JVC GY-HD100 User manual
GY-HD100 shooting angle calculation table
Image size of GY-HD100 Angle of GY-HD100 Calculated focal length
34.864 2.739 5.582 78.1 49.1 85.9 4.3 5.9 23.3
44.864 2.739 5.582 62.6 37.8 69.8 5.7 7.9 31.0
54.864 2.739 5.582 51.9 30.6 58.3 7.2 9.9 38.8
64.864 2.739 5.582 44.1 25.7 49.9 8.6 11.8 46.5
74.864 2.739 5.582 38.3 22.1 43.5 10.0 13.8 54.3
84.864 2.739 5.582 33.8 19.4 38.5 11.5 15.8 62.0
94.864 2.739 5.582 30.2 17.3 34.5 12.9 17.7 69.8
10 4.864 2.739 5.582 27.3 15.6 31.2 14.3 19.7 77.5
11 4.864 2.739 5.582 24.9 14.2 28.5 15.8 21.7 85.3
12 4.864 2.739 5.582 22.9 13.0 26.2 17.2 23.6 93.0
13 4.864 2.739 5.582 21.2 12.0 24.2 18.6 25.6 100.8
14 4.864 2.739 5.582 19.7 11.2 22.5 20.1 27.6 108.5
15 4.864 2.739 5.582 18.4 10.4 21.1 21.5 29.6 116.3
16 4.864 2.739 5.582 17.3 9.8 19.8 22.9 31.5 124.0
17 4.864 2.739 5.582 16.3 9.2 18.6 24.4 33.5 131.8
18 4.864 2.739 5.582 15.4 8.7 17.6 25.8 35.5 139.5
19 4.864 2.739 5.582 14.6 8.2 16.7 27.2 37.4 147.3
20 4.864 2.739 5.582 13.9 7.8 15.9 28.7 39.4 155.0
21 4.864 2.739 5.582 13.2 7.5 15.1 30.1 41.4 162.8
22 4.864 2.739 5.582 12.6 7.1 14.5 31.5 43.4 170.5
23 4.864 2.739 5.582 12.1 6.8 13.8 33.0 45.3 178.3
24 4.864 2.739 5.582 11.6 6.5 13.3 34.4 47.3 186.0
25 4.864 2.739 5.582 11.1 6.3 12.7 35.8 49.3 193.8
26 4.864 2.739 5.582 10.7 6.0 12.3 37.3 51.2 201.5
27 4.864 2.739 5.582 10.3 5.8 11.8 38.7 53.2 209.3
28 4.864 2.739 5.582 9.9 5.6 11.4 40.1 55.2 217.0
29 4.864 2.739 5.582 9.6 5.4 11.0 41.6 57.1 224.8
30 4.864 2.739 5.582 9.3 5.2 10.6 43.0 59.1 232.6
31 4.864 2.739 5.582 9.0 5.1 10.3 44.4 61.1 240.3
32 4.864 2.739 5.582 8.7 4.9 10.0 45.9 63.1 248.1
33 4.864 2.739 5.582 8.4 4.8 9.7 47.3 65.0 255.8
34 4.864 2.739 5.582 8.2 4.6 9.4 48.7 67.0 263.6
35 4.864 2.739 5.582 7.9 4.5 9.1 50.2 69.0 271.3
36 4.864 2.739 5.582 7.7 4.4 8.9 51.6 70.9 279.1
37 4.864 2.739 5.582 7.5 4.2 8.6 53.0 72.9 286.8
38 4.864 2.739 5.582 7.3 4.1 8.4 54.5 74.9 294.6
39 4.864 2.739 5.582 7.1 4.0 8.2 55.9 76.9 302.3
40 4.864 2.739 5.582 7.0 3.9 8.0 57.3 78.8 310.1
41 4.864 2.739 5.582 6.8 3.8 7.8 58.8 80.8 317.8
42 4.864 2.739 5.582 6.6 3.7 7.6 60.2 82.8 325.6
43 4.864 2.739 5.582 6.5 3.6 7.4 61.6 84.7 333.3
44 4.864 2.739 5.582 6.3 3.6 7.3 63.1 86.7 341.1
