How to Set Up Your JATP400 Appliance

Overview

Juniper Networks Advanced Threat Prevention 400 (JATP400) appliance is an advanced threat prevention platform that is

designed to identify and prevent targeted attacks across multiple threat vectors. The appliance can be deployed as a Core device,

Traffic Collector, Email Collector, Manager of Central Managers (MCM), Secondary Core, or as an All-In-One device.

The JATP400 appliance is a 1-rack-unit (1-U), rack-mountable chassis with hot-swappable dual AC power supplies (or optional

dual DC power supplies), four hot-swappable hard disk drives that support RAID, 32-GB memory, two 10-Gigabit Ethernet

interfaces, two 10-Gigabit Ethernet SFP+ interfaces, and four 1-Gigabit Ethernet interfaces.

Package Contents

Verify that you have the following parts available:

•JATP400 appliance

•End User License Agreement

•Product registration information

•Documentation roadmap card

•Front bezel

•7 feet Ethernet cable, Qty 2

•DB-9 to RJ-45 adapter

•Rail kit

•Screws bag

•Rail adapters

•AC power cord, Qty 2

Front Panel

g100240

4 5

666

4—1— Reset buttonFront bezel

5—2— Power buttonLock

6—3— Hard driveLEDs

Back Panel

g100241

1 1

16 1314

2 4 5 6 7 8 9 10 11 12

9—1— RJ-45 1-Gigabit Ethernet LAN port (eth2, Alternate exhaust

interface)

Power supplies

10—2— RJ-45 1-Gigabit Ethernet LAN port (eth3)USB1 (2.0)

11—3— 10-Gigabit Ethernet SFP+ ports (eth5)Dedicated IPMI LAN port

12—4— 10-Gigabit Ethernet SFP+ ports (eth1), eth4 when this port is used

as 1-Gigabit Ethernet copper port for traffic monitoring

USB7 (3.0)

13—5— VGA port10-Gigabit Ethernet LAN port (GLAN1, eth6). This port is not

supported.

14—6— USB8 (3.0)10-Gigabit Ethernet LAN port (GLAN2, eth7). This port is not

supported.

15—7— USB2 (2.0)RJ-45 1-Gigabit Ethernet LAN port (eth0, management interface)

16—8— COM port. This port is not supported.RJ-45 1-Gigabit Ethernet LAN port (eth4), eth1 when this port is

used as 1-Gigabit Ethernet copper port

Specifications

1.7 in. x 17.2 in. x 25.6 in.Dimensions (H x W x D)

36 lbs (16.33 kg)Chassis weight

•500 W AC-DC redundant power supply

•650 W DC -DC redundant power supply

Power

How to Set Up Your JATP400 Appliance

Initial Configuration Process

g100242

Verifying the

Settings

Connecting the

Management

Device

Configuring a

JATP400

Appliance

Powering On

the Device

Step 1: Powering On the Appliance

CAUTION: Before connecting the appliance to the power supply, attach an ESD strap to an ESD point and fasten

the other end of the strap around your bare wrist.

1. Plug the power cord into the AC receptacle on the rear panel.

If your appliance contains two power supplies, plug each of the power cords into each of the AC receptacles.

g100251

NOTE: Grounding for the appliances is provided through the power supply ground terminal. Ensure that you

connect the AC power supply module in the appliance to a grounded AC power outlet by using an AC power cord

(with the grounding pin) appropriate for your geographical location.

2. Plug the other end of the power cord into a wall socket.

3. Press the Power button on the front panel.

4. Note the following indications:

g100243

1 2 3 4 56

How to Set Up Your JATP400 Appliance

Use the reset button to reboot the appliance and the power button to power on or power off the appliance.

StateLEDCallout

Depressing the UID (unit identifier) button illuminates an LED on both the front and rear of the

chassis for easy system location in large stack configurations. The LED will remain on until the

button is pushed a second time.

UID button1

•Solid red—Indicates an overheat condition, which might be caused due to cable congestion.

TIP: Check the routing of the cables if they are obstructing the airflow from the system.

•Blinking red (1Hz)—Fan failure; check for an inoperative fan.

•Blinking red (0.25Hz)—Power failure; check for an inoperative power supply.

•Solid blue—Local UID has been activated. Use this function to locate the server in a rack

environment.

•Blinking blue (300 msec)—Remote UID is on. Use this function to locate the server from a

remote location.

Information2

•Flashing—Indicates network activity on LAN port 2.

•Steady—Indicates link.

GLAN23

•Flashing—Indicates network activity on LAN port 1.

•Steady—Indicates link.

GLAN14

Indicates activity on a hard drive when ashing.Hard drive5

For AC power supply:

•Solid green—Indicates that the appliance is receiving power.

•Solid amber—Indicates that the power supply is plugged in and turned off, or the system is off

but in an abnormal state.

For DC power supply:

•Solid green—Indicates that the appliance is receiving power.

•Solid amber—Indicates that the power supply is plugged in and turned off, or the system is off

but in an abnormal state.

•Amber (blinking)—Indicates that the system power supply temperature has reached 63° C.

•The system powers down automatically when the power supply temperature reaches 70° C

and restarts when the power supply temperature goes below 60° C.

