Just Add Power Cardware VBS-PTP-308B User manual

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 1of 28
Worship
Center
Broadcast
System
Installation Guide
Just Add Power Cardware Company
www.justaddpower.com
[e-mail]

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 2of 28
Worship Center Broadcast System
Installation Guide
Table of Contents
Introduction.....................................................................................................................................................3
WCBS Functions ........................................................................................................................................ 3
System Components ...................................................................................................................................4
Installation Procedure .....................................................................................................................................5
Receiver Box Installation............................................................................................................................5
Connect Receivers to the Video Genie™ Bus Ports ................................................................................... 6
Video Genie™ DS1 Hardware Installation and Configuration................................................................... 6
Worship Center Broadcast System Software Installation and Configuration .................................................8
1 of 3 Install the WCBS Graphical User Interface..................................................................................8
2 of 3 Install the HotKeys utility program ............................................................................................ 10
3 of 3 Customize the Worship Center Broadcast System Graphical User Interface .............................11
Change Serial Port .................................................................................................................................... 11
Disable or Enable Hotkeys........................................................................................................................ 11
Change Messages...................................................................................................................................... 12
Message Save........................................................................................................................................12
Change Delay Timer.................................................................................................................................12
IR Learning Mode.....................................................................................................................................13
Worship Center Broadcast System Operation............................................................................................... 14
Broadcast Buttons.....................................................................................................................................14
A/V Source Buttons .................................................................................................................................. 14
Resolution Button ..................................................................................................................................... 14
MONITOR Preview Buttons ....................................................................................................................14
Control Buttons.........................................................................................................................................15
Matrix Buttons ..........................................................................................................................................15
F10 –Split Button..................................................................................................................................... 15
IR Matrix ..................................................................................................................................................15
RS232 Remote Control.............................................................................................................................16
Total Control Console Basic Operation........................................................................................................ 19
Total Control Console™ System setup.....................................................................................................22
Panel Key Sounds on/ off .........................................................................................................................22
IR Command Learning ............................................................................................................................. 22
Group Port Setting ....................................................................................................................................23
Video Scaler Resolution setting................................................................................................................ 23
Basic Trouble Shooting Techniques ............................................................................................................. 25
Example Diagnostic Procedures ................................................................................................................... 25
Specific Problem Diagnosis..........................................................................................................................26

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 3of 28
Introduction
Welcome to the Worship Center Broadcast System (WCBS). The primary function of the WCBS is to
connect computers and video devices (VCR, Camera, DVD, Satellite, etc.) to viewing screens. The
viewing screens can be LCD projectors, CRT monitors, LCD panels, and other compatible VGA devices.
The typical installation includes the Video Genie DS1 matrix switcher that combines a video scaler
(converts Video signals to high resolution VGA signals), a video switch (instantly switches between several
VGA and Video signals), and a CAT5e based audio/video distribution system (inexpensive industry
standard cabling).
The WCBS is a hardware-based audio/video switching system that can be installed with any computer
system using VGA compatible graphics (this includes IBM compatible PC’s and Macintosh PC’s running
any operating system). The WCBS requires you to install a small Receiver Box adjacent to every viewing
screen that will be connected to the system.
Your choice of the WCBS will give you many benefits:
•Easy to use system –a simple click of the mouse performs most functions.
•Fast Switching -Eliminates the unwanted delay seen switching from Video Mode to VGA mode
•Easy Expansion –You can use WCBS to transmit the video and audio to an unlimited number of
viewing screens.
•Enhanced Functionality –The WCBS can be used for more sophisticated functions such as
Multicasting (showing different video signals to different groups)
One of the greatest strengths of the WCBS is realized because the system is entirely hardware based. You
can install your WCBS system with complete confidence that it will in no way impact your software or
system performance. This is possible because WCBS requires no software, no drivers, no memory, and no
interrupts.
WCBS Functions
The easy to use functions of the WCBS are quite sophisticated, allowing the owner to apply the most
effective audio/video distribution strategies possible.
