Juren DZ-1B User manual

DZ-1B Home oxygen generator
!"#$%"&'()!(*
Please read the manual before use
!
!
table of Contents
!"#$%&$'%( .............................................................................................................................. 1
)
*"+&%,-./'012"30&"2-3%".2% ......................................................................................... 2

4*"5/&.,/.&-6",7-&-,/%&'2/',2"-18"(0&9'1:";&'1,';6% ...................................... 3
4. Technical characteristics .................................................................................................. 5
<*"=1;-,9'1:"-18"'12/-66-/'01
..................................................................................... 7
>*"=2%"-18"0;%&-/'01
........................................................................................................ 9
?"@-.6/"-1-6A2'2"-18"/&0.B6%2700/'1:
................................................................... 11
C*"D-'1/%1-1,%"-18",-&%
............................................................................................... 12
9. Transportation and storage ........................................................................................... 14
!E*"F-&&-1/A";%&'08"-18"-3/%&G2-6%2"2%&$',%
.................................................... 15
!!*"+-,9'1:"6'2/H"2.;;0&/'1:"-,,%220&'%2"2;%,'3',-/'012
........................... 16

- 1 -
!!Overview!
Thank you for purchasing our domestic oxygen generator.
In order to ensure that you can use this oxygen generator safely and correctly,
please read this manual carefully before using it to fully understand and master the
performance of the product and the correct operation and maintenance methods.
This manual describes the operation, use, and maintenance of the DZ-1B domestic
oxygen generator.
1.1 Product Features
The DZ-1B household oxygen generator is one of the series of products produced
by our company. The product uses molecular sieve as the adsorbent, uses the advanced
pressure swing adsorption (PSA) principle, and uses air as the raw material to produce
oxygen through physical means. The following features:
1) The air is taken from nature.
2) Adopt advanced pressure swing adsorption technology (PSA), advanced process
flow and low energy consumption.
3) The product has a novel shape design, simple operation, stable operation and
convenient maintenance.

- 2 -
"
#$%&'()*+,-./$0-&$/)0'$*/'$
When using this product, please observe the following safety precautions:
oxygen is a combustion-supporting gas ,it is not allowed to use the oxygen generator in an environment with
bright or dark fire source or with flammable or explosive danger. Smoking is strictly prohibited near the oxygen
inhaler
It is not allowed to place the oxygen tube under the bedspread or seat cushion . when there is no oxygen
absorption ,turn off the power supply of the oxygen generator .
The power supply must meet the requirements for safe use of electricity. if the power supply does not meet the
requirements, do not use oxygen generator .
Please turn off the power supply and unplug the power plug ,before cleaning ,maintaining or replacing the safety
tube of the oxygen generator .
Improper use of power cord and plug may cause burns or other electric shock hazards. do not use if the power
cord is damaged . To avoid danger, it must be replaced by a professional authorized by the manufacturer .Unplug
the power plug.
Please select safe and qualified socket and wiring board with safety electrician .
It is forbidden to plug in or unplug the power supply with wet hands . It is forbidden to drag the machine through
the traction oxygen absorption pipe or power line.
Personnel not authorized by the company shall not remove the cover for maintenance.

- 3 -
1#$2+&*(+*&)3$(4)&)(+'&,/+,(/$).5$6-&7,.8$9&,.(,93'$
Figure 1 DZ-1B domestic oxygen generator outline drawing
Control panel
and display
Humidifying cup
Oxygen
outlet
Atomization switch and
outlet
Carry
handle
Inlet silencer filter
switch
power cable
Ve n t s
Nameplate
Tele control
reception

- 4 -
1#$2+&*(+*&)3$(4)&)(+'&,/+,(/$).5$6-&7,.8$9&,.(,93'$
3.2 Working principle
The oxygen flow of DZ-1B oxygen generation mechanism is shown in Figure 2:
Figure 2 Oxygen flow diagram of the oxygen generation mechanism
The DZ-1B type domestic oxygen generator uses molecular sieve as the adsorbent
and uses the principle of pressure swing adsorption (PSA) to filter the air and send it to
the molecular sieve adsorption tower for pressure adsorption and decompression.
oxygen.

