COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD
SERVICE MANUAL
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).
Camcorder
For General
Power supply : DC 6.3 V (Using AC Power Adapter/Charger)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 3.8 W
LCD monitor on, viewfinder off : Approx. 4.9 W
Dimensions (W x H x D) : 74.5 mm x 91 mm x 198 mm
(with the LCD monitor closed and the viewfinder pushed back in)
Weight : Approx. 660 g
(without cassette, memory card and battery)
Approx. 740 g
(incl. cassette, memory card and battery)
Operating temperature :0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature :–20°C to 50°C
Pickup : 1/4" CCD
Lens : F 1.2, f = 3.8 mm to 38 mm, 10:1 power zoom lens
Filter diameter : ø52 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.24" colour LCD
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video : Digital component recording
Audio : PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz
2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time
(using 80 min. cassette) : SP: 80 min. LP: 120 min.
For Digital Still Camera
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
Moving image : MPEG4 (compatible)
File size
Still image : 4 modes (1600 x 1200 pixels/1280 x 960 pixels/1024 x 768 pixels/
640 x 480 pixels)
Moving image : 2 modes (240 x 176 pixels/160 x 120 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of storable images
:Zpg. 39
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
For Connectors
S
S-Video input : Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
C: 0.2 V to 0.4 V (p-p), 75 Ω, analogue
S-Video output : Y: 1.0 V (p-p), 75 Ω, analogue
C: 0.29 V (p-p), 75 Ω, analogue
AV
Video input : Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
Video output : Y: 1.0 V (p-p), 75 Ω, analogue
Audio input : 300 mV (rms), 50 kΩ, analogue, stereo
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
EDIT : ø3.5 mm, 2-pole
Headphone output : Stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
USB : 5-pin
AC Power Adapter/Charger
For General
Power requirement : AC 110 V to 240 Vd, 50 Hz/60 Hz
Power consumption : 23W
Output
Charge :DC7.2VG, 1.2 A
VTR :DC6.3VG, 1.8 A
No.86756
2003/06
GR-DV4000EX, GR-DV4000EY,
GR-DV4000EZ, GR-DV4000EK
GR-DV4000EK M3D6L7
GR-DV4000EX M3D6L7
GR-DV4000EY M3D6L7
GR-DV4000EZ M3D6L7
DIGITAL VIDEO CAMERA
SPECIFICATIONS (The specifications shown pertain specifically to the model GR-DV4000EK.)

3-1
SECTION 3
ADJUSTMENT
3.1 Before adjustment
3.1.1 Precaution
This model does not contain adjustment controls (VR).
General deck system, camera system and monitor system ad-
justment are not required. However, if circuit board mounting
the EEPROM needs replacement, please use original EEPROM
on to new board. Then adjustment are not required. And if parts
such as the following need replacement, special computerized
adjustment are required. Electrical adjustment with personal
computer is setup and it adjusts using a service support sys-
tem. Please contact to JVC Service for detail information.
• OP BLOCK ASSEMBLY
• EEPROM (IC1003 of MAIN board)
In the event of malfunction with electrical circuits, troubleshoot-
ing with the aid of proper test instruments most be done first,
and then commence necessary repair, replacement and ad-
justment, etc.
• In case of wiring to chip test points for measurement, use IC
clips, etc. to avoid any stress.
• Since connectors are fragile, carefully handle them in discon-
necting and connecting.
• In the following work, use the patch cords as required. For
details of the patch cords, see the "BOARD INTERCONNEC-
TIONS" (CHARTS AND DIAGRAMS).
3.1.2 Required test equipments
• AC power adapter
• Color television or monitor
• Oscilloscope
(dual-trace type, observable 100 MHz or higher frequency)
It is recommended to use one observable 300 MHz or higher
frequency.
• Digital voltmeter
• Frequency counter (with threshold level adjuster)
• Personal computer
3.1.3 Required adjustment tools
Service support system
YTU94057-**
INF adjustment lens
YTU92001B
INF lens holder
YTU94087 Camera stand YTU93079
Light box assembly
YTU93096A Gray scale chart YTU94133A Color bar chart YTU94133C
Communication cable
YTU93107A
PC cable
QAM0099-***
Alignment tape
MC-*
Jig connector cable
YTU93106B
Extension connector
YTU94145C-30
Torque driver
YTU94088 Bit YTU94088-003
Chip IC replacement jig
PTS40844-2
Tweezers
P-895
Cleaning cloth
KSMM-01
Guide driver (Hexagonal)
D-770-1.27
Table 3-1-3a

3-2
• Torque driver
Be sure to use to fastening the mechanism and exterior parts
because those parts must strictly be controlled for tightening
torque.
• Bit
This bit is slightly longer than those set in conventional torque
drivers.
• Tweezers
To be used for removing and installing parts and wires.
• Chip IC replacement jig
To be used for replacement of IC.
• Cleaning cloth
Recommended the Cleaning cloth to wipe down the video
heads, mechanism (tape transport system), optical lens sur-
face.
• Guide driver (Hexagonal)
To be used for mechanism compatibility adjustment.
• INF adjustment lens
To be used for adjustment of the camera system.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• INF lens holder
To be used together with the Camera stand for operating the
Videocamera in the stripped-down condition such as the sta-
tus without the exterior parts or for using commodities that
are not yet conformable to the interchangeable ring.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• Camera stand
To be used together with the INF adjustment lens holder.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• Light box assembly
To be used for adjustment of the camera system.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• Gray scale chart
To be used for adjustment of the camera system.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• Color bar chart
To be used for adjustment of the camera system.
For the usage of this tool, refer to the Service Bulletin No. YA-
SB-10035.
• Alignment tape
To be used for mechanism compatibility adjustment.
MC-1 [For NTSC model]
MC-2 [For PAL model]
• PC cable
To be used to connect the Videocamera and a personal com-
puter with each other when a personal computer is used for
adjustment.
QAM0099-001 [For J* model]
QAM0099-002 [For U* and K* models]
QAM0099-003 [For E* models]
QAM0099-005 [For A* models]
• Communication cable
Connect the Communication cable between the PC cable and
Jig connector cable when performing a PC adjustment.
• Service support system
To be used for adjustment with a personal computer. Soft-
ware can be downloaded also from JS-net.
• Jig connector cable
Connected to CN for Jig of the circuit board and used for elec-
trical adjustment, etc.
• Extension connector
Connect this extension connector to the connector of the Jig
connector cable for extending the cable connector.

3-3
3.1.4 Jig connector cable connection
3.1.4.1 Preparation
The Jig connector cable (YTU93106B) has been provided for
GR-DV2000 series. And it has been connected only 9 termi-
nals for low cost, although it has 30 terminals.
Now it can be used another series camcorder, but all the
terminals have to be connected by soldering wires. Refer to
the Service Bulletin (No. YA-SB-10082), and connect all the
terminals.
3.1.4.2 Connection
3.2 Mechanism compatibility adjustment
3.2.1 Tape pattern check
(1) Play back the tape for compatibility adjustment.
(2) Apply the external trigger signal to HID1, to observe the
waveform of the ENV_OUT.
(3) Set to the manual tracking mode (ATF OFF).
(4) Make sure that there is no significant level drop of the
waveform caused by the tracking operation, with its gen-
erally parallel and linear variation ensured. Perform the fol-
lowing adjustments when required.
(5) Reduce the waveform by the tracking operation. If a drop
in level is found on the left side, turn the guide roller (sup-
ply side) to make the waveform linear.
If a drop in level is on the right side, likewise turn the guide
roller (take-up side) to make it linear.
(6) Unload the cassette tape once, play back the tape again
and confirm that the waveform is flat.
(7) Record at the recording tape, and play back the recorded
signal.
(8) Confirm that the waveform is flat.
3.3 Electrical adjustment
Adjustment is performed by using personal computer. Read
README.TXT file to use the software for Service support sys-
tem properly.
As for the connection of cables, see Fig. Cable connection.
GUIDE ROLLER (TU)
GUIDE ROLLER (SUP)
TO JLIP_RX
TO JLIP_TX
TO GND
TO ENV_OUT
TO HID1
MENU
COMMUNICATION
CABLE
COMMUNICATION
CABLE TO COMMUNICATION CABLE
PC CABLE
SERVICE SUPPORT SYSTEM
RS232C
COM PORT
PERSONAL COMPUTER
JIG CONNECTOR
JIG
CONNECTOR
CABLE
TO JIG CONNECTOR
JIG CONNECTOR
RED
WHITE
BLACK
OSCILLOSCOPEJIG CONNECTOR
JIG CONN.
SRV_RX
D_REG3V
DRST
SRV_TX
TXD2
RXD2
SPA
SBE
GND
MON_R
MON_G
MON_B
MONI_CHG
JLIP_RX
JLIP_TX
PB_CLK
GND
IF_TX
FS_PLL
VPPC
VPPD
HID1
N C
GND
ATFI
MAIN_VCO
ENV_OUT
DISCRI
AL_3VSYS
CJIG_RST
MAIN CN105
Fig. 3-1-4-2b Schematic diagram of Jig CN
Fig. 3-1-4-2a Cable connection
ENV_OUT
HID1
Flatten the waveform.
Misalignment of guide roller
height on the take-up side
Misalignment of guide
roller height on the
supply side
Fig. 3-2-1a
Fig. 3-2-1b