45 4.864 2.739 5.582 6.2 3.5 7.1 64.5 88.7 348.8
46 4.864 2.739 5.582 6.1 3.4 6.9 65.9 90.6 356.6
47 4.864 2.739 5.582 5.9 3.3 6.8 67.4 92.6 364.3
48 4.864 2.739 5.582 5.8 3.3 6.7 68.8 94.6 372.1
49 4.864 2.739 5.582 5.7 3.2 6.5 70.2 96.6 379.8
50 4.864 2.739 5.582 5.6 3.1 6.4 71.7 98.5 387.6
51 4.864 2.739 5.582 5.5 3.1 6.3 73.1 100.5 395.3
52 4.864 2.739 5.582 5.4 3.0 6.1 74.5 102.5 403.1
53 4.864 2.739 5.582 5.3 3.0 6.0 76.0 104.4 410.8
54 4.864 2.739 5.582 5.2 2.9 5.9 77.4 106.4 418.6
55 4.864 2.739 5.582 5.1 2.9 5.8 78.8 108.4 426.3
56 4.864 2.739 5.582 5.0 2.8 5.7 80.3 110.4 434.1
57 4.864 2.739 5.582 4.9 2.8 5.6 81.7 112.3 441.8
58 4.864 2.739 5.582 4.8 2.7 5.5 83.1 114.3 449.6
59 4.864 2.739 5.582 4.7 2.7 5.4 84.6 116.3 457.4
60 4.864 2.739 5.582 4.6 2.6 5.3 86.0 118.2 465.1
61 4.864 2.739 5.582 4.6 2.6 5.2 87.4 120.2 472.9
62 4.864 2.739 5.582 4.5 2.5 5.2 88.9 122.2 480.6
63 4.864 2.739 5.582 4.4 2.5 5.1 90.3 124.1 488.4
64 4.864 2.739 5.582 4.4 2.5 5.0 91.7 126.1 496.1
65 4.864 2.739 5.582 4.3 2.4 4.9 93.2 128.1 503.9
66 4.864 2.739 5.582 4.2 2.4 4.8 94.6 130.1 511.6
67 4.864 2.739 5.582 4.2 2.3 4.8 96.0 132.0 519.4
68 4.864 2.739 5.582 4.1 2.3 4.7 97.5 134.0 527.1
69 4.864 2.739 5.582 4.0 2.3 4.6 98.9 136.0 534.9
70 4.864 2.739 5.582 4.0 2.2 4.6 100.3 137.9 542.6
71 4.864 2.739 5.582 3.9 2.2 4.5 101.8 139.9 550.4
72 4.864 2.739 5.582 3.9 2.2 4.4 103.2 141.9 558.1
73 4.864 2.739 5.582 3.8 2.1 4.4 104.6 143.9 565.9
74 4.864 2.739 5.582 3.8 2.1 4.3 106.1 145.8 573.6
75 4.864 2.739 5.582 3.7 2.1 4.3 107.5 147.8 581.4
76 4.864 2.739 5.582 3.7 2.1 4.2 108.9 149.8 589.1
77 4.864 2.739 5.582 3.6 2.0 4.2 110.4 151.7 596.9
78 4.864 2.739 5.582 3.6 2.0 4.1 111.8 153.7 604.6
79 4.864 2.739 5.582 3.5 2.0 4.0 113.2 155.7 612.4
80 4.864 2.739 5.582 3.5 2.0 4.0 114.7 157.6 620.1
81 4.864 2.739 5.582 3.4 1.9 3.9 116.1 159.6 627.9
82 4.864 2.739 5.582 3.4 1.9 3.9 117.5 161.6 635.6
83 4.864 2.739 5.582 3.4 1.9 3.9 119.0 163.6 643.4
84 4.864 2.739 5.582 3.3 1.9 3.8 120.4 165.5 651.1
85 4.864 2.739 5.582 3.3 1.8 3.8 121.8 167.5 658.9
86 4.864 2.739 5.582 3.2 1.8 3.7 123.3 169.5 666.6
87 4.864 2.739 5.582 3.2 1.8 3.7 124.7 171.4 674.4
88 4.864 2.739 5.582 3.2 1.8 3.6 126.1 173.4 682.1