•Darken All Screens/Projectors
•Darken Group Screens/Projectors
•Broadcast Audio/Video to All
•Broadcast Audio/Video to Group
•Independent Rear Projector Output
•Matrix output (audio/video are independent)
•Video Genie™ DS1 supports full motion
full screen video (60 fps) from 4 sources
•Support for unlimited attached devices
•Infrared Remote Control learning (DS1)
•Software based RS232 Remote Control
•All functions delivered over CAT5e cable

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 4of 28
System Components
You dealer should have helped you order the right components to install your WCBS. If you ever need to
order replacement parts, or make additions to your system, please refer to the following chart:
Item
Part Number
Projector Connector™ Transmitter –Type B
VBS-PTP-308B
Video Genie™ DS0 2x10 Matrix Switcher/Transmitter
VBS-ST-308AS
Video Genie™ DS1 3x10 Matrix Switcher/Scaler/Transmitter
VBS-ST-308AV
Projector Connector™ Passive Receiver (10, 20, 30, 40, 50, or 60M)
VBS-PTP-108B-xxM
Projector Connector™ Extended Receiver –200’ to 1000’ distances
VBS-PTP-300M
Projector Connector™ Dual Monitor Active Receiver
VBS-ST-1082B
UTP Terminators
VBS-TR8
Total Control Console™
VBS-ST-400A
Guiding Light™ Keyboard
VBS-SLK-4502
Projector Connector™ Transmitter/Receivers
Video Genie™ DS0
Video Genie™ DS1
Projector Connector™ Extended Receiver
Projector Connector™ Dual Monitor Receiver
Total Control Console™
Guiding Light™ Keyboard

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 5of 28
Installation Procedure
The installation of the WCBS is quite easy and can be summarized as follows:
1. Install a Receiver Box at each viewing device (page 5)
2. Connect all Receiver Boxes devices to the Video Genie Transmitter (page 6)
3. Install Video Genie™
Detailed instructions for each step are provided on the following pages.
Receiver Box Installation
Use the VBS-PTP-108B Receiver Box for Projectors and Stand Alone Monitors installed within 60 Meters
(200’) of the Video Genie. The VBS -PTP-108B is available in 6 models, tuned with Video Gain settings
for UTP/STP cables in 10M increments. Choose the model that is closest to the installed cable distance.
Use the VBS-PTP-300M Receiver Box for cable distances between 200’ and 1,000’. The VBS -PTP-300M
has fine tuning knobs to adjust the gain/focus for optimal image outputs.
Use the VBS-ST-1082B Dual Monitor Receiver for locations with multiple monitors. This device also has
the option to display a local VGA source when the WCBS transmitter is in break mode (i.e. rolling
announcements in the Narthex or Hallway when not showing a worship service)
Installation of the VBS-PTP-108B Receiver Box should be performed as follows:
1. Turn off the power to the projector or monitor.
2. Locate the VBS-PTP-108B Receiver Box kit for the viewing device. Each VBS-PTP-108B Receiver
Box kit includes the following items:
Receiver Box
AC Adapter
1.2M VGA Cable
3. Use the VGA Cable to connect the computer monitor or projector to
the VGA port labeled monitor. Longer VGA cables can be used to
accommodate conduits and other cosmetic connections.
4. If you are going to broadcast sounds to this position, you can use a
3.5mm stereo mini-plug type cable to connect the speakers or
headphones from the display station to the green 3 audio out port on the
Receiver Box.
5. If you are installing the VBS-ST-1082B receiver you can
connect the VGA Output of the announcements PC to the port
labeled VGA. This VGA signal will be displayed on the
attached monitor/projector when the WCBS is not controlling
the output device.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 6of 28
Connect Receivers to the Video Genie™ Bus Ports
The Video Genie™ has 8 UTP/STP Bus Ports. You can connect one VBS-PTP receiver to each port with a
single twisted pair cable. You can attach multiple VBS-ST dual monitor receivers to each bus port in a
daisy-chain. When installing multiple receivers on a best port we suggest that you follow these guidelines
for the best quality audio/video transmissions:
•Keep the CAT5e cable length from the Video Genie™ to the first receiver box under 50 Meters.
•Keep the CAT5e cable distance between any two receiver boxes in a chain under 25 Meters.
•Do not connect more than 10 receiver stations in a single chain.
•Try to keep the total CAT5e cable length out of any booster port under 100 Meters.
•Whenever possible, use the shortest possible cable lengths.