HGFEDCBA
4
5
3
2
1
y10356001a_rev0.1
CCD
C_FG[+]
Vdd
HG_BS[-]
C_FG[-]
HG_U[-]
HG_W[+]
HG_W[-]
AUDIO
ADDA
HG_U[+]
HG_V[-]
HG_V[+]
LOAD_REV
GND
C_COIL_U
C_COIL_U
C_COIL_W
C_COIL_W
C_COIL_V
C_COIL_V
P/R_GND / GND
D_PFG[+]
COIL_COM
D_COIL_W
D_COIL_W
D_COIL_V
D_COIL_V
D_COIL_U
D_COIL_U
D_PG[-]
D_FG[-]
JIG CONN.
BACKLIGHT
P/R_GND / GND
P/R_GND / GND
P/R_GND / GND
P/R_GND / GND
P/R_GND / GND
GND
P/R_GND / GND
P/R_GND / GND
P/R_GND
CN406
ZOOM_SW
REG_3V
CN408
CN112
GND
CN402
CAMERA
DSP
CN110
SYSCON
SYSCON
SRV_RX
DSC
TAPE_LED
USB
SD
USB
D_REG3V
CN105
10
RCsub
GND
DRST
PRE/MDA
DEW_SENS
0
CN106
AUDIO AD/DA
SDODAT2
OP BLOCK
Z_LED
Z_PTR_AD
Z_VCC
HGout+
GND
ZOOM01
ZOOM04
ZOOM03
SRV_TX
ZOOM02
F_VCC
TXD2
RXD2
F_LED
FOCUS01
FOCUS04
FOCUS03
FOCUS02
DRIVE-
OP_THRMO
F_PTR_AD
GND
PHOTO_F
PHOTO_H
FOCUS1
CAM_SW_A
DAMP-
SD
HGVcc+
HGout-
HGVss-
DRIVE+
DAMP+
GND
CN106
4
GND
MENU_SET
CN401
V1
VFREG4.8
DEW_SENS
MENU_P_B
MENU_P_A
HG_BS[+]
LOAD_REV
TRIG_SW
LOAD_FWD
LOAD_FWD
JVC
SENSOR
CN401
SD
LOCK
SUB LCD
MM
NIGHT MODE
M
SPA
SBE
R.E.SW
DSC
GND
MON_R
MON_G
CAPSTAN MOTOR DRUM MOTOR HEAD
M_HCK2
DSC
MON_B
LED
MONI_CHG
LOADING MOTOR
JLIP_RX
V2
SYSCON
JLIP_TX
DSC
CAM_SW_B
ROTARY
ENCODER SW
PB_CLK
GND
DIAL_PB
OP_DRV
IF_TX
STO.SENS
FS_PLL
V4
VPPC
CN110
SYSCON
VPPD
DV
I/O
CN110
HID1
AUDIO
AD/DA
N C
GND
CN107
CN105
CN110
DV MAIN
CAMERA
DSP
MAIN
AUDIO
ATFI
OP DRV
MAIN
AUDIO
MSD CPU
CN110
DIAL_OFF
DIAL_AUTO
CAMERA
DSP
CN110
TALLY
CN110
MAIN_VCO
IN/OUT
VIDEO I/O
CAS_SW
REC_SAFE
ENV_OUT
CN107
DV_MAIN
S_SENS
V3
CN110
AUDIO
ADDA
VIDEO I/O
VF_CS
CN106
DV_MAIN
TAP+
CN105
DV_MAIN
1
TAP-
MONITOR (Page 4-47)(Page 4-49)
MONI OPE IF (Page 4-44)
MONI SW (Page 4-45)(Page 4-46)
VF (Page 51)
07
USB
VF_SW
CDS
TPB+
TPB-
01MAIN
MONITOR
CDS
CN106
MAIN IF
USB
EL_CTL
E_SENS
CAMERA DSP
USB
SYSCON
MAIN IF
1
2
DISCRI
AL_3VSYS
3
45
6
7
DIAL_MENU
PWR_LED
S-ZMIC/R
Info SHOE
S-ZMIC/L S-SHOE_PWM
MZ-V5
Vout
S-SHOE_DET
N C
GND
GND
S-SHOE_AD
S-GATEPULS
RG
S-STRB_CHG S-STO_OFF
S-UNREG
S-UNREG
VL-V3
N C
VL-F3
N C
or
N C
or
SEGL_CS
N C
SYSCON
SEGL_CD
CN103
REG_4.8V
CJIG_RST
REG_4.8V
CN110
MAIN IF
CN114
CN111
SYSCON
CN109
CN110
VIDEO I/O
ZOOM
STO.SENS
CN107
DV_MAIN
CN111
CDS
CN110
STO.SENS
REG_4.8V
DIAL OPE
INT MIC
EXT MIC
HP
(D6 ONRY)
(D6 ONRY) (D6 ONRY)
D6:J2G
D4:J2GorJ7C
REG_4.8V
M_BL_ON
GND
H1
GND
MSD CPU
SYSCON
CN110
SYSCON
OP DRV
TG
MAIN AUDIO
MDA
PRE/REC
PRE/MDA IF (Page 4-39)
LCD(MONITOR) PANEL
H2
SUB
VL
CAMERA
DSP
AV
TG
GND
GND
GND
GND
GND
GND
SPK+
SPK-
MONI_SW
IR_OUT
REG_12V
REG_12V
IR_AMP
HRP
REG_3V
REG_3V
ROM_CS
S_DT_OUT
S_CLK
S_DT_IN
M_CS
P_MEDIA
REG_3V
VDCVF
HDCVF
BATT_TERM.
MIC3
MIC2
MIC1
2
CN101
CDS
CAMERA DSP
MSD CPU
VIDEO
I/O
MECHA(Z27L)
TG
3
4
EJECT
SW
LITHIUM
CN106
CN110
MSD CPU
SYSCON CN110
CN108
CN105
CN110
CN114
MAIN AUDIO
CN110
SYSCON
MAIN
AUDIO
CN111
CN110
CAMERA
DSP
SYSCON
OP
MAIN_IF
J101
VIDEO I/O
EDIT
CAMERA
DSP
S
VIDEO I/O
SYSCON
CN110
CAMERA
DSP
CN102
CN110
TG
DSC
OP_DRV
DSC SD
SYSCON
CAMERA DSP
CN408
CN403CN405 CN404
BATT.
CAM_SW_C
LCD_B
LCD_G
LCD_R
MONI_CHG
REG_3V
REG_3V
REG_3V
REG_4.8V
REG_4.8V
REG_4.8V
REG_4.8V
REC_CLK
M_RVS
REC_DATA
RECCADJ
REF_CLK
REG_2.5V
NOSIG_LV
KEY_C
MON_B
MON_R
P/R_GND
MON_G
ATFI
VRB_ATF
ATF_GAIN
VRB_AGC
AGC_OUT
VREF_1.1
EVV_OUT
REC_CTL
RECH
PBH
HID1
HID3
DUMP_CTL
M_REG4.8
M_REG4.8
M_REG4.8
UNREG
M_REG3V
M_REG3V
GND
GND
GND
GND
GND
GND
DRUM_ERR
DRUM_PWR
DRUM_PWR
DRUM_PWR
CAP_PWR
CAP_PWR
CAP_PWR
CAP_ERR
CAP_REF
CAP_FG
C_FRB
MDA_PS
LD_ON
L_FRB
DRUM_REF
DRUM_FG
DRUM_PG
MIC3
MIC2
MIC1
REC_SAFE
S_SENS
E_SENS
TAPE_LED
CAS_SW
S_REEL
T_REEL
REEL_VCC
KEY_A
CAM_SW_A
CAM_SW_B
CAM_SW_C
P/R_GND
N C
N C
T_RL[+]
GND
T_RL[-]
REEL_VCC
S_RL[+]
S_RL[-]
MDA_2.9V
MDA_2.9V
P/R_GND
P/R_GND
P/R_GND
P/R_GND
1F
1S
2F
2S
SDOWP
SDOCD
SD0DAT2
SD0DAT1
SD0DAT3
SD0CMD
SD0DAT0
SDCLK
CARD_3V
M_HCK1
GND
BL
06
GND
GND
M_BL_ON
REG_4.8V
REG_4.8V
REG_4.8V
M_RVS
N C
N C
N C
N C
N C
REG_3V
M_REF
M_VST
M_HST
M_VCK
M_WIDE
M_EN
M_DOWN
S_CLK
S_DT_OUT
EL_CTL
SEGL_CD
SEGL_CS
M_VVDD
M_VVDD
GND
GND
GND
M_COM
M_RGT
M_BLUE
M_BLUE
M_RED
M_RED
M_GREEN
M_GREEN
M_PSIG
EL
EL
ELB
ELB
N C
N C
TESTR
RGT
BLUE
RED
GREEN
PSIG
HCK1
HCK2
Cext/Rext
TEST
REF
HST
WIDE
SLVSG
VSSG
VDDG
VSS
VDD
DWN
EN
VCK
VST
COM
TESTL
EL
SEG11
SEG10
SEG9
SEG8
SEG7
SEG6
SEG5
SEG4
SEG3
SEG2
SEG1
COM4
COM3
COM2
COM1
GND
GND
N C
N C
M_RVS
REG_3V
RVS
SW LCD(CVF) PANEL
VF BL
08
VDD(12V) VDD(12V)
GND
GND
VFREG4.8
GND
VST VST
VCK VCK
STB
STB
EN EN
DWN DWN
RGT RGT
HST
HST
HCK2 HCK2
HCK1
or
HCK1
BLK
BLK CVF_B
CVF_B CVF_R
CVF_R CVF_G
CVF_G VF_COM
VF_COM
SDODAT3
SDOCMD
VSS
VDD
SDCLK
VSS2/CD
SDODAT0
SDODAT1
GND
SDOCD
SW_CDM
SDOWP
GND
VF_SW
GND
VF
SW
SPEAKER
JACK
02
EJT_SW
S_DET
Y_OUT
C_OUT
JLIP_TX
JLIP_RX
REM_OUT
GND
GND
GND
GND
GND
STROBE
STROBE
UNIT
M_REG4.8
M_REG4.8
GND
GND
GND
GND
GND
STRB_AD
CHG_ON
GATEPULS
REG_4.8V
STRB_CLS
POP_STRB
M_REG4.8
M_REG4.8
STO_OFF
11
IN_MIC/L
IN_MIC/R
IM_GND
FRONT
05
GND
GND
STO_E
FOCUS_PA
STO_C
BACKLIGHT
FOCUS2
FOCUS_PB
FOCUS_PA
SW
09
STO_C
STO_E
GND
GND
GND
GND
FOCUS_PB
FOCUS_PA
BACKLIGHT
SW
FOCUS
SW
STOROBE
SENS
FOCUS_PB
FOCUS2
STO_C
STO_E
GND
GND
GND
GND
TALLY
REG_3V
IR_RMC
REG_4.8V
REG_4.8V
REG_4.8V
LAMP_ON
HP_SIG/L
HP_SIG/R
HP_DET
EX_MIC/L
EX_MIC/R
EMJ_DET
EM_GND
IN_MIC/L
IN_MIC/R
IM_GND
IM_GND
ZMIC/L
ZMIC/R
CCD_CTL
V1
V2
V3
V4
GND
GND
GND
GND
GND
GND
GND
CCD_OUT
CCD_15V
CCD_15V
SUB
CCD-7.5V
H2
H1
RG
CCD_OUT
GND
CJIG_RST
I_MTR
AREG_SO
ADP_H
AREG_CLK
T_BATT
REG_CS
AL_3V
AL_3V
AL_3V
LIT_3V
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
V_BATT
UNREG
UNREG
UNREG
REG_1.8V
REG_1.8V
REG_1.8V
REG_1.8V
REG_3V
REG_3V
REG_3V
REG_3V
REG_3V
REG_3V
REG_2.5V
REG_2.5V
REG_2.5V
REG4.8V
REG4.8V
REG4.8V
REG4.8V
M_REG4.8
M_REG4.8
M_REG4.8
VFREG4.8
VFREG4.8
REG_12V
REG_12V
REG_15V
REG_15V
REG-CCD
REG-CCD
VF_CTL
CHRG_EVR
CAP_PWR
CAP_PWR
CAP_PWR
DRUM_PWR
DRUM_PWR
DRUM_PWR
CAP_ERR
DRUM_ERR
D_GAIN
AU_SIG/R
AU_SIG/L
V_OUT
P_DET
REG
03
SPK+
SPK-
DC
JACK JACK
+-
T
CN110
RECH
CN102
DOBCK2
CN403CN404CN405
REG_3V
CN104
CN406
RECH
PBH
HID3
DUMP_CTL
HG_U[+]
HG_W[-]
HG_BS[-]
HG_W[+]
HG_BS[+]
HG_U[-]
HG_V[+]
HG_V[-]
C_COIL_U
C_COIL_W
C_FG[+]
C_FG[-]
C_COIL_V
CN106
MDA_PS
CN701
DOMCK2
J201
PBH
DOLRCK2
CN101
DODAT2
CN105
S-SHOE_DET
CN601
S-SHOE_PWM
S201
ATF_GAIN
RECCADJ
Z_VCC
ATFI
ADCLK
REF_CLK
PBLK
SHP
REC_DATA
REC_CTL
MONI_CHG
HID3
ROM_CS
MONI_CHG
HID1
REC_CLK
VRB_AGC
VRB_ATF
AGC_OUT
S-ZMIC/L
EEPROM_CS
EEP_DT_CLK
CLK_OUT
CN6501
DATA_OUT
CAM_SW_C
CN605
HDIN
CPOB
REG_4.8V
S-ZMIC/R
DRUM_ERR
CAM_SW_B
SHOE_VON
CN108
SHD
REG_3V
REG_2.5V
V_OUT
REG_4.8V
VREF_1.1
S_RL[+]
ENV_OUT
2S
2F
CN402
1S
M_REG4.8
1F
SHOE_DET
CN601
P/R_GND
REG_1.8V
CAM_SW_A
REG-CCD
HID1
AGC_OUT
VRB_AGC
ATFI
VRB_ATF
REC_DATA
REC_CTL
SHOE_OFF
REF_CLK
VREF_1.1
HID1
S_CLK
DISCRI
EEP_DT_OUT
EEP_IN
REG_1.8V
SRV_CS
S_CLK
SBE
IR_RMC
CALE
TDO
TDA
CAPT_REQ
CCD_CTL
VDIN
TAPE_LED
SHOE_CHG
CN606
FS_PLL
T_RL[+]
MAIN_VCO
S_DT_IN
ZOOM01
PB_CLK
E_SENS
ZOOM04
F_PTR_AD
F_VCC
F_LED
REEL_VCC
ZOOM03
ZOOM02
L_FRB
GND
DAMP+
DCO[0-3]
EXT_IN_L
S_DT_OUT
HGout+
DAMP-
SHOEGATE
OP_THRMO
HGout-
HGVss-
HGVcc+
DRIVE+
REG_2.5V
S_REEL
GND
S_SENS
MIC1
SHOE_AD
UREG_SEL
MIC2
MIC3
REC_SAFE
DEW_SENS
Z_PTR_AD
IRIS_PWM
SHOE_PWM
SRV_RDY
MDA_PS
CAM_VD
GND
SPA
CAP_REF
CAP_FG
DRUM_REF
DRUM_PG
DRUM_FG
CN702
PHOTO_F
S_REEL
CLK9A
ZMIC/L
LD_ON
DRST
S_IN_L
TBC_RST
DYO[0-3]
TBC_CS
TBC_CLK
TBC_DTO
DCI[0-3]
TBC_DTI
CAM_VD
SHOEGATE
HID1
SPA
SRV_RST
IM_GND
HID1
FRP
TSR OUTV
SRV_TRK
CLK27SEL
DV_RST
T_REEL
C_FRB
FOCUS_PA
KEY_C
DUMP_CTL
VC[0-3]
SRV_RX
NOSIG_LV
SRV_TX
D_GAIN
ADDT[00-15]
OUTV
REC_CLK
DV_WAIT
EEPROM_CS
TG_36M
EEP_DT_CLK
EEP_DT_OUT
EEP_IN
MONI_CHG
REG_4.8V
S_DT_IN
VPPD
ADDT[00-15]
PBPLLCTL
MD_DEM1
CLK27A
REG_3V
NOSIG_LV
GND
CJIG_RST
CLK_OUT
DV_WAIT
ATF_GAIN
DRWSEL
TG_CS
DRE
DWE
DALE
INV
INH
OUTV
OUTH
BLK[A-C]
MENU_P_A
MENU_P_B
A_CSYNC
MENU_SET
DIAL_PB
DIAL_OFF
TBCCTL
OSD_HD
OSD_VD
DOT_CLK
RECCADJ
DIAL_AUTO
M_VCOCTL
J101
ZMIC/R
DIAL_MANU
OUT_Y[0-3]
TRIG_SW
UNREG
J6002
DYI[0-3]
AIDAT
AODAT
AILRCK
AIBCK
AIMCK
TSR
J202
FRP PBVCOCTL
CLK27A
DV_RST
SPA
TPA+
TPA-
TPB+
TPB-
FOCUS_PB
POW_LED
ZOOM_SW
IF_TX
VPPC
AL_3VSYS
SDODAT2
GND
AIDAT2
PHOTO_H
FOCUS1
JLIP_TX
JLIP_RX
T_BATT
ADP_H
JLIP_TX
V_BATT
LAMP_ON
VF_CTL
I_MTR
EM_DET
CLK27SEL
AREG_SO
AREG_CLK
SRV_TRK
FSPLLCTL
REG_CS
S_DC_IN
ASPECT2
ASPECT1
HP_SIG/L
CN107
HP_SIG/R
BACKLIGHT
SHOE_PWM
SHOE_AD
SHOEGATE
SHOE_CHG
SHOE_DET
SHOE_OFF
SHOE_VON
UREG_SEL
S-SHOE_AD
S-GATEPULS
LD_ON
S-STRB_CHG
S-STO_OFF
S-UNREG
REG_3V
SDODAT1
CN602
DSCIO[0-7]
DSYIO[0-7]
FOCUS04
FOCUS03
MD_AU/L
FOCUS02
FOCUS2
KEY_B
MD_AU/R
EM_AU/L
SDODAT0
EM_AU/R
PWDA2
HDCVF
PWAD2
REM_OUT
HP_DET
MD_DEM1
DOBCK2
DOMCK2
DOLRCK2
FOCUS01
REG_3V
HALL_AD
IRIS_O/C
DODAT2
F/Z_CS
AIDAT2
IR_AMP
JLIP_RX
IR_OUT
DATA_OUT
CJIG_RST
STO_C
STO_E
DATA_OUT
OUT_C[0-3]
OUT_VS
POP_STRB
STRB_CLS
OUT_HS
STO_OFF
STRB_AD
GATEPULS
SENSPULS
STRB_CHG
POP_STRB
STRB_CLS
STO_OFF
STRB_AD
GATEPULS
SENSPULS
STRB_CHG
STO_OFF
CHG_ON
GATEPULS
F/Z_CS
EXT_IN_L
S_IN_L
TBC_RST
TBC_CS
CLK_OUT
F/Z_RST
M_REG4.8
OP_THRMO
STRB_AD
TBC_CLK
H_GAIN
CAM_VD
TBC_DTO
TBC_DTI
CLK4M5
H_GAIN
LCD_G
LCD_B
LCD_R
H_OFFSET
POP_STRB
H_OFFSET
STRB_CLS
ASPECT1
VDCVF
REG_4.8V
REG_3V
REG_1.8V
GND
M_REG4.8
ASPECT2
REG-CCD
REG_4.8V
CHRG_EVR
REG_15V
TG_RST
CN706
H2
H1
RG
SUB
M_REG4.8
REG_4.8V
REG_3V
REG_12V
GND
INV
INH
DYO[0-3]
CAP_PWR
DRUM_REF
DRUM_PG
REG_3V
DCO[0-3]
LOAD_FWD
LOAD_REV
MDA_2.9V
COIL_COM
D_PFG[+]
D_COIL_W
D_COIL_V
D_COIL_U
D_PG[-]
D_FG[-]
CAP_ERR
PBVCOCTL
M_VCOCTL
FSPLLCTL
GND
DRUM_PWR
EMJ_DET
CAP_REF
CAP_FG
DRUM_FG
PBPLLCTL
DSCO[0-7]
INV
GND
V1
V2
V3
V4
INH
DSYO[0-7]
DRIVE-
CN401
Z_PTR_AD
F_PTR_AD
UNREG
REG_3V
REG_4.8V
GND
L_MUTE
SHUT_ATT
AILRCK
AIMCK
AIBCK
AODAT
AIDAT
TMS
M_CS
S_DT_OUT
SPK-
MXDT_OUT
SPK+
M_BL_ON
CN408
IN_MIC/L
IN_MIC/R
S_SHUT
M_RVS
P_MEDIA
PWAD2
PD_L
PWDA2
AUDIO_CS
ZMIC_ATT
A_MUTE
BUZZER
AU_SIG/R
AU_SIG/L L_MUTE
PD_L
CLK_OUT
AUDIO_CS
DATA_OUT
A_MUTE
BUZZER
KEY_B
KEY_A
TALLY
MONI_SW
CAS_SW
CAS_SW
J102
FLDDSC
HRP
S_RL[-]
T_RL[-]
TCMK
TRST
DATA_OUT
SHUT_ATT
DAC_CS
TBCCTL
Z_LED
OUT_Y[0-3]
OUT_C[0-3]
OUT_VS
OUT_HS
GND
CN603
HALL_AD
IRIS_O/C
CN407 CN704
HDDSC
VDDSC
FLDDSC
CN604
OP_THRMO
F_PTR_AD
CN103 CN114
DYO[0-3]
DCO[0-3]
P_DET
Z_PTR_AD
SENS_EVR
HDDSC
F/Z_RST
CN705
DATA_OUT
T_REEL
CLK_OUT
DSC_STS
FLSH_RST
DSC_RST
DSC_CS
DSC_DT_IN
DSC_DT_OUT
DSC_CLK
DSC_WKUP
SDOCD
USBDOWN
VDDSC
AL_3V
CLKDSC
CLK27B
CLK27B
TDI
FLSH_RST
SDOCD
SDOCD
DSC_RST
DSC_CLK
DSC_DT_OUT
DSC_DT_IN
DSC_CS
MXDT_OUT
DSC_STS
CAPT_REQ
DSC_WKUP
GIO4
EM_CS1
FLSH_OE
FLSH_WE
SD_MCLK
A[8-14]
D[0-15]
D[0-15]
A10
EM_CS2
FLSH_OE
FLSH_WE
USBDOWN
DSC_RST
C_OUT
GIO3
C_FRB
Y_OUT
GIO6
GIO15
GIO2
M_REG3V
L_FRB
GIO1
EX_MIC/R
LIT_3V
GND
REG_3V
EX_MIC/L
EM_GND
ZMIC_ATT
EM_DET
MD_AU/L
EM_AU/R
MD_AU/R
EM_AU/L
DSCIO[0-7]
CLK_OUT
DATA_OUT
CRWSEL
CDSTB
CLKDSC
GIO15
CRWSEL
CDSTB
DSP_RST
DSP_RST
GIO6
GIO3
ADCLK
CAM_3.1V CAM_3.1V
CLK9A
HDIN
TG_36M
VDIN
REG_3V
CLK27A
IRIS_C
IRIS_C
ADIN[0-9]
CPOB
CLK27A
PBLK
CDS_CS
BUS[0-15]
OMT
DSYO[0-7]
DSCO[0-7]
GND
CPOB
SHP
SHD
CLK27B
TCMK
TMS
BLK[A-C]
TRST
USBDOWN
DSC_RST
DSYIO[0-7]
TDA
CCD_CTL
SHOEGATE
A_CSYNC
PBLK
CCD_OUT
CDS_CS
CLK_OUT
DATA_OUT
ADIN[0-9]
REG_4.8V
GND
CPOB
PBLK
IRIS_PWM
OSD_HD
BUS[0-15]
OSD_VD
DOT_CLK
VC[0-3]
CAM_VD
CLK4M5
MVD
CALE
OMT
MFLD
MFLD
OUTH
OUTV
DYI[0-3]
MVD
DCI[0-3]
INV
DCO[0-3]
INH
DYO[0-3]
CN802
CN801
CN703
CN112
S_SHUT
REG_3V
GND
CN201
CN109
CLK27B
S_DET
S_DC_IN
CN501 CN111
CN502
CN901
CN903CN902
S902
S901
J502
J501
J301
FLSH_WE
FLSH_OE
EM_CS2
A10
D[0-15]
D[0-15]
A[8-14]
SD_MCLK
FLSH_WE
FLSH_OE
EM_CS1
GIO4
GIO2
GIO1
SDOCMD
SDODATO
SDCLK
SDODAT3
SDOCD
SDOWP
REG_1.8V
REG_3V
GND
RXD2
TXD2
S_DT_IN
SEGL_CD
SEGL_CS
EL_CTL
VF_SW
REG_3V
GND
SDOCD
SDOWP
SDOCMD
VF_CS
GND
REG_4.8V
USB_DP
USB_DN
USBSENS
SDODAT3
SDCLK
SDOCD
CLK_OUT
DAC_CS
DATA_OUT
CLK_OUT
USB_DN
USB_DP
USBSENS
GND
USBDOWN
CCD_CTL
EJT_SW
CAS_SW
CARD_3V
CLK_OUT
DATA_OUT
TG_RST
DRWSEL
DRE
DWE
DALE
TG_CS
SRV_RDY
SRV_CS
S_CLK
S_DT_OUT
SRV_RST
SUB LCD
SENS_EVR
CN111
OPEN
(Page 4-32)
(Page 4-40)
(Page 4-54)
(Page 4-32)
(Page 4-35)
(Page 4-37)
(Page 4-9)
(Page 4-29)
(Page 4-11)
(Page 4-13)
(Page 4-21)
(Page 4-23)
(Page 4-53)
(Page 4-25) (Page 4-18) (Page 4-5)
(Page 4-17) (Page 4-19)
(Page 4-15)
(Page 4-27)
(Page 4-42)
(Page 4-43)
(Page 4-41)
(Page 4-31)
(Page 4-30)
(Page 4-5)
(Page 4-7)
(Page 4-33)
*5
*5
*5
*5
*5
*5
*5 *5
*3
*3
*5 *5 *5 *5 *5 *5
*5 *5 *5 *5
*5
*5*5*5
*3/*5: The connector has 0.3mm or 0.5mm pitch size. The patch cord which has same pin number is available.
(0.3mm) YTU94129A-##, YTU94109-## (## is number of connector pin. For 27, 33 or 39 pins)
(0.3mm) YTU94150A-##, YTU94109-## (## is number of connector pin. For 57 pins)
(0.5mm) YTU94074-##, YTU94077-## (## is number of connector pin. For 8 to 30 pins)
(0.5mm) YTU94105-##, YTU94077-## (## is number of connector pin. For 40pins)
4-3 4-4
4.1 BOARD INTERCONNECTIONS

