Find the Julabo SW23 at our website: Click HERE

Print date: 26.07.04 19534023.doc
English
Operating
manual
Shaking Water Baths
SW22
SW23
Software Version
SW22 n2.6
SW23 n2.7
JULABO USA, Inc.
754 Roble Road, Suite 180
Allentown, PA 18109
([phone]
3(610) 231-0260
šinfo @ julabo.com
üwww.julabo.com
1.953.4023BU4 07/04
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Congratulations!
You have made an excellent choice.
Julabo thanks you for the trust you have placed in us.
This operating manual has been designed to help you gain an understanding of the
principles of operating and possibilities of our circulators. For optimum utilization of
all functions, we recommend that you thoroughly study this manual prior to
beginning operation.
Safety Warnings
Take care your unit is operated only by qualified persons.
Make sure you read and understand all instructions and safety precautions listed in
this manual before installing or operating your unit. If you have any questions
concerning the operation of your unit or the information in this manual, contact
JULABO.
Performance of installation, operation, or maintenance procedures other than those
described in this manual may result in a hazardous situation and may void the
manufacturer's warranty.
Transport the unit with care. Sudden jolts or drops may cause damages in the interior
of the unit.
Observe all warning labels. Never remove warning labels.
Never operate damaged or leaking equipment.
Never operate the unit without bath fluid in the bath.
Always turn off the unit and disconnect the mains cable from the power source
before performing any service or maintenance procedures, or before moving the unit.
Always empty the bath before moving the unit.
Never operate equipment with damaged mains power cables.
Refer service and repairs to a qualified technician.
In addition to the safety warnings listed above, warnings are posted
throughout the manual. These warnings are designated by an exclamation
mark inside an equilateral triangle. Read and follow these important
instructions. Failure to observe these instructions can result in permanent
damage to the unit, significant property damage, personal injury or death.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
3
TABLE OF CONTENTS
1. Operating controls and functional elements...........................................5
2. The JULABO Quality Management System...........................................7
3. Description................................................................................................7
4. Unpacking and checking..........................................................................7
5. Preparations..............................................................................................8
5.1. Installation.....................................................................................8
5.2. Bath liquid......................................................................................8
5.3. Filling / Draining.............................................................................9
5.4. Maintaining a constant water level / Countercooling.................10
6. Operating procedures............................................................................11
6.1. Power connection.......................................................................11
7. Switching on............................................................................................11
7.1. Setting the temperature..............................................................12
7.2. Warning functions or temperature limit......................................12
7.3. Adjustment of the shaking frequency........................................14
7.4. Electronic timer...........................................................................15
8. Menu functions........................................................................................16
8.1. Shaking operation On/Off...........................................................16
8.2. Circulator pump on/off................................................................17
8.3. Temperature indication in °C or °F............................................17
8.4. ATC - Absolute Temperature Calibration..................................18
8.5. Setup for remote control............................................................19
8.6. Adjusting interface parameters..................................................20
8.7. Evaluation of the temperature limits ..........................................21
9. Safety installation (with shutdown function)...........................................22
10. Troubleshooting guide / Error messages.......................................22
10.1. Acoustical signals and their differentiation................................24
11. Electrical connection.........................................................................25
12. Remote control.................................................................................26
12.1. Communication with a PC or a superordinated data system...26
12.2. List of commands.......................................................................27
12.3. Status messages........................................................................27
12.4. Error messages..........................................................................28
13. OPERATING SAFETY / MAINTENANCE......................................29
13.1. Cleaning the unit.........................................................................29
14. TECHNICAL DATA..........................................................................30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
15. Warranty conditions..........................................................................32
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
5
1. OPERATING CONTROLS AND FUNCTIONAL ELEMENTS
1
Mains power switch, illuminated
on
off
2Working temperature
3High temperature warning limit
4Low temperature warning limit
5Operating hours indicator key
6Nominal value shaking frequency display key
7Indication:
•MULTI-DISPLAY (LED)
Temperature display optionally in °C or °F;
time display in h:m and shaking frequency.
The corresponding symbol will illuminate on selection.
•Indicator light - Alarm red illuminated
•Indicator light - Heating yellow illuminated
8Cursors left/right
9Edit keys (increase/decrease setting)
10 Enter key (store/quitting the audible signal)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Operating controls and functional elements
6
11
12
13
14
11 Drainage screw
Connector for liquid level/cooling set (accessory)
12 Mains power cable with plug
13 T 10 A power supply fuses behind side cover
14 RS232C interface
15 Shaking carriage - totally removable
- 8 kg load-carrying capability
16 Surface for placement of items (fixtures)
17 Stroke bar with fastening screw
19
17
15
16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
7
2. THE JULABO QUALITY MANAGEMENT SYSTEM
Development, production and distribution of temperature application
instruments for research and industries conform to the requirements
according to DIN EN ISO 9001:1994-08.
