Judge Jea98 User manual

Cautions (continued)

Pull the plug (do not pull Mains Lead) to disconnect from mains

socket.

Do not pull the Mains Lead to move the Hand Mixer.

It is not recommended that the Hand Mixer be used with an

extension lead.

This Hand Mixer is not intended to be operated by means of an

external timer or a separate remote-control system.

Do not use the Hand Mixer outdoors.

This Hand Mixer is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities

or lack of experience or knowledge, unless they have been

given supervision or instruction concerning use of the Hand

Mixer by a person responsible for their safety.

Always keep the Hand Mixer out of the reach of children less

than 8 years.

Children shall not play with the Hand Mixer.

The Hand Mixer can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

Hand Mixer in a safe way and understand the hazards involved.

Cleaning and user maintenance shall not be made by children

unless they are older than 8 and supervised.

Never eject beaters or dough hooks when the Hand Mixer is in

operation.

Avoid contacting with moving parts.

Keep hands, clothing, as well as spatulas and other utensils

away from beaters during operation to reduce the risk of injury

to persons, and/or damage to the mixer.

Speciﬁcation

Name Model

No.

Rated Voltage Rated

Frequency

Rated

Power

Judge Twin Blade Hand Mixer JEA98 220-240V 50Hz 400W

THIS PRODUCT IS INTENDED

FOR DOMESTIC USE ONLY

HORWOOD SHALL NOT BE LIABLE

FOR INCIDENTAL OR CONSEQUENTIAL

DAMAGES RESULTING FROM THE USE

OF THIS PRODUCT (INCLUDING COLOUR

FADING, SCRATCHES OR ACCUMULATED

DIRT) WITHOUT FOLLOWING THE USE,

CARE & SAFETY INSTRUCTIONS.

Note: Due to the introduction of

improvements from time to time, the

right is reserved to supply products

which differ slightly from those illustrated

and described in this publication.

Errors and Omissions Excepted.

CORRECT DISPOSAL

OF THIS PRODUCT

This marking indicates that

this product should not be

disposed with other household

wastes throughout the EU. To

prevent possible harm to the

environment or human health

from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse

of material resources. To return your used

device, please use the return and collection

systems or contact the retailer where the

product was purchased. They can take this

product for environmental safe recycling.

Customer Services

Horwood, Avonmouth Way, Bristol,

BS11 9HX, Great Britain

www.horwood.co.uk

customerservice@horwood.co.uk

Tel: 0117 940 0000

◆The Judge 2 Year Domestic

Electrical Guarantee covers the

product to be free of defects in

materials and workmanship for

a period of TWO YEARS from the

date of original retail purchase.

◆During this period, Judge will, at their

option, repair or replace defective

parts of the product, or replace the

product, providing the Use Care and

Safety Advice have been followed.

◆The Guarantee does not cover

damage, defect or failure caused by

or resulting from accidents, external

damage, alteration, modiﬁcation,

abuse, misuse or misapplication.

◆The Guarantee does not cover

any damage caused by taking

the appliance apart yourself,

or attempting to repair the

appliance yourself.

◆Please keep your Purchase

Receipt and contact us

directly if you encounter any

problems with your product.

Cautions (continued)

The use of attachments not recommended or sold by the

manufacturer may cause re, electric shock or injury

The appliance should be used only as instructed and for the

purpose for which it was intended; there is potential for injury or

damage from misuse.

Do not use the appliance to mix liquids other than foodstuffs.

Unplug from the mains socket before cleaning.

Remove beaters from mixer before washing.

Please retain these instructions and your purchase receipt.

Twin Blade

Hand Mixer

Model No. JEA98

400W

Instruction manual

◆Please read carefully before use and save for later reference

◆Unpack your Twin Blade Hand Mixer carefully

◆Remove packing pieces, labels and stickers

Identifying the parts

(with Part Numbers for customer replaceable items)

Mixer Body

Handle

Mains Plug and Lead

Beaters (JEA98BT, each)

Dough Hook with Collar (JEA98HC)

Dough Hook without Collar (JEA98HN)

Left Hand Attachment Receptacle

Right Hand Attachment Receptacle

Eject Button

OFF (0) / Speed Selector (1-6) Switch

Turbo Button

Storage Clip for Beaters and Dough Hooks

Before ﬁrst use

1. Remove any labels and/or swing tickets.

2. Pull the Storage Clip to remove from the Mixer Body . Wash the

Beaters and Dough Hooks and with liquid detergent and

warm water, rinse and dry. These parts are dishwasher safe.

3. Wipe the outside of the Mixer Body with a cloth dampened slightly

with liquid detergent and warm water, then dry with a dry cloth.

◆DO NOT IMMERSE ANY PART OF THE MIXER BODY IN WATER.

How to use (continued)

◆Do not use any utensils such as knives, forks or spoons in the bowl

and do not reach into the bowl when the mixer is in use. Do not allow

the Mixer Body to come into contact with the ingredients.

