JVC GZMC500US - Everio Camcorder - 1.33 MP Mounting instructions

SOFTWARE INSTALLATION AND
USB CONNECTION GUIDE
ENGLISH
LYT1425-001A EN
M5S7_InstallGuide_EN_Cov1.fm Page 1 Friday, April 15, 2005 10:56 AM

–2–
MasterPage: Body
JVC SOFTWARE LICENSE AGREEMENT .... 2
Notice for Users ............................................... 6
System Requirements ..................................... 7
Software Installation ........................................ 9
Connections ................................................... 11
Viewing the Contents of a Recording Medium ........12
Copying Files to the PC ................................. 14
Playing Back Files on the PC ........................ 14
Copying Edited Files back to Camera ........... 15
Disconnecting the USB cable ........................ 15
User’s Guide/Help/Readme ........................... 17
Subsidiary Information ................................... 18
Creating DVDs and Writing Video Files Back to
Camera .................................................. 18
How To Create DVDs simply ..................... 21
JVC SOFTWARE LICENSE AGREEMENT
The right to use the Program is granted by Victor
Company of Japan, Limited (“JVC”) to You only
on the condition that You agree to the following.
Should You not agree to the terms hereof, You
may not install or use the Program. HOWEVER,
INSTALLING OR USING THE PROGRAM
INDICATES YOUR ACCEPTANCE OF THESE
TERMS AND CONDITIONS.
1COPYRIGHT; OWNERSHIP
You acknowledge that all copyrights and other
intellectual property rights in the Program are
owned by JVC and its licensor, and remain
vested in JVC and such licensor. The
Program is protected under the copyright law
of Japan and other countries, and related
Conventions.
2GRANT OF LICENSE
(1) Subject to the conditions of this
Agreement, JVC grants to You a non-
exclusive right to use the Program. You
may install and use the Program on a
HDD or other storage devices
incorporated in Your PC.
(2) You may make one (1) copy of the
Program solely for your personal backup
or archival purposes.
Contents
IMPORTANT
TO CUSTOMERS: PLEASE MAKE SURE TO READ
THIS CAREFULLY BEFORE INSTALLING OR USING
THE SOFTWARE PROGRAM NAMED “DIGITAL
PHOTO NAVIGATOR” (“Program”) ON YOUR PC.
M5S7_InstallGuide.book Page 2 Friday, April 1, 2005 8:26 PM

–3–
MasterPage: Body
3RESTRICTION ON THE PROGRAM
(1) You may not reverse engineer, decompile,
disassemble, revise or modify the
Program, except to the extent that
expressly permitted by applicable law.
(2) You may not copy or use the Program, in
whole or in part, other than as expressly
specified in this Agreement.
(3) You have no right to grant a license to use
the Program, and may not distribute, rent,
lease or transfer the Program to any third
party or otherwise let them use the
Program.
4LIMITED WARRANTY
JVC warrants that any media in which the
Program is embodied are free from any
defects in materials and workmanship for a
period of thirty (30) days from the date of Your
purchasing any our products accompanying
the Program. JVC’s entire liability and your
exclusive remedy in connection with the
Program shall be replacement of such
defective media. EXCEPT FOR THE
EXPRESS WARRANTIES STATED HEREIN
AND TO THE EXTENT PERMITTED BY
APPLICABLE LAW, JVC AND ITS
LICENSORS DISCLAIM ANY OTHER
WARRANTIES, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED
TO IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE IN REGARD TO
THE PROGRAM AND THE
ACCOMPANYING PRINTED MATERIALS.
SHOULD THERE BE ANY PROBLEM
ARISING FROM OR CAUSED BY THE
PROGRAM, YOU SHOULD SETTLE ALL
SUCH PROBLEM AT YOUR OWN COST
AND EXPENSE.
5LIMITED LIABILITY
TO THE EXTENT PERMITTED BY
APPLICABLE LAW, IN NO EVENT SHALL
JVC AND ITS LICENSORS BE LIABLE FOR
ANY INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES
WHATSOEVER, REGARDLESS OF THE
FORM OF ACTION WHETHER IN
CONTRACT, TORT OR OTHERWISE
ARISING OUT OF OR IN CONNECTION
WITH THE USE OF OR INABILITY TO USE
THE PROGRAM, EVEN IF JVC HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. YOU WILL INDEMNIFY AND
HOLD HARMLESS JVC FROM ANY LOSS,
LIABILITY OR COST ARISING OUT OF OR
IN ANY WAY CONNECTED TO CLAIMS
FROM ANY THIRD PARTY RELATING TO
THE USE OF THE PROGRAM.
6TERM
This Agreement will become effective on the
date when You install and use the Program on
Your machine, and continue to be in effect
until the termination under the following
provision.
Should You breach any provision of this
Agreement, JVC may terminate this
Agreement without giving any notice to You.
In this event, JVC may claim against You for
any damages caused by Your breach. Should
this Agreement be terminated, You must
immediately destroy the Program stored in
Your machine (including the erasing from any
memory in Your PC), and no longer own such
Program.
CONTINUED ON NEXT PAGE
M5S7_InstallGuide.book Page 3 Friday, April 1, 2005 8:26 PM

