE POUR SE PRÉVALOIR DE LA GARANTIE.
AVERTISSEMENT
soigneusement
des verres,
s
demeurent
service,
contacter le service à la clientèle à : [email protected].
Service à la clientèle:
JR Home Products
Unit 306 - 19100 Airport Way, Pitt Meadows BC V3Y 0E2 Numéro
sans frais: 1-800-561-5550
Courriel: [email protected]
Vous DEVEZ enregistrer votre produit dans les 30 jours suivant l'achat
pour bénéficier du service de garantie.
L’enregistrement sera complet une fois que vous aurez posté ce
formulaire ou que vous serez inscrit en ligne.
200120