89 4.864 2.739 5.582 3.1 1.8 3.6 127.6 175.4 689.9
90 4.864 2.739 5.582 3.1 1.7 3.6 129.0 177.4 697.7
91 4.864 2.739 5.582 3.1 1.7 3.5 130.4 179.3 705.4
92 4.864 2.739 5.582 3.0 1.7 3.5 131.9 181.3 713.2
93 4.864 2.739 5.582 3.0 1.7 3.4 133.3 183.3 720.9
94 4.864 2.739 5.582 3.0 1.7 3.4 134.7 185.2 728.7
95 4.864 2.739 5.582 2.9 1.7 3.4 136.2 187.2 736.4
96 4.864 2.739 5.582 2.9 1.6 3.3 137.6 189.2 744.2
97 4.864 2.739 5.582 2.9 1.6 3.3 139.0 191.2 751.9
Focal length
(mm)
Horizontal
length
(mm)
Vertical length
(mm)
Diagonal
length
(mm)
Horizontal
angle
(degree) Vertical angle
(degree) Diagonal
angle
(degree) Focal length with
1/2" lens(mm) Focallengthwith
2/3" lens(mm)
Focallength
calculated to be
equivalent to
35mm film (mm)
98 4.864 2.739 5.582 2.8 1.6 3.3 140.5 193.1 759.7
99 4.864 2.739 5.582 2.8 1.6 3.2 141.9 195.1 767.4
100 4.864 2.739 5.582 2.8 1.6 3.2 143.3 197.1 775.2
101 4.864 2.739 5.582 2.8 1.6 3.2 144.8 199.0 782.9
102 4.864 2.739 5.582 2.7 1.5 3.1 146.2 201.0 790.7
103 4.864 2.739 5.582 2.7 1.5 3.1 147.6 203.0 798.4
104 4.864 2.739 5.582 2.7 1.5 3.1 149.1 204.9 806.2
105 4.864 2.739 5.582 2.7 1.5 3.0 150.5 206.9 813.9
106 4.864 2.739 5.582 2.6 1.5 3.0 151.9 208.9 821.7
107 4.864 2.739 5.582 2.6 1.5 3.0 153.4 210.9 829.4
108 4.864 2.739 5.582 2.6 1.5 3.0 154.8 212.8 837.2
109 4.864 2.739 5.582 2.6 1.4 2.9 156.2 214.8 844.9
110 4.864 2.739 5.582 2.5 1.4 2.9 157.6 216.8 852.7
111 4.864 2.739 5.582 2.5 1.4 2.9 159.1 218.7 860.4
112 4.864 2.739 5.582 2.5 1.4 2.9 160.5 220.7 868.2
113 4.864 2.739 5.582 2.5 1.4 2.8 161.9 222.7 875.9
114 4.864 2.739 5.582 2.4 1.4 2.8 163.4 224.7 883.7
115 4.864 2.739 5.582 2.4 1.4 2.8 164.8 226.6 891.4
116 4.864 2.739 5.582 2.4 1.4 2.8 166.2 228.6 899.2
117 4.864 2.739 5.582 2.4 1.3 2.7 167.7 230.6 906.9
118 4.864 2.739 5.582 2.4 1.3 2.7 169.1 232.5 914.7
119 4.864 2.739 5.582 2.3 1.3 2.7 170.5 234.5 922.5
120 4.864 2.739 5.582 2.3 1.3 2.7 172.0 236.5 930.2
121 4.864 2.739 5.582 2.3 1.3 2.6 173.4 238.4 938.0
122 4.864 2.739 5.582 2.3 1.3 2.6 174.8 240.4 945.7
123 4.864 2.739 5.582 2.3 1.3 2.6 176.3 242.4 953.5
124 4.864 2.739 5.582 2.2 1.3 2.6 177.7 244.4 961.2
125 4.864 2.739 5.582 2.2 1.3 2.6 179.1 246.3 969.0
126 4.864 2.739 5.582 2.2 1.2 2.5 180.6 248.3 976.7