•Install a Blue Terminator plug in the open bus port at the end of a receiver daisy-chain.
While it is certainly possible to achieve acceptable results outside of these guidelines, keep in mind
that the local environmental conditions (type of devices, amount of RFI noise, dirty power, defective
lighting ballasts, etc.) will dictate the maximum distance that can be supported.
Video Genie™ DS1 Hardware Installation and Configuration
The Video Genie™ DS1 Scaler allows the WCBS Operator to connect up to 4 standard Video devices plus
2 VGA devices to the WCBS. For example, a VCR, DVD Player, Satellite Dish, and a Video Camera
could all be connected to the WCBS using one Video Genie™ Scaler.
1. Connect the Worship Center PC VGA Adapter to the PC1 VGA Port of the Video Genie™ Scaler.
2. Connect the MONITOR Port of the Video Genie™ Scaler to the VGA Monitor in the Control Booth.
3. Connect the PC1-IN Port of the Video Genie™ Scaler to the SOUND-OUT port of the Worship Center
PC Sound Card
4. If a second VGA signal is desired (i.e. PC-In-The-Pulpit), connect that device to the VGA-2 Port of the
Video Genie™.
5. Connect the PROJECTOR Port of the Video Genie™ to the “rear of house” projector. If you are not
using a rear of house projector you may want to use this for a second VGA Monitor in the Control
Booth, allowing the operator to preview multiple items at the same time.
6. Connect the PC OUT Stereo Out port of the Video Genie™ Scaler to the operators Headphones or
Speakers
7. Connect up to 4 Video Devices to the Video Genie™ Scaler using standard video cables.
8. Optional: Connect a composite video monitor to the A/V OUT port for A/V preview functions.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 7of 28
9. Connect the green 3.5mm stereo AMP OUT port of the Video Genie™ to the house Audio Amplifier if
desired (unbalanced signal cable). This will let you route the A/V devices sound signals back to the
house sound system using the audio matrix functions.
10. Connect the IR Blaster Extension Cables to the IR OUT ports on the front and route the transmitters to
the IR EYE location of the devices to be controlled by the Video Genie™.
11. Connect the single IR Learning Eye to the IR IN PORT on the front of the Video Genie™.
12. If you are using the Windows GUI to control the system, connect the control PC COM port to the DB9
port on the front of the Video Genie™ marked CONTROL.
13. If you are using the Total Control Console to control the system, connect the CONSOLE to the
PANEL port on the Video Genie™ with an RJ11 cable.
14. If you want the option to simultaneously use both control systems (Windows GUI and Console), you
will need to use the optional RS232 BRIDGE device (contact Just Add Power support for details).
15. Connect the twisted pair BUS ports to the Receiver Boxes. Do not turn on the Video Genie™ or
Receiver Boxes until the CAT5e Cables have been connected to all of the receivers to prevent
accidental electrical surges.
16. Install UTP Terminator plugs in any unused BUS ports. Be sure to check the Video Genie™ UTP
ports and all of the Receiver Box chains UTP ports.
17. Connect the Power Cord to an appropriate electrical outlet.
18. Optional: Plug the guiding Light Keyboard
into the control PC using a USB port, or the
PS/2 adapter.
19. Power on all devices and proceed with the
software installation for Windows GUI
control of the system.
20. Optional: Connect a microphone to the
MIC port if you want to be able to talk to the remote viewing locations with a microphone in the booth.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 8of 28
Worship Center Broadcast System Software Installation and Configuration
The software to control the Worship Center Broadcast System is distributed on a CDROM that should have
been shipped with your system. The system software is for PC’s running practically any version of the
Microsoft Windows Operating System. If you are using Windows NT, 2K, or XP, you should first log onto
the computer using an ID with full administrator privileges.
1 of 3 Install the WCBS Graphical User Interface
1. Insert the CDROM into the Supervisor PC (the one
with the RS232 interface). The CD should
autorun, if this does not happen, browse the CD
and run the SETUP.EXE program. The Welcome
screen should appear. You must click on the
“Next” button to continue.
2. The Software License Agreement screen should
appear. You must click on the option to accept
the terms in the license agreement first. Then you
should click on the “Next” button to continue.