HGFEDCBA
4
5
3
2
1
y10357001a_rev0
TO INFO SHOE
∗
∗
0
USB
#
#
1MAIN
(MAIN IF section)
PWB
#
∗∗ ∗
#
#
∗
SHOE_IF_Section
∗
∗
TO ZOOM UNIT
∗
∗
∗
#
#
∗∗
TO PRE MDAIF CN401
TO MSD CPU
TO PRE/MDA CN408
∗∗
∗
∗
∗
∗
∗
∗
(MECHA GND)
(MECHA GND)
∗
CN108
R2006
J102J102
CN107
GND
TL2005
C2001
T_REEL
REEL_VCC
S_REEL
TAPE_LED
DRUM_ERR
JLIP_RX
J102
D_GAIN
CAS_SW
E_SENS
GND
MIC1
CN105
REC_SAFE
MIC2
MIC3
REG_3V
S_SENS
GND
GND
CAP_PWR
CAP_PWR
FOCUS_PB
CAP_PWR
CAP_ERR
DRUM_PG
DRUM_FG
UNREG
DRUM_REF
L_FRB
CAP_FG
MDA_PS
CAP_PWR
LD_ON
DRUM_PWR
OP_THRMO
FOCUS02
DRUM_PWR
DRUM_PWR
DIAL_MANU
DRUM_ERR
JLIP_TX
VREF_1.1
VRB_AGC
REG_3V
REG_3V
FOCUS03
CJIG_RST
M_REG4.8
DRUM_PWR
GND
CHRG_EVR
FOCUS04
CAP_REF
FOCUS01
J102
F_LED
MONI_CHG
C_FRB
M_REG4.8
TDI
M_REG4.8
REG_3V
GND
GND
GND
GND
DUMP_CTL
GND
HID3
HID1
PBH
RECH
AREG_SO
F_VCC
REC_CTL
ENV_OUT
GND
AGC_OUT
F_PTR_AD
GND
ATF_GAIN
VRB_ATF
ATFI
ZOOM02
ZOOM03
ZOOM04
REG-CCD
REG_12V
ZOOM01
GND
CN111
VFREG4.8
DAMP+
J102
DRIVE+
HGVss-
HGout-
HGVcc+
DRIVE-
R2007
DAMP-
HGout+
Z_VCC
Z_PTR_AD
M_REG4.8
Z_LED
CN104
CN103
GND
CN112
REF_CLK
REM_OUT
REC_CLK
REC_DATA
REG_3V
CN111
NOSIG_LV
REG_2.5V
ZMIC/L
RXD2
RECCADJ
MONI_CHG
REG_4.8V
REG_4.8V
REG_4.8V
REG_4.8V
ZMIC/R
CAM_SW_C
TXD2
CAM_SW_B
CAM_SW_A
D2901
FOCUS_PA
FOCUS2
BACKLIGHT
L2001
GND
USB_DP
USBSENS
USB_DN
R2014
R2012R2013
C2003
DEW_SENS
GND
GND
GND
ZOOM_SW
REG_3V
GND
J102
CN114
DIAL_AUTO
AREG_CLK
R2008
R2009
REG_CS
REG_2.5V
REG_15V
PHOTO_H
J102
REG_4.8V
TL2001
VF_CTL
C2904
PHOTO_F
REG_3V
REG_1.8V
DIAL_OFF
UNREG
DIAL_PB
TRIG_SW
R2903
R2902
C2902
KEY_B
GND
C2901
R2001
SHOE_DET
R2906
SHOEGATE
SHOE_PWM
R2905
Q2901
R2904
R2907
C2905
TL2006
R2002
FOCUS1
BACKLIGHT
R2003
R2004
GND
LIT_3V
R2011
SHOE_VON
MENU_P_A
T_BATT
V_BATT
AL_3V
R2005
C2004
ADP_H
REG_3V
FOCUS2
Q2902
GND
MENU_P_B
FOCUS1
MENU_SET
PWR_LED
D2003
D2001
D2002
D2903
SHOE_CHG
R2908
JLIP_RX
JLIP_TX
HID1
SBE
R2901
C2903
L2902
C2040
ENV_OUT
AL_3VSYS
DISCRI
ATFI
MAIN_VCO
VPPC
VPPD
IF_TX
CJIG_RST
FS_PLL
GND
TDO
TCMK
TMS
TRST
GND
SPA
SRV_TX
DRST
SHOE_OFF
SHOE_AD
STO_E
IR_RMC
EX_MIC/L
HP_DET
EX_MIC/R
EMJ_DET
IN_MIC/L
MON_B
IN_MIC/R
GND
R2015
R2016
REG_3V
L2903
ZMIC/L
ZMIC/R
L2904
SRV_RX
L2905
L2907
CAP_ERR
Q2903
GND
R2909
L2908
L2906
L2910
PHOTO_F
PHOTO_H
R2910
L2909
L2901
R2911
Q2905
Q2904
UREG_SEL
GND
UNREGS-UNREG
I_MTR
CN110
GND
MON_G
MON_R
TL2003
TL2004
REG_3V
R2912
C2907 C2906
PB_CLK
S-SHOE_PWM
S-GATEPULS
S-STRB_CHG
S-STO_OFF
S-SHOE_DET
S-ZMIC/L
S-ZMIC/R
S-SHOE_AD
S-UNREG
GND
S-SHOE_PWM
S-GATEPULS
S-STRB_CHG
S-STO_OFF
S-SHOE_DET
S-ZMIC/L
S-ZMIC/R
TO L2909
TO L2910
TO L2908
TO L2907
TO SHOE IF
TO L2905
TO L2904
TO L2903
TO L2902
TO L2901
S-SHOE_AD
C2043
C2042
C2045
C2046
C2044
C2041
R2017
STO_C
GND
TALLY
REG_3V
REG_4.8V
LAMP_ON
REG_4.8V
EM_GND
HP_SIG/L
HP_SIG/R
REG_4.8V
GND
GND
GND
IM_GND
IM_GND
S_DET
Y_OUT
EJT_SW
GND
C_OUT
GND
AU_SIG/R
GND
AU_SIG/L
GND V_OUT
P_DET
VFREG4.8
CN106CN106
VF_CS
VF_SW
EL_CTL
SEGL_CS
SEGL_CD
REG_4.8V
KEY_A
MON_R
MON_G
MON_B
KEY_C
M_RVS
LCD_R
LCD_G
LCD_B
REG_4.8V
HDCVF
VDCVF
REG_3V
P_MEDIA
M_CS
S_DT_IN
S_CLK
S_DT_OUT
ROM_CS
REG_3V
HRP
GND
IR_AMP
REG_12V
IR_OUT
MONI_SW
SPK-
SPK+
GND
M_BL_ON
CARD_3V
SDCLK
SD0DAT0
SD0CMD
SD0DAT3
SD0DAT1
SD0DAT2
SD0CD
SD0WP
0Ω
0Ω
0Ω0Ω
0.01
1M
1M
0.01
0Ω
10k
1k
0Ω
1.5k
1.8k
2.7k
3.9k
10k
4.7k
1.0
0Ω
0.01
0Ω
0Ω
0Ω
0Ω
0Ω
1.2k
0Ω
3.3k
0Ω
100k
0Ω
0Ω
UMZ6.8EN-W
2SB1188/QR/-W
DTC144EE-X
EMZ6.8N-X
NQR0251-004X
2SD1759-X
NQR0251-004X
NQR0251-004
NQR0251-004
DTC144EE-X
CPH3314-X
T
T
SG
D
TO CN103
TO OP DRV
TO SYSCON
TO SYSCON
TO SYSCON
TO SYSCON
TO SYSCON
TO SYSCON
TO VIDEO I/O
TO VIDEO I/O
TO MAIN IF CN110
TO MAIN IF CN110
TO SYSCON
TO
MAIN AUDIO
TO SHOE IF
TO MAIN IF
CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO STO.SENS
TO R2004
TO R2005
TO MSD CPU
TO MSD CPU
TO MSD CPU
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110 TO MAIN IF CN110
TO MAIN IF CN105, DV MAIN
TO MAIN IF CN105
TO MAIN IF CN110
TO MAIN IF CN110
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO DV MAIN
TO VIDEO I/O
TO VIDEO I/O
TO VIDEO I/O TO VIDEO I/O
TO USB
TO USB
TO MAIN IF
CN110
(OPEN)
TO SYSCON
TO DV MAIN
TO MSD CPU
TO MSD CPU
TO MSD CPU
TO CN107
TO CN110
TO CN110
TO CN110
TO MSD CPU
TO DSC
TO CN106
TO MSD CPU
TO DV MAIN
TO DV MAIN
TO SYSCON
TO SYSCON
TO SYSCON TO SYSCON
TO DV MAIN TO CN105
TO VIDEO I/O
TO MAIN AUDIO
TO
SYSCON
TO MAIN AUDIO,TG
TO TG
TO DSC
TO DSC, SD
TO DSC, SD
TO SYSCON
TO CN105
TO SYSCON
TO VIDEO I/O
TO CN110
TO CN110
TO CN110
TO CN110
TO CN110
TO CN110
TO CN110
TO CN110
TO SHOE IF, R2015, CN104~CN108,
CN111, CN112, CN114, SYSCON,
MSD CPU, MAIN AUDIO, CDS,
DV MAIN, VIDEO I/O, CAMERA DSP,
OP DRV, TG, DSC, USB, SD,
AUDIO AD/DA, STO.SENS
TO SYSCON
TO SYSCON
TO SYSCON
TO SYSCON
TO SYSCON
TO
MAIN AUDIO
TO VIDEO I/O
TO VIDEO I/O
TO SD
TO CN106, STO.SENS
TO CN106
TO MSD CPU, OP DRV,
STO.SENS
TO CN106, CN107, CN111,
MAIN AUDIO, VIDEO I/O,
OP DRV, TG, CDS, USB, STO.SENS
TO MSD CPU
TO CN107, DV MAIN, STO.SENS
TO DV MAIN, VIDEO I/O,
CAMERA DSP, DSC
TO R2908, CN105~CN107,
CN111, CN114, SYSCON,
MSD CPU, MAIN AUDIO,
DV MAIN, VIDEO I/O,
CAMERA DSP, OP DRV, TG, DSC,
SD, AUDIO AD/DA, STO.SENS
TO Q2901, MSD CPU
TO SYSCON
TO SYSCON
TO CN114
TO CN111
TO
SYSCON
TO
SYSCON
TO SYSCON
TO CN110
TO CN110
TO R2003 TO R2006 TO R2002
TO CN110
TO MAIN IF CN110
TO MAIN IF CN110
TO SYSCON
TO SYSCON
TO SYSCON
TO CN111
Q2903 Q2904 Q2905 R2909 R2910 R2911 R2912
# EXCHANGE PARTS LIST
D6
D4
WARE
WARE WARE WARE WARE WARE WARE
NO_WARE NO_WARE NO_WARE NO_WARE NO_WARE NO_WARE
NO_WARE
TO REG
CN601
TO MONITOR
CN701
TO JACK
CN201
TO FRONT
CN501
TO
OP BLOCK
NOTE : The parts with marked (
∗
) is not used.
4.2 MAIN(MAIN IF) SCHEMATIC DIAGRAM
4-5 4-6

