SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.YF036
2004/2
COMPACT VHS CAMCORDER
YF03620042
GR-SXM277UA,GR-SXM277UM,
GR-SXM278UM,GR-SXM279UB,GR-SXM279UM
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).
Regarding service information other than these sections, refer to the service manual No. YF016 (GR-SXM260US).
Also, be sure to note important safety precautions provided in the service manual.
GR-SXM277UA, GR-SXM277UM, GR-SXM278UM, GR-SXM279UB, GR-SXM279UM [M4C623]

(No.YF036)
AV & MULTIMEDIA COMPANY CAMCORDER CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
SPECIFICATION (The specifications shown pertain specifically to the model GR-SXM277UM/GR-SXM278UM/GR-SXM279UM)
DIFFERENT TABLE OF FEATURE
The following table indicate main different points between models GR-SXM260US, GR-SXM277UA, GR-SXM277UM, GR-SXM278UM,
GR-SXM279UB and GR-SXM279UM.
MODEL GR-SXM260US GR-SXM277UA GR-SXM277UM GR-SXM278UM GR-SXM279UB GR-SXM279UM
BODY COLOR SILVER SILVER SILVER BLUE SILVER SILVER
AC ADAPTER
AP-V14U or AP-V15U AP-V14UA AP-V14U or AP-V15U AP-V14U or AP-V15U AP-V14E AP-V14U or AP-V15U
AC CORD NO IRAM PLUG NO NO SASO PLUG NO

(No.YF036)3-1
PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
1. EXPLODED VIEW
1.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
2
20
1
25
24
FINAL ASSEMBLY
<M2>
LABEL
(SERIAL)
3
MODEL MARK
GR-SXM277UA A
B
C
D
E
26
42
21 41
31
30
29
4
GR-SXM277UM
GR-SXM278UM
GR-SXM279UB
GR-SXM279UM
5
98
99

3-2(No.YF036)
1.2 FINAL ASSEMBLY <M2>
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine
JVC parts be used.
E.VF ASSEMBLY
<M4>
W2
k
b
143
144
MAIN BOARD
ASSEMBLY
<01>
150
F8
F10
F7
W4
W1
F6
F3
W2
F1
F9
F2
F4
F5
W3
W5
151
W6
104
125
124
125
125
125
F1
F9
F10
252
253
254
255
256
251B
OP BLOCK
SECTION
251E
CCD BOARD
ASSEMBLY
<02>
251C
251
251C
251A
n
135
135B
135A
135D
135D
135C
135D
136
g
W4
m
f
139
a
W3
138
137
106
105
104A
106
106
104B
109
109
104B
104B
109
109
s
g
h
j
123 123 123
126
122
122
122
121C
b
123
123
121A
121E
121D
d
c
121F
121B
127 121
W1
a
123
251C
251D
251C
123
123
251C
251D 251C
256
251C
128
257

(No.YF036)3-3
102
101G
101C
101G
101B
101
101A
101E
101E
101D
e
F2
k
157
MONITOR
ASSEMBLY
<M5>
107
j
F3
108
107
q
158
W6
148
146
147
152
145G
145B
145A
145E
m
145C
d
h
ps
t
c
145D 145D
RATING
LABEL
145F
145F
152
160
145
160
159
159
145D
145D
109
r
n
110
MECHANISM
ASSEMBLY
<M3>
156
r
153
p
e
F6
W5
F8
F7 F4
F5
109
f
q
t
103A
103

3-4(No.YF036)
1.3 MECHANISM ASSEMBLY <M3>
Classification Part No. Symbol in drawing
Grease KYODO-SH-JP AA
Oil YTU94027 BB
The section marked in AA and BB indicate
lubrication and greasing areas
452
451
b
405
404
403
461
460
466
AA
471
472
473
471
402
gBB
AA
431
415
432
x
y
h
422
423
416
AA n
m
449
456
450
448
450 a
462
401
464
465
c
455
435
436
465
463
438
d
437
AA 413
411
m
427
425
454
429
428
429A
419
430
412
420
418
AA
417
421 424
n
426
441
434
433
cd
a
414
439A
g
j
440
AA
410
j409
h
439
457
453
400
410
408
x469A
469B
AA
469
444
443
445
470
442
470
445
442
446
445
458
459
459
447
y
467
406B
406
406A
407
AA
468
410
b
414
457
457
423 423 423
467 467 467
BB BB
AA
425
425
425 425
425
425
AA
469B
NOTE:
Parts that do not meet specifications may cause trouble in regard to safety and
performance.We recommend that genuine JVC parts be used.
BEWARE OF BOGUS PARTS
YMA0046A-E

(No.YF036)3-5
482
482
482
482
481
485
488
487
485
484
400
489A
489B 490
490
489
YMA0046A-E

3-6(No.YF036)
1.4 E.VF ASSEMBLY <M4>
E.VF BOARD
ASSEMBLY
<60>
355
356
354
SERIAL NO.
LABEL
a
a
352
351
353
350
357
357A

(No.YF036)3-7
1.5 MONITOR ASSEMBLY <M5>
MONITOR BOARD ASSEMBLY
<07>
516
501
500
506
502C
502B
502A
502
515515
514
503
505
504
509
511
511
512
510
508
507
513
c
b
fa
a
d
e
e
c
d
b
501A
517
f