–4–
MasterPage: Body
7EXPORT CONTROL
You agree that You will not ship, transfer or
export the Program or underlying information
and technology to any countries to which
Japan and other relevant countries have
initiated an embargo on such goods.
8U.S. GOVERNMENT USER
If You are an agency of the United States of
America (the “Government”), You
acknowledge JVC’s representation that the
Program is a “Commercial Item” as defined in
Federal Acquisition Regulation (FAR) part
2.101 (g) consisting unpublished “Commercial
Computer Software” as those items are used
at FAR part 12.212 and is only licensed to You
with the same use rights JVC grants all
commercial end users pursuant to the terms
of this Agreement.
9GENERAL
(1) No modification, change, addition, deletion
or other alternation of or to this Agreement
will be valid unless reduced to writing and
signed by an authorized representative of
JVC.
(2) If any part of this Agreement is held invalid
by or in conflict with any law having
jurisdiction over this Agreement, the
remaining provisions will remain in full
force and effect.
(3) This Agreement shall be governed by and
interpreted under the laws of Japan. The
Tokyo District Court has jurisdiction over
all disputes which may arise with respect
to the execution, interpretation and
performance of this Agreement.
Victor Company of Japan, Limited
NOTE:
If You acquired the Program in Germany, the
provisions of Sections 4 (Limited Warranty) and 5
(Limited Liability) provided above will be replaced
with those of the German version of this Agreement.
M5S7_InstallGuide.book Page 4 Friday, April 1, 2005 8:26 PM

–5–
MasterPage: Body
You can find the latest information (in
English) on the provided software program at
our world wide web server at http://www.jvc-
victor.co.jp/english/global-e.html
CAUTION:
●Operate this equipment according to the
operating procedures described in this manual.
●Use only the provided CD-ROM. Never use any
other CD-ROM to run this software.
●Do not attempt to modify this software.
●Changes or modifications not approved by JVC
could void user’s authority to operate the
equipment.
How to handle a CD-ROM
●Take care not to soil or scratch the mirror surface
(opposite to the printed surface). Do not write
anything or put a sticker on either the front or
back surface. If the CD-ROM gets dirty, gently
wipe it with a soft cloth outward from the center
hole.
●Do not use conventional disc cleaners or
cleaning spray.
●Do not bend the CD-ROM or touch its mirror
surface.
●Do not store your CD-ROM in a dusty, hot or
humid environment. Keep it away from direct
sunlight.
M5S7_InstallGuide.book Page 5 Friday, April 1, 2005 8:26 PM