HGFEDCBA
4
5
3
2
1
y10358001a_rev0.1
VDD
OUT
16MHZ
R1013 R1014
32kHz
VSS
[-]
[+]
Q1005
FOCUS_PA/
FOCUS_PB/
∗
∗∗0R0 ∗
BATT_H/
0R0
∗
RESET_DET
IC1004
# ∗
∗
STRB_AD/
∗
∗
#
IC1005
D6L
D4L IC1012 R1086 R1087 R1107 R1109 C1041
0.0174HC4053PW-X
∗0R0 ∗0R0 0R0 ∗
∗∗∗∗
62K
R1019 R1027 R1028 R1031 R1038 C1020 C1021
∗∗∗ ∗ ∗∗∗∗ 100K 1.8M 1K 100K 0.01 0.01
R1009 R1057 Q1006
470
470 ∗∗ ∗
TG_RST
S_DT_IN
S_DT_OUT
TL1020
IC1004
PWR_LED
SRV_RST
CALE
CCD_CTL
R1115
R1058
R1060
R1016
R1077
GND
P_MEDIA
CRWSEL
GND
V_BATT
C1017
SHOE_VON
R1066
SHOE_DET
TL1021
R1088
X1001
SHOE_PWM
VF_SW
SHOE_AD
HP_DET
GATEPULS
OP_THRMO
DSC_CLK
REG_3V
R1026
BLKC
R1023
R1036
TL1007
CLK_OUT
DATA_OUT
R1001
R1029
TL1022
BUS1
BUS2
BUS3
BUS4
BUS5
BUS6
BUS7
BUS9
C1019
Q1003
BUS11
BUS8
BUS12
BUS10
BUS13
BUS14
BUS15
R1063
F_PTR_AD
CDSTB
DSP_RST
MFLD
CAS_SW
M_BL_ON
IC1005
R1038
R1017
DSC_DT_OUT
R1022
DSC_STS
R1116
R1020
EEPROM_CS
R1018
SRV_RDY
A_MUTE
RA1009
RA1008
OSD_VD
R1027
EEP_DT_CLK
SRV_CS
R1085
R1046
R1050
T_BATT
R1049
R1048
DSC_DT_IN
C1028
RA1010
R1010
C1029
C1030
R1110
AL_3V
F/Z_CS
R1071
AL_3VSYS
IRIS_O/C
F/Z_RST
Z_PTR_AD
HALL_AD
OMT
BUS0
OSD_HD
MVD
R1109
I_MTR
SHOEGATE
R1037
IC1003
IC1006
CJIG_RST
MONI_SW
L1002
VPPC
DSC_CS
R1030
TG_CS
C1006
R1013
CDS_CS
IF_TX
IC1002
P_DET
R1107
C1004
R1072
JLIP_RX
X1002
S_CLK
Q1004
JLIP_TX
R1035
C1026
VF_CS
AREG_SO
AREG_CLK
R1047
IC1007
REM_OUT
D1002
C1034
C1037
KEY_A
C1023
LIT_3V
C1027
R1044
R1045
IR_OUT
C1018
C1036
C1038
C1007
R1014
R1004
R1005
C1015
TL1018
C1013
TL1017
C1011
R1076
C1016
ASPECT1
ASPECT2
AUDIO_CS
PWAD2
M_CS
M_RVS
IR_RMC
IR_AMP
TALLY
TL1016
R1084
SHUT_ATT
MD_DEM1
R1089
R1090
R1057
R1021
EL_CTL
BUZZER
PWDA2
Q1002
Q1001
R1055R1056
R1053 R1051
R1052
C1031
D1001
R1054
S_DET
R1015
R1006
R1007
R1003
R1002
EEP_IN
R1039
TL1011
BLKA
VC3
BLKB
VC2
VC1
VC0
DOT_CLK
EEP_DT_OUT
USBDOWN
DSC_RST
SD0CD
DSC_WKUP
SEGL_CD
SEGL_CS
FOCUS_PB
FOCUS_PA
STRB_CLS
R1064
TBC_CLK
TBC_DTO
TBC_DTI
A_CSYNC
S_IN_L
EXT_IN_L
TBC_CS
TBC_RST
PD_L
R1083
ROM_CS
REG_CS
S_DC_IN
R1011
EM_DET
R1012
IC1008
LAMP_ON
R1024
FLSH_RST
CAPT_REQ
MXDT_OUT
DIAL_PB
DIAL_OFF
DIAL_AUTO
DIAL_MANU
ZOOM_SW
TRIG_SW
TL1003
KEY_C
MENU_SET
MENU_P_A
MENU_P_B
Q1005
R1040
R1009
EJT_SW
DAC_CS
R1019
C1020
C1014
C1012
C1009
C1010
C1021
R1028
ADP_H
R1065
R1032
R1031
R1034
R1033
KEY_B
R1081
IC1001
TL1019
CHRG_EVR
ZMIC_ATT
R1093
TL1002
R1092
R1091
R1025
SENSPULS
R1086
R1087
STRB_AD
VF_CTL
EXTM_H
TL1012
TL1013
UREG_SEL
R1114
R1113
IC1009
TL1004
Q1007
Q1006
R1041
R1042
L_MUTE
POP_STRB
C1005
IC1001
STRB_CHG
SHOE_CHG
STO_OFF
SHOE_OFF
IC1012
R1108
C1041
1K
2.2k
47K
0R0
0.01
47K
10k
4.7K
10k
1k
100K
47K
0.01
1K
100k
1K
330
1K
330
10K
10K
100k
100k
1K
10k
22k
39k
100K
0.01
100K
470
0.01
0.01
470K
10K
22µ
100k
13p
0.1
100K
47k
0.1
47K
0.01
0.01
0.1
0.01
12k
8.2k
0.01
0.01
0.01
0.01
10K
15K
0.01
0.01
0.01
0R0
0.01
0R0
10k
10k
470
330
10K
4.7K
150K 2.7K
18K
1
47K
470K
10K
33K
4.7K
0R0
10k
1K
0Ω
82k
10K
470
62k
0.01
0.01
0.01
0.01
0.01
0.01
1.8M
1K
100k
1k
1k
1k
0R0
10K
10K
10K
47K
1K
1K
10K
1K
10µ/
0.01
NJU7108F3-X
NAX0474-001X
MC74HC1G00DF-X
SN74AHC1G00K-X
DTC143EE-X
74HC1G00GW-X
VCC
HOLD
SCK
SI
CS
SO
WP
VSS
AT25320N-10SI-X
SCLK
CS
DATA
RST
VDD
SDR
XD
EXD
TEST
VSS BLKC
TST0
BLKB
VC3
VD
HD
VC0
VC1
VC2
BLKA
MB90099PFV123-X
VSS
VDD
SIO
CLK
CS Xin
Xout
INTR
RS5C314-X
NAX0564-001X
DTC143XE-X SN74AHC1G08K-X
1SS376-X
2SC4617/QR/-X
DTC124EE-X
DA221-X
74HC2G08DP-X
2SJ347-X
DSC_CLK
RXD
EEPROM_CS
S_DT_IN
TXD
S_DT_OUT
S_CLK
DATA_IN
DATA_OUT
CLK_OUT
SRV_CS
SRV_RDY
VDD
VSS
SRV_RST
RTC_CS
VF_CS
TIMER_OUT
IR_WB
OSD_CS
OSD_TBC_IN
OSD_TBC_OUT
OSD_TBC_CLK
TBC_CS
BZ_FREQ
BZ_ENV
A_CSYNC
TBC_RST
EXT_IN_L
S_IN_L
TGFZ_RST
TG_CS
CDS_CS
CCD_CTL
M_CS
VDD
VSS
M_RVS
FLSH_RST
DAC_CS
DIAL_PB
DIAL_OFF
DIAL_AUTO
DIAL_MANU
SHOE_PWM
P_MEDIA
GATEPULS
F/Z_CS
IRIS_O/C
VPP
XT1
RESET
VDD
OSCO
OSCI
VSS
AUDIO_CS
A_MUTE
PWDA2
PWAD2
MD_DEM1
VDD
VSS
SHUT_ATT
VF_SW
JLIP_INT
SHOE_VON
MXDT_OUT MONI_SW
CAS_SW
EJCT_SW
VD
OMT
DSC_CS
VDD
VSS
REMOTE
STO_OFF
FLD
DSP_RST
ASPECT1
ASPECT2
CAPT_REQ
RTC_INT
MMC_L
TALLY
TRG_OUT
V_BATT
HALL_AD
Z_PTR_AD
F_PTR_AD
SHOE_AD
OP_THRMO
ZOOM_SW
IR_DET
KEY_A
KEY_B
KEY_C
SHOE_DET
S_DC_IN
AVREF
AVSS
AVDD
VDD
VSS
NC
NC
R/W
DSTB
ASTB
ADP_H
BUS0
BUS1
BUS2
BUS3
BUS4
BUS5
BUS6
BUS7
BVDD
BVSS
BUS8
BUS9
BUS10
BUS11
BUS12
BUS13
BUS14
BUS15
P_DET
TRIG_SW
KENTO
SYSCLK
WAIT
DSC_STS
DSC_RST
DSC_PCTL
USBDOWN
DSC_DT_IN
DSC_DT_OUT
ROM_CS
REG_CS
CHRG_WKUP
AVREF_OFF/SEGL_CS
SEGL_CD
CHRG_EVR
PD_L
EM_DET
EL_CTL
FOCUS_PB
POP_STRB
MENU_P_A
MENU_P_B
SENSPULS
MENU_KEY
I_MTR
T_BATT
CHRG_LED
S_DET
MENU_SET
STRB_SEL
SHOE_GATE
FOCUS_PA
VF_LCD
M_BL_ON
VF_CTL
NC
STRB_CHG
L_MUTE LAMP_ON/NIGHT_LED EXTM_H
UREG_SEL
STRB_CLS
ZMIC_ATT
HP_DET
NC
UPD70F3038F1A10
UPD70F3038FA10A
UPD703038F1-A10
IC-PST3423U-X
DTC143XE-X
DTC143XE-X
6V
74HC4053PW-X
D
G
S
T
Z38544/M3D6/MSGys
TO MAIN IF
CN110
TO MAIN IF
CN110
TO MAIN IF
CN110
TO MAIN IF
CN110
TO MAIN IF
CN105
TO MAIN IF
CN105, CN112
TO MAIN IF
CN105
TO MAIN IF
CN110
TO MAIN IF
CN106
TO MAIN IF
CN112
TO MAIN IF
CN114
TO MAIN IF
CN105, CN110
TO MAIN AUDIO,
VIDEO I/O, CDS,
OP DRV, TG
TO
VIDEO I/O
TO TG
TO TG
TO MAIN AUDIO
TO CDS
TO MAIN IF
CN106
TO MAIN IF CN110
TO OP DRV
TO MAIN IF
CN111
TO MAIN IF
CN114
TO MAIN IF CN114
TO MAIN IF
CN114
TO MAIN IF
CN106
TO MAIN IF
CN112
TO MAIN IF
CN106
TO MSD CPU
TO MAIN IF
TO MAIN IF CN106
TO MAIN IF
TO MAIN IF
TO MAIN IF
TO MAIN IF,
CAMERA DSP
TO MAIN IF CN106,
MSD CPU
TO STO.SENS
TO STO.SENS
TO STO.SENS
TO MSD CPU
TO MSD CPU
TO DSC
TO DSC
TO
CAMERA DSP
TO STO.SENS
TO MAIN IF
TO VIDEO I/O
TO VIDEO I/O
TO MAIN IF
CN110
TO
CAMERA DSP
TO MAIN IF CN110
TO MAIN IF CN111
TO MAIN IF CN111
TO MAIN IF CN106
TO STO.SENS
TO STO.SENS
TO MAIN IF
TO
VIDEO I/O
TO MAIN AUDIO
TO AUDIO AD/DA
TO MAIN AUDIO
TO MAIN AUDIO
TO MAIN IF CN112
TO USB
TO DSC, SD
(NOT USED)
#
#
#
#
#
(builtin capacitor 15pF)
0 1 MAIN (SYSCON)
NOTE : The parts with marked (
∗
) is not used.
# EXCHANGE PARTS LIST
4.3 MAIN(SYSCON) SCHEMATIC DIAGRAM
4-7 4-8

HGFEDCBA
4
5
3
2
1
y10359001a_rev0.1
UPD703040YF-M20
DRST
SPA
∗
FFREWH
UPD70F3040YFM20
XI164SEL
SRV_TRK
VPPD
DRUM_REF
CAP_REF
SRV_TRK
SRV_CS
TAPE_LED
REEL_VCC
FRP
SPA
TSR
HID
FRP
TSR
TESTDA0 TESTDA1
IC1401
GND
REG_3V
IC1401
TL1418
EEPROM_CS
TL1419
R1428
GND
R1429
TL1401
S_DT_IN
S_DT_OUT
S_CLK
L_FRB
R1432
TL1415
D_GAIN
CAS_SW
SRV_CS
SRV_RST
SRV_RDY
TL1405
R1402
C1416
REC_SAFE
MIC1
OUTV
MIC2
MIC3
R1403
R1414 R1413 R1412 R1411
C1414C1415 C1413 C1412
E_SENS
S_SENS
R1427
R1430
R1431
R1409
REEL_VCC
TAPE_LED
S_REEL
R1408
MONI_CHG
CAM_SW_B
CAM_SW_A
CAM_SW_C
DRUM_PWR
CAP_PWR
T_REEL
DEW_SENS
Q1403
Q1402
R1410
R1415
GND
R1416
REG_3V
M_REG4.8
UNREG
C1402
R1401
X1401
C1401
DRUM_ERR
TL1410
TL1409
TL1408
ADDT06
ADDT07
ADDT08
ADDT09
ADDT10
ADDT11
ADDT12
ADDT13
ADDT14
ADDT15
ADDT00
ADDT01
ADDT02
ADDT03
ADDT04
ADDT05
DRE
TL1407
REG_3V
TSR
M_REG4.8
VPPD
DRST
TL1403 TL1404
TL1411
UNREG
TL1406
HID1
SPA
SRV_TRK
L1401
NQR0006-001X C1403C1408
0.1
RA1401
CAS_SW
CAP_ERR
C1404
C1405
DRUM_ERR
CAP_FG
DRUM_PG
DRUM_FG
C1406 DRWSEL
DALE
DWE
CAP_ERR
CAP_PWR
DRUM_PWR
DRUM_REF
CAP_REF
MDA_PS
C_FRB
LD_ON
R1407
R1406
R1405
Q1401
C1407
EEP_DT_CLK
EEP_DT_OUT
EEP_IN
R1404
FRP
CAM_VD
C1411
C1410
C1409
TL1402
TL1416
CLK27SEL
DV_RST
HID3
RECH
PBH
DV_WAIT
SRV_RX
SRV_TX
TL1417
TL1412
TL1413
R1417
TL1414
0
10K
10K
1k
0.1 10K
3.3k 3.3k 3.3k 3.3k
0.0220.022 0.022 0.022
10K
10K
0
330k
75k
4.7K
4.7K
22p
1M
10p
0.1
47k
0.1
0.1
0.1
3.3k
3.3k
3.3k
0.1
4.7k
0.01
0.01
0.01
100
MDA_PS
NC
C_FRB2
C_FRB1
LD_ON
D_GAIN
L_FRB2
L_FRB1
CAM0
CAM1
CAM2
REC_SAFE
HID
NC
NC
XI164SEL
VDD
VSS
REEL_ON
MONI_CHG
CLK27SEL
FFREWH
DV_RST
NC
NC
NC
NC
NC
NC
NC
NC
CAP_REF
DRUM_REF
KENTO1_REF
KENTO2_REF
NC
NC
NC
NC
VPP
XT1
RESET
XT2
VDD
OSCO
OSCI
VSS
NC
HID
PBH
RECH
NC
NC
NC
NC
VDD
VSS
NC
NC
NC
NC
NC
NC
MSELECT
NC
NC
NC
DRUM_FG
DRUM_PG
NC
OUTV
NC
NC
VDD
VSS
T_REEL
S_REEL
TSR
FRP
NC
NC
NC
NC
SPA
SRVTRK
DRUM_FG
CAP_FG
NC
NC
NC
NC
S_SENS
E_SENS
DEW_SENS
BCID1
BCID2
BCID3
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
AVREF
AVSS
AVDD
VDD
VSS
DEW
NC
DRWSEL
DRE
DALE
NC
NC
ADDT00
ADDT01
ADDT02
ADDT03
ADDT04
ADDT05
ADDT06
ADDT07
BVDD
BVSS
ADDT08
ADDT09
ADDT10
ADDT11
ADDT12
ADDT13
ADDT14
ADDT15
NC
NC
NC
NC
SYS_OUT
KENTO1
KENTO2
NC
NC
CLK_OUT
NC
NC
NC
SYS_IN
READY
MIC_SDA
MIC_CTL
MIC_SCL
EEP_READ
EEP_WRITE
EEP_CLK
EEP_CS
NC
Vdd
Vss
CAM_VD
NC
NC
NC
TAPE_LED
NC
NC
NC
HID3
DV_WAIT
SYS_CLK
RXD
TXD
NC
UMC3N-W
UMC3N-W
NAX0204-001X
DTA114EE-X
RN2102-X
PDTA114EE-X
T
TO MAIN IF
CN110
TO CAMERA DSP
TO DV MAIN
TO DV MAIN
TO MAIN IF
CN105, CN107
DV MAIN
TO SYSCON
TO SYSCON
TO MAIN IF
CN105
TO MAIN IF
CN110
TO MAIN IF
CN108
TO MAIN IF
CN110
TO SYSCON
TO MAIN IF
CN108
TO MAIN IF
CN107
TO MAIN IF
CN107
TO MAIN IF
CN107
TO MAIN IF
CN105, CN107
TO DV MAIN
TO MAIN IF
CN108
0 1
TO MAIN IF
CN108
MAIN (MSD-CPU)
NOTE : The parts with marked (
∗
) is not used.
4.4 MAIN(MSD-CPU) SCHEMATIC DIAGRAM
4-9 4-10