3-8(No.YF036)
2. PARTS LIST
PACKING AND ACCESSORY ASSY <M1>
FINAL ASSEMBLY <M2>
MECHANISM ASSEMBLY <M3>
 Symbol No. Part No. Part Name Description Local
1 LY33811-009A PACKING CASE FOR JAPAN B
1 LY33811-019A PACKING CASE FOR JAPAN C
1 LY33811-021A PACKING CASE FOR JAPAN E
1 ------------ PACKING CASE A,D
2 LY33075-002A CUSHION
3 LY30023-002A POLY BAG
4 QPA02003506 POLY BAG DOCUMENT 20cm x 35cm
 5 LYT1230-001A INST BOOK(SP) (SPANISH) B,C,E
 5 LYT1231-001A INST BOOK(SP) (SPANISH) A
 5 LYT1232-001A INST BOOK(PT) (PORTUGUESE) D
20 QPA02003506 POLY BAG ACCESSORY 20cm x 35cm
 21 LY21103-001A AC ADAPTER AP-V14U B,C,E
 21 LY21104-001B AC ADAPTER AP-V14E D
 21 LY21104-005B AC ADAPTER AP-V14UA A
 24 LY10481-001B BATTERY PACK ASSY BN-V10U
25 LY20186-001B SHOULDER STRAP
26 LY43388-001A LENS CAP ASSY
29 ------------ BATTERY AA(R6) A,B,C,E
30 YQ31963B-3 CASSETTE ADAPTER ASSY A,B,C,E
31 YQ43446 POLY BAG A,B,C,E
41 LY34145-001B COVER1(DC PLUG)
42 LY34146-001B COVER2(DC PLUG)
98 QAM0511-001 A/V CABLE D
 99 QMPS270-190-JR POWER CORD IRAM PLUG 1.9m BLACK A
 99 QMPS300-190-JR POWER CORD SASO PLUG 1.9m BLACK D
 Symbol No. Part No. Part Name Description Local
101 LY20927-006D CASSETTE COVER(M)ASSY C
101 LY20927-012A CASSETTE COVER(M)ASSY A,B,D,E
101A LY32952-001A PUSH PLATE(M)
101B LY44124-001B LABEL (CAUTION)
101C LY42883-001B MARK
101D LY43336-001A SPRING
101E LY30031-019A SPECIAL SCREW (x2)
101G LY40076-001A SPACER (x2)
102 QYSLSF2060DA TAP SCREW C.COV-INSD
103 LY33712-001B COVER(UPPER/M)ASSY D,E
103 LY33712-003B COVER(UPPER/M)ASSY A,B
103 LY33712-004A COVER(UPPER/M)ASSY C
103A LY21100-001B ORNAMENT D,E
103A LY21100-002B ORNAMENT A,B,C
104 LY20950-002B UPPER CASE(M)ASSY
104A LY20918-001B BRACKET(MON.)
104B QYSLSP2020DA SCREW (x3)
105 LY43942-001B SHEET(FPC)
106 QYSLSF2060ZA TAP SCREW COV UPPER(x3)
107 LY30031-020A SPECIAL SCREW HING-BKT(x2)
108 QYSLSP2030DA SCREW M.FPC-BKT
109 QYSLSF2060DA TAP SCREW UPPER-FRM(x6)
110 QYSLSP2030DA SCREW UPPER-FRM
 121 LY20925-014D LOWER CASE ASSY
121A LY40081-001A CAP
121B LY20682-001B GRIP BELT
121C LY30031-018A SPECIAL SCREW LOW-BELT
121D QAS0158-001 SPEAKER
121E LY42764-001B HOLDER(SPEAKER)
121F QYSLSF2050ZA TAP SCREW LOW-HLDR(S)
122 QYSLSF2050ZA TAP SCREW LOWER-VF(x3)
123 QYSLSF2060DA TAP SCREW
LOWER-FRM(x8)
 124 LY10393-002B ZOOM UNIT
125 QYSLSF2050ZA TAP SCREW ZOOM-LOWER(x4)
126 LY31945-003A COVER(JACK)
 127 LY32955-003A COVER(JIG)
128 LY44592-001A SPACER(FPC)
 135 LY21099-009B FRONT COVER ASSY A,B,D,E
 135 LY21099-011A FRONT COVER ASSY C
135A LY32951-001F HOOD
135B LY32950-001A COVER(HOOD)
135C LY43983-004A STICKER(A)
135D QYSLSF1770DA TAP SCREW (x3)
136 QYSLSF2060DA TAP SCREW FRONT-FRM
137 LY33067-001A DC LIGHT
138 LY32981-006A MIC
139 QYSLSF2060DA TAP SCREW FRONT-MIC
143 WJT0086-001A E-CARD WIRE
144 QAL0450-001 FPC FOR CCD
 145 LY20949-002C FRAME ASSY
145A LY32972-001A KNOB(BATT.)
145B LY32973-001B HOLDER(KNOB)
145C YQ31843-1-1 BASE
145D QYSLSF2060DA TAP SCREW (x4)
145E LY30002-053A COMPRESION SPRING
145F LY41082-001A CUSHION(OP) (x2)
145G LY30030-0Z6A SPACER(A)
146 LY32966-001C SHIELD CASE(MAIN)
147 QYSPSPU1720ZA SCREW SHLD-MECHA
148 QYSPSTU1725MA TAP SCREW SHLD-MECHA
150 QYSLSF2060DA TAP SCREW M.PWB-FRM
151 QYSLSF2060DA TAP SCREW JACK-FRM
152 LY30032-004A SPECIAL SCREW FRM-MECHA(x2)
153 QYSLSF1750DA TAP SCREW MECHA-FRM
156 LY32953-001A CASSETTE COVER INSIDE
157 LY10392-012B TOP OPE UNIT A,B,D,E
157 LY10392-013A TOP OPE UNIT C
158 LY33749-001A REAR BOARD ASSY
159 QYSLSF2060DA TAP SCREW FRM-TERM(x2)
160 LY30031-017A SPECIAL SCREW OP-FRM(x2)
251 LY33085-001G OP BLOCK ASSY
251A LY30724-001B FOCUS MOTOR
251B LY30723-001B ZOOM MOTOR
251C PTY33085-001 TAP SCREW (x7)
251D PTY31727-116 TAP SCREW (x2)
251E PTY33085-006 AUTO IRIS UNIT
252 LY44004-001A OP LPF
253 LY44005-001A SHEET
254 LY32975-001A SPACER
255 LYH30522-002A CCD BASE ASSY
256 LY30031-060A SPECIAL SCREW (x2)
257 LY44532-001A FPC PROTECTOR
 Symbol No. Part No. Part Name Description Local
400 YMA0046A-E MECHA(B)ASSY OL-Y07399
401 LY20612-003A MAIN DECK ASSY
402 LY31817-001A CASSETTE GUIDE (L)
403 LY31815-001A SW LEVER (L)
404 LY42581-001A TORSION SPRING
405 LY42722-004A TAPPING SCREW
406 YQ44339A-7 CASSETTE GUIDE(R)ASSY
406A YQ32162-1-3 SW.LEVER(R)
406B YQ44340-1-4 TORSION SPRING
407 LY42819-002A TAPPING SCREW
408 LY31826-002A MOTOR BRACKET ASSY
409 LY20951-001A WORM BRACKET
410 LY42722-004A TAPPING SCREW (x3)
411 LY31925-001A WHEEL GEAR
412 LY42730-001A MIDDLE GEAR
413 LY42521-002A CANCEL LEVER ASSY
414 LY42754-003A SLIT WASHER (x2)
415 YQ20827-2-1 CONTROL CAM
416 PQM30017-25 SLIT WASHER
417 LY42733-001A LOADING GEAR(T)ASSY
418 LY42754-003A SLIT WASHER
419 LY42732-001A LOADING GEAR(S)ASSY
420 LY42754-003A SLIT WASHER
421 LY42403-001A COVER PLATE
422 LY42452-002A LOADING RING ASSY
423 LY42728-002A TAPPING SCREW (x4)
424 LY10239-001A GUIDE RAIL
425 LY42728-002A TAPPING SCREW (x7)
426 LY30161-001B POLE BASE(S)ASSY
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