Certificate Registration No. QA 051004008.
3. DESCRIPTION
JULABO shaking water baths of the series SW22 and SW23 are ideally suited for
laboratory applications and research in the fields biology, biochemistry, pharma-
cology, chemistry and general medical technologies. They are likewise suited for
routine laboratory tasks and long-term unattended operation. The JULOBO shaking
water bath SW 23 with constant bath liquid circulation, ensures a constant water
temperature with a maximum deviation of ±0.02 °C .
Julabo shaking water baths feature a stainless steel bath containing heater,
temperature sensor and the overtemperature protection safety element. The shaking
carriage is totally removable.
The units are operated via a water protected foil keypad with integrated mains
switch. Microprocessor technology enables selection and storage of different
temperature values and operating times, and display of them in the LED-
MULTI-DISPLAY. The self-optimizing electronic PID-control circuit
automatically adjusts the heat supply to the value required by the bath.
The RS232C port permits modern process engineering without additional
interface, directly on-line, from the waterbath to your application equipment.
The overtemperature protection to DIN 12876-1: 2000 is a safety feature with a
fixed safety value of 130 °C. It functions independent of the regulator circuit.
The waterbaths conforms to the safety requirements specified by
DIN 12876-1: 2000 (class 1), as well as DIN 12876-2: 1999/12, the guideline for first
voltage range EN 61010.
FThe safety classification 1 permits unattended operation
with non-flammable bath liquids!
4. UNPACKING AND CHECKING
Unpack the shaking water bath and accessories and check for damages incurred
during transit. These should be reported to the responsible carrier, railway, or postal
authority, and a request for a damage report should be made. These instructions
must be followed fully for us to guarantee our full support of your claim for
protecting against loss from concealed damage. The form required for filing such a
claim will be provided by the carrier.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Preparations
8
5. PREPARATIONS
5.1. Installation
>80 mm
The installation site should meet the following
conditions:
1. The base of the installation site should be level to
ensure proper functioning of the safety features.
2. The laboratory table, for example, should be
sturdy enough, to where the shaking frequency
cannot cause vibration of the table. Consider that
the masses moved may be in the order of several
kg.
At unattended operation, the vibration may
cause items on the table top to fall off under
extreme unfavorable circumstances.
3. Keep a wall distance of minimum 80 mm.
5.2. Bath liquid •Recommended bath liquid: Water
Do not use flammable bath liquids!
No liability for use of other bath liquids!
The temperature controlling i.e. immersing of test tubes,
Erlenmeyer flasks or similar objects directly within the circulator
constitutes normal circulator practise.
We do not know which substances are contained within these
vessels. Many substances are:
•inflammable, easily ignited or explosive
•hazardous to health
•environmentally unsafe
i.e.:dangerous
You alone are responsible for the handling of these substances!
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
9
5.3. Filling / Draining
Filling:
•Maximum filling level: 6 cm below the bath rim
•Minimum filling level: 7 cm (level approx. 3 cm
above surface (16) for the placement of
items/fixtures)
Note:
The working filling level depends on size and number
of the items (fixtures) to be placed inside.
Fill to minimum level only. Insert the complemented
shaking carriage and correct the filling level (adding or
removing liquid) as required.
Draining:
•Switch off the shaking water bath with the mains
switch and move the equipment to the table edge.
•Place a suitable collecting bucket or tub underneath
the equipment for draining the used liquid.
•To drain the liquid open the dainage screw (11) on
the side of the water bath.
•After the liquid has been fully drained, securely
tighten the drainage screw (11) again.
Exercise CAUTION when emptying hot bath liquids!
Recommendation:
Use the water bath cover to keep temperature losses
to a minimum. This is especially important for working
temperatures above 70 °C.
Lift-up Makroloncover
Order No. 8 970 288
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Preparations
10
5.4. Maintaining a constant water level / Countercooling
For cooling tasks near the ambient air temperature the
liquid level/cooling set can be used for
countercooling.
By special pipe routing, cool faucet water is
continuously supplied to the water bath, while at the
same time, the heated water is drained via the overflow
connection of the Level/Cooling set.
A specific water flow rate of 100 ml/minute is
sufficient to compensate for the characteristic
temperature.
Use of the liquid level/cooling set for a continuous
supply of faucet water:
1. to keep the water level constant, especially for
applications up to the boiling point (supply of
faucet water only in the amount of evaporation
losses).