- 5 -
4. Technical characteristics
$
4.1 Use environment
Ambient temperature: 10 ℃ ~ 40 ℃
Relative humidity 30% ~ 75%
Atmospheric pressure 86.0kPa ~ 106.0kPa
220 -240V（+5/-10V）
Power frequency 50Hz ± 1Hz
4.2 Working conditions
Impurities in raw air ≤ 0.3 mg / cm 3
Oil content in the air ≤ 0.01 ppm
The$ surrounding$ environment$ should$ be$ free$ of$ corrosive$ gases$ and$ strong$
magnetic$fields$
4.3 Product Features
Display mode: digital tube display, English characters
Timing function continuous running timing, timing running timing, automatic
cumulative timing
Atomization function
Remote control function: infrared remote control operation
Local this key is invalid

- 6 -
4. Technical characteristics
4.4 Technical indicators
Oxygen concentration（when the flow≤1 liter） 90 ± 3% (v / v)
Carbon dioxide content ≤0.01% (v / v)
Smell Odorless
Particle size of solid matter ≤10um
Solid matter content ≤0.5mg / m 3
Product technical indicators:
Adjustment range (1 ~ 7 L / min)可调
Running noise ≤60dB (A)
Timer error ≤ ± 3%
Input power 150W
Machine weight about 6kg
Outline size 390 × 270 × 200 mm

- 7 -
:#$;.9)(7,.8$).5$,./+)33)+,-.$
5.1 Unpacking
Open the box from the top surface of the box, remove the foam, open the plastic
bag, pull the back cover handle, and take out the oxygen generator.
5.2 Inspection
First check the oxygen generator for transportation damage, and then check the
accessories and random documents according to the packing list.
5.3 Installation precautions
When installing the oxygen generator, please observe the following precautions:
5.4 Installation
1) Before use, loosen (or draw out) the bottom Velcro strap to avoid the air
compressor working in a vibration state.
2) Add water to the humidifier: Turn off the power of the oxygen generator, put your
fingers on the fingers of the humidifier, and gently pull out the humidifier. Pull out the
water-filled silicone plug on the humidifier, The water injection funnel delivered is
Installation Precautions
1. The oxygen generator should be installed in an indoor ventilation place free of dust, corrosion, toxic and
harmful gases and oil mist. Avoid direct sunlight, and the distance from the wall and other objects should be greater
than 20 cm.
2. The oxygen generator cannot be installed in a place with bright or dark fire sources, flammable, explosive
danger, humidity, high or low temperature, or used in a closed room (space).
3. The air inlet of the oxygen generator (above the rear shell of the machine) should be well ventilated.
4. Keep the oxygen generator stable, otherwise it will increase the noise during operation.
5. It is forbidden to lay on the oxygen generator.
6. The oxygen generator uses 220-240V (+ 5 / -10V), 50 ± 1Hz single-phase AC power. If the grid voltage is
unstable, it will affect the normal startup of the compressor. Please install a voltage stabilizer.
7. Before using the oxygen generator, you must loosen (or withdraw) the Velcro strap under the fuselage.

- 8 -
:#$;.9)(7,.8$).5$,./+)33)+,-.$$
inserted into the water injection hole, and an appropriate amount of pure water is poured
into the humidification cup through the funnel (the liquid level should not exceed the
highest water level line). Take out the funnel, plug the water injection silicone plug at the
water injection hole, and then insert the humidification cup Back (see Figure 3).
"
Figure 3 Humidification cup"
Finger
pull
Water-filled
silicone plug
Wat er
injection
hole

- 9 -
<#$;/'$).5$-9'&)+,-.$
6.1 Precautions for use
When using an oxygen generator, please observe the following precautions:
6.2 Use
The touch display control panel of DZ-1B oxygen generator is shown in Figure 4:
Figure 4 Control panel of DZ-1B oxygen generator
Precautions for use
1. Make sure that the exhaust of the bottom of the oxygen generator is unobstructed during use, otherwise it will
affect the heat dissipation of the oxygen generator.
2. The specified performance can only be achieved after the oxygen generator is started for 10 minutes.
3. There is a gap of exhaust sound when the oxygen generator is in use (about once every 4 seconds).
4. Do not use oil, grease or other similar substances on or near the oxygen generator.
5. In use, when the water in the humidifying cup is insufficient, make up for it in time.
6. The oxygen generator cannot be started frequently. It should be restarted after 5 minutes after shutting down.
7. Molecular sieves will age due to factors such as the use time and the environment, which will cause the
recoverability of the oxygen production to decrease. When this phenomenon is found, please contact the
maintenance point or the manufacturer to replace the molecular sieve.
8. When the oxygen generator is stopped, you must unplug the power cord.
9. During the use of the oxygen generator, the shutdown due to the high ambient temperature and the thermal
protection of the air compressor is a normal phenomenon. The power must be turned off and the machine cooled
down before being used.