HGFEDCBA
4
5
3
2
1
y20250001a_rev0
MIC Power Supply
MRF
Control
MPWR
01MAIN PWB
I/F
CSN
CCLK
CDTI
Register
Audio
I/F
Controller
BCLK
MCLK
LRCK
SDTO
SDTI
EXTR
EXTL
INTR
INTL
MVDD
PDN
HPL
HVDD
DVDD
SVDD
LOUT1
ROUT1
LOUT2
ROUT2
LIN1
LIN2
RIN1
RIN2
ATT
DAC
AVDD
HPR HVCMVCOM MUTET BEEP2
ADC
EQ
LPF
HPF
ALC1
MIX
ALC2
SPK+
SPK-
+2dB
+2dB
BEEP1
MUTE
+
+-
-
MGND
SGND
DGND
AGND
NEAR CNTHE
R2408
PD_L
S_SHUT
L_MUTE
REG_3V
AODAT
DATA_OUT
AIMCK
REG_4.8V
BUZZER
AIBCK
CLK_OUT
AUDIO_CS
AU_SIG/L
AILRCK
IN_MIC/R
L2602
L2603
L2601
R2602
R2601
C2608
C2604
C2603
C2607
C2610
C2606
C2605
C2609
C2613
R2610
R2609
R2607
R2608
C2611
C2612
R2201
R2203
C2201
C2223
C2224
R2233
R2204
R2234
C2202
R2202
C2615
C2207
C2206
D2202
D2204
R2613
R2404
R2405
R2406
L2401
D2203
C2402
C2401
Q2401
R2401
D2205
D2201
R2407
L2402
C2403
AIDAT
C2405
Q2402
C2204
C2203
R2224
R2223
R2222
R2221
R2220
R2219
R2218
R2217
C2219
C2220
C2221
C2222
A_MUTE
SPK+
SPK-
R2213
R2212
C2218
C2217
C2210
C2214
C2209
C2213
R2207
R2206
R2211
R2210
IM_GND
IM_GND
R2209
R2208
IN_MIC/L
R2231
C2212
C2216
C2211
C2215
EM_AU/R
EM_AU/L
MD_AU/R
MD_AU/L
R2604
R2606
R2605
R2603
EM_DET
R2611
D2206
D2601
GND
R2225
R2226
R2228
R2227
IC2201
C2619
C2621
R2620R2618
R2409
C2226
C2227
R2229
R2230
C2406
C2614
Q2403
R2402
R2403C2404
REG-CCD
C2205
HP_SIG/L
R2232
AU_SIG/R
Q2701
R2704
R2703
R2705
R2701
R2702
Q2202
D2703
C2618
Q2702
R2709
R2708
R2710
R2706
R2707
R2711
D2701
D2704
D2702
HP_SIG/R
SHUT_ATT
C2620
R2617 R2619
Q2603
R2614
R2616
EM_GND
EX_MIC/L
EX_MIC/R
R2615
C2617
EXTM_H
EMJ_DET
Q2601
Q2602
R2612
ZMIC_ATT
C2616
OPEN
0Ω
0Ω
0Ω
2.2k
2.2k
0.047
0.022
0.022
0.047
0.001
0.0047
0.0047
0.001
1.0
22k
22k
2.2k
2.2k
1.0
1.0
220k
39k
0.1
0.1
0.1
3.3k
150k
3.3k
1.0
560k
100p
47
47
OPEN
OPEN
0Ω
4.7k
12k
OPEN
10µ
OPEN
10
10
4.7k
OPEN
OPEN
10
OPEN
10
0.1
1.0
1.0
10
10
10
0Ω
0Ω
0Ω
10
10
OPEN
OPEN
OPEN
OPEN
2.7
2.7
0.1
0.1
1.0
0.1
1.0
0.1
33k
33k
0Ω
0Ω
22k
22k
1k
0.1
0.1
0.1
0.1
6.8k
3.3k
3.3k
6.8k
0Ω
OPEN
OPEN
0Ω
0Ω
820
820
OPEN
OPEN
OPENOPEN
OPEN
OPEN
OPEN
OPEN
OPEN
10
100p
4.7k
18k10
1.0
OPEN
560k
560k
3.3k
820
820
OPEN
OPEN
10k
10k
3.3k
220
220
100k
OPEN
OPEN
OPEN
OPEN
OPEN OPEN
OPEN
0Ω
OPEN OPEN
OPEN
10k 0.1
CH
/4
/4
/6.3
/6.3
2SC4617/QR/-X
/6.3
2SC4617/QR/-X
AK4564VQ
/6.3
CH
2SC4617/QR/-X
/6.3
UMX1N-W
DTC144EE-X
UMX1N-W
2SC5585-X
2SC5585-X
TT
T
T
T
T
T
TO MAIN IF
CN111
(OPEN)
TO MAIN IF
CN111
TO MAIN IF
CN106
TO MAIN IF
CN110
TO MAIN IF
CN111
TO MAIN IF
CN110
TO
CAMERA DSP
TO
AUDIO AD/DA
TO
DV MAIN
TO SYSCON
Audio Section
4-11 4-12
4.5 MAIN(MAIN AUDIO) SCHEMATIC DIAGRAM

HGFEDCBA
4
5
3
2
1
y10360001a_rev0
PHYFIL
[DVMAIN]
VCO D/AA/D A/DD/A
VCO
ANALOG_2.5V
ANALOG_1.8V
DIGITAL_1.8V
DIGITAL_3V
∗
PHY_2.85V
DV I/O
∗
∗
VCO
∗
∗
IC3001
GND
REG_2.5V
CLK27SEL
REG_3V
ADDT15
ADDT07
L3002
L3004
L3006
ADDT06
R3059
D3004
R3049
C3005
ADDT05
ADDT04
ADDT03
ADDT02
ADDT01
ADDT00
ADDT08
ADDT09
ADDT10
ADDT11
ADDT12
ADDT13
ADDT14
X3002
R3020
C3065
DV_WAIT
C3047
DISCRI
DRWSEL
DRE
DWE
DALE
INV
INH
OUTV
OUTH
DCO3
DCO2
DCO1
DCO0
DYO3
DYO2
DYO1
DYO0
DCI3
DCI2
DCI1
DCI0
DYI3
DYI2
DYI1
DYI0
AIDAT
AODAT
AILRCK
AIBCK
AIMCK
C3030
RA3004
R3032
C3037
C3031
C3028
R3010
C3049
C3048
TSR
FRP
R3015
C3027
R3013
R3014
R3018
R3019
R3016
R3017
C3026
R3045
R3021
C3017
C3059
C3055
HID1
CLK27A
DV_RST
RA3003
R3012
C3024
C3023
R3022
R3009
L3001
C3025
AGC_OUT
RA3001
SPA
VRB_AGC
ATFI
VRB_ATF
REC_DATA
C3015
REC_CTL
C3010
L3005
C3008
C3007
C3011
C3050
C3013
PBPLLCTL
C3043
C3016
C3029
PB_CLK
C3020
C3038
C3045
C3003
R3046
R3041
TRST
REF_CLK
TDA
IC3002
C3001
R3002
VREF_1.1
J101
RA3002
R3006
L3012
C3064
TCMK
TMS
TDO
M_VCOCTL
FSPLLCTL
R3007
R3008
FS_PLL
MAIN_VCO
R3038
R3033
R3028
R3051
R3030
D3002
SBE
REG_1.8V
C3042
C3039
C3036
C3063
C3044
IC3003
R3039
C3056
R3036
R3037
C3058
C3057
R3034
R3035
PBVCOCTL
C3061
R3040
R3029
C3062
D3001
R3011
R3058
R3027
C3021
C3012
R3004
TL3001
SRV_TRK
C3033
C3046
REC_CLK
C3022
L3007
L3008
D3003
C3032
R3031
10
56
10
[24.576MHz]
5.1k
0.1
0.1
10k
1M
6p
0.1
270p
10k
0.0022
0.047
3.9k
0.0047
2.4k
3.9k
56
56
56
56
1
10k
10
0.1
0.001
1
0
0Ω
0.001
33p
10
10k
0.1
100
0.01
0.01
10
10
0.1
0.001
0.01
0.01
0.1
0.01
0.1
0.1
0.1
1
680
10
10k
100
10
5.6k
2.2k
560
2.2k
8.2k
100
220k
0.01
0.1
6p
0.1
560
1
1.2K
1.5K
0.047
82K
12K 0.01
2.2K
1M
0.01
220k
10k
10k
0.1
0.1
10k
22p
0.01
0.1
2.2µ
12µ
0.001
220k
LPFIN
LPFOUT
ADVIN0
ADAVD0
ADAVS0
ADVRH0
ADVRL0
EXDATAI7
EXDATAI6
EXDATAI5
EXDATAI4
EXDATAI3
EXDATAI2
EXDATAI1
EXDATAI0
PBCLKO
PBCLKI
VSSP
VCI4185
VDDP
DAAOUT0
DAVRO0
DAVREF0
DAAVS0
DAAVD0
DAAOUT1
DAVRO1
DAVREF1
DAAVS1
DAAVD1
SBE
HID
HSP
RECDATA
RECCLK
RECCTL
SPA
VSS
VDDE
VSS
OSC4185I
OSC4185O
DISCRI
REFCLK
ADVIN1
ADAVD1
ADAVS1
ADVRH1
ADVRL1
VSS
PWM27O
VDDE
OSC27I
OSC27O
CLK27I
CLK27O
CLK27SEL
VSS
CLK135O
VDDI
FRRES
FRREF
TRKREF
SERVOFRREF
SERVOTRKREF
PHYTPA
PHYTPB
PHYTPBIAS
PHYXTPA
PHYXTPB
PHYRO
PHYRF
PHYFIL
XRESET
PHYVDA
PHYVDR
PHYVSA
PHYVSR
PHYAVS3
VDDE
N.C
VDDE
VSS
PWMAUDIO
VDDE
VSSP
VCIAUD
VDDP
VCXO11I
VCXO11O
VCXO12I
VCXO12O
OSC24I
OSC24O
OSC11I
OSC11O
DILRCK
DIBCK
DIMCK
DIDAT
AILRCK
AIBCK
AIMCK
AIDAT1
AIDAT0
DOLRCK
DOBCK
VDDI
DODAT
AOLRCK
AOBCK
VSS
AODAT1
AODAT0
YSO0
YSO1
YSO2
YSO3
BRSO0
BRSO1
BRSO2
BRSO3
YSI0
YSI1
YSI2
YSI3
BRSI0
BRSI1
BRSI2
BRSI3
OUTH
OUTV
INH
INV
CPUALE
XCPUDSTB0
XCPUDSTB1
XCPURW
XCPUCS
XINT
CPUWAIT
CPUWAITLOGIC
CPUDSLOGIC
CPUBUSTYPE
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
VSS
VDDE
VDDI
VSS
ADRS0
ADRS1
ADRS2
ADRS3
ADRS4
VDDE
VDDI
BUSCLK
VSS
ADRS5
ADRS6
ADRS7
ADRS10
ADRS8
ADRS9
VSS
VDDI
VSS
EXTFRP
EXTREQ
EXTACCESS
EXTDATA0
EXTDATA2
VDDE
EXTDATA5
VSS
EXTDATA6
N.C
N.C
EXTDATA1
VSS
EXTDATA3
EXTDATA4
EXTDATA7
N.C
N.C
TTST
VPD
N.C
N.C
N.C
PBI
TBST
N.C
DCTEST0
VSS
TDI
DCTEST1
TRST
TCK
TMS
TDO
VDDI
MON2
MON5
N.C
VDDE
MON3
N.C
MON0
MON1
MON4
VSS
MON6
MON9
MON11
VDDE
MON14
MON16
MON7
MON8
MON12
VDDI
MON13
MON17
MON10
MON15
MON27
N.C
MON18
MON19
MON21
VDDE
VSS
MON20
MON22
MON23
VDDE
MON24
MON25
MON26
VDDE
VSS
N.C
VSS
VDDE
VDDP
VSSP
VDDA
N.C
VDDE
VSS
VSS
VDDI
VDDE
VDDI
VSS
VSS
MTEST
PHYAVD2
BUSRST
PMODE
VDDI
PHYAVD3
PWR3
PHYAVS2
PWR1
PWR2
PHYAVS1
PHYAVD1
VSS
VSS
VDDE
VDDI
JCY0152
NQR0129-002X
NQR0006-001X
NQR0006-001X
MA2Z720-X
/6.3
CH
CH
CH
NQR0129-002X
NQR0006-001X
/6.3
NCB10JK-106X
JCY0174-X
/6.3
TPA+
TPA-
TPB+
TPB-
NQR0006-001X
EC2C01C-X
CH
SN74AHC1G04K-X
EC2C01C-X
CH
EC2C01C-X
T
T
T
T
MAIN
[DVMAIN section]
01
TO
CAMERA DSP
TO MAIN IF
CN110
TO MAIN IF
CN107
TO VIDEO I/O,
CAMERA DSP
TO VIDEO I/O,
CAMERA DSP
TO
CAMERA DSP
TO MSD CPU, CAMERA DSP
TO CAMERA DSP
TO MAIN AUDIO
TO MSD CPU
TO MAIN IF
CN105, MSD CPU
TO MSD CPU
TO MAIN IF
CN105
TO VIDEO I/O
NOTE : The parts with marked (
∗
) is not used.
4-13 4-14
4.6 MAIN(DV MAIN) SCHEMATIC DIAGRAM