127 4.864 2.739 5.582 2.2 1.2 2.5 182.0 250.3 984.5
128 4.864 2.739 5.582 2.2 1.2 2.5 183.4 252.2 992.2
129 4.864 2.739 5.582 2.2 1.2 2.5 184.9 254.2 1000.0
130 4.864 2.739 5.582 2.1 1.2 2.5 186.3 256.2 1007.7
131 4.864 2.739 5.582 2.1 1.2 2.4 187.7 258.2 1015.5
132 4.864 2.739 5.582 2.1 1.2 2.4 189.2 260.1 1023.2
133 4.864 2.739 5.582 2.1 1.2 2.4 190.6 262.1 1031.0
134 4.864 2.739 5.582 2.1 1.2 2.4 192.0 264.1 1038.7
135 4.864 2.739 5.582 2.1 1.2 2.4 193.5 266.0 1046.5
136 4.864 2.739 5.582 2.0 1.2 2.4 194.9 268.0 1054.2
137 4.864 2.739 5.582 2.0 1.1 2.3 196.3 270.0 1062.0
138 4.864 2.739 5.582 2.0 1.1 2.3 197.8 271.9 1069.7
139 4.864 2.739 5.582 2.0 1.1 2.3 199.2 273.9 1077.5
140 4.864 2.739 5.582 2.0 1.1 2.3 200.6 275.9 1085.2
141 4.864 2.739 5.582 2.0 1.1 2.3 202.1 277.9 1093.0
142 4.864 2.739 5.582 2.0 1.1 2.3 203.5 279.8 1100.7
143 4.864 2.739 5.582 1.9 1.1 2.2 204.9 281.8 1108.5
144 4.864 2.739 5.582 1.9 1.1 2.2 206.4 283.8 1116.2
145 4.864 2.739 5.582 1.9 1.1 2.2 207.8 285.7 1124.0
146 4.864 2.739 5.582 1.9 1.1 2.2 209.2 287.7 1131.7
147 4.864 2.739 5.582 1.9 1.1 2.2 210.7 289.7 1139.5
148 4.864 2.739 5.582 1.9 1.1 2.2 212.1 291.7 1147.3
149 4.864 2.739 5.582 1.9 1.1 2.1 213.5 293.6 1155.0
150 4.864 2.739 5.582 1.9 1.0 2.1 215.0 295.6 1162.8
151 4.864 2.739 5.582 1.8 1.0 2.1 216.4 297.6 1170.5
152 4.864 2.739 5.582 1.8 1.0 2.1 217.8 299.5 1178.3
153 4.864 2.739 5.582 1.8 1.0 2.1 219.3 301.5 1186.0
154 4.864 2.739 5.582 1.8 1.0 2.1 220.7 303.5 1193.8
155 4.864 2.739 5.582 1.8 1.0 2.1 222.1 305.4 1201.5
156 4.864 2.739 5.582 1.8 1.0 2.0 223.6 307.4 1209.3
157 4.864 2.739 5.582 1.8 1.0 2.0 225.0 309.4 1217.0
158 4.864 2.739 5.582 1.8 1.0 2.0 226.4 311.4 1224.8
159 4.864 2.739 5.582 1.8 1.0 2.0 227.9 313.3 1232.5
160 4.864 2.739 5.582 1.7 1.0 2.0 229.3 315.3 1240.3
161 4.864 2.739 5.582 1.7 1.0 2.0 230.7 317.3 1248.0
162 4.864 2.739 5.582 1.7 1.0 2.0 232.2 319.2 1255.8
163 4.864 2.739 5.582 1.7 1.0 2.0 233.6 321.2 1263.5
164 4.864 2.739 5.582 1.7 1.0 1.9 235.0 323.2 1271.3
165 4.864 2.739 5.582 1.7 1.0 1.9 236.5 325.2 1279.0
166 4.864 2.739 5.582 1.7 0.9 1.9 237.9 327.1 1286.8
167 4.864 2.739 5.582 1.7 0.9 1.9 239.3 329.1 1294.5
168 4.864 2.739 5.582 1.7 0.9 1.9 240.8 331.1 1302.3