- 10 -
>*"=2%"-18"0;%&-/'01"
1) Turn on the power: Plug in the power cord and turn on the power. Turn on the power switch (located at the bottom of the
back of the oxygen generator), the oxygen generator starts, and the touch button at the bottom of the screen lights up to enter the
standby state.
2) Continuous oxygen generation: Touch the "Oxygen" button on the control panel, and with the voice prompt of a real
person, the oxygen generator enters the "continuous oxygen generation" working state. The continuous oxygen generation time
of the oxygen generator is displayed on the top of the screen, and the bottom of the screen is displayed The cumulative use time
of the oxygen machine.
3) Adjusting the flow rate: Touch the "flow +" key on the control panel, accompanied by the voice prompt of a human voice,
and increase the oxygen flow rate of the oxygen generator by 1 l, up to 7 l; touch the "flow-" key on the control panel,
accompanied by real voice Prompt tone, the oxygen flow of the oxygen generator is reduced by 1l, and the lowest can be
adjusted to 1l.
4) Start oxygen inhalation: Insert the oxygen inhaler into the "Oxygen Socket", confirm the oxygen output from the nose of
the oxygen inhaler, wear the oxygen inhaler (for the method of wearing the oxygen inhaler, please refer to the instructions of the
oxygen inhaler) to start oxygen inhalation. .
5) Atomizing operation: Unscrew the knurled screw of the atomizing socket by hand, first insert the inlet pipe of the atomizer
into the atomizing socket, touch the "oxygen" key, the flow rate is adjusted to 1 liter, and the air compressor starts The
atomization can be performed at work. For the use of the atomizer, please follow the instructions of the atomizer's instruction
manual. After the atomization is over, touch the "oxygen" key, the air compressor will stop working, and the atomizer will be
unplugged. Air tube, and then screw the knurled screw back to the atomizing socket. (For the operation process of the atomizer
and atomization, please refer to the atomizer manual)
6) Time setting: Touch the "Timing +" key on the control panel, the oxygen generator will enter the "Timing Oxygen" state.
The user can preset the oxygen time according to the needs. Each time you touch the "Timing +" key, the preset The setting
time is increased by 5 minutes. The user can also press and hold the "Timing +" button. This operation mode allows the preset
time to be superimposed in 5 minutes. The maximum time can be 9 hours and 55 minutes. The "Timing-" button can reduce the
preset time. The timing of oxygen generation, each time you touch the "timing-" key, the preset time is reduced by 5 minutes, or
press and hold the "timing-" key, this operation mode can continuously reduce the preset time by 5 minutes, until the reduction
is At 0 o'clock, the oxygen generator changes from "timed oxygen" state to "continuous oxygen" state.
7) Shut down: When the "timed oxygen generator" of the oxygen generator is finished or the "oxygen generator" button is
touched in the state of "continuous oxygen generator", the oxygen generator display goes out but the humidifier lamp is still on
and the oxygen generator is in standby In the standby state, touch any key to light up the display, and then touch the "oxygen"
key to enter the "continuous oxygen" state. Press the power switch when the oxygen generator is in "standby state" or