(No.YF036)3-9
E.VF ASSEMBLY <M4>
MONITOR ASSEMBLY <M5>
MAIN BOARD ASSEMBLY <01>
427 LY30162-002A POLE BASE(T)ASSY
428 LY42523-002A DRIVE LEVER ASSY
429 LY44000-002A SLANT ARM ASSY
429A LY43992-001A TORSION SPRING(S)
430 LY42754-003A SLIT WASHER
431 LY42739-003A ROLLER BASE ASSY
432 LY42722-004A TAPPING SCREW
433 LY42494-002B LINK ARM ASSY
434 PQM30017-25 SLIT WASHER
435 LY43950-001B PINCH ROLLER ARM ASSY
436 PQM30017-25 SLIT WASHER
437 LY42541-001C TAKE UP GUIDE ARM ASSY
438 LY42754-003A SLIT WASHER
439 LY42571-002A TENSION ARM ASSY
439A LY42669-001A TENSION SPRING
440 LY42754-003A SLIT WASHER
441 YQ20797-1-5 MOTOR BASE
442 LY42722-004A TAPPING SCREW (x2)
443 YQ44460-2 TAPPING SCREW
444 QAR0212-003 CAPSTAN MOTOR SAMSUNG
445 YQ44304-2 TAPPING SCREW (x3)
446 LY42731-001A SLANT POLE BASE ASSY
447 YQ44304-2 TAPPING SCREW
448 YQ43710-2 TIMING BELT
449 LY42678-004A CENTER PULLEY UNIT
450 LY42722-005A TAPPING SCREW (x2)
451 LY42670-001A SUPPLY CLUTCH ASSY
452 LY42754-003A SLIT WASHER
453 YQ31861-1-7 REEL DISC
454 LY42755-001A WASHER
455 LY31924-001A TAKE UP GEAR
456 LY42738-001A BRAKE SUB GEAR
457 LY42754-003A SLIT WASHER (x3)
458 LY33747-001A A/C HEAD UNIT
459 QYSPSGU1750ZA TAP SCREW (x2)
460 LY42517-002A EJECT LEVER ASSY
461 LY42754-003A SLIT WASHER
462 YQ31833-1-1 LED GUIDE
463 LY42722-004A TAPPING SCREW
464 LY42729-001A DRUM SPACER
465 LY42722-004A TAPPING SCREW (x2)
466 QSW1006-002 ROTARY ENCODER
467 LY42722-005A TAPPING SCREW (x4)
468 LY31814-002A LINK LEVER
469 YDV2098D-CX DRUM FINAL ASSY
469A YDM1003-1-5 CATCHER
469B QYSPSPU1735MA SCREW (x2)
470 LY42722-004A TAPPING SCREW (x2)
471 QYSPSPU1740ZA SCREW (x2)
472 LY43542-001A BRUSH
473 LY42722-006A TAPPING SCREW
481 LY31808-003A CASSETTE HOUSING FINAL ASSY
482 LY42722-006A TAP SCREW (x4)
484 LY32326-002A BRACKET(MECHA)
485 LY42722-006A TAP SCREW (x2)
487 LY31807-002A SIDE BRACKET L
488 LY42722-006A TAPPING SCREW
489 LY44193-002A FRONT FRAME ASSY
489A LY33428-001B TAPE GUIDE
489B LY44176-002A TENSION SPRING
490 QYSPSPU1725ZA SCREW (x2)
 Symbol No. Part No. Part Name Description Local
 350 LY20701-018A B/W VF ASSY
351 PEDP0193 CRT
 352 QQD0026-001 DEFLECTION YOKE
 353 LY10165-001B CASE(L)
354 QYSPSGU1760M TAP SCREW (x2)
 355 LY41280-001A SHEET(SHIELD)
 356 PTY20701-011 BOTTOM CASE ASSY
357 PTY20374-201 LENS ASSY
357A LY20411-001A EYE CAP
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 500 LY21117-006A MONITOR ASSY A,B,D,E
 500 LY21117-009A MONITOR ASSY C
 501 LY33713-006D MONITOR COVER ASSY A,B,D,E
 501 LY33713-008B MONITOR COVER ASSY C
501A LY44436-006A STICKER(B)
502 LY33714-001C MONITOR CASE ASSY
502A LY32967-001B KNOB(LOCK)
502B LY32988-001A LOCK SPRING
502C QYSLSF2050ZA TAP SCREW
503 LY33005-006D MONITOR HINGE ASSY C
503 LY33005-008A MONITOR HINGE ASSY A,B,D,E
504 NSW0200-001X LEVER SWITCH
505 LY44159-001A WASHER
506 LY21101-001B SHIELD CASE(2.5)
507 LY44411-001C SPACER(LCD)
508 QLD0305-001 LCD MODULE
509 LY44481-001A LIGHT SCREEN
510 QLL0142-001 LAMP
511 LY43936-001A HOLDER(LAMP) (x2)
512 LY43396-001A SHEET(REFLECT)
513 LY44412-001B DIFFUSION SHEET(2.5)
514 LY30033-002A SPECIAL SCREW(W) MON.PWB
515 QYSLSF2060DA TAP SCREW MON.CV-CAS(x2)
516 QYSLSP2040DA SCREW MON.CV-CAS
517 LY44129-001A SHEET(M.SENSOR)
 Symbol No. Part No. Part Name Description Local
PW1 YB10450UD1-02 MAIN BOARD ASSY D
PW1 YB10450UB1-02 MAIN BOARD ASSY A,B,C,E
IC101 UPD703039-058 IC(MICRO C ROM) MASK
IC101 or UPD70F3040-058 IC(MICRO C ROM) FLASH
IC102 M95160-WMN6W-X IC STMAICRO
IC102 or 25LC160-I/SN-X IC MAICROCHIP
IC102 or CAT25C16SI-X IC CATALYST
IC102 or AT25160N-10SC-X IC ATMEL
IC103 RS5C314-X IC
IC104 BD4827FVE-W IC RHOM
 IC1601 BD6637KV IC MDA_IC
IC1801 RPM7138 IR DETECT UNIT RPM7138 D
IC1801 or RPM7138-S IR DETECT UNIT D
IC2001 MC74AC04DT-X IC
IC2001 or TC74AC04FT-X IC(DIGITAL)
IC2401 NJM2149V-X IC
IC3501 HA118224F IC
IC4001 JCY0140-3 IC CAM&VTRDSP
IC4003 UPD6467GR-556-X IC(MICRO C ROM)
IC4201 BA10324AF-XE IC
IC4201 or LM324AD-X IC
IC4201 or LM324ADR-X IC
IC4202 BA10324AF-XE IC
IC4202 or LM324AD-X IC
IC4202 or LM324ADR-X IC
IC4501 UPD16835AGS-X IC
IC4702 BA7665FS-X IC S ONLY
IC4702 or BA7665AFS-X IC S ONLY
IC5201 HD49335F IC
IC5202 MN31121SA-X IC
IC6001 FA3698F IC
Q101 2SA1774/RS/-X TRANSISTOR UNREG
Q101 or 2SA1836/6-7/-X TRANSISTOR UNREG
Q101 or BC857BT-X TRANSISTOR UNREG
Q102 DTC144EE-X DIGI TRANSISTOR P_ON
Q102 or UN9213J-X DIGI TRANSISTOR P_ON
Q102 or RN1104-X DIGI TRANSISTOR P_ON
Q102 or BCR148T-X DIGI TRANSISTOR P_ON
Q103 2SC4617/QR/-X TRANSISTOR CTL_ERASE
Q103 or 2SC4783/5-6/-X TRANSISTOR CTL_ERASE
Q105 2SC4617/RS/-X TRANSISTOR TAPE_LED
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