3. The Customer Information screen should appear.
Please input your User Name and Organization,
and then click on the “Next” button to continue.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 9of 28
4. Simply click on the symbol next to
the feature you want to install and choose
the option to install that feature (i.e. This
feature will be installed on local hard drive).
5. The Ready To Install screen should appear.
You should not need to change anything on
this screen. Simply click on the “Next”
button to continue.
6. The Installation Completed screen should
appear. Now click on the “Finish” button to
exit the installation Wizard.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 10 of 28
2 of 3 Install the HotKeys utility program
The HotKeys utility program is used in conjunction with the Guiding Light Keyboard to control the
Worship Center Broadcast System. The HotKeys utility is a freeware program that is provided at no cost.
The complete source code for the HotKeys program can be found in a ZIP file on the WCBS Installation
CDROM.
1. Browse the Supervisor PC and locate the HKSETUP.EXE program, which should be located in the
C:\SLPORTAP directory.
2. Run the HKSETUP program, and accept all of the default choices.
3. Reboot the Supervisor PC and the HotKeys program should start automatically.
4. Right Click on the HotKeys Icon in the Windows Toolbar -
5. The HotKeys options menu should appear:
6. Click on “Edit hotkeys…” and the HotKeys
Editor screen should appear:
7. Click on the “Load” Button and the “Select Hotkey
Definition File” dialog will appear. You should
browse your PC to locate the file
C:\SLPORTAP\WCBS.HKD and load that file into
HotKeys. This will customize HotKeys to match
the functions on the Guiding Light™ keyboard.
8. After you “Load” the Definition File, you can use
the same screens to add additional HotKeys to
activate other functions on the Worship PC.
NOTE: The default setting for the HotKeys on the
Guiding Light™ Keyboard is set to have the operator
press the CTRL key and the WINDOWS key at the same time, and while holding them down, press one of
the designated F keys.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 11 of 28
3 of 3 Customize the Worship Center Broadcast System Graphical User Interface
The WCBS has several options for customization. The least you should do is make sure the COM port
settings are set to match the RS232 port. Beyond that, you can also change the names of all the buttons to
match the attached devices.
1. Start the WCBS GUI. Locate the shortcut
icon on the desktop and
double click it to start the
GUI. You can also start the
GUI by locating the WCBS in the Programs
Menu.
NOTE: If the control PC is dedicated to the
Worship Center, it is a good idea to copy
this shortcut into the STARTUP folder, as
this will activate the WCBS every time the
computer is turned on.
2. The first time you start the program you will
be prompted to choose the COM port on the
Worship PC being used to control the
system. Don’t “guess” this, you should be
certain of the COM port before using the
software to control the system.
3. The WCBS GUI will appear, and the default
settings will be activated –The screens will
go “dark”, PC1 will appear on Monitor 1,
AV1 will be the active AV Source.
4. Click on the “Setu p” button to access the
service menu. An input box will appear and
you will be prompted to enter the service
password. The service password is “ecivres” (that’s “service”
spelled backwards! The password prompt is only required once
per active session. If you close the WCBS application, you will
be prompted for the password the next time you click on Setup.
5. The Service Options menu will appear. You can choose any of
the options presented:
Change Serial Port
You must make sure the correct serial port is being used. This setting must be confirmed
before you can perform any of the following functions.
Disable or Enable Hotkeys
If you are using the Guiding Light™ Keyboard (or any other PC keyboard) to control the
system with the Hotkeys program, you should enable this function. Otherwise disable
hotkeys to cut down on the PC overhead associated with the system.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 12 of 28
Change Messages
The Change Language function in Advanced Setup can be used to customize the WCBS program for use in
almost any location. When you choose this option, you are presented a series of 3 screens that list all of the
messages (approximate 120 messages) used in the Windows interface. On the each screen you will see the
following information:
The first two columns are
“fixed” data t hat cannot be
changed. The third column
(blue text) can be replaced
with any text you desire. It
should be noted that some
fields are limited in length
on the Control PC. For
example, messages in the
yellow feedback area
should be kept under 25
characters. Other fields,
such as menu entries, can
be up to 80 characters long.
After you finish changing
the messages on a screen,
you should click the right
arrow to go to the next
screen. On page 2 you can
choose the right arrow to
go to the next screen, and
the left arrow to go the
previous screen. On page 3, you can choose a left arrow to go back to page 2, or the Language Save button
to save your changes.