–6–
MasterPage: BodyAcross
Use of this software is authorized according to the terms of the software license.
JVC
When contacting the nearest JVC office or agency in your country about this software (refer to the
JVC Worldwide Service Network at http://www.jvc-victor.co.jp/english/worldmap/index-e.html), please
fill out the following and have the appropriate information ready.
Please note that it may take some time to respond to your questions, depending on their subject
matter.
JVC cannot answer questions regarding basic operation of your PC, or questions regarding
specifications or performance of the OS, other applications or drivers.
CyberLink
For details of CyberLink’s technical support service, refer to the “Readme” of each software or the
following list. To access “Readme”, refer to “User’s Guide/Help/Readme” (pg. 17).
Notice for Users
Product Name
Model
Problem
Error Message
PC
Manufacturer
Model □ Desktop □ Laptop
CPU
OS
Memory MB
Available Hard Disk Space MB
Region Location Phone# Web Language
Fax #
Europe 1 Germany
(aixTeMa)
[phone] support.gocyberlink.com German / French /
English
[phone]
Europe 2
Europe area
other than
Germany
support.gocyberlink.com English
US/Canada US [phone] support.gocyberlink.com English
Asia &
Pacific 1 South Korea [phone] www.gocyberlink.co.kr Korean
[phone]
Asia &
Pacific 2 Ta i w a n [phone] support.cyberlink.com.tw Mandarin / English
[phone] support.gocyberlink.com
Asia &
Pacific 3
Australia & New
Zealand
(Manacom)
[phone]
support.gocyberlink.com English
[phone]
M5S7_InstallGuide.book Page 6 Friday, April 1, 2005 8:26 PM

–7–
MasterPage: BodyAcross
8Digital Photo Navigator
The following requirements must be satisfied to connect a camera to a PC and to use Digital Photo
Navigator.
System Requirements
OS :Windows
®Millennium Edition [Me] (pre-installed),
Windows®2000 Professional [2000] (pre-installed),
Windows®XP Home Edition [XP] (pre-installed),
or Windows®XP Professional [XP] (pre-installed)
CPU : Intel®MMXTM Pentium®, at least 200 MHz
RAM : At least 64 MB
Free hard disk space : At least 40 MB for installation, at least 500 MB recommended
Connector : USB 1.1/2.0 connector
Display : Must be capable of displaying 800 x 600 dots with 16-bit color
Miscellaneous : Internet Explorer 5.5 or later
CONTINUED ON NEXT PAGE
M5S7_InstallGuide.book Page 7 Friday, April 1, 2005 8:26 PM

–8–
MasterPage: BodyAcross
8CyberLink DVD Solution
The following requirements must be satisfied to use CyberLink DVD Solution.
●DirectX is necessary so that CyberLink DVD Solution works properly and it is automatically installed during
CyberLink DVD Solution installation.
●The system requirements information above is not a guarantee that the provided software will work
on all personal computers meeting those requirements.
●Windows®is either registered trademark or trademark of Microsoft Corporation in the United States
and/or other countries.
●Other product and company names included in this instruction manual are trademarks and/or
registered trademarks of their respective holders.
OS :Windows
®Millennium Edition [Me] (pre-installed),
Windows®2000 Professional [2000] (pre-installed),
Windows®XP Home Edition [XP] (pre-installed),
or Windows®XP Professional [XP] (pre-installed)
CPU : Intel®Pentium®III, at least 700 MHz
(Intel®Pentium®4, at least 2 GHz recommended)
RAM : At least 128 MB (at least 256 MB recommended)
Free hard disk space : At least 350 MB for installation
For creating DVD Video, at least 10 GB recommended
For creating VCD, at least 1 GB recommended
Connector : USB1.1/2.0 connector
Display : Must be capable of displaying 1024 x 600 dots
Miscellaneous : Internet Explorer 5.5 or later
DirectX 9.0 or later
Supported media : DVD-Video: DVD-R/-RW, DVD+R/+RW
DVD-VR: DVD-RW, DVD+RW, DVD-RAM
VideoCD: CD-R/RW
For the compatible DVD/CD burners, refer to CyberLink web
site: http://www.gocyberlink.com/english/products/powerproducer/
2_gold/comp_dvd_drives.jsp
M5S7_InstallGuide.book Page 8 Friday, April 1, 2005 8:26 PM