2. for countercooling of cooling tasks near the
ambient surrounding temperature (cool faucet water
is continuously supplied to the water bath, while at
the same time, the heated water is drained via the
overflow connection of the liquid level/cooling set).
Liquid level/cooling set
Order number: 8 970 415
11 drainage screw on water bath
20 compensation reservoir
21 connecting sleeve
22 supply/drainage sleeve
23 overflow sleeve
24 adaptor screw for constant liquid level function
25 adaptor screw assy. for countercooling function
and simultaneous constant liquid level control
26 adjuster screw for filling level adjustment
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
11
6. OPERATING PROCEDURES
6.1. Power connection
Connect the unit only to a grounded mains power socket!
We disclaim all liability for damage caused by incorrect line
voltages!
Check to make sure that the line voltage matches the
supply voltage specified on the identification plate.
Deviations of ±10 % are permissible.
7. SWITCHING ON
•Switching on:
Turn on the mains power switch.
The unit performs a self-test. All segments of the 4-digit
MULTI-DISPLAY (LED) and all indicator lights will
illuminate.
Then the software version (example: n 0.0) appears.
Together with the display of the water bath temperature
the operating state is also displayed.
(Example: 18.6 °C)
The monitor lamp illuminates when the heater is in
operation (on).
Notes:
•Adjustable parameters and temperature values are
retained and the electronic timer is reset to zero when the
equipment is switched off.
•When the shaking water bath is operating under remote
control at the time of switchoff (connected to PC via
RS-232 interface connection), the MULTI-DISPLAY
(LED) will display the message „OFF“.
(see chapter 8.5. Setup for remote control
•If shaking operation is not desired it can be switched off
at menu level. Select the menu level and activate the
option SA (see page 16)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Switching on
12
7.1. Setting the temperature
Display and adjustment of the working temperature:
•Press the setpoint key .
The indicator light blinks and the value previously set
appears on the MULTI-DISPLAY (LED).
(example: 25.0 °C).
If no further key is pressed the display will return to show
the actual bath temperature after approx. 8 seconds.
‚Use the cursor keys to move left or right on
the display until the numeral you wish to change is
blinking.
ƒUse the increase/decrease arrows to change
the selected numeral (0, 1, 2, 3, ... 9).
„Press enter to store the selected value
(example: 38.0 °C).
The working temperature is maintained constant after a
short heat-up time (e. g. 38.0 °C).
When the working temperature is higher than 90 °C, it might happen
that due to strong production of steam there is considerable dripping
on the inside of the lift-up Makroloncover. Some drops may fall
directly into the material to be tempered.
7.2. Warning functions or temperature limit
%)..)..)..)
More protection for your samples in the bath!
As soon as the actual temperature leaves one of the pre-
adjusted limits, this status is evaluated.
The high- and low-temperature limit can be evaluated in two
ways (see page 21).
1. As pure warning function with an acoustic signal in
regular intervals. (Signal - Pause)
(DBGM: G94 10 134.5)
2. As temperature limit by switching-off the heating and
alarm.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
13
Display and adjustment of over-/undertemperature:
•Press the key
(example: 41 °C)
or
(example: 35 °C).
The indicator light blinks and the value previously set
appears on the MULTI-DISPLAY (LED).
If no further key is pressed the display will return to show
the actual bath temperature after approx. 8 seconds.
‚Use the cursor keys to move left or right on
the display until the numeral you wish to change is
blinking.
ƒUse the increase/decrease arrows to change
the selected numeral (0, 1, 2, 3, ... 9).
„Press enter to store the selected value
38
C°
t
41
35
20
FNote:
The warning functions will be activated only after the bath
temperature has remained for at least 3 seconds within the
adjusted threshold values after the equipment is switched
on.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Switching on
14
7.3. Adjustment of the shaking frequency
The shaking frequency is adjustable between 20...200 rpm.
If shaking operation is not desired it can be switched off at
menu level. Select the menu level and activate the option
SA (see page 16)
Display and adjustment of the shaking frequency
•Press the key .
The indicator light blinks and the value previously set
appears on the MULTI-DISPLAY (LED).
(example: 120 rpm).
If no further key is pressed the display will return to show
the actual bath temperature after approx. 8 seconds.
‚Use the cursor keys to move left or right on
the display until the numeral you wish to change is
blinking.
ƒUse the increase/decrease arrows to change
the selected numeral (0, 1, 2, 3, ... 9).
„Press enter to store the selected value
CAUTION!
Do NOT reach between shaking carriage and bath
casing during shaking operation. Danger of injury!
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
15
7.4. Electronic timer
%))..))..))
The electronic timer enables adjustment of the operating
time up to a maximum of 9 hours and 59 minutes.