HGFEDCBA
4
5
3
2
1
y10361001a_rev0
∗
∗
∗
WARE
∗
C3731-C3747
NO WARE
WITH ANALOG INPUT
∗
Q3731-Q3735
L3731,L3732
WITHOUT ANALOG INPUT
NO WARE
NO WARE
NO WARE
NO WARE
WARE
WARE
#: EXCHANGE PARTS LIST
IC3731
WARE
WARE
R3731-R3748
75W
75W
6dB
75W
6dB
MAIN [Analog video I/O section]01
20k
Mute
Chroma Mute
6dB
∗
[12ch_EVR_DAC]
C3814-C3818 WARE NO WARE
IC3801 JCP8045 JCP8055
R3722
R3725
R3728
WITH SELF RECORDING
WITHOUT SELF RECORDING
150
150
150
120
120
120
Q3701
IC3701
Q3701
R3712
Q3705
R3704
R3701
C3714
C3740
D3701
R3702
R3705
C3702
C3704
C3703
C3705
C3707
R3706
R3703
C3741
R3726
R3742
R3743
IC3901
C3901
R3809
R3728R3725
C3706
R3711
Q3702
R3710
L3701
C3701
R3709
R3708
R3707
Q3731
R3732
R3713
R3714
R3715
C3709
R3731
R3730C3731
C_OUT
BLKC
SENS_EVR
C3715
C3708
IC3801
L3803
L3804
C3803 C3804
L3801
L3802
C3801 C3802
R3806
R3807
CLK27A
R3741 R3739
R3740
R3738
R3736
R3737 R3735
R3734
R3733
R3744
R3745
R3746
R3747
R3748
C3820
GND
REG_4.8V
REG_1.8V
TBCCTL
DYO3
DYO2
DYO1
DYO0
DCO3
DCO2
DCO1
DCO0
INV
INH
OUT_HS
OUT_VS
OUT_C0
OUT_C1
OUT_C2
OUT_C3
OUT_Y0
OUT_Y1
OUT_Y2
OUT_Y3
TBC_DTI
TBC_DTO
TBC_CLK
TBC_CS
CLK27B
R3727
ASPECT1
S_IN_L
EXT_IN_L
TBC_RST
VC3
VC2
VC1
VC0
BLKB
OSD_HD
OSD_VD
DOT_CLK
BLKA
ASPECT2
S_DC_IN
C3713
R3721
R3722
R3724
VDCVF
Q3704
A_CSYNC
IC3731
LCD_R
LCD_B
LCD_G
HDCVF
Y_OUT
V_OUT
REG_3V HRP
TL3801
TL3802
R3801
IC3802
C3712
R3808
R3802
C3807
C3819
C3805
C3806
R3805
C3808
C3809
C3812
C3810
C3811
C3813
C3814
C3815
C3816
C3817
C3818
R3803 R3804
L3732
C3746
C3742
Q3735
C3744
C3747
C3743C3745
C3732L3731
C3738 Q3732
C3733C3735
Q3734
Q3733
C3736
C3737
C3734
C3739
C3902
L3901
C3711
C3710
RECCADJ
H_OFFSET
H_GAIN
PBPLLCTL
PBVCOCTL
M_VCOCTL
FSPLLCTL
DUMP_CTL
NOSIG_LV
ATF_GAIN
DATA_OUT
CLK_OUT
DAC_CS
1M
300
270
1
270
300
56p
68p
27p
27p
0.01
3.3k
3.3k
1
4.7k
100k
100k
22
0
1
10k
10k
10µ
10
68
68
68
100
100k
82k
10k
0.01
4.7k
4.7k0.01
0.01
0.1
10µ
10 47
11
1k 820
820
680
18k
18k 1.8k
8.2k
560
560
1.5k
2.2k
1k
470k
0.01
4.7k
100
0
3.3k
100
100
820
0.01
0.01
0.01
0.01
820
0.01
0.1
0.1
0.01
0.1
0.1
0.01
0.1
0.1
0.1
0.1
27k 15k
6.8µ
4.7
0.1
5p
0.01
3p33p
0.001
6.8µ
0.01
3p33p
0.001
5p
0.01
0.01
22
22
UMT1N-W
BA7665FS-X
UMT1N-W
CH
AO1
AO2
GND
DI
CLK
LD
DO
AO12
AO11
VCC VREFU
AO10
AO9
AO8
AO7
AO6
AO5
AO4
AO3
VREFL
BU2501FV-X
/4
UMZ1N-W
/6.3
2SC4617/RS/-X
CSO0
CSO1
CSO2
CSO3
YSO0
YSO1
YSO2
YSO3
OUTH
VDD(C)
VSS
OUTV
ZCNT
RESVD
RESHD
MONI1
MONI2
SDOUT
SDIN
SCLK
CS
VDD(I)
VSS
RST
CLK
VC0
VC1
VC2
VC3
BLK1
BLK2
BLK3
HDCVF
VDCVF
CSYNC
HDOUT
VDOUT
VSS
VDD(I)
CLKOSD
SCANMODE
SCANEN
ADDATEST
RAMTEST
AVSS
AVDD[DA]
IREF2
CROUT
ABAR2
COMP2
CBOUT
VREF2
COUT
AVDD[DA]
AVSS
IREF1
YCOUT
ABAR1
COMP1
YSOUT
VREF1
AVSS
AVDD[DA]
CLPY
VYIN
AVSS
AVDD[AD]
VRM
VRL
VRH
CIN
AVDD[AD]
AVSS
AMUTE
HRP1
HRP2
CSI0
CSI1
CSI2
CSI3
CSI4
CSI5
CSI6
CSI7
VDD(C)
VSS
YSI0
YSI1
YSI2
YSI3
YSI4
YSI5
YSI6
YSI7
INH
INV
NQR0006-001X
/6.3 /4
NQR0129-002X
NQR0129-002X
/4
2SA1774/RS/-X
MM1504XN-X
IN2[H]
IN1[L]
GND
VCC
OUT
SW
SN74AHC1G04K-X
/4
UMZ1N-W
CH
CHCH
DTC144EE-X
CHCH
2SC4617/RS/-X
UMZ1N-W
CH
CH
NQL38DK-100X
/4
/4
#
#
#
#
T
##
T
#
#
#
#
#
TT
##
#
#
#
##
#
#
#
#
#
#
#
T
#
#
T
#
#
#
#
##
#
#
#
#
#
##
#
#
##
##
#
#
#
#
#
T
T
TO
CAMERA DSP
TO
DV MAIN
TO SYSCON
TO MAIN IF
CN110
TO MAIN IF
CN112
TO MAIN IF
CN110
TO MAIN IF
CN112
TO MAIN IF
CN106
TO DV MAIN
TO DV MAIN
TO STO.SENS
TO MAIN IF
CN107
TO OP DRV
TO SYSCON
NOTE : The parts with marked (
∗
) is not used.
4-15 4-16
4.7 MAIN(VIDEO I/O) SCHEMATIC DIAGRAM

DCBA
4
5
3
2
1
y30225001a_rev0
0 1 MAIN PWB [Audio AD/DA section]
EM_AU/R
EM_AU/L
R2104
AIDAT2
R2103
REG_3V GND DOBCK2
L2101
C2107
C2110
PWDA2 MD_DEM1
IC2101
DOLRCK2
C2108
R2102R2101
C2106
C2105
DODAT2 DOMCK2 PWAD2
C2109
MD_AU/R
MD_AU/L
C2102 C2101
R2110
R2112
R2113 R2111
C2112
C2113
C2114
OPENOPEN
10µ
10
4.7
0.1
470470
0.0022
0.0022
0.1
1.0 1.0
0Ω
0Ω
OPEN 0Ω
OPEN
OPEN
OPEN
/6.3
/6.3
VCOM
AINR
AINL
VSS
VDD
DEM0
DEM1
SDTO SDTI
LRCK
MCLK
SCLK
PWAD
PWDA
AOUTL
AOUTR
AK4550VT-X
T
T
TO SYSCON
TO MAIN IF CN110
TO DSC
TO MAIN AUDIO
DCBA
4
5
3
2
1
y20251001a_rev0
0 1 MAIN [CDS]
[CDS/AGC/AD]
[3.1V_REG]
C4202
R4204
TL4202
TL4201
R4203
C4219
C4207
ADCLK
IC4202
CN101
C4220
C4221
C4222
CPOB
PBLK
C4203
C4201
CN102
IC4201
R4205
RA4201
RA4202
SHD
R4202
R4206
C4216
CAM_3.1V
GND
SHP
CDS_CS
DATA_OUT
CLK_OUT
REG_4.8V
L4201
C4205
C4210
C4211
C4214
C4204
R4201
C4215
C4209
C4208
C4213
C4206
ADIN9
ADIN8
ADIN7
ADIN6
ADIN5
ADIN4
ADIN3
ADIN2
ADIN1
ADIN0
10
100
33k
0.1
0.1
1
1
1
0.01
1
100
100
100
0R0
1
10µ
0.1
1
1
0.1
100
0Ω
0.1
0.1
0.012
0.1
0.1
/6.3
GND
CCD_OUT
CONT
GND
NOISEVOUT
VIN
MM1613BN-X
CCD_OUT
GND
GND
CCD_OUT
GND
GND
CCD_15V
H2
H1
RG
GND
GND
CCD-7.5V
SUB
CCD_15V
GND
GND
V4
V3
V2
V1
CCD_CTL
QGF0517F2-20X
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
DRVVDD
DVSS
ADCLK
DVDD
PBLK
OBP
SPBLK
SPSIG
AVSS
BLKFB
CDSIN
BLKC
BIAS
ADCIN
SCK
SDATA
CS
DVSS
DVDD
VRB
VRT
VRM
AVSS
AVDD
BLKSH
AVDD
HD49340HMP-X
NRZ0034-101W
NRZ0034-101W
/4
T
∗
T
TO SYSCON
TO
CAMERA DSP
TO MAIN IF
CN110
TO TG
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
TO CCD
CN5201
OPEN
NOTE : The parts with marked (
∗
) is not used.
4-17 4-18
4.8 MAIN(AUDIO AD/DA) SCHEMATIC DIAGRAM 4.9 MAIN(CDS) SCHEMATIC DIAGRAM

HGFEDCBA
4
5
3
2
1
y10362001a_rev0.1
*
[CAMERA_DSP]
NTSC
[1.2V_REG]
[54MHz_CXO]
PAL
0
*
[L:NT,H:PAL]
[L:NEC,H:Pana]
[L:54,H:108]
[L:SONY,H:Pana]
1
R4301 R4302
0R0
MAIN(DSP)
* 0R0
*
IC4301
TL4319
TL4320
TL4318
RA4306
RA4305
TL4316
RA4307
RA4308
RA4301
RA4302
RA4303
RA4304
TL4314
TL4312
TL4313
TL4317
R4306
ADIN9
ADIN8
ADIN7
ADIN6
ADIN5
ADIN4
ADIN3
ADIN2
ADIN1
ADIN0
BUS15
BUS14
BUS13
BUS12
BUS11
BUS10
BUS9
BUS8
BUS7
BUS6
BUS5
BUS4
BUS3
BUS2
BUS1
BUS0
CDSTB
CRWSEL
CALE
MVD
MFLD
OMT
DSP_RST
CAM_VD
IRIS_PWM
CLK4M5
IRIS_C
C4304
R4304
TL4311
R4313
R4312
DYO0
DYO1
DYO2
DYO3
DCO0
DCO1
DCO2
DCO3
INH
INV
CLK9A
CLK27A
S_SHUT
OUTV
OUTH
DCI3
DCI2
DCI1
DCI0
DYI3
DYI2
DYI1
DYI0
OUT_VS
OUT_HS
OUT_C3
OUT_C2
OUT_C1
OUT_C0
OUT_Y3
OUT_Y2
OUT_Y1
OUT_Y0
TBCCTL
R4319
R4318
R4317
R4316
R4315
TCMK
TMS
TRST
TDI
TDA
IC4302
REG_3V
C4310
C4302 C4301
REG_1.8V
GND
C4309
C4311
R4301
L4301
L4302
L4303
C4308
DSYIO7
DSYIO6
C4303
C4307
DSYIO5
DSYIO4
DSYIO3
DSYIO2
DSYIO1
DSYIO0
DSCIO7
DSCIO6
DSCIO5
DSCIO4
DSCIO3
DSCIO2
DSCIO1
DSCIO0
CLKDSC
HDDSC
VDDSC
FLDDSC
DSYO7
DSYO6
DSYO5
DSYO4
DSYO3
DSYO2
DSYO1
DSYO0
DSCO7
DSCO6
DSCO5
DSCO4
DSCO3
DSCO2
DSCO1
DSCO0
R4307
R4308
R4320
R4321
R4322
R4323
R4324
R4325
R4326
R4327
R4328
TL4310
TL4309
TL4308
TL4307
TL4306
TL4305
TL4304
TL4303
TL4302
TL4301
R4302
TG_36M
HDIN
VDIN
PBLK
CPOB
L4304
C4305
X4301
R4303
L4305
C4306
R4314
CLK27B
C4312
R4310
R4309
R4305
SHOEGATE
TL4315
R4311
10
10
10
10
100
100
100
100
22
0.01
22
0
0
100
100
100
100
100
0.1
10 10
0.1
0.1
0Ω
10
10
10
22
0
0
0
0
0
0
0
0
0
0
1
22
10
1k
0.1
0
0
0
CLK45
PWM
VDMDA
MDRV
SDRV
FRP
FLDCPU
VDCPU
HDCPU
CS
AS
RE
WE
BUS0
BUS1
BUS2
BUS3
BUS4
BUS5
BUS6
BUS7
BUS8
BUS9
BUS10
BUS11
BUS12
BUS13
BUS14
BUS15
ADIN0
ADIN1
ADIN2
ADIN4
ADIN3
ADIN5
ADIN6
ADIN7
ADIN8
ADIN9
CLK36I
HDTG
VDTG
PBLK
OBCP
FLDDSC
VDDSC
HDDSC
CLKDSC
DSCIO7
DSCIO6
DSCIO5
DSCIO4
DSCIO3
DSCIO2
DSCIO1
DSCIO0
DSYIO7
DSYIO6
DSYIO5
DSYIO4
DSYIO3
DSYIO2
DSYIO1
DSYIO0
DSCO7
DSCO6
DSCO5
DSCO4
DSCO3
DSCO2
DSCO1
DSCO0
DSYO7
DSYO6
DSYO5
DSYO4
DSYO3
DSYO2
DSYO1
DSYO0
OUTVA
OUTHA
ACI1
ACI2
AYI3
AYI2
AYI1
AYI0
INVA
INHA
ACO3
ACO2
ACO1
ACO0
AYO3
AYO2
AYO1
AYO0
KO
CLK27AO*
CLK27CO
CLK27I*
OUTV*
OUTH*
DCI3*
DCI2*
DCI1*
DCI0*
DYI3*
DYI2*
DYI1*
DYI0*
INV*
INH*
DCO3*
DCO2*
DCO1*
DCO0*
DYO3*
DYO2*
DYO1*
DYO0*
TDO
TDI
TRST
TMS
TCK
VBGP
VBGEN
VBB_ENA
SERSTB
SECNT1
SECNT0
ROM_TEST
PLL_TEST
SCAN_ENA
SCAN_TEST
BIST_TEST
JTEST7
JTEST6
JTEST5
JTEST4
JTEST3
JTEST2
JTEST1
JTEST0
CKSEL
AVSSP2
AVSSP1
AVDDP2
AVDDP1
CLK72O
CLK54I
CLK9AO
CLK9BO
CLK27BO
ANACTL
ACI0
ACI3
VDANA
VCC*
VCC*
VCC*
GND
GND
GND
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VDDcore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
VSScore
OMT
CLR
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
GND
GND
GND
GND
GND
GND
GND
GND
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
GND
GND
GND
GND
GND
GND
GND
GND
VCC
VCC
VCC
VCC
GND
GND
GND
GND
USEL
GND
GND
TVSEL
CCDSEL
JCY0183
VDD
GND
EC CE
Vout
R1160N121B-X
/6.3 /6.3
NQR0129-002X
NQR0129-002X
NQR0129-002X
/6.3
/6.3
/6.3
NQR0129-002X
NC
GND OUT
VDD
NAX0319-001W NQR0129-002X
/6.3
TT
T
T
T
T
TO TG
TO CDS
TO SYSCON
TO OP DRV
TO OP DRV
TO MSD CPU,
OP DRV
TO
DV MAIN
TO VIDEO I/O
TO
MAIN AUDIO
TO DV MAIN, VIDEO I/O
TO VIDEO I/O, DSC
TO DV MAIN
TO MAIN IF
CN110
TO DSC
4.10 MAIN(DSP) SCHEMATIC DIAGRAM
4-19 4-20

HGFEDCBA
4
5
3
2
1
y20252001a_rev0
FILa
FILb
FILc
FILd
130mA
∗
∗
[Zoom/Focus_MDA]
01MAIN PWB
∗
∗
∗
∗
∗
∗
Q4805
H_GAIN
DRIVE-
H_OFFSET
GND
L4802
M_REG4.8
IRIS_C
R4821
C4855
IC4804
R4804
R4820
C4854
R4841
OP_THRMO
R4809
IC4802
R4812
IC4803
R4813
R4808
R4814
IRIS_PWM
GND
FOCUS02
M_REG4.8
C4866
HALL_AD
R4819
C4813
C4804
C4811
R4811
R4834
REG_4.8V
C4816
IC4805
R4805
C4815
R4828
R4810
IRIS_O/C
IC4851
C4853
R4815
R4862
R4864
R4863
R4865
R4866
R4842
R4874
C4806
C4821
R4867
R4868 C4858
C4859
C4860 C4861
C4862 R4855
R4854
C4863
R4857
R4856
R4858
R4859
R4832
R4860
F/Z_RST
R4829
CAM_VD
F/Z_CS L4852
L4851
DATA_OUT
CLK_OUT
CLK4M5
FOCUS03
FOCUS04
FOCUS01
C4851C4852
Q4806
F_LED
F_VCC
C4812
REG_3V
C4809
F_PTR_AD
R4806
ZOOM02
ZOOM03
ZOOM04
R4807
C4808
ZOOM01
Q4802
L4853
C4865 C4864
DAMP+
DRIVE+
HGVss-
HGout-
HGVcc+
GND
R4824
Q4851
DAMP-
R4870
HGout+
Z_VCC
Z_PTR_AD
Z_LED
C4814
R4830
Z_PTR_AD
R4826
R4825
R4831
R4817
R4818
C4810
C4803
R4871
R4852
R4823
R4872
F_PTR_AD
OP_THRMO
R4833
R4822
R4836
C4819
R4816
Q4801
R4845
Q4803
Q4804
10µ
100k
0.1
560k
100k
10
10k
330
15k
24k
1M
10k
0.1
0.1
0.01
560k
100k
0.1
10k
1500p
18k
10k
3.3
4.7k
6.8
1k
6.8
1k
1k
10k
0
0.1
1k
0Ω
68p 1000p
1000p 1000p
1000p
0R0
6.8
6.8
33k
0Ω
33k
0Ω
1.2k
10µ
100.1
0.1
0.1
68k
68k
1
10µ
0.1 10
4.7k
270
0.1
2.2k
47k
2.2k
47k
4.7k
10k
0.01
10
0
1k
100k
47k
560
0.1
1M
2SC4617/RS/-X
VCC
GND
NJM3414AV-X
/10
VCC
GND
NJM2143R-X
VCC
GND
NJM2143R-X
VCC
GND
MM6564XFBE-X
LGND
Cosc
FILa
FILb
FILc
FILd
Vref
Vdd
Vm3
D2
FBd
D1
Vm4
C2
FBc
C1
EXP0
EXP1
VREFSEL
PGND
EXTa
Vm1
A1
FBa
A2
Vm2
B1
FBb
B2
LATCH
SDATA
SCLK
OSCin
OSCout
RESET
EXTb
VD
UPD16879GS-X
/10
NQR0129-002X
/6.3
2SA1774/QR/-X
2SC4617/RS/-X
/6.3
2SC4617/RS/-X
/6.3
2SC4655/BC/-X
DTC144EE-X
DTA144EE-X
TT
T
T
T
TO VIDEO I/O
TO SYSCON
TO SYSCON
TO SYSCON
TO CAMERA DSP
TO MAIN IF
CN110
TO MAIN IF
CN110
TO MAIN IF
CN104
OP_DRIVE Section
NOTE : The parts with marked (
∗
) is not used.
4-21 4-22
4.11 MAIN(OP DRV) SCHEMATIC DIAGRAM [FOR F1.2 LENS MODEL]