–9–
MasterPage: Body
Follow the procedure described below to install
the software. From the [SETUP] screen in step 2,
you can install the following drivers or software.
Quit any other software you are using. (Check
that there are no other application icons on the
status bar.)
Digital Photo Navigator 1.0
This application is used to organize still images
and convert them into a variety of formats.
CyberLink DVD Solution
PowerProducer 2 Gold NE
PowerProducer 2 Gold NE is software for
creating movie discs incorporating not only video
but also slideshows. This software uses a simple
wizard format for creating a wide range of
different format discs. You can also edit imported
video. You can import video from the camera, edit
it, and then create a slideshow from still images.
You can create a customized menu for the video
or slideshow and write the contents to DVD or
other media.
PowerDirector Express NE
PowerDirector Express NE is software for easily
editing MPEG, AVI, and other video files, still
images, and other contents for creating a movie.
This software has an interface that allows editing
in either timeline or storyboard mode, maintains
superior image quality, uses SVRT for high-speed
rendering, and has a host of other advanced
video editing features.
PowerDVD 5 NE
PowerDVD 5 NE is software for playing back
DVD-Video and video files.
1Load the provided CD-ROM into the PC.
After a moment, the [SETUP] screen appears.
●From the [SETUP] screen, you can install the
desired software.
●If the [SETUP] screen does not appear, double-
click the CD-ROM icon in the [My Computer]
window.
2Click [Install] on the right side of the
desired software and follow the on screen
instructions to complete the installation.
The installation of the selected software starts.
The procedure differs depending on the software.
Following steps are the example of CyberLink
DVD Solution.
3Click [Install] on the right side of
[CyberLink DVD Solution] on the [SETUP]
screen.
[Choose Setup Language] screen appears.
4Select the desired language and click [OK].
The [CyberLink DVD Solution Setup] screen in
step 5appears.
●If [Information] screen for Windows Messenger
appears, see NOTES: on pg. 11.
Software Installation
CONTINUED ON NEXT PAGE
M5S7_InstallGuide_EN.fm Page 9 Friday, April 1, 2005 8:54 PM

–10–
MasterPage: Body
5Click [Next].
[License Agreement] screen appears.
6Click [Yes].
[Customer Information] screen appears.
7Confirm your information and click [Next].
●It is possible to change the information.
[Choose Destination Location] screen appears.
8Click [Next].
[Setup Type] screen appears.
9Select the program(s) you want to install,
then click [Next].
[Setup Status] screen appears. Wait for a
moment until the installation is finished and
[Setup Complete] screen appears.
10 Click [Finish] then restart the PC.
M5S7_InstallGuide.book Page 10 Friday, April 1, 2005 8:26 PM

–11–
MasterPage: Body
Install all of the desired software in the same
way.
To display [SETUP] screen, double-click the CD-
ROM icon in the [My Computer] window.
NOTES:
●Even if PowerDirector/PowerProducer/PowerDVD
have already been installed on the PC:
Video files captured with this camera can only be
handled on the provided software. Please install
and use the provided software (PowerDirector
Express NE, PowerProducer 2 Gold NE,
PowerDVD 5 NE). If PowerDirector/
PowerProducer/PowerDVD have already been
installed, uninstall them before installing the
provided software.
●If you perform installation of a software that is
already installed, uninstallation will start. In this
case, perform the installation again after
uninstallation is finished.
●Windows Messenger has to been closed during
CyberLink DVD Solution installation. If it is running
during installation, [Information] screen appears.
To close Windows Messenger:
1) While holding [Ctrl + Alt] key, click [Delete] key
so that [Task Manager] appears.
2) Click [Processes] tab.
3) Select [msmsgs.exe].
4) Click [End process].
Connecting the USB cable
Connect the USB cable to copy still image, video
files and voice files in a recording medium to the
PC.
1To assure safety, make sure all units are
turned off before making any connections.
2Use the USB cable to connect the camera
to the PC.
NOTES:
●It is recommended to use the AC Adapter as the
power supply instead of the battery pack.
●When the USB cable is connected, turning on or off
the camera causes malfunctions of the PC.
●If you connect the camera to the PC through a USB
hub, compatibility issues between the hub and the
PC may result in instability in the operation of the
PC. If this happens, connect the camera directly to
the PC, not through the hub.
●Do not use an extension USB cable.
Connections
Camera
To USB connector
PC
To USB connector
USB cable
M5S7_InstallGuide_EN.fm Page 11 Monday, April 4, 2005 5:26 PM