- 11 -
=$>)*3+$).)3?/,/$).5$+&-*@3'/4--+,.8$
"continuous oxygen" The oxygen generator can be completely powered off and shut down.
If you have a problem using the oxygen generator, please read this chapter carefully
before sending it for repair. You may be able to solve the problem yourself very easily.
If you cannot solve the problem successfully according to the suggestions in this
chapter, please unplug the oxygen generator and send it for repair. Do not try to repair
the oxygen generator or remove the casing of the oxygen generator yourself.
Examples of fault analysis and troubleshooting are shown in Table 1:
Table 1 Failure analysis and troubleshooting example table
Failure phenomenon
Cause Analysis
Method of exclusion
When turned on, the oxygen
generator does not work and the
display does not light up.
1. Is the power on?
2. Is the fuse blown?
1. Check and tighten the power
cord.
2. Replace the fuse.
When the oxygen generator is
running, the air compressor does not
rotate when it is rotated.
Unstable power supply voltage?
Configure a dedicated voltage
regulator.
The oxygen generator is operating
normally, but there is no oxygen
output from the oxygen pipe.
1. The oxygen pipe plug is not
inserted properly.
2. The humidifier cup is not in place.
1. Plug the oxygen pipe plug in.
2. Install the humidifier in place.
Start up works normally, no
bubbles in the humidification cup.
1. The air intake filter is blocked by
dust.
2. The oxygen suction tube is
dead-folded or squeezed to block the
outlet pipe
1. Clean or replace the filter.
2. Smooth out the oxygen suction
tube.
Noisy running
1.The oxygen generator is not placed
smoothly.
2.Bottom cable tie is not loosened
1.Place the oxygen generator
smoothly.
2. Loosen the bottom cable tie
Other faults
Contact the dealer or manufacturer. Do not repair by non-professionals.
Maintenance Tel: [phone] (Maintenance)

- 12 -
A#$B),.+'.).('$).5$()&'$
8.1 Maintenance precautions
When performing maintenance, please observe the following precautions:
"
"
8.2 Cleaning the humidifier
Pull out the humidification cup in the direction shown in Figure 3, remove the rubber plug of the
water injection hole and wash it with water. Generally, it can be washed with water.
After cleaning, sterilize (recommended with a disinfectant containing 500mg / L of effective
chlorine) and rinse with pure water. Add an appropriate amount of pure water (the water level should be
below the highest level) to the cup, and plug the rubber plug of the water injection hole Back (to prevent
oxygen from leaking from the water injection hole), plug in the humidifier and use it.
8.3 Cleaning the oxygen generator
In the case of cutting off the power of the oxygen generator, you can use a soft towel dipped in a
small amount of neutral household detergent to clean the whole area, and then dry it with a dry towel.
When wiping, care should be taken not to allow liquid to penetrate the gaps in the chassis.
8.4 Cleaning of Intake Silencer Filter
Clean the intake muffler and intake cover weekly.
Maintenance precautions
1. If the oxygen generator fails, you should contact the dealer or the manufacturer for repair. Only personnel
authorized by the manufacturer can debug and repair the oxygen generator. Do not disassemble and repair it by
yourself.
2. Under normal use, the humidification cup should be kept clean. The humidification cup should be filled with
pure water and the water level should be below the maximum water level. It is recommended to clean the
humidification cup, air filter cotton and air intake cover once a week to ensure Oxygen Hygiene.
3. The power cord is configured according to the power of the oxygen generator, please do not replace it at will.
4. Cleaning the oxygen suction tube, please follow the instructions in the instruction manual of the accessory.
5. Before using the oxygen generator for a long time, it should be turned on and checked before use, and it should
be put into use after confirming that the functions are normal.

- 13 -
!"#$%&'()'%'*)#%'+#*%,)#
8.5 Cleaning the oxygen pipe
The oxygen tube supplied by the oxygen generator is a single-use sterilized product and should be
replaced by a special person. It should be replaced regularly. The nose of the oxygen tube should be
cleaned and disinfected after each use. Wash it with water after soaking for 5 minutes; it can also be
wiped with medical alcohol. It is recommended that the oxygen suction tube be replaced every one year
after use. (Note: The oxygen suction tube should be kept dry.)
8.6 Replacement of the fuse
The fuse holder is located on the control board of the oxygen generator.The specification of the fuse
is: f2.0al250v φ5 × 20.
The replacement of the safety tube requires a professional or the company's maintenance service
department.
8.7 Handling during long periods of inactivity
Before preparing to leave the oxygen generator for a long time, please do the following:
(1) Remove the humidification cup, drain the water from the humidification cup, and put it back in
place.
(2) Cut off the power and retract the power cord.
(3) Store the oxygen suction tube dry at room temperature to avoid direct sunlight and pollution.
After leaving the oxygen generator for a long time, before you prepare to reuse it, please do the
following:
(1) Inspect the power cord for damage.
(2) Clean the oxygen suction tube, check whether it is blocked or discounted, and clean it up in
time.
(3) Clean the humidification cup.
(4) Clean the intake silencer and the air intake cover.