3-10(No.YF036)
Q105 or BC847BT-X TRANSISTOR TAPE_LED
Q114 2SC4617/QR/-X TRANSISTOR LED_RV
Q114 or 2SC4783/5-6/-X TRANSISTOR LED_RV
Q115 2SC4617/QR/-X TRANSISTOR LED_GV
Q115 or 2SC4783/5-6/-X TRANSISTOR LED_GV
Q2001 DTA114TE-X DIGI TRANSISTOR
Q2007 PUMX1-W PAIR TRANSISTOR
Q2007 or UMX1N-W PAIR TRANSISTOR
Q2007 or HN1C01FU/G/-X PAIR TRANSISTOR
Q2007 or BC847S-X PAIR TRANSISTOR
Q2008 PUMT1-W PAIR TRANSISTOR
Q2008 or HN1A01FU/G/-X PAIR TRANSISTOR
Q2021 DTC144EE-X DIGI TRANSISTOR
Q2021 or UN9213J-X DIGI TRANSISTOR
Q2021 or RN1104-X DIGI TRANSISTOR
Q2021 or BCR148T-X DIGI TRANSISTOR
Q2022 DTC144EE-X DIGI TRANSISTOR
Q2022 or UN9213J-X DIGI TRANSISTOR
Q2022 or RN1104-X DIGI TRANSISTOR
Q2022 or BCR148T-X DIGI TRANSISTOR
Q2023 2SC4617/QR/-X TRANSISTOR
Q2023 or 2SC4783/5-6/-X TRANSISTOR
Q2023 or BC847BT-X TRANSISTOR
Q2071 2SC4617/QR/-X TRANSISTOR
Q2071 or 2SC4783/5-6/-X TRANSISTOR
Q2071 or BC847BT-X TRANSISTOR
Q2401 DTC144EE-X DIGI TRANSISTOR
Q2401 or UN9213J-X DIGI TRANSISTOR
Q2401 or RN1104-X DIGI TRANSISTOR
Q2401 or BCR148T-X DIGI TRANSISTOR
Q3501 HN1C01FU/G/-X PAIR TRANSISTOR
Q3502 HN1C01FU/G/-X PAIR TRANSISTOR
Q3505 DTC144EE-X DIGI TRANSISTOR S ONLY
Q3505 or UN9213J-X DIGI TRANSISTOR S ONLY
Q3505 or RN1104-X DIGI TRANSISTOR S ONLY
Q3505 or BCR148T-X DIGI TRANSISTOR S ONLY
Q3901 HN1A01FU/G/-X PAIR TRANSISTOR
Q4001 DTC144EE-X DIGI TRANSISTOR S ONLY
Q4001 or UN9213J-X DIGI TRANSISTOR S ONLY
Q4001 or RN1104-X DIGI TRANSISTOR S ONLY
Q4001 or BCR148T-X DIGI TRANSISTOR S ONLY
Q4201 2SC4617/QR/-X TRANSISTOR
Q4201 or 2SC4783/5-6/-X TRANSISTOR
Q4201 or BC847BT-X TRANSISTOR
Q4202 2SC4617/QR/-X TRANSISTOR
Q4202 or 2SC4783/5-6/-X TRANSISTOR
Q4202 or BC847BT-X TRANSISTOR
Q4251 RPM-22PB PHOTO TRANSISTOR
Q4501 DTC114EE-X DIGI TRANSISTOR
Q4501 or UN9211J-X DIGI TRANSISTOR
Q4501 or RN1102-X DIGI TRANSISTOR
Q4501 or BCR133T-X DIGI TRANSISTOR
Q4701 2SA1774/QR/-X TRANSISTOR
Q4701 or 2SA1836/5-6/-X TRANSISTOR
Q4701 or BC857BT-X TRANSISTOR
Q4702 2SA1774/QR/-X TRANSISTOR
Q4702 or 2SA1836/5-6/-X TRANSISTOR
Q4702 or BC857BT-X TRANSISTOR
Q6101 QS6U24-W MOS FET
Q6201 QS6U24-W MOS FET
Q6301 FDC6506P-X MOS FET
Q6302 2SK3577-X MOS FET LIGHT
Q6401 QS6U24-W MOS FET
Q6501 QS6U24-W MOS FET
Q6604 DTC144EE-X DIGI TRANSISTOR
Q6604 or UN9213J-X DIGI TRANSISTOR
Q6604 or RN1104-X DIGI TRANSISTOR
Q6604 or BCR148T-X DIGI TRANSISTOR
Q6701 RSQ035P03-W MOS FET
Q6702 2SC4097/QR/-X TRANSISTOR
Q6702 or 2SC4173/3-4/-X TRANSISTOR
Q6702 or BC817-25W-X TRANSISTOR
Q6802 2SB1121/TU/-X TRANSISTOR
Q6803 DTA144EUA-X DIGI TRANSISTOR
Q7001 PUMX1-W PAIR TRANSISTOR
Q7001 or UMX1N-W PAIR TRANSISTOR
Q7001 or HN1C01FU/G/-X PAIR TRANSISTOR
Q7002 PUMX1-W PAIR TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q7002 or UMX1N-W PAIR TRANSISTOR
Q7002 or HN1C01FU/G/-X PAIR TRANSISTOR
Q7003 PUMX1-W PAIR TRANSISTOR
Q7003 or UMX1N-W PAIR TRANSISTOR
Q7003 or HN1C01FU/G/-X PAIR TRANSISTOR
Q7301 2SA1774/QR/-X TRANSISTOR BWJ/BWP
Q7301 or 2SA1836/5-6/-X TRANSISTOR BWJ/BWP
Q7301 or BC857BT-X TRANSISTOR BWJ/BWP
Q7302 CPH3101-X TRANSISTOR BWJ REG4.8
Q7303 2SC4617/QR/-X TRANSISTOR BWJ REG4.8
Q7303 or 2SC4783/5-6/-X TRANSISTOR BWJ REG4.8
Q7303 or BC847BT-X TRANSISTOR BWJ REG4.8
 D101 SB007W03Q-X SB DIODE LITHIUM
 D101 or RB715F-X SB DIODE LITHIUM
D102 UDZS7.5B-X Z DIODE UNREG_BATT
D103 1SS355-X SI DIODE TU
D104 1SS355-X SI DIODE SUP
D4001 DAN222-X SI DIODE S ONLY
D5201 1SS355-X SI DIODE
D6301 RB160M-30-X SB DIODE
D6601 RB480Y-W SB DIODE
D6602 RB480Y-W SB DIODE
D6604 UDZS7.5B-X Z DIODE
D6701 CRS09-X SB DIODE
D6702 CRS09-X SB DIODE
C103 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C104 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C105 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C107 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C108 NBE21AM-225X TA E CAPACITOR 2.2uF 10V M
C109 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C110 NDC31HJ-101X C CAPACITOR 100pF 50V J
C112 NEAF0JM-226X E CAPACITOR 22uF 6.3V M
C113 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C114 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C115 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C118 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C119 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C120 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C121 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C122 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C123 NDC31HJ-100X C CAPACITOR 10pF 50V J
C124 NDC31HJ-120X C CAPACITOR 12pF 50V J
C125 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C126 NDC31HJ-100X C CAPACITOR 10pF 50V J
C127 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C128 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C129 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C131 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C132 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C133 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C134 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C138 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C140 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C142 NDC31HJ-3R0X C CAPACITOR 3pF 50V J
C1201 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1202 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1205 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C1206 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1601 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1602 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1603 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1604 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1605 NCB31HK-681X C CAPACITOR 680pF 50V K
C1606 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1607 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1608 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1609 NCB21CK-334X C CAPACITOR 0.33uF 16V K
C1610 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1611 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1612 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1613 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1614 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1615 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1616 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1617 NCB21EK-224X C CAPACITOR 0.22uF 25V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

