JVC GR-SXM600AS User manual

1
INSTRUCTIONS ENGLISH LYT1202-001B
AUTOMATIC DEMONSTRATION
Automatic Demonstration takes place when “DEMO MODE” is set to “ON”
(factory-preset).
• Available when the Power Switch @is set to “ ” or “ ” while pressing down the Lock Button !located
on the switch.
• Performing any operation during the demonstration stops the demonstration temporarily. If no operation
is performed for more than 1 minute after that, the demonstration will resume.
• “DEMO MODE” remains “ON” even if the camcorder power is turned off.
• To cancel Automatic Demonstration, set the Power Switch @to “ ” and press the MENU Wheel 1in
while the demo is in progress. This takes you directly to the demo mode’s Setting Menu (so you will not
have to go through the main Menu Screen). Rotate the MENU Wheel 1to select “OFF” and press it.
NOTES:
• When a tape whose Erase Protection tab is in the position that allows recording is loaded in the
camcorder, demonstration is not available.
• If you do not detach the Lens Cap, you cannot see the actual changes of the Automatic Demonstration
activated on the LCD monitor* or viewfinder.
* Applicable models only.
Dear Customer,
Thank you for purchasing the JVC Compact VHS camcorder. Before use, please read
“PRECAUTIONS” (pg. 3, 4) to ensure safe use of this product.
Printed in Malaysia
1003-AS-YL-PJ
AG/AS/AA
COMPACT VHS CAMCORDER
GR-SXM600 AS
GR-SXM300 AG/AS/AA
GR-SXM255 AS
GR-SXM200 AG/AS
GR-SX260 AG
GR-SX160 AG/AS
VHS
PAL
625
®Registered Trademark owned by VICTOR COMPANY OF JAPAN, LTD.
COPYRIGHT© 2003 VICTOR COMPANY OF JAPAN, LTD.
GR-SXM600AS_EN_Malaysia 11/6/03, 02:31 PM1
Black

2
PROVIDED ACCESSORIES
• Battery Pack
BN-V10U
• Shoulder Strap
• Lens Cap
• Power Cord
• A/V (Audio/Video)
Cable
• Remote Control Unit
RM-V715U
(GR-SXM600AS, GR-
SXM300AG/AS/AA, GR-
SXM255AS, GR-SX260AG only)
• AAA (R03) Battery x 2
(for Remote Control Unit,
GR-SXM600AS, GR-SXM300AG/AS/AA,
GR-SXM255AS, GR-SX260AG only)
• Cassette Adapter
C-P7U
• AA (R6) Battery
(for Cassette Adapter)
NOTE:
In order to maintain optimum performance of the camcorder, provided cables may be equipped with
one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be
connected to the camcorder.
• AC Adapter
AP-V14E/A or AP-V15E
GR-SXM600AS_EN_Malaysia 11/6/03, 02:31 PM2
Black

3
SAFETY PRECAUTIONS
PRECAUTIONS
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR
MOISTURE.
CAUTIONS
•If you notice smoke or a peculiar smell coming
from the camcorder or AC adapter, shut it down
and unplug it immediately. Continue using the
camcorder or AC adapter under these conditions
could lead to fire or electric shock. Contact your
JVC dealer. Do not attempt to repair the
malfunction yourself.
•To prevent shock, do not open the cabinet. No
user serviceable parts inside. Refer servicing to
qualified personnel.
•When you are not using the AC Adapter for a long
period of time, it is recommended that you
disconnect the power cord from AC outlet.
•The socket outlet shall be installed near the
equipment and easily accessible, or the mains
plug or an appliance coupler shall remain readily
operable.
NOTES:
•The rating plate (serial number plate) and safety
caution are on the bottom and/or the back of the
main unit.
•The rating information and safety caution of the
AC Adapter are on its bottom.
CAUTIONS
•This camcorder is designed to be used with
PAL-type colour television signals. It cannot be
used for playback with a television of a different
standard. However, live recording and LCD
monitor*/viewfinder playback are possible
anywhere.
•Use the JVC BN-V10U/V12U/V20U/V400U
battery packs and, to recharge them or to supply
power to the camcorder from an AC outlet, use
the provided multi-voltage AC Adapter. (An
appropriate conversion adapter may be
necessary to accommodate different designs of
AC outlets in different countries.)
* Applicable models only.
CAUTIONS
To avoid electric shock or damage to the
unit, first firmly insert the small end of the
power cord into the AC Adapter until it is no
longer wobbly, and then plug the larger end
of the power cord into an AC outlet.
Cassettes marked and can be used with this camcorder.
However, S-VHS recordings are possible only with cassettes marked .
GR-SXM600AS_EN_Malaysia 11/6/03, 02:31 PM3
Black

4
When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space
on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get
out.)
No naked flame sources, such as lighted candles, should be placed on the apparatus.
When discarding batteries, environmental problems must be considered and the local rules or
laws governing the disposal of these batteries must be followed strictly.
The apparatus shall not be exposed to dripping or splashing.
Do not use this equipment in a bathroom or places with water.
Also do not place any containers filled with water or liquids (such as cosmetics or medicines,
flower vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)
ATTENTION USERS OF RECHARGEABLE BATTERIES
DO NOT DISPOSE RECHARGEABLE BATTERIES OR PRODUCTS POWERED BY
NON-REMOVABLE RECHARGEABLE BATTERIES, THESE BATTERIES AND
PRODUCTS CAN BE RECYCLED.
AT THE END OF NORMAL LIFE,
IN AUSTRALIA, RETURN TO YOUR POINT OF PURCHASE OR MAIL TO:
Hagemeyer Brands Australia PTY Limited, T/A Hagemeyer Appliances, ABN 22 000 668 977
PO Box 4013, Kingsgrove NSW 2208 Australia
Attn : Service Dept.
Phone : [phone] Website : www.jvc-australia.com
IN NEW ZEALAND, PLEASE RETURN BATTERIES BY MAIL TO:
Hagemeyer (NZ) Limited P.O. Box 100589 Auckland 1333
Phone : [phone]
GR-SXM600AS_EN_Malaysia 11/6/03, 02:31 PM4
Black

5