NOTE: It may be helpful to rename the AV devices to match the equipment. For example you could
rename “AV1 –F1” to “Camera 1 –F1”. Every message on the screen can be customized to match the
customer installation.
Message Save
When you click on the Message
Save button, you will see several options, including a
Save/Restore routine. There is one other detail about
Alternate Messages that you may need to know. At
this time, the language files are limited to Latin
characters. Users with a need for alternate character
sets should send a message to Just Add Power support.
The unique requirements for non-Latin characters
usually require special treatment.
Change Delay Timer
The Delay Timer settings should only be changed when Just Add Power support has identified a problem
with screen transitions on the customer projection system. This will give a longer black screen time
between transitions.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 13 of 28
IR Learning Mode
Use this option to “teach” your Video Genie DS1 up to 48 different IR commands. The process is simple,
but it must be followed in the exact order specified below. The first prompt you will see is the following
message in the Status Box:
At the same time there will be a message box prompting you for
the next step. First click on OK in the message box.
After you click OK, the Status box will prompt you to click on
the IR Button you want to learn:
To the right side of the WCBS GUI you will see the IR Control
Panel (you may have to expand the GUI window to see this
panel). Click on one of the 12 buttons that you want to teach the
system. It should be noted that the button Icon does not have to
match the function you are teaching the system. The icons are
provided as a suggestion for organization, but they don’t have
any real impact on what the system does. At the same time, you
should be aware that the IR output follows the 4 AV sources.
When you teach the system the “play” command for AV1, that
IR signal is only broadcast out of the AV1 IR Blaster port.
Now you are ready to click
on the AV Source. Simply
click on AV1, AV2, AV3, or
AV4 on the left side of the
WCBS Windows GUI. You
must first click on “OK”, and
then you can indicate the AV Source.
The next step is when you teach the system. First
click OK on this prompt, then the status box will
flash a message advising you to press the button on
the remote control, while aiming it at the learning
eye of the Video Genie.
After about 5 seconds the flashing will stop, and the command will
have been learned by the system. Keep repeating this process to learn
additional commands, or click on RESET to get out of IR Learning
Mode.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 14 of 28
Worship Center Broadcast System Operation
The software to control the Worship Center Broadcast System can be controlled with the mouse, or with
the HotKeys shortcuts marked on the Guiding Light™ keyboard. The HotKeys are activated by holding
down the Ctrl key and the Windows Key at the same time, and then pressing one of the designated F
Keys. The HotKeys are especially helpful, as they can be used while operating the worship software
presentation program in the foreground. The buttons on the GUI are organized into logical columns:
Broadcast Buttons
These are the main action buttons. They decide what is being sent to the projector screens.
F7 -Darken This will put a black screen up on all the projectors.
F5 -PC1VGA This will put the signal from PC1-VGA on all the projectors.
F6 -PC2VGA This will put the signal from PC2-VGA on all the projectors.
F8 –A/V IN This will put the current AV Source on all projectors.
F10 -Split This will take the system in and out of Split Mode (Multicasting)
A/V Source Buttons
The first 4 buttons let you choose between the 4 A/V inputs (AV1, AV2, AV3, AV4) using the first 4 F
keys on the Guiding Light™ keyboard. The active A/V Source will also be displayed on the Composite
A/V OUT port of the Video Genie™
Resolution Button
Choose the option that matches your computer VGA output settings to help
deliver the best possible transition between sources.
MONITOR Preview Buttons
The MONITOR and PROJECTOR ports operate independently. Monitor 1 column is used for the preview
monitor in the booth. Monitor 2 column is for the rear PROJECTOR port or second preview screen.
Darken This will put a black screen up on the target monitor/projector.
PC1 VGA This will put the signal from PC1-VGA on the target monitor/projector.
PC2 VGA This will put the signal from PC2-VGA on the target monitor/projector.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 15 of 28
A/V Source This will put the current AV Source on the target monitor/projector.
Control Buttons
Reset Same as pressing F7 Darken, F1 AV1
Setup Used to customize WCBS Settings
Quit Used to exit the WCBS GUI.