HGFEDCBA
4
5
3
2
1
y20253001a_rev0
FILa
FILb
FILc
FILd
130mA
∗
∗
[Zoom/Focus_MDA]
01MAIN PWB
OP_DRIVE Section
∗
OP_DRIVER
∗
∗
∗
∗
∗
Q4805
H_GAIN
DRIVE-
H_OFFSET
GND
L4802
M_REG4.8
IRIS_C
R4821
C4855
IC4804
R4804
R4820
C4854
R4841
OP_THRMO
R4809
IC4802
R4812
IC4803
R4813
R4808
R4814
IRIS_PWM
GND
FOCUS02
M_REG4.8
C4866
HALL_AD
R4819
C4813
C4804
C4811
R4811
R4834
REG_4.8V
C4816
IC4805
R4805
C4815
R4828
R4810
IRIS_O/C
IC4851
C4853
R4815
R4862
R4864
R4863
R4865
R4866
R4842
R4874
C4806
C4821
R4867
R4868 C4858
C4859
C4860 C4861
C4862 R4855
R4854
C4863
R4857
R4856
R4858
R4859
R4832
R4860
F/Z_RST
R4829
CAM_VD
F/Z_CS L4852
L4851
DATA_OUT
CLK_OUT
CLK4M5
FOCUS03
FOCUS04
FOCUS01
C4851C4852
Q4806
F_LED
F_VCC
C4812
REG_3V
C4809
F_PTR_AD
R4806
ZOOM02
ZOOM03
ZOOM04
R4807
C4808
ZOOM01
Q4802
L4853
C4865 C4864
DAMP+
DRIVE+
HGVss-
HGout-
HGVcc+
GND
R4824
Q4851
DAMP-
R4870
HGout+
Z_VCC
Z_PTR_AD
Z_LED
C4814
R4830
Z_PTR_AD
R4826
R4825
R4831
R4817
R4818
C4810
C4803
R4871
R4852
R4823
R4872
F_PTR_AD
OP_THRMO
R4833
R4822
R4836
C4819
R4816
Q4801
R4845
Q4803
Q4804
10µ
100k
0.1
560k
100k
10
10k
330
15k
24k
1M
10k
0.1
0.1
0.01
560k
100k
0.1
10k
1500p
18k
10k
3.3
4.7k
6.8
1k
6.8
1k
1k
10k
0
0.1
1k
0Ω
68p 1000p
1000p 1000p
1000p
0R0
6.8
6.8
33k
0Ω
33k
0Ω
1.2k
10µ
100.1
0.1
0.1
68k
68k
1
10µ
0.1 10
4.7k
270
0.1
2.2k
47k
2.2k
47k
4.7k
10k
0.01
10
0
1k
100k
47k
560
0.1
1M
2SC4617/RS/-X
VCC
GND
NJM3414AV-X
/10
VCC
GND
NJM2143R-X
VCC
GND
NJM2143R-X
VCC
GND
MM6564XFBE-X
LGND
Cosc
FILa
FILb
FILc
FILd
Vref
Vdd
Vm3
D2
FBd
D1
Vm4
C2
FBc
C1
EXP0
EXP1
VREFSEL
PGND
EXTa
Vm1
A1
FBa
A2
Vm2
B1
FBb
B2
LATCH
SDATA
SCLK
OSCin
OSCout
RESET
EXTb
VD
UPD16879GS-X
/10
NQR0129-002X
/6.3
2SA1774/QR/-X
2SC4617/RS/-X
/6.3
2SC4617/RS/-X
/6.3
2SC4655/BC/-X
DTC144EE-X
DTA144EE-X
TT
T
T
T
TO VIDEO I/O
TO SYSCON
TO SYSCON
TO SYSCON
TO CAMERA DSP
TO MAIN IF
CN110
TO MAIN IF
CN110
TO MAIN IF
CN104
NOTE : The parts with marked (
∗
) is not used.
4-23 4-24
4.12 MAIN(OP DRV) SCHEMATIC DIAGRAM [FOR F1.8 LENS MODEL]

HGFEDCBA
4
5
3
2
1
y20254001a_rev0
01
MODEL
MAIN [TG/VDR]
[TG/V_DRIVER]
[3.3V_REG]
M3D4L
M3D6L
L5007 L5008 R5001 R5021
NQR0129-002X
∗∗∗
NQR0129-002X
∗
100K
100K
∗
∗
∗
*
*
*
*R5022 R5023
*
* 0R0
0R0
GND
IC5001
ADCLK
R5005 C5028
C5010
REG_12V
L5008
CCD_CTL
CLK9A
R5003
R5002
TG_36M
CN102
R5020
R5021
R5022
R5023
CAM_3.1V
TG_CS
C5014
C5005
C5023
C5012
R5004
R5009
R5006
C5026
C5024
C5029
L5003
C5027
DATA_OUT
CLK_OUT
C5025
IC5002
R5017
C5011
C5020
C5013
L5001
REG_4.8V
C5006
TG_RST
C5004
R5010
C5016
L5007 #
#
L5005 REG-CCD
C5007 C5008
C5009
L5002
REG_3V
REG_15V
R5001
D5001
CPOB
IC5003
C5001
C5003
C5002
C5022
L5006
C5019
C5021
C5018
L5004
C5015
C5017
SHP
SHD
PBLK
VDIN
HDIN
0R0
10
4.7
10
10
0R0
0R0
0R0
0.1
0.1
0.1
0.1
0R0
10
10
1
10µ
0.1
1
100
0.1
0.1
0.1
1
10
47
10
10µ
100k
1
22
0.01
0.1
10µ
0.1
4.7
10µ
47
TEST1
RST
VDD1
GND
GND
CLD
CL
RG
GND(RG)
GND(H)
H1
H2
AVD(H)
AVD(RG)
XCLPOB
AVD(CDS)
XSHP
XSHD
GND(CDS)
XCLPDM
XPBLK
TEST2
NC
VDD2
CLKI
GND
GND
TEST3
VDI
HDI
VGAT
WEN
SEN
SSI
SSCK
SGEN
VDD3
SGMOD
VM
V2
V4
V1
VH
V3
SUB
VL
DSGAT
VDD4
CXD3602AR
/6.3
/20
NQR0129-002X
CCD_CTL
V1 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
V2
V3
V4
GND
GND
GND
CCD_OUT
CCD_15V
GND
GND
GND
GND
CCD-7.5V
SUB
CCD_15V
H2
H1
RG
QGF0517F2-20X
/35
FBI
IN
GND
FS0 FS1
OUT2
VDD
OUT1
W194-70G-X
NQR0129-002X
NQR0129-002X
NQR0129-002X
/4
/6.3
1SS355-X
NOISE
GND
CONT Vin
Vout
MM1613DN-X
/6.3
/20
/10
T
T
#
#
T
T
T
TT
T
T
T
TO SYSCON
TO MAIN IF
CN110
TO CAMERA DSP, CDS
TO CDS
TO CDS
TO CAMERA DSP, CDS
TO
CAMERA DSP
TO CCD
CN5201
#
#
NOTE : The parts with marked (
∗
) is not used.
4-25 4-26
4.13 MAIN(TG/VDR) SCHEMATIC DIAGRAM

HGFEDCBA
4
5
3
2
1
y10363001a_rev0.1
(ISP1182 WAKEUP)
(1608)
[CSP 64M 32bit SDRAM]
[FLASH_MEMORY]
∗
(ISP1181 IRQ)
(ISP1181 SUSPEND)
(MN5774 IRQ)
∗∗
(MN5774 STANDBY)
(MN5774 RST)
GIO13
[SD/MMc DAT OUT]
[SD/MMC DAT IN]
∗
[SD/MMC CS]
(MN5774 is not used, and SPI mode.)
(MN5774 is used, and SD mode.)
∗
FLSH_RST
01MAIN [DSC section]
∗
∗
∗
∗
L8006
DOLRCK2
AIDAT2
R8009
L8005
R8032
C8013
TL8008
SD0CD
R8001
TL8013
IC8004
TL8015
USBDOWN
DOMCK2
DOBCK2
R8010
R8021
TL8001
TL8011
R8033
R8018
TL8014
SDCLK
L8002
R8036
L8003
DODAT2
TXD2
R8028
RXD2
IC8001
R8014
SD0CMD
CLK27B
TL8016
SD0DAT3
Q8002 R8038
R8034
R8029
R8037
R8031
CARD_3V
R8039
R8040
R8035
SD0WP
R8030
SD0DAT0
TL8012
L8004
IC8002IC8002
R8016
IC8003
C8011
C8012
R8020
C8015
C8016
C8017
C8014
R8019
R8015
C8018
R8008
R8011
R8005
Q8001
R8017
R8006
R8007
C8021
C8019
C8020
TL8005
TL8004
TL8010
TL8003
TL8006
TL8007
CAPT_REQ
C8025
DSCO4
R8022
R8004
R8003
DSCO3
DSCO2
DSCO1
DSCO0
DSYO7
DSYO6
DSYO3
DSYO5
DSYO4
R8024
DSYO2
DSYO1
FLDDSC
HDDSC
GIO4
SD_MCLK
EM_CS1
MXDT_OUT
L8001
FLSH_OE
FLSH_WE
A8
A9
A10
A11
A12
A13
A14
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
GIO2
GIO1
VDDSC
DSYIO4
DSYIO3
C8001
DSC_WKUP
C8022
C8006
C8007
C8010
C8003
C8005
C8008
C8004
C8009
C8027
C8026
C8023 C8024
RA8004
DSYIO2
RA8003
DSYIO1
DSCIO6
DSYIO0
C8002
RA8002
R8002
R8027
DSC_RST
FLSH_RST
RA8001
DSCIO7
DSCIO3
DSCIO5
DSCIO4
DSCIO2
R8025 R8023
R8026
DSC_STS
DSC_DT_OUT
DSCIO1
DSYIO5
DSYIO6
DSC_CS
DSYIO7
DSC_CLK
DSYO0
DSC_DT_IN
DSCO5
DSCO6
DSCO7
DSCIO0
CLKDSC
R8012
REG_3V
GND
REG_1.8V
A10
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
EM_CS2
FLSH_OE
FLSH_WE
GIO3
GIO15
GIO6
1M
0Ω
0.1
0Ω
0Ω
22
10k
0Ω
10k
10
0Ω
10k
10K
10
0.1
0.1
1
0.01
0.1
0.1
560
0Ω
22
10k
1K
0.01
10
0Ω
22
22
10
10
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1 0.1
100
100
10
100
10k
10k
100
4.7k 4.7k
0Ω
NQR0006-001X
NQR0129-002X
VDD2
VSS2
27M
TEST
AVDD
AVSS
XO
XICLKA
512FS
DVSS
DVDD
16M
FSEL
33M
OE
BU2288FV-X
NQR0129-002X
NQR0129-002X
SDR_CLK
SDR_RAS
SDR_CAS
SDR_CS
SDR_CKE
SDR_WE
SDR_DQMLL
SDR_DQMLH
SDR_DQMHL
SDR_DQMHH
SDR_DQ0
SDR_DQ1
SDR_DQ3
SDR_DQ2
SDR_DQ4
SDR_DQ5
SDR_DQ7
SDR_DQ6
SDR_DQ8
SDR_DQ9
SDR_DQ10
SDR_DQ12
SDR_DQ11
SDR_DQ13
SDR_DQ14
SDR_DQ15
SDR_DQ16
SDR_DQ17
SDR_DQ18
SDR_DQ19
SDR_DQ20
SDR_DQ21
SDR_DQ22
SDR_DQ23
SDR_DQ24
SDR_DQ25
SDR_DQ26
SDR_DQ27
SDR_DQ28
SDR_DQ29
SDR_DQ30
SDR_DQ31
SDR_A0
SDR_A1
SDR_A2
SDR_A3
SDR_A4
SDR_A5
SDR_A6
SDR_A7
SDR_A8
SDR_A9
SDR_A10
SDR_A11
SDR_A12
SDR_A13
SDR_A14
EMU1
EMU0
TRST
TDO
TDI
TCK
TMS
RESERVE
NC
EM_WIDTH
EM_CS0
EM_CS1
EM_CS2
EM_CS3
EM_CS4
EM_BEL
EM_BEH
EM_WE
EM_OE
EM_RNW
ARM_A0
ARM_A1
ARM_A2
ARM_A3
ARM_A4
ARM_A5
ARM_A6
ARM_A7
ARM_A8
ARM_A9
ARM_A10
ARM_A11
ARM_A12
ARM_A13
ARM_A14
ARM_A15
ARM_A16
ARM_A17
ARM_A18
ARM_A19
ARM_A20
ARM_A21
ARM_A22
ARM_D0
ARM_D1
ARM_D2
ARM_D3
ARM_D4
ARM_D5
ARM_D6
ARM_D7
ARM_D8
ARM_D9
ARM_D10
ARM_D11
ARM_D12
ARM_D13
ARM_D14
ARM_D15
SDEN3
SCLK3
SDI3
SDO3
SCLK2
SDI2
SDO2
SCLK1
SDI1
SDO1
RESET
PWDN
TEST0
TEST1
TEST2
TEST4
TEST3
USB_DP
USB_DN
M48XI
M48XO
MXI
MXO
CLKIN2
CLKIN1
USB_VDD
PLL_VDD1
PLL_GND1
PLL_VDD2
PLL_GND2
GIO20
GIO19
GIO18
GIO17
GIO16
GIO15
GIO14
GIO13
GIO12
GIO11
GIO10
GIO9
GIO8
GIO7
GIO6
GIO5
GIO4
GIO3
GIO2
GIO1
GIO0
DSP_CLKS
DSP_BFSR
DSP_BFSX
DSP_BCLKR
DSP_BCLKX
DSP_BDR
DSP_BDX
RXD2
TXD2
RXD1
TXD1
RESERVE
VDIN
HDIN
FID
YIN7
YIN6
YIN5
YIN4
YIN3
YIN2
YIN1
YIN0
CIN7
CIN6
CIN5
CIN4
CIN3
CIN2
CIN1
CIN0
YIO7
YIO6
YIO5
YIO4
YIO3
YIO2
YIO1
YIO0
CIO7
CIO6
CIO5
CIO4
CIO3
CIO2
CIO1
CIO0
DGND9
DGND8
DGND7
DGND6
DGND5
DGND4
DGND3
DGND2
DGND1
DVDD10
DVDD9
DVDD8
DVDD7
DVDD6
DVDD5
DVDD4
DVDD3
DVDD2
DVDD1
CGND9
CGND8
CGND7
CGND6
CGND5
CGND4
CGND3
CGND2
CGND1
CVDD11
CVDD10
CVDD9
CVDD8
CVDD7
CVDD6
CVDD5
CVDD4
CVDD3
CVDD2
CVDD1
DVDD11
DVDD12
SCAN
NQR0006-001X
VDD
VDD
VDDQ
VDDQ
VDDQ
VDDQ
VSSQ
VSSQ
VSSQ
VSSQ
DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
VSSQ
DQM0
WE
CAS
RAS
CS
VSSQ
NC
NC
NC
BA0
BA1
VSS
VSS
A7
A8
A9
CKE
CLK
DQM1
DQ8
DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
K4S643233F-SE75
VDD
VDD
VDDQ
VDDQ
VDDQ
VDDQVSSQ
VSSQ
VSSQ
VSSQ
VDDQ
A10
A0
A1
A2
DQM2
VDDQ
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23 VSS
VSS
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQM3
A3
A4
A5
A6
A1
A2
A3
A4
A5
A6
A7
A17
A18
RY/BY
NC
NC
RESET
FLSH_WE
NC
A19
A8
A9
A10
A11
A12
A13
A14
A15
A0
FLSH_CE
Vss
FLSH_OE
DQ0
DQ8
DQ1
DQ9
DQ2
DQ10
DQ3
DQ11
Vcc
DQ4
DQ12
DQ5
DQ13
DQ6
DQ14
DQ7
DQ15/A-1
Vss
BYTE
A16
MBV160TE90PBA00
/6.3
2SA1774/RS/-X
/6.3
NQR0129-002X
/6.3
/6.3
/6.3
#
#
#
#
#
#
T
#
#
#
T
T
T
T
TO MAIN IF
CN110
TO MAIN IF
CN106
TO MAIN IF
CN106
TO MAIN IF
CN106, SYSCON
TO SYSCON
TO SYSCON
TO SYSCON, USB
TO MAIN IF
CN105
TO CAMERA DSP
TO AUDIO AD/DA
TO SD
TO USB
M3D4
M3D6
R8010 R8015 R8018 R8019 R8020 R8021 R8034 R8035
# EXCHANGE PARTS LIST
22Ω
0Ω
0Ω
0Ω0Ω0Ω0Ω0Ω
∗∗∗∗∗∗∗∗
IC8001
TMS320DSC24GHKL
TMS320DSC24GHK
NOTE : The parts with marked (
∗
) is not used.
4-27 4-28
4.14 MAIN(DSC) SCHEMATIC DIAGRAM