(No.YF036)3-11
C1618 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C1619 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1620 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1621 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C1629 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1630 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C2001 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C2002 NFV91HJ-183X MPPS CAPACITOR 0.018uF 50V J
C2003 NDC31HJ-331X C CAPACITOR 330pF 50V J
C2004 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C2005 NCB21CK-105X C CAPACITOR 1uF 16V K
C2021 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2022 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C2023 NBP21CM-105X TA E CAPACITOR 1uF 16V M
C2024 NCB31HK-122X C CAPACITOR 1200pF 50V K
C2025 NCB21CK-105X C CAPACITOR 1uF 16V K
C2026 NCB31HK-222X C CAPACITOR 2200pF 50V K
C2027 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C2028 NCB21CK-105X C CAPACITOR 1uF 16V K
C2029 NCB21CK-105X C CAPACITOR 1uF 16V K
C2031 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2032 NCB31HK-472X C CAPACITOR 4700pF 50V K
C2033 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C2034 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2035 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C2036 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C2038 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C2051 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C2071 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C2072 NCB31HK-222X C CAPACITOR 2200pF 50V K
C2401 NEAF0GM-476X E CAPACITOR 47uF 4V M
C2402 NCB21CK-105X C CAPACITOR 1uF 16V K
C2403 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C2404 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C3506 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3507 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3508 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3510 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3512 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C3513 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C3514 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3515 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3902 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3903 NDC31HJ-3R0X C CAPACITOR 3pF 50V J
C4002 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4003 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4004 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4005 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4007 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4008 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4009 NDC31HG-100X C CAPACITOR 10pF 50V G
C4010 NDC31HG-100X C CAPACITOR 10pF 50V G
C4012 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4013 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4014 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4015 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4016 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4017 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4018 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4019 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4020 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4021 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4023 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4025 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4026 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C4027 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4028 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4029 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4030 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4031 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4032 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4033 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4034 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4035 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4036 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4037 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4038 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4039 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
 Symbol No. Part No. Part Name Description Local
C4040 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4045 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4046 NDC31HJ-221X C CAPACITOR 220pF 50V J
C4047 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4048 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4049 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C4201 NEAF1HM-225X E CAPACITOR 2.2uF 50V M
C4202 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4203 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4205 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4207 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4208 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4209 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4210 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C4211 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4251 NEA71HM-335X E CAPACITOR 3.3uF 50V M
C4252 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4253 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C4254 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C4256 NEAF1CM-106X E CAPACITOR 10uF 16V M
C4502 NDC31HJ-330X C CAPACITOR 33pF 50V J
C4503 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C4504 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C4505 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4506 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4507 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4508 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4509 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C4510 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4702 NDC31HJ-270X C CAPACITOR 27pF 50V J
C4703 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C4704 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4705 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4706 NEAF0GM-107X E CAPACITOR 100uF 4V M
C4707 NEAF0JM-226X E CAPACITOR 22uF 6.3V M
C4708 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4709 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C4713 NEAF0JM-226X E CAPACITOR 22uF 6.3V M
C4714 NEAF0GM-107X E CAPACITOR 100uF 4V M
C4715 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4716 NDC31HJ-270X C CAPACITOR 27pF 50V J
C4717 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C5201 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C5203 NBP21CM-685X TA E CAPACITOR 6.8uF 16V M
C5204 NCB11EK-105X C CAPACITOR 1uF 25V K
C5207 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5209 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5211 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5212 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5213 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5214 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5215 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C5216 NCB21CK-105X C CAPACITOR 1uF 16V K
C5218 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5219 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5220 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5221 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5222 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5223 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5224 NCB11EK-105X C CAPACITOR 1uF 25V K
C5225 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5226 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5231 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6003 NEAF1CM-106X E CAPACITOR 10uF 16V M
C6021 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6022 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6023 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6024 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6025 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6026 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6027 NCB31HK-472X C CAPACITOR 4700pF 50V K
C6029 NCB31HK-102X C CAPACITOR 1000pF 50V K
C6030 NCB31HK-102X C CAPACITOR 1000pF 50V K
C6031 NCB31HK-102X C CAPACITOR 1000pF 50V K
C6032 NCB31HK-102X C CAPACITOR 1000pF 50V K
C6033 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C6034 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

3-12(No.YF036)
C6035 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6036 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6037 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6038 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C6039 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C6040 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C6041 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C6042 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C6043 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C6044 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C6045 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6046 NCB31HK-561X C CAPACITOR 560pF 50V K
C6101 NCB21CK-105X C CAPACITOR 1uF 16V K
C6103 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C6104 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6201 NCB21CK-105X C CAPACITOR 1uF 16V K
C6203 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C6204 NCB31HK-102X C CAPACITOR 1000pF 50V K
C6301 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C6303 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C6304 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6305 NEAF1CM-106X E CAPACITOR 10uF 16V M
C6401 NCB21CK-105X C CAPACITOR 1uF 16V K
C6403 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6405 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C6501 NCB21CK-105X C CAPACITOR 1uF 16V K
C6503 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6505 NCB21CK-105X C CAPACITOR 1uF 16V K
C6602 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6603 NCB11EK-105X C CAPACITOR 1uF 25V K
C6606 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6607 NCB11EK-105X C CAPACITOR 1uF 25V K
C6609 NCB21CK-105X C CAPACITOR 1uF 16V K
C6701 NCB21CK-105X C CAPACITOR 1uF 16V K
C6703 NCB21CK-105X C CAPACITOR 1uF 16V K
C6705 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C6801 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6802 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6803 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C6804 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7001 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C7002 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7003 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7004 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7005 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7006 NCB11EK-105X C CAPACITOR 1uF 25V K
C7007 NCB11EK-105X C CAPACITOR 1uF 25V K
C7008 NCB11EK-105X C CAPACITOR 1uF 25V K
C7302 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7303 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7304 NDC31HJ-100X C CAPACITOR 10pF 50V J
R101 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R102 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R103 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R105 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R106 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R107 NRVA63D-153X CMF RESISTOR 15k
Ω 1/16W D
R108 NRVA63D-243X CMF RESISTOR 24k Ω 1/16W D
R109 NRVA63D-183X CMF RESISTOR 18k
Ω 1/16W D
R110 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R111 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R112 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R113 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R114 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R115 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R116 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R117 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R118 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R119 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R120 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R121 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R122 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R123 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R124 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R125 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R126 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R127 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R128 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R129 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R130 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R131 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R132 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R133 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R134 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R135 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R136 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R137 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R138 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R139 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R140 NRSA63J-753X MG RESISTOR 75k Ω 1/16W J
R141 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R142 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R143 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R144 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R145 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R146 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R147 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R148 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R149 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R150 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R151 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R152 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R153 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R154 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R155 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
 R156 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R157 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R158 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R159 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R160 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R161 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R162 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R163 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R164 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R165 NRSA63J-560X MG RESISTOR 56 Ω 1/16W J
R166 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R167 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R168 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R169 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R170 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R171 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R172 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R173 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R174 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R175 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R176 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R177 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R178 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R179 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R180 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R185 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R186 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R189 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R190 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R191 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R192 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R193 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R194 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R195 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R198 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R199 NRS181J-101X MG RESISTOR 680
Ω 1/8W J
R1601 NRV142F-R33X CMF RESISTOR 0.33 Ω 1/4W F
R1602 NRV142F-R33X CMF RESISTOR 0.33
Ω 1/4W F
R1603 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R1604 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1605 NRSA63J-684X MG RESISTOR 680k
Ω 1/16W J
R1606 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1607 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1608 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R1609 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R1610 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1611 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R1612 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R1613 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R1614 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