- 14 -
9. Transportation and storage
9.1 Precautions for transportation and storage
Please observe the following precautions during transportation and storage:
9.2 Environmental requirements for storage and transportation
Ambient temperature: -20 ℃ ~ 50 ℃;
Relative humidity ≤95%;
Atmospheric pressure 500hPa ~ 1060hPa.
9.3 Transport
The oxygen generator with complete packaging should avoid severe collision and
direct rain and snow during transportation.
9.4 Storage
The oxygen generator should be stored in a well-ventilated room that avoids strong
sunlight and non-corrosive gases.
"
"
Precautions for transportation and storage
1. Before the oxygen generator is transported or stored, the water in the
humidification cup should be drained.
2. It is forbidden to place the oxygen generator upside down or horizontally
during transportation and handling.
3. When the storage temperature is lower than 10 ℃, the oxygen generator
should be left in the normal working environment for 8 hours before use.
4. The oxygen generator has been disabled for a long time, and it should be
turned on and checked before use, and it can be put into use after confirming that
all functions are normal.

- 15 -
!C#$D)&&).+?$9'&,-5$).5$)0+'&E/)3'/$/'&F,('$
"
10.1 Warranty period
Since the product was sold, the warranty period is as long as the requirements for handling,
storage, use and maintenance are observed.
One year, and the product usage time is less than 3000 hours. If one of the following situations
occurs, it does not belong to our company
Free warranty coverage:
1) Damage caused by the user's incorrect operation or use under abnormal conditions.
2) The damage caused by the user's own disassembly, repair and modification.
3) Damage caused by natural disasters.
4) Fragile, consumables and accessories that should be replaced by the user (such as
oxygen suction tubes, insurance tubes, filters, etc.).
5) Cannot provide proof of purchase to prove the date of purchase.
10.2 Disclaimer
The company is not responsible for direct or indirect damages to users due to improper
use or failure to operate in accordance with the instruction manual.
10.3 After-sales service
The company has maintenance points at various dealers to maintain products for
life. It only charges maintenance costs and offers a variety of spare parts at a discount.

!!#$%)(7,.8$3,/+G$/*99-&+,.8$)(('//-&,'/$/9'(,0,()+,-./$
11.1 Attentions for selecting accessories
When choosing accessories, please observe the following precautions:
11.2 Packing List
Table 2 Packing list of DZ-1B domestic oxygen generator
Serial
number
model
name
unit
Quantit
y
Notes
1
DZ-1B
Host of home oxygen
generator
station
1
2
Oxygen pipe
root
1
3
Nebulizer
set
1
4
remote control
Each
1
5
Intake filter
Each
1
6
Sealing ring
only
4
7
user's manual
this
1
8
Product certification
Share
1
Attentions for selecting accessories
1. The oxygen generator uses a special humidification cup. If you need repair or
replacement, please contact the supplier.
2. The oxygen suction tube should use qualified products with medical device
registration certificate, and can be tightly connected with the corresponding
"oxygen output" socket of the oxygen generator. Users can purchase according to
the sample specifications in the random accessories. Avoid adverse effects on
safety.

!!warranty!card!
Purchase account:
Order number:
contact number:
Shipping address:
Receiving Name:
Reason for repair:
Date of purchase:
"#$%&'%#%(')*'(+,-).+,/)
8-/%"
@-'6.&%";7%10I%101"
D-'1/%1-1,%"
&%,0&82"
J%;-'&"
I-1"
"
"
"
"
"
"
"
"
"
"
"
"
D)&&).+?$()&5$5'/(&,9+,-.$
l After the user purchases the product, the user information of the warranty card
should be filled in and kept properly.
l Within one year from the date of purchase by the user and within 3,000 hours of
use, you can enjoy the free warranty of the entire machine, subject to the requirements
of handling, storage, use and warranty instructions.
l During the product warranty period, users can take the warranty card to the
company's after-sales department or local distributors to enjoy the company's free
maintenance service; beyond the warranty period, a maintenance cost fee is charged.
l Please bring the user warranty card when repairing
This card is saved by the user