DCBA
4
5
3
2
1
y30226001a_rev0.1
TO STROBE CN6501
∗
∗
∗
∗
STO_OFF STRB_AD POP_STRB GATEPULS SENSPULS REG_4.8V
C6602
STO_C
R6617
IC6601
R6602
REG_3V M_REG4.8
GND
STRB_CHG SENS_EVR
IC6602
STO_E
C6601
C6603
Q6601
R6618
Q6615
STRB_CLS
C6605
Q6602
Q6613
Q6612
Q6611
R6601
R6604
R6603
R6605
CN109
R6620
R6621
R6619
C6614
TH6601
R6622
R6623
C6613
C6604
L6601
R6615 R6616
R6611 C6611
R6606
R6614
Q6614
R6613 R6612
C6612
L6602
REG_12V
1.0
10k
0.01
0.001
150k
8.2k
100k
68k
180k
100k
56k
27k
0.01
0Ω
1M
120p
0.047
10µ
470k
3.3M 0.001
82k
47k
47k 470k
220p
CK
Q-
GND
VCC PR CLR
TC7W74FU-X
BA10358FVM-W
DTC144EE-X
UMC4N-W
UMS1N-W
2SC4617/RS/-X
UMS1N-W
2SA1774/RS/-X
M_REG4.8 M_REG4.8 STRB_AD CHG_ON GATEPULS STO_OFF REG_4.8V GND GND GND STRB_CLS POP_STRB M_REG4.8 M_REG4.8 GND GND
CH
RN1702-X
CH
NQR0129-002x
D
Q
TO SYSCON TO SYSCON
TO SYSCON TO VIDEO I/O
TO MAIN IF CN111
TO MAIN IF CN110
TO MAIN IF CN110
TO MAIN IF CN110
0MAIN PWB (STO. SENSE)
1
NOTE : The parts with marked (
∗
) is not used.
DCBA
4
5
3
2
1
y20255001a_rev0.1
∗
∗
01
∗
∗
MAIN [USB section]
∗ ∗
X8301
GND
R8314
REG_4.8V
R8315
L8301
C8301
C8306
C8311
D8
USB_DP
IC8301
C8309
IC8302
C8308
R8312
C8310
D8301
R8311
C8305
R8305
R8310
C8307
TL8305
R8313
R8303 R8302
USB_DN
C8303
C8304
USBDOWN
USBSENS
D0 D1 D2 D3 D4 D5 D6 D7 D9 D10 D11 D12 D13 D14 D15 A10 EM_CS2 FLSH_OE FLSH_WE GIO3 GIO15 GIO6 DSC_RST
R8306 R8307 R8308 R8309
1M1M
10
0.1
0.1
0.1
0.1
1M
15k
0.1
0Ω
22 22
10k 10k 10k 10k
NAX0612-001X
NQR0129-002X
/6.3
GL WAKEUP SUSPEND EOT DREQ DACK SDWR SDRD INT READY BCNF0
DATA14
DATA13
DATA12
DATA11
DATA10
GND
VREF(5.0)
DATA8
DATA7
DATA6 DATA5 DATA3 DATA2 DATA1
GND
VCC(3.3)
AD
RD
WR
ALE
CS
RESET
CLKOUT
GND
XTAL2
XTAL1
VCC
REGGND
VREG(3.3)
D-
D+
VBUS
BCNF1
DATA15
DATA9
DATA4
A0
ISP1181ABS
VDD
OUT
VSS
NC
S-80842CNNB-W
1SS355-X
T
TO MAIN IF CN110
TO MAIN IF
TO SYSCON, DSC
TO DSC
NOTE : The parts with marked (
∗
) is not used.
4-29 4-30
4.15 MAIN(STO. SENSE) SCHEMATIC DIAGRAM [FOR STROBE MODEL] 4.16 MAIN(USB) SCHEMATIC DIAGRAM

DCBA
4
5
3
2
1
y20256001a_rev0.1
01
∗
MAIN [SD section]
R8504
SD0DAT3 SD0CMD SDCLK SD0DAT0
R8503
IC8501
SD0DAT1 SD0DAT2 SD0CD SD0WP
C8502
C8505
C8503
C8504
R8502
R8501
GND
REG_3V
L8501 C8501
GIO4
SD_MCLK
EM_CS1
FLSH_OE
FLSH_WE
A8 A9
A10 A11 A12 A13 A14
D0 D1 D2 D3 D4 D5 D6 D7 D8 D9
D10 D11 D12 D13 D14 D15
GIO1 GIO2
22
22
MN5774
0.1
0.1
0.1
0Ω
0Ω
10
VSS DMAACK MINTESTY XSTANDBY MNA7 MNA6 MNA5 MNA4 MNA3 MNA2 MNA1 XMNRE
XMNWE
XRST
MND15
MND14
MND13
MND12
MND11
MND10
MND9
MND8
MND7
MND6
MND5 MND4 MND3 MND2 MND1 MND0
XMNCS
VSS
MCLK
VDD
XMNDK
XMNIRQ
DMAREQ
SDWP
SDCD
SDDAT1
SDDAT0
VDD
SDCLK
VSS
SDCMD
SDDAT3
SDDAT2
VDD
NQR0129-002X /6.3
T
TO MAIN IF CN110
TO DSC
TO MAIN IF CN106
TO MAIN IF CN106, SYSCON TO MAIN IF CN106
DCBA
4
5
3
2
1
y40108001a_rev0
y40107001a_rev0
QNS0147-001
GND
GND
GND
GND
EDIT
JACK PWB02
CN201
S201
TL203
TL202
R210
J202
R209
R207
R205
R204
R206
D203 D202
D201
J201
R202
R203
R201
0Ω
0Ω
0Ω
220
0Ω
330
NQR0251-004X
MA8068-X
0Ω
QGF0507F4-12X
NSW0122-001X
PEMC1203 MA8068-X EMZ6.8N-X
EJECT SW
QND0004-001
S IN/OUT
TO MAIN IF
CN112
NQR0251-004X
∗∗
CN902
C901
S901
S902
CN903
TP902
BACKLIGHT SW
TP901
CN901
C902
STO_E
STO_C
NSW0145-001X
NSW0145-001X
GND
GND
GND
GND
FOCUS_PB
FOCUS_PA
# EXCHANGE PARTS LIST
S901
D6 D4
WARE NO WARE
#
SW PWB09
TO
FOCUS UNIT
TO FRONT
CN502
TO
STROBE SENS
FOCUS SW
NOTE : The parts with marked (
∗
) is not used.
4.17 MAIN(SD) SCHEMATIC DIAGRAM 4.18 JACK AND SW SCHEMATIC DIAGRAMS
4-31 4-32

HGFEDCBA
4
5
3
2
1
y10364001a_rev0
∗
(+)
Nch
∗
Pch
(-)
3V
1.8V
4.8V
VFREG4.8
∗
15V
DRUM
CAPS
VFREG4.8
AU_SIG/R
AU_SIG/L
AV_GND
AV JACK
∗
∗∗
0
BATTERY
TERMINAL
DC_JACK
(T)
REG PWB
∗
CJIG_RST
AREG_SO
GND
GND
∗
∗
AREG_CLK
GND
GND
∗
CAP_PWR
GND
∗
∗
for
D_GAIN
GND
UNREG
UNREG
UNREG
REG_1.8V
REG_1.8V
REG_1.8V
REG_1.8V
REG_3V
REG_3V
REG_3V
Verr REG_3V
REG_3V
REG_3V
REG_2.5V
REG_2.5V
DRUM_PWR
GND
GND
REG_2.5V
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
REG_4.8V
REG_4.8V
REG_4.8V
REG_4.8V
REG_12V
REG_12V
REG-CCD
for
REG-CCD
REG_15V
REG_15V
for
M_REG4.8
M_REG4.8
2.5V
AL_3V
M_REG4.8
I_detect
Ierr
for
for
CHRG_EVR
VF_CTL
CAP_PWR
CAP_PWR
DRUM_PWR
DRUM_PWR
CAP_ERR
DRUM_ERR
AV_GND
V_OUT
P_DET
REG_CS
I_MTR
ADP_H
T_BATT
LIT_3V
V_BATT
AL_3V
AL_3V
AL_3V
D6201
IC6101
TP602
D6203
R6221
Q6204
R6242
C6702
R6231
L6701
C6102
R6228
Q6202
R6232
C6101
R6233
R6205
C6224
Q6205
C6130
Q6201
C6703
C6221
C6131
IC6201
Q6208
C6701
R6235
R6214
C6132
C6128
C6129
C6125
R6110
R6234
L6101
L6102
C6105
C6107
R6223
R6240
R6241
C6226
C6210
C6216
C6202
C6207
C6211
C6217
C6203
C6201
F6101
C6110
R6203
Q6701
Q6002
C6106
C6223
R6204
C6208
Q6203
R6201
Q6207
R6202
C6126
C6209
C6220
Q6209
R6704
R6705
IC6003
C6215
C6206
R6215
R6226
R6211
R6213
C6122
R6225
R6210
C6009
R6227
R6112
R6209
R6113
R6703
L6206
D6101
TP601
R6107
L6205
Q6206
L6203
L6201
C6005
R6212
R6218
C6225
BT6001
R6224
L6202
L6001
C6006
R6006
R6111
R6702
C6213
TP603
R6229
R301
J6002
R6216
J301
C6212
R6219
J301
R6220
L303
C6117
R6007
D301
C6121
C6119
C6124
C6123
C6120
J6002
C6116
R302
C6118
R6222
J301J301
D6701
R6217
C6214
C6113
C6111
J301
J6002J6002
R6701
J6002
C6219
CN601
C6112
R6105
D6001
J301
C6115
IC6002
CN601
C6003
CN601
TO MAIN IF
CN110
R6008
C6002
R303
R6020
C301
C6004
C302
L301
L302
C6133
C303C304
R6103
R6102
R6101
R6104
R6206
R6010
R6012
C6007
C6109
C6218
C6104
R6011
L6207
Q6003
F6201
F6001
F6701
TL6020
R6014
C6008
C6108
R6207
C6114
C6127
R6109
C6134
R6005
R6230
D6002
R6208 C6205
C6204
IC6001
R6106
R6108
L6204
D6702
R6004
R6001
Q6001
C6001
R6002
R6003
100k
47k
47k
3.3k
0.1
47k
1
0.01
0.01
62k
0.01
0.047
0.01
100p
15k
8.2k
4.7µ
4.7µ
1
1
10k
1
10
1
10
10
0.001
0.22
0.001
1
0.1
470k
10
1
10k
0.0047
33
22k
1
1
1
82k
33k
1
1
4.7k
5.6k
15k
18k
47k
12k
47k
0Ω
33
1k
47µ
4.7k
47µ
39µ
39µ
22
33
33
1
33
39µ
470
0Ω
1
33
10k
1
24k
3k
0.033
1k
0.01
0.0027
0.1 0.1
560p
0.1
100
560p
12k
1.5k
0.068
1
1
1
1
5.6k
0.1
10
0.1
100
0Ω
0.01
1
0.01
0.001
10k
750
10k
33k
1k
0.1
1
0.1
220µ
1
18k
1
0.1
82k
1
100k
2.7k
12k 1
560p
22k
82k
22µ
18k
100k
0.01
100k
220k
RB480Y-W
IN7+
IN7-
FB7
IN8+
IN8-
FB8
IN1-
FB1
IN2-
FB2
IN3-
FB3
IN6-
FB6
IN4+
IN4-
FB4
IN5+
IN5-
FB5
CT
GND
RT
CP
VDRV
CSS4
CSS5
CSS1
CSS2
CSS3
SHUTDOWN
IN11-
FB10
IN10-
OUT10
PGND1
OUT7P
OUT7N
OUT1
OUT2
OUT3
OUT6
OUT4
OUT5
PGND2
VCC2
OUT11
FB11
GND
FB9
IN9+
IN9-
IBW
VREG1
CREF
VREF1
VCC1
VREF2
DGND
RST
SDATA
SCLK
CS
VREG2
FA3698F
RB480Y-W
NC
CA
QS6U24-W
2SA1577/RS/-X
CPH3101-X
NC
CA
QS6U24-W
REG1
VCC
REG2
VEE CTL2
STB
GND
CTL1
BD3987FV
NC
CA
QS6U24-W
2.0A
NMFZ007-2R0X-K
S1
G1
D2 S2
G2
D1
MCH6613-W
/20
NC
CA
QS6U24-W
NC
CA
QS6U24-W
CPH3314-X
Vo
Vin
Noise
GND
CE
MM1613BN-X
DTC124TE-X
/6.3
QAB0040-001
QAB0041-001
NQA0027-001
QNS0078-001QNS0078-001
NQR0251-004X
UDZS6.8B-X
NQA0027-001
QNS0078-001QNS0078-001QNS0078-001
NQA0027-001NQA0027-001
0.5W
NQA0027-001
RB706D-40-X
QNS0078-001
GND VDD
NC VOUT
S-817A33ANB-W
/6.3
NQR0251-004X
NQR0251-004X
Ca
NMFZ007-1R25X-K
NMFZ007-R50X-K
RB715F-X
OUTVDD
NC VSS
S-80842CNNB-W
DTC144EE-X
A
S
GD
#
#
#
A
S
GD
#
A
S
GD
#
#
#
S
G
D
#
T
A
S
GD
A
S
GD
S
G
D
#
#
T
#
#
##
T
#
#
#
E
B
A
C#
#
#
#
#
3
Change parts list
M3D6
M3D4
# R6008 R6010 R6012 R6014 C6008 C6009
FML9-W R1224N102G-X
L6001Q6003 IC6003
XXXXXXX X
680 51k 24k 0 0.01 150p
MM1613BN-X
47
Ω
µ
C6121 C6221 R6240 R6241 R6242
NMFZ007-1R25X-K
F6701
NRZ0058-R20X
R6701 R6702 R6703 C6701 C6702 L6701
CPH3314-X EP10HY03-X
Q6701 D6701,6702
0.01
0.022
0.01
1000p
75k 15k X
47k 10k 68k X X XXXXX X X 100k 12k 1 1 10
µ
NOTE : The parts with marked (
∗
) is not used.
4-33 4-34
4.19 REG SCHEMATIC DIAGRAM