(No.YF036)3-13
R1615 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1616 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1617 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1618 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1619 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R2001 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2002 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R2003 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2004 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R2005 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2006 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2011 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2012 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2021 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2022 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R2023 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R2024 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R2025 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R2027 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2028 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2030 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2031 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R2051 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2071 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2072 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2401 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R2402 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R2403 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3506 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3507 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3508 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3901 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R3902 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3903 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R4001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4002 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R4003 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R4004 NRSA63D-153X MG RESISTOR 15k Ω 1/16W D
R4009 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R4010 NRSA63D-153X MG RESISTOR 15k Ω 1/16W D
R4014 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4016 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4017 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4018 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4019 NRSA63D-822X MG RESISTOR 8.2k Ω 1/16W D
R4020 NRSA63D-471X MG RESISTOR 470 Ω 1/16W D
R4021 NRSA63D-181X MG RESISTOR 180 Ω 1/16W D
R4022 NRSA63D-182X MG RESISTOR 1.8k
Ω 1/16W D
R4023 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4025 NRSA63D-222X MG RESISTOR 2.2k
Ω 1/16W D
R4026 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R4027 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4028 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R4029 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R4032 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4033 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R4034 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R4035 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R4037 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R4038 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R4039 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R4040 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R4201 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4202 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R4203 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R4204 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4205 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R4206 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4207 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R4208 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4209 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4210 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R4211 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R4214 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4215 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R4216 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R4217 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4218 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R4219 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4220 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R4221 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R4222 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R4223 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R4224 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R4251 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R4252 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4253 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4254 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R4255 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4256 NRSA63J-824X MG RESISTOR 820k Ω 1/16W J
R4257 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R4258 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4259 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R4262 NRSA63J-302X MG RESISTOR 3k Ω 1/16W J
 R4501 NRSA63J-6R8X MG RESISTOR 6.8 Ω 1/16W J
 R4502 NRSA63J-6R8X MG RESISTOR 6.8 Ω 1/16W J
 R4503 NRSA63J-6R8X MG RESISTOR 6.8 Ω 1/16W J
 R4504 NRSA63J-6R8X MG RESISTOR 6.8 Ω 1/16W J
R4505 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4507 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4508 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R4509 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R4516 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R4527 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4701 NRSA63D-561X MG RESISTOR 560 Ω 1/16W D
R4703 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R4704 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R4706 NRSA63D-680X MG RESISTOR 68 Ω 1/16W D
R4707 NRSA63D-561X MG RESISTOR 560 Ω 1/16W D
R4709 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R4710 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R4712 NRSA63D-680X MG RESISTOR 68 Ω 1/16W D
R4713 NRSA63D-680X MG RESISTOR 68 Ω 1/16W D
R5201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5203 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5204 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5205 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5206 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5208 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R5212 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5214 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R5218 NQR0360-001X FERRITE BEADS
R5219 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5220 NQR0360-001X FERRITE BEADS
R5221 NQR0360-001X FERRITE BEADS
R6007 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6008 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6027 NRSA63D-153X MG RESISTOR 15k
Ω 1/16W D
R6028 NRSA63D-681X MG RESISTOR 680
Ω 1/16W D
R6029 NRSA63D-912X MG RESISTOR 9.1k Ω 1/16W D
R6030 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R6031 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6033 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6034 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R6035 NRSA63D-184X MG RESISTOR 180k Ω 1/16W D
R6036 NRSA63D-184X MG RESISTOR 180k
Ω 1/16W D
R6037 NRSA63D-153X MG RESISTOR 15k
Ω 1/16W D
R6038 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6039 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6041 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6042 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6044 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R6045 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R6046 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6047 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R6102 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R6103 NRVA63D-103X CMF RESISTOR 10k
Ω 1/16W D
R6110 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R6202 NRVA63D-103X CMF RESISTOR 10k Ω 1/16W D
R6203 NRVA63D-123X CMF RESISTOR 12k
Ω 1/16W D
R6204 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R6302 NRVA63D-183X CMF RESISTOR 18k Ω 1/16W D
R6303 NRVA63D-472X CMF RESISTOR 4.7k
Ω 1/16W D
R6305 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