Countdown then commences to zero, at which time an
acoustical time signal will be issued in intervals
(double signal - pause).
- the equipment will not be switched off -
Display and adjustment of the operating time:
•Press the key .
The indicator light blinks and and the MULTI-
DISPLAY (LED) will display the remaining operating
time (example: 4.28 h:m).
If no further key is pressed the display will return to show
the actual bath temperature after approx. 8 seconds.
‚Use the cursor keys to move left or right on
the MULTI-DISPLAY (LED) until the numeral you wish
to change is blinking.
ƒUse the edit keys to increase or decrease the
numeral value (0, 1, 2, 3, ... 9).
„Press enter to store the value when the countdown
will commence. During that time the monitor lamp
(control lamp) will remain permanently illuminated.
When the operating time is expired an acoustical time signal
is issued in intervals.
=
Cancellation of the time signal:
Press enter to silence the time signal.
Notes:
•Following switch-on of the equipment and after a power
failure, the timer will show 0:00 h:m.
•When the equipment is operating remotely controlled
the timer is rendered inoperative.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Menu functions
16
8. MENU FUNCTIONS
Adjustment of parameters which, in most instances, need
only be adjusted once, are performed on the water bath at
menu level.
1. Shaking operation On/Off
2. Circulator pump On/Off
(Only shaking water bath SW23).
3. MULTI-DISPLAY temperature display in °C or °F
4. ATC (absolute temperature calibration)
5. Switchover to remote controlled operation
6. Adjustment of interface parameters
7. Adjustment of the high and low temperature limit. Choice
between pure warning function or a temperature limit by
switching off the heating.
Selecting/exiting the menu level.
•Simultaneously
press the cursor key and enter .
8.1. Shaking operation On/Off
ŒPress the cursor key and enter at the same
time.
•Use the cursor keys to select the menu
option „shaking operation“
example: „SA1“ = shaking frequency ON.
ŽSelect the alternative state with the edit keys
and confirm the selection with the ENTER key .
The display now shows „SA0“ = shaking frequency
OFF.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
17
8.2. Circulator pump on/off
Only shaking water bath SW23 feature a circulator pump.
The pump can be set to on and off at the menu level.
At working temperatures > 80°C the pump will switch off
automatically
ŒPress and at the same time.
•Use the cursor keys to select the menu option
PUMP
(example: „Pu1“ = Pump ON )
ŽSelect the alternative state with the edit keys
and confirm the selection with the ENTER key
(example: „Pu0“ = Pump OFF).
•Press and at the same time.
8.3. Temperature indication in °C or °F
The working temperature can be displayed in the MULTI-
DISPLAY (LED) in °C or °F as desired.
ŒPress and at the same time.
•Use the cursor keys to select the menu
option „temperature display“
(example: „t C“ = temperature display in °C).
ŽSelect the alternative state with the edit keys
and confirm the selection with the ENTER key .
The display now shows „t F“ = temperature display in
°F.
•Press and at the same time.
Switchover to the selected display mode takes place
automatically upon leaving the menu level.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Menu functions
18
8.4. ATC - Absolute Temperature Calibration
Internal sensor (TF)
Measuring point(TM)
ATC serves to compensate a temperature difference that
might occur between circulator and a defined measuring
point in the bath tank because of physical properties.
The difference temperature is determined (∆T= TM- TT)
and stored as correcting factor (example ∆T = -0.2 °C).
ŒPress the cursor key and enter at the same
time.
•Use the cursor keys to select the menu
option „At0“.
ŽWith the edit keys select "At1" and then
press enter .
Measuring point
Enter the corrective value.
•Using the cursor keys and the edit keys
set the correcting factor (example -0.20 °C)
and then press enter .
•Press and at the same time.
The temperature on the measuring point rises to a
temperature of 37.0 °C and is indicated on the
MULTI-DISPLAY (LED).
The ATC function stays activated until resetting to 00.0 °C.
FRecommendation:
Use a calibrated temperature measuring instrument.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Shaking Water Baths
19
8.5. Setup for remote control
If the shaking water bath is to be remotely controlled or
monitored, the parameter of the menu option REMOTE
must be changed and set from 0 to 1.
REMOTE 0 = Keypad control
1 = Remote control via RS232 interface
ŒPress and at the same time.
•Use the cursor keys to select the menu
option REMOTE
(display „r 0“).
ŽSelect the alternative state with the edit keys
and confirm the selection with the ENTER key
(display „r 1“).
The shaking water bath will switch to the REMOTE
„STOP“ condition and the MULTI-DISPLAY will
show the message „OFF“.
•Press and at the same time.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