◆The Turbo Button may be used to increase the mixer speed for short intervals.

◆Do not operate the Mixer for more that 5 minutes continuously at a

time, after which a 20-minute cooling period should be allowed.

6. When mixing is completed, return the OFF/Speed Selector Switch

to the “0” (OFF) position and unplug the Mains Plug .

◆If necessary, when the mixer is off you may scrape any excess food mix

from the mixing attachments with a wooden or plastic spatula.

7. Grasp the mixing attachments with one hand, close to the Mixer Body

, to avoid getting food mix on your hand. Press the Eject Button with

your other hand, to release the mixing attachments for cleaning.

◆The Eject Button cannot be operated unless the OFF/Speed Selector

Switch is in the “0” (OFF) position; this is a safety feature. Do not

attempt to pull mixing attachments out of their receptacles.

Mixing Tips

◆Do not over mix beyond the recommended times in your recipe.

◆Fold in dry ingredients at the lowest speed, until only just combined.

◆Refrigerated ingredients, such as butter, cheese and eggs, should

be allowed to reach room temperature before mixing.

◆An approximate guide to the function of the speed

settings is given in the following table:

1 - 2 3 - 4 5-6

Starting mixing

Kneading dough

Folding in dry ingredients

Mixing dry ingredients

Combining ingredients

Preparing batters

and mixes

Making cake and

biscuit mixes

Creaming butter and sugar

Whipping butter, cream,

aerated mixtures

Mashing potato

Beating eggs

Beating icing sugar

Beating puddings

Cleaning

1. Always return the OFF/Speed Selector Switch to the “0” (OFF)

position and unplug the Mains Plug before cleaning.

2. Wash the mixing attachments with liquid detergent and warm

water, rinse and dry. These parts are dishwasher safe.

3. Wipe the outside of the Mixer Body and the Mains Lead with a cloth dampened

slightly with liquid detergent and warm water, then dry with a dry cloth.

◆DO NOT IMMERSE ANY PART OF THE MIXER BODY IN WATER.

4. When all parts are dry, push ﬁt the Storage Clip to attach to the underside

of the Mixer Body and use to safely store attachments / / .

Cautions

Before using the Hand Mixer, the following basic

precautions should always be followed:

Read all instructions before use.

Ensure that your home electrical supply corresponds to the

requirements of the appliance - see “Specications”.

Always check that the control is OFF before connecting the

Hand Mixer plug into a mains socket.

Do not connect the Mains Plug into a mains socket, or use the

appliance, if your hands or the appliance are wet.

To disconnect, turn the control to OFF, then remove plug from

the mains socket.

Unplug from mains socket while not in use, before changing

accessories or approaching parts which move in use.

The Mains Lead should be positioned so as not to cause an

obstruction or to overhang the edge of the surface, where it

could accidentally be snagged or pulled by children.

Never leave the unit unattended when it is operating.

DO NOT IMMERSE ANY PART OF THE HAND MIXER IN

WATER.

Should the Hand Mixer accidentally fall into water, unplug

immediately and do not use; contact Judge Customer Services

at the address given in the warranty section.

Do not switch on or attempt to operate the Hand Mixer if it

appears to be faulty in any way. Never attempt to make any

repair to the Hand Mixer yourself - contact Judge Customer

Services at the address given in the warranty section.

Do not place the Hand Mixer or Mains Lead close to a heat

source.

Inserting the Beating attachments

1. Set the OFF/Speed Selector Switch to the “0” (OFF)

position and unplug the Mains Plug .

2. Insert the ﬁrst of the Beaters into either Attachment

Receptacle /on the underside of the Mixer Body . Rotate

the attachment until it clicks into place, then push home.

3. Repeat step 2 with the second Beater .

Inserting the Dough Hooks

How to use

1. Follow the instructions for inserting the required mixing attachments (above).

2. Place the ingredients to be mixed into a bowl or other suitable container.

3. Ensure that the OFF/Speed Selector Switch is set to the “0” (OFF) position.

4. Plug the Mains Plug into a mains socket.

5. Lower the mixing attachments until they are well covered by the ingredients

to be mixed and move the OFF/Speed Selector Switch to the required

speed setting of “1” to “6” to mix the ingredients according to your recipe.

◆It is recommended to start mixing at the lowest speed

and gradually increase the speed, if required.

1. Set the OFF/Speed Selector Switch

to the “0” (OFF) position and

unplug the Mains Plug .

2. Insert the Dough Hook with Collar

into the Right Hand Attachment

Receptacle on the underside of the

Mixer Body . Rotate the attachment

until it clicks into place, then push home.

3. Insert the Dough Hook without Collar

into the Left Hand Attachment

Receptacle on the underside of the

Mixer Body . Rotate the attachment

until it clicks into place, then push home.