3-14(No.YF036)
CCD BOARD ASSEMBLY <02>
R6306 NRS12BK-R47W MG RESISTOR 0.47 Ω 1/2W K
R6310 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R6402 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6403 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6405 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6406 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6502 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R6503 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6505 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R6506 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R6507 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R6602 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
R6603 NRVA63D-392X CMF RESISTOR 3.9k Ω 1/16W D
R6604 NRVA63D-683X CMF RESISTOR 68k Ω 1/16W D
R6612 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6613 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R6619 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6620 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6701 NRZ0058-R20X MG RESISTOR 0.2 Ω 1/2W J
R6703 NRVA63D-153X CMF RESISTOR 15k Ω 1/16W D
R6706 NRVA63D-823X CMF RESISTOR 82k
Ω 1/16W D
R6707 NRVA63D-333X CMF RESISTOR 33k
Ω 1/16W D
R6708 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R6709 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6710 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6711 NRS016J-121X MG RESISTOR 120 Ω 1W J
R6712 NRS016J-121X MG RESISTOR 120 Ω 1W J
R6713 NRS016J-121X MG RESISTOR 120 Ω 1W J
R6802 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6803 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6804 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R6805 NRVA63D-104X CMF RESISTOR 100k Ω 1/16W D
R6806 NRVA63D-124X CMF RESISTOR 120k Ω 1/16W D
R6807 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6808 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6811 NRVA63D-154X CMF RESISTOR 150k Ω 1/16W D
R7001 NRSA63D-123X MG RESISTOR 12k Ω 1/16W D
R7002 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R7003 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R7004 NRSA63D-123X MG RESISTOR 12k Ω 1/16W D
R7005 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7006 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R7007 NRSA63D-123X MG RESISTOR 12k Ω 1/16W D
R7008 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7009 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R7010 NRSA63D-123X MG RESISTOR 12k Ω 1/16W D
R7011 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7012 NRSA63D-333X MG RESISTOR 33k Ω 1/16W D
R7013 NRSA63D-333X MG RESISTOR 33k Ω 1/16W D
R7014 NRSA63D-333X MG RESISTOR 33k
Ω 1/16W D
R7015 NRSA63D-333X MG RESISTOR 33k Ω 1/16W D
R7016 NRSA63D-333X MG RESISTOR 33k
Ω 1/16W D
R7017 NRSA63D-333X MG RESISTOR 33k
Ω 1/16W D
R7301 NRSA63D-102X MG RESISTOR 1k Ω 1/16W D
R7303 NRSA63D-821X MG RESISTOR 820
Ω 1/16W D
R7304 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R7311 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7312 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R7313 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
RA101 NRZ0038-222X NET RESISTOR 2.2k
Ω 1/16W J
RA102 NRZ0038-222X NET RESISTOR 2.2k
Ω 1/16W J
RA103 NRZ0038-222X NET RESISTOR 2.2k Ω 1/16W J
RA104 NRZ0038-222X NET RESISTOR 2.2k
Ω 1/16W J
RA107 NRZ0038-222X NET RESISTOR 2.2k
Ω 1/16W J
RA108 NRZ0038-222X NET RESISTOR 2.2k Ω 1/16W J
RA109 NRZ0038-474X NET RESISTOR 470k
Ω 1/16W J
RA110 NRZ0038-474X NET RESISTOR 470k
Ω 1/16W J
RA111 NRZ0038-474X NET RESISTOR 470k
Ω 1/16W J
RA112 NRZ0038-104X NET RESISTOR 100k
Ω 1/16W J
RA6001 NRZ0038-102X NET RESISTOR 1k Ω 1/16W J
L101 NQL365K-220X COIL 22uH K
L1601 NQL144M-1R0X P COIL 1uH M
L1602 NQL144K-470X P COIL 47uH K
L1603 NQL144K-470X P COIL 47uH K
L2001 NQL144K-470X P COIL 47uH K
L2003 NQL034K-470X P COIL 47uH K
L2004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
L2005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L2021 NQL315K-470X COIL 47uH K
L2022 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L2023 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L2052 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L2072 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L2401 NQL315K-470X COIL 47uH K
L3502 NQL315K-220X COIL 22uH K
 L4001 NQL365K-220X COIL 22uH K
 L4002 NQL365K-220X COIL 22uH K
L4201 NQR0006-001X FERRITE BEADS
L4501 NQR0006-001X FERRITE BEADS
L4502 NQL034K-220X P COIL 22uH K
L4701 NQL365K-220X COIL 22uH K
L5201 NQL315K-220X COIL 22uH K
L5203 NQL315K-220X COIL 22uH K
L5204 NQL315K-220X COIL 22uH K
L6001 NQL82EN-100X COIL 10uH N
L6002 NQL82EN-100X COIL 10uH N
L6101 NQL82EN-330X COIL 33uH N
L6201 NQL82EN-470X COIL 47uH N
L6301 NQL52EM-220X COIL 22uH M
L6401 NQL52EM-470X COIL 47uH M
L6501 NQL52EM-470X COIL 47uH M
L6601 NQL52EM-221X COIL 220uH M
L6701 NQL73EM-100X COIL 10uH M
L7001 NQL365K-220X COIL 22uH K
L7002 NQL365K-220X COIL 22uH K
L7301 NQL144K-100X P COIL 0.30 Ω 10uH K
CN1 QGF0534F1-10X CONNECTOR DRUM.MOTOR FFC/FPC (1-10)
CN2 QGF0534F1-14X CONNECTOR SENSOR FFC/FPC (1-14)
CN3 QGF0503F4-18X CONNECTOR CAPSTAN.M. FFC/FPC (1-18)
CN4 QGA1201F2-02X CONNECTOR LOADING.M. W-B (1-2)
CN5 QGF0534F1-11X CONNECTOR VIDEO.HEAD FFC/FPC (1-11)
CN6 QGA1201C2-02X CONNECTOR LIGHT 2P W-B (1-2)
CN7 QGF0534F1-11X CONNECTOR A/C.HEAD FFC/FPC (1-11)
CN8 QGA1201C2-02X CONNECTOR MIC W-B (1-2)
CN12 QGA1501F2-03V CONNECTOR B/W.VF 3P W-B (1-3)
CN13 QGF0534F1-14X CONNECTOR JVC Z.OPE FFC/FPC (1-14)
CN15 QGF0534F1-24X CONNECTOR OP FFC/FPC (1-24)
CN16 QGF0534F1-25X CONNECTOR LCD 25P FFC/FPC (1-25)
CN18 QGF0503C1-13X CONNECTOR TOP OPE FFC/FPC (1-13)
CN22 QGF0534F1-14X CONNECTOR CCD FFC/FPC (1-14)
CN25 QGB0801M1-20X CONNECTOR JV/PA JIG B-B (1-20)
CN27 QGA1201C2-02X CONNECTOR SPEAKER 2P W-B (1-2)
CN28 QGA1002F1-10X CONNECTOR REAR.UNIT W-B (1-10)
 F1601 NMFZ007-R20X-K FUSE 0.2A 50V
 F1602 NMFZ007-R50X-K FUSE 0.5A 50V
 F6001 NMFZ007-2R0X-K FUSE 2A 32V
 F6301 NMFZ007-1R6X-K FUSE 1.6A 32V
 F6302 NMFZ007-R40X-K FUSE 0.4A 50V
 F6801 NMFZ007-R20X-K FUSE 0.2A 50V
 F7301 NMFZ007-R50X-K FUSE 0.5A 50V
 J101 QAB0050-001 LITHIUM BATTERY LITHIUM CR2032/H1G 3V 220mAh
J504 LY33041-001A JACK UNIT A/V OUT
J505 QND0068-001 S JACK S OUT
X101 NAX0571-001 CRYSTAL 16.000MHz
X102 NAX0564-001X CRYSTAL
X4001 QAX0709-001 CRYSTAL 28.636360MHz
OT1 LY30016-049A SPACER-A AUDIO PB
SD1 LY43421-001B SHIELD PLATE SHIELD
WR1 WJV0081-001A E-PRIMARY WIRE AUDIO PB
 Symbol No. Part No. Part Name Description Local
PW2 YB10450A2-02 CCD BOARD ASSY
Q5301 2SC3931/CD/-X TRANSISTOR
Q5301 or 2SC4774/RS/-X TRANSISTOR
C5301 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5302 NBP21EM-155X TA E CAPACITOR 1.5uF 25V M
C5303 NCB31HK-222X C CAPACITOR 2200pF 50V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