RS232 Used to remotely control devices using ASCII or HEX commands through your PC
Matrix Buttons
The audio and video Matrix functions can operate independently. When Audio Matrix is OFF, the audio
follows the active Video source to each of the four target zones. When the Matrix is ON, the audio is
routed according to your selection.
F10 –Split Button
When SPLIT MODE is on, you can assign different outputs to each bus port as Zone A or Zone B. At the
same time, the rear projector port operates independently from the rest of the system.
Total Control Console Operation
IR Matrix
When you select an A/V source and make it active, the IR
Control switches to the associated IR port (i.e. AV1 and IR1,
AV2 and IR2). However, you can override the default and
choose to control a different IR device while the other AV
device is still active. For example, you could use this function
to queue a DVD player while the Video Camera is still being
broadcast.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 16 of 28
RS232 Remote Control
When you click on the RS232 option, the following ASCII screen appears:
If the projector you are controlling provided HEX instructions, click on “GoToHex” (see next page for
HEX Usage advise)
ASCII Usage:
There are 13 command lines that you can teach the Simple Projector Control System. Here are the fields
presented for each command:
Click on the “Play” button to execute a command
Next to the Play button you can enter a friendly description of the commands function
Next to the description you enter the ASCII command you want the Play button to send
If you need an ASCII “Carriage Return” BEFORE the command click <CR> Before
If you need an ASCII “Carriage Return” AFTER the command click <CR> After
Baud –enter the number correctly or things won’t work!
Parity –valid inputs are “n” for NONE, “e” for “EVEN”, and “o” for ODD
Length –typically 7, 8, or 9

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 17 of 28
Stop Bit –typically 1 or 0
COM Port –you can assign a different Com port to each command.
When you click on “GoToHex” the program, the following HEX screen appears:
If the projector you are controlling provided ASCII instructions, click on “GoToASC”
HEX Usage:
There are 13 command lines that you can teach the Simple Projector Control System. Here are the fields
presented for each command:
Click on the “Play” button to execute a command
Next to the Play button you can enter a friendly description of the commands function
Next to the description you enter the HEX command you want the Play button to send. HEX commands
can only be in the range “0123456789ABCDEF” and must be entered in pairs with NO SPACES between
the pairs.
Baud –enter the number correctly or things won’t work!
Parity –valid inputs are “n ” for NONE, “e” for “EVEN”, and “o” for ODD
Length –typically 7, 8, or 9
Stop Bit –typically 1 or 0

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 18 of 28
COM Port –you can assign a different Com port to each command.

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 19 of 28
Total Control Console Basic Operation
LCD
To preview PC1/PC2/Video on the control booth LCD preview Monitor 1
Function
Procedure
Preview PC1on LCD
Press [LCD] • Press [PC1]
Preview PC2 on LCD
Press [LCD] • Press [PC2]
Preview Video1 on LCD
Press [LCD] • Press [Video1]
Preview Video2 on LCD
Press [LCD] • Press [Video2]
Preview Video3 on LCD
Press [LCD] • Press [Video3]
Preview Video4 on LCD
Press [LCD] • Press [Video4]

Copyright 2008, Just Add Power Cardware Co., Inc. All Rights Reserved.
Page 20 of 28
Broadcast to ALL
To broadcast to all bus ports (Group A or B).
Function
Procedure
Broadcast PC1 to all
Press [ALL] • Press [PC1]
Broadcast PC2 to all
Press [ALL] • Press [PC2]
Broadcast Video1 to all
Press [ALL] • Press [Video1]
Broadcast Video2 to all
Press [ALL] • Press [Video2]
Broadcast Video3 to all
Press [ALL] • Press [Video3]
Broadcast Video4 to all.
Press [ALL] • Press [Video4]
Rear of House Projector
To show PC1/PC2/Video on the Rear of House projector port (or secondary booth monitor)
Function
Procedure
Show PC1 on Projector
Press [Projector] • Press [PC1]
Show PC2 on Projector
Press [Projector] • Press [PC2]
Show Video1 on Projector
Press [Projector] • Press [Video1]
Show Video2 on Projector
Press [Projector] • Press [Video2]
Show Video3 on Projector
Press [Projector] • Press [Video3]
Show Video4 on Projector
Press [Projector] • Press [Video4]