Power6

Step 2: Connecting the Management Device

You can connect external devices to the JATP400 appliance using the ports on the back panel.

To connect a keyboard and monitor to the JATP400 appliance:

1. Connect the end of the keyboard cable to any of the USB ports on the back panel of the appliance.

2. Connect the end of the video monitor cable to the VGA port on the back panel of the appliance.

Step 3: Configuring a JATP400 Appliance

The following topics describe the steps to configure a JATP400 appliance:

•Selecting the Form Factor on page 5

•Configuring the IP Address and Domain Name Servers on page 6

•Configuring the Device Host Name on page 6

How to Set Up Your JATP400 Appliance

•Configuring the Alternate Exhaust Interface on page 7

•Configuring the Device Basic Attributes on page 7

Selecting the Form Factor

To select a form factor:

1. At the console prompt, log in to JATP with the following default credentials: username admin and the password 1JATP234.

NOTE: The username is case sensitive.

2. Press Enter.

The End User License Agreement (EULA) appears.

3. Read the information and press the Spacebar to advance each window until you have reached the end of the agreement.

4. Type Yes to accept the agreement, and then press Enter.

5. Enter a new CLI admin password to change the default password and then press Enter.

NOTE: The password must be at least eight characters long.

6. Reenter the new password and then press Enter.

Juniper Networks Advanced Threat Prevention window appears.

NOTE: By default, the JATP400 is installed as an All-In-One appliance.

7. Type Yes if you want to change the appliance form factor.

NOTE: If you type No, then:

a. Type Yes to confirm that you do not want to change the appliance form factor.

b. Proceed to Step 10.

How to Set Up Your JATP400 Appliance

8. Enter a number from 1-4 to choose your desired form factor. For example, enter 2to change the All-In-One to Traffic Collector

form factor.

9. Type Yes to reconfirm to change the current form factor of the appliance.

Services are restarted and a successful confirmation message displays about the change of the form factor.

10. Type Yes to configure the system by using the configuration wizard.

Configuring the IP Address and Domain Name Servers

To configure the JATP network settings, enter the values for the following parameters:

NOTE: Use the up or down arrow keys to navigate the fields.

1. Type the IP address of the management interface (eth0).

2. Enter the network mask address for the eth0 interface.

3. Enter the default gateway for the eth0 interface.

4. Enter the primary DNS server for the eth0 interface.

5. (Optional) Type Yes and enter the IP address of the secondary DNS server for the eth0 interface.

6. (Optional) Type Yes and enter the search domain for the eth0 interface. For example, example.com.

NOTE: Provide a space to enter multiple search domains.

7. Type Yes and press Enter to restart the management (eth0) interface.

NOTE: The network interface restart can take up to more than 60 seconds.

Configuring the Device Host Name

To configure the device host name:

1. Enter a valid hostname. For example, JATP400.

NOTE: Enter a unique name for the host and do not include the domain.

Updates server to JATP400.example.com.

2. Type Yes to create a new SSL certificate for the JATP Appliance Server Web UI.

How to Set Up Your JATP400 Appliance

NOTE: If you decline the self-signed certificate by entering No, the JATP400 appliance will continue to use the

existing certificates. These certificates might contain an incorrect hostname or fully qualified domain name

(FQDN). To resolve this issue on the Web UI, regenerate a new self-signed SSL certificate or upload your private

key and certificate. For more information on the certificates, see the Managing Certificates section in the Operator’s

Guide.

SSL self-signed certificate is regenerated successfully and the hostname will be updated after the next login.

Configuring the Alternate Exhaust Interface

To configure the alternate exhaust interface:

1. (Optional) Type No to not to use the alternate exhaust interface for the analysis engine exhaust traffic.

Use the alternate exhaust interface for external connectivity in threat detection.

NOTE: You can configure alternate exhaust interface only for Core or All-In-One appliance.

Configuring the Device Basic Attributes

To configure basic server attributes:

1. Type Yes if the device is a Core, an All-In-One, or a Manager of Central Managers (MCM) system.

NOTE: If your device is a Traffic Collector, a Secondary Core, or an Email Collector, type No and enter the Core or

All-In-One IP address.

2. Enter the device name.

3. Enter the device description.

4. Enter the device key passphrase.

NOTE: You must enclose white space and \ special characters in double quotation marks.

How to Set Up Your JATP400 Appliance

5. Press Enter to complete the installation.

All services are restarted. You are now ready to access JATP.

6. Type exit and press Enter.

Step 4: Verifying the Settings

To verify the appliance configuration settings.

1. Open your Web browser.

2. Log in to your JATP appliance: https://<IP Address>

Where <IP Address> is the IP address of the JATP appliance.

3. Enter the default username admin and the default password juniper.

Ensure to change the default password after the login. The password must be at least eight characters long.

How to Set Up Your JATP400 Appliance

4. Click Log In.

With this step, you have successfully completed the configuration, and your JATP400 appliance is ready for use.

Powering Off the Appliance

You can power off the JATP400 appliance in one of the following ways:

•Graceful shutdown—Press and immediately release the Power button. Or

You can run the following command in the server configuration mode:

shutdown

•Forced shutdown—Press the Power button, and hold it for five seconds. Use this method only if the appliance is not responding

to the graceful shutdown method.