169 4.864 2.739 5.582 1.6 0.9 1.9 242.2 333.0 1310.0
170 4.864 2.739 5.582 1.6 0.9 1.9 243.6 335.0 1317.8
171 4.864 2.739 5.582 1.6 0.9 1.9 245.1 337.0 1325.5
172 4.864 2.739 5.582 1.6 0.9 1.9 246.5 338.9 1333.3
173 4.864 2.739 5.582 1.6 0.9 1.8 247.9 340.9 1341.0
174 4.864 2.739 5.582 1.6 0.9 1.8 249.4 342.9 1348.8
175 4.864 2.739 5.582 1.6 0.9 1.8 250.8 344.9 1356.5
176 4.864 2.739 5.582 1.6 0.9 1.8 252.2 346.8 1364.3
177 4.864 2.739 5.582 1.6 0.9 1.8 253.7 348.8 1372.1
178 4.864 2.739 5.582 1.6 0.9 1.8 255.1 350.8 1379.8
179 4.864 2.739 5.582 1.6 0.9 1.8 256.5 352.7 1387.6
180 4.864 2.739 5.582 1.5 0.9 1.8 258.0 354.7 1395.3
181 4.864 2.739 5.582 1.5 0.9 1.8 259.4 356.7 1403.1
182 4.864 2.739 5.582 1.5 0.9 1.8 260.8 358.7 1410.8
183 4.864 2.739 5.582 1.5 0.9 1.7 262.3 360.6 1418.6
184 4.864 2.739 5.582 1.5 0.9 1.7 263.7 362.6 1426.3
185 4.864 2.739 5.582 1.5 0.8 1.7 265.1 364.6 1434.1
186 4.864 2.739 5.582 1.5 0.8 1.7 266.6 366.5 1441.8
187 4.864 2.739 5.582 1.5 0.8 1.7 268.0 368.5 1449.6
188 4.864 2.739 5.582 1.5 0.8 1.7 269.4 370.5 1457.3
189 4.864 2.739 5.582 1.5 0.8 1.7 270.9 372.4 1465.1
190 4.864 2.739 5.582 1.5 0.8 1.7 272.3 374.4 1472.8
191 4.864 2.739 5.582 1.5 0.8 1.7 273.7 376.4 1480.6
192 4.864 2.739 5.582 1.5 0.8 1.7 275.2 378.4 1488.3
193 4.864 2.739 5.582 1.4 0.8 1.7 276.6 380.3 1496.1
194 4.864 2.739 5.582 1.4 0.8 1.6 278.0 382.3 1503.8
195 4.864 2.739 5.582 1.4 0.8 1.6 279.5 384.3 1511.6
??=2Tan-1(??/2f)
??=2LTan(??/2)
This manual suits for next models
1
Other JVC Camcorder manuals
JVC
JVC GZMC100 - Everio 2MP 4 GB Microdrive... User manual
JVC
JVC GR-45 User manual
JVC
JVC GR-D22US User manual
JVC
JVC GR-DVL920 User manual
JVC
JVC Everio GZ-MS100 User manual
JVC
JVC GR-AXM205 User manual
JVC
JVC GR-D270 User manual
JVC
JVC GZ-MG730US Administrator Guide
JVC
JVC EVERIO GZ-HM650BUS User manual
JVC
JVC GR-D728EK User manual
JVC
JVC GR-250AH User manual
JVC
JVC Everio GZ-HM655BEK Operating and maintenance manual
JVC
JVC GR-DLS1 User manual
JVC
JVC HD EVERIO GZ-HM340 User manual
JVC
JVC GY-HD250U - 3-ccd Prohd Camcorder User manual
JVC
JVC GR-DVP9 User manual
JVC
JVC GV-LS1 U User manual
JVC
JVC Everio GZ-HD500 Instructions for use
JVC
JVC GR-SX20 User manual
JVC
JVC GZ-EX210 Everio User guide
