JVC GY-HD250U - 3-ccd Prohd Camcorder Instruction Manual

Manfrotto:143S
Flash Shoe, 1/4" Male Attachment
Marshall:V-LCD-MT-01
Flash Shoe, 1/4" Male Attachment
LCD Monitor/Viewfinder connection to KA-HD250
1.Marshall VC-R70P-HDA
AC adapter
[provided]
Analog component
BNCx3-BNCx3
Tally
D-sub 9-pin
1/4” tap
Recommended attachment
(alternative)
Etsumi:E-6085
Pin Screw (1/4” male/male)
Velbon:QHD-51
Pan head

Astor design:MA-700
14”- 1/4" Male Attachment
LCD Monitor/Viewfinder connection to KA-HD250
2.Astro Design DM-3106
AC adapter
[provided]
Analog component
BNCx3-BNCx3
Tally
D-sub 9-pin
1/4” tap
Recommended attachment

No optional
attachment
is required
LCD Monitor/Viewfinder connection to KA-HD250
3.VF-P400
KA-V400
20-pin/6-pin
converter
VF 6-pin
Component out SDI out
SD Yes Yes
HD No Yes
(letter box)
When VF-P400 is used, the setting of VF signal in
the menu of LCD/VF screen of GY-HD250 should
be set to “Y”. When this is set to Y or COMPOSITE in
the HDV mode, images are not output from the
[Y/PB/PR] terminal. (Images can be output from SDI
terminal even in HDV mode.)

LCD Monitor/Viewfinder connection to KA-HD250
4.VF-P550W
Not available.
(Physically the connector of VF-P550W can be
connected to KA-HD250 directly. But, picture
cannot be displayed on VF-P550W due to the
different pin assignment.)

Notification of LCD Monitor/Viewfinder connection
RGB Y Y/PB/PR Y/PB/PR VBS Y
BNCx3 20-pin BNCx3 BNCx3 BNCx3 BNCx1
RGB Y HD component SD component Composite Y
RGB Y Component Component Composite Y
HD YesYesYesYesYesYes
DV Yes Yes No Yes Yes Yes
Reverse picture Yes Yes Yes Yes Yes Yes
Zebra Yes Yes Yes Yes Yes Yes
Skin detail range Yes No No No No No
Safety zone Yes No No No No No
Focus assist Yes No No No No No
Signal
Display
Terminal
Signal
GY-HD250 VF signal
Type of viewfinder LCD monitorsProvided VF VF-P400
*1 Characters from the GY-HD250 are displayed for Y/PB/PR terminal output signals.
Therefore, use the HD/SDSDI terminal output signal for this line.
*2 Signal is only output to the Y terminal of the Y/PB/PR terminal.
*3 SKIN TONE display is not available.