(No.YF036)3-15
MONITOR BOARD ASSEMBLY <07>
E.VF BOARD ASSEMBLY <60>
C5304 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C5305 NDC31HJ-270X C CAPACITOR 27pF 50V J
R5301 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5302 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
CN5301 QGF0505F1-14X CONNECTOR M4A/C FFC/FPC (1-14)
 Symbol No. Part No. Part Name Description Local
PW1 YB20935F MONITOR BOARD ASSY
IC7601 MN5814 IC
IC7602 RC4558D-X IC
IC7604 DN8797MS-X IC TEZUKE
Q7501 2SD1664/QR/-W TRANSISTOR
Q7502 2SD1664/QR/-W TRANSISTOR
Q7503 DTA144EE-X DIGI TRANSISTOR
Q7503 or UN9113J-X DIGI TRANSISTOR
Q7503 or RN2104-X DIGI TRANSISTOR
Q7503 or BCR198T-X DIGI TRANSISTOR
Q7504 DTC144EE-X DIGI TRANSISTOR
Q7504 or UN9213J-X DIGI TRANSISTOR
Q7504 or RN1104-X DIGI TRANSISTOR
Q7504 or BCR148T-X DIGI TRANSISTOR
Q7601 2SC4617/QR/-X TRANSISTOR
Q7601 or BC847BT-X TRANSISTOR
Q7602 2SA1774/QR/-X TRANSISTOR
Q7602 or BC857BT-X TRANSISTOR
Q7603 2SC4617/QR/-X TRANSISTOR
Q7603 or BC847BT-X TRANSISTOR
Q7604 2SA1774/QR/-X TRANSISTOR
Q7604 or BC857BT-X TRANSISTOR
Q7606 DTA144EE-X DIGI TRANSISTOR
Q7606 or UN9113J-X DIGI TRANSISTOR
Q7606 or RN2104-X DIGI TRANSISTOR
Q7606 or BCR198T-X DIGI TRANSISTOR
Q7608 DTC144EE-X DIGI TRANSISTOR
Q7608 or UN9213J-X DIGI TRANSISTOR
Q7608 or RN1104-X DIGI TRANSISTOR
Q7608 or BCR148T-X DIGI TRANSISTOR
D7601 MA365-X VARI CAP DIODE
D7602 RB471E-W SB DIODE
D7603 UDZS5.1B-X Z DIODE
D7604 MA741WA-X SB DIODE
C7501 NCZ1016-120X C CAPACITOR 12pF 2kV J
C7502 NCB21EK-273X C CAPACITOR 0.027uF 25V K
C7503 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7504 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C7601 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7602 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7606 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7607 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C7608 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7609 NBP41CM-106X TA E CAPACITOR 10uF 16V M
C7610 NDC31HJ-330X C CAPACITOR 33pF 50V J
C7611 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7612 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7613 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7614 NCB21CK-334X C CAPACITOR 0.33uF 16V K
C7615 NDC31HJ-331X C CAPACITOR 330pF 50V J
C7616 NDC31HJ-330X C CAPACITOR 33pF 50V J
C7617 NDC31HJ-560X C CAPACITOR 56pF 50V J
C7618 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7619 NDC31HJ-270X C CAPACITOR 27pF 50V J
C7620 NDC31HJ-270X C CAPACITOR 27pF 50V J
C7621 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7622 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7624 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7626 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
 Symbol No. Part No. Part Name Description Local
R7501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7601 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R7602 NRSA63D-822X MG RESISTOR 8.2k Ω 1/16W D
R7603 NRSA63D-333X MG RESISTOR 33k
Ω 1/16W D
R7604 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R7605 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R7606 NRSA63D-153X MG RESISTOR 15k Ω 1/16W D
R7607 NRSA63D-822X MG RESISTOR 8.2k Ω 1/16W D
R7608 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R7610 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R7611 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7612 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R7613 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7615 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7617 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7619 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7620 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7621 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7623 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7624 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7628 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R7629 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R7630 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R7631 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7632 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R7633 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R7635 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7636 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7637 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7638 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7639 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7640 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R7641 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R7642 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7645 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R7646 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R7650 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7654 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
L7501 NQLZ010-680X COIL 68uH
L7502 NQL03BK-100X P COIL 10uH K
L7601 NQL315K-220X COIL 22uH K
L7604 NQL315K-220X COIL 22uH K
L7605 NQL085J-4R7X COIL 4.7uH J
T7501 NQS0056-001X SW TARNSF
CN7601 QGF0303F1-25W CONNECTOR FFC/FPC (1-25)
CN7602 QGF0508F1-24X CONNECTOR FFC/FPC (1-24)
 F7501 NMFZ007-R40X-K FUSE 0.4A 50V
SD1 LY44535-001A SHIELD SHEET TEZUKE
WR1 QAL0449-001 FPC TEZUKE
WR2 YU40017-060-1 THIN WIRE TEZUKE
 Symbol No. Part No. Part Name Description Local
PW1 LY41289-011A E.VF BOARD ASSY
IC7001 BA7149F-XE IC
Q7001 2SD968A(RS) PH TRANSISTOR
Q7002 2SA1748(QR) PH TRANSISTOR
Q7003 2SA1748(QR) PH TRANSISTOR
D7001 MA142WA DIODE
C7001 QFV11HJ-104A F CAPACITOR 0.1uF 50V J
C7002 QEDP1AM-227 E CAPACITOR 220uF 10V M
C7003 QEDP1AM-227 E CAPACITOR 220uF 10V M
C7004 QEDP1AM-227 E CAPACITOR 220uF 10V M
C7005 NCF21CZ-105X CAPACITOR 1uF 16V Z
C7006 NCB21HK-152X CAPACITOR 0.0015uF 50V K
C7007 NCB11CK-105X CAPACITOR 1uF 16V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

3-16(No.YF036)
C7008 NCF21CZ-105X CAPACITOR 1uF 16V Z
C7009 PECA1131-A107 E CAPACITOR 100uF 10V
C7010 CM316UJ472J100A CAPACITOR 0.0056uF 100V
C7011 NDC21HJ-180X CAPACITOR 18pF 50V J
C7012 QEKC1HM-105Z E CAPACITOR 1uF 50V M
C7013 NCF21HZ-104X CAPACITOR 0.1uF 50V Z
C7014 NCF21HZ-104X CAPACITOR 0.1uF 50V Z
C7015 QCZ0212-151 CAPACITOR 150pF 1kV K
C7016 PECA1006 CAPACITOR 330pF 500V
R7002 NRSA02J-3R9X MG RESISTOR 3.9 Ω 1/10W J
R7003 NRVA02D-153X CMF RESISTOR 15k Ω 1/10W D
R7005 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
R7006 NRSA02J-113X MG RESISTOR 11k Ω 1/10W J
R7007 NRSA02J-330X MG RESISTOR 33 Ω 1/10W J
R7008 NRSA02J-394X MG RESISTOR 390k Ω 1/10W J
R7009 NRSA02J-103X MG RESISTOR 10k Ω 1/10W J
R7010 NRVA02D-104X CMF RESISTOR 100k Ω 1/10W D
R7011 NRSA02J-223X MG RESISTOR 22k Ω 1/10W J
R7012 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R7013 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R7014 NRSA02J-472X MG RESISTOR 4.7k
Ω 1/10W J
R7015 NRSA02J-223X MG RESISTOR 22k Ω 1/10W J
R7016 NRSA02J-122X MG RESISTOR 1.2k Ω 1/10W J
R7017 NRSA02J-472X MG RESISTOR 4.7k Ω 1/10W J
R7018 NRSA02J-223X MG RESISTOR 22k Ω 1/10W J
R7019 NRSA02J-120X MG RESISTOR 12 Ω 1/10W J
R7020 NRSA02J-685X MG RESISTOR 6.8M Ω 1/10W J
R7021 NRSA02J-475X MG RESISTOR 4.7M Ω 1/10W J
R7022 NRSA02J-475X MG RESISTOR 4.7M Ω 1/10W J
R7023 NRSA02J-564X MG RESISTOR 560k Ω 1/10W J
R7024 NRSA02J-105X MG RESISTOR 1M Ω 1/10W J
R7025 NRSA02J-275X MG RESISTOR 2.7M Ω 1/10W J
R7026 NRSA02J-275X MG RESISTOR 2.7M Ω 1/10W J
VR7001 NVP0001-221X TRIM RESISTOR V.SIZE
VR7002 NVP0001-225X TRIM RESISTOR BRIGHT
VR7003 PERE0595-565 V RESISTOR FOCUS
L7001 QQR0970-001 LINEARITY COIL
L7002 PU49994-220 COIL 22uH
L7003 PELN1101-680JY COIL 68uH
 T7001 QQH0011-002 FB TRANS
CN7001 B4B-ZR CAP HOUSING
CN7002 WJK0095-007A WIRE ASSY
OT1 PU59915-105 SPACER#500 for L7001
OT2 QNZ0462-001 CRT SOCKET
WR1 TT-AWG24-WHITE WIRE G3
WR2 TT-AWG28-WHITE WIRE H
WR3 TT-AWG28-BROWN WIRE G2
WR4 TT-AWG28-BLUE WIRE G1
WR5 TT-AWG28-YELLOW WIRE HK
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-SXM277UA
GR-SXM277UM
GR-SXM278UM
MODEL MARK
D
E
GR-SXM279UB
GR-SXM279UM

SERVICE MANUAL
COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN, LIMITED No.YF016
2004/1
COMPACT VHS CAMCORDER
YF01620041GR-SXM161US,GR-SXM256UC,
GR-SXM260UC,GR-SXM260US,
GR-SXM265UC,GR-SXM265US
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
GR-SXM161US[M4C623],GR-SXM256UC[M4C622]
GR-SXM260UC/US[M4C623],GR-SXM265UC/US[M4C623]

1-2 (No.YF016)
SPECIFICATION (The specifications shown pertain specifically to the model GR-SXM260)