–12–
MasterPage: Body
1Make sure that there is a recording
medium in the camera.
2Set the camera's power switch to the
playback mode while pressing down the lock
button located on the switch.
The camera turns on.
3Connect the camera to the PC with a USB
cable. (pg. 11)
On the camera’s LCD monitor [USB] appears.
4When using Windows®XP:
The [Removable Disk]
window appears on
the PC’s screen after
a moment.
Select [Open folders
to view files using
Windows Explorer]
and click [OK].
NOTE:
If the [Removable Disk]
window does not
appear, confirm the connection (pg. 11) or
perform the steps 1and 2(pg. 12).
When using Windows®Me/2000:
1Double-click
the [My
Computer] icon
on the desktop.
The [Removable
Disk] icon which
represents the
recording
medium in the
camera appears in the [My Computer] window.
2Double-click the [Removable Disk] icon.
5The folders in the recording medium
appear.
Different file types are stored in different folders.
Viewing the Contents of a Recording
Medium
Still images
Voice f ile s
DPOF setting data
Video files
M5S7_InstallGuide.book Page 12 Friday, April 1, 2005 8:26 PM

–13–
MasterPage: Body
Folder structure within the recording medium
Video files: Stored in the [PRGxxx] folder (where
xxx is a number), within the [SD_VIDEO] folder.
Still image files: Stored in the [xxxJVCSO] folder
(where xxx is a number), within the [DCIM] folder.
Voice files: Stored in the [xxxJVCMC] folder
(where xxx is a number), within the [DCVC]
folder.
[DCIM]: Contains folders with still images (JPEG)
(extension “.jpg”)
[DCVC]: Contains folders with voice (WAVE) files
(extension “.wav”)
[SD_VIDEO]: Contains folders with video
(MPEG2) files (extension “.mod”)
[EXTMOV]: Contains video (MPEG2) files
produced on a PC (extension “.mpg” (pg.15))
[MISC]: Contains folders with DPOF setting data
AStill image file folder
BVoice file folder
CManagement information for the media as a
whole
DManagement information
EVideo file
FManagement information for the video file
GVideo file produced on a PC
* Management information: Information such as the
date and time of recording, recorded with the video
file.
NOTES:
●Any folders or files other than those described
above are recorded in the recording medium.
●Saving the wrong kinds of files in a recording
medium or deleting files or folders from a recording
medium can cause problems with the operation of
the camera. When it is necessary to delete a file
from a recording medium, delete it through the
camera. Also, do not move or rename folders and
files within the medium on PC.
●Never disconnect the USB cable while the
ACCESS lamp on the camera lights or blinks.
●If you are using a brand new recording medium,
you need to format the recording medium with the
camera first. You may not be able to copy files from
the recording medium to the PC without doing so.
●If the video file is not recorded or saved properly,
the file is moved to [EXTMOV] folder with extension
“.mod”.
●The file extension may not appear depending on
the [FOLDER] option setting of Windows®.
]
OSCVJ101[
]OSCVJ201[
]CVCD[
]
MICD
[
]CMCVJ001[
]CMCVJ101[
]CMCVJ201[
]
2
0
0G
RP[
]300GRP
[
]OFNI_RGM[
]10
0
GR
P[
]OEDIV_DS[
]VOMTX
E
[
GPM.
1
0
0
0_VOM
GP
M
.
2
0
00
_VOM
…………
]
OSCVJ001[
]IGP
.100
GR
P[
]
DOM.10
0
V
O
M[
]IO
M
.100VOM[
…
Recording
medium
M5S7_InstallGuide_EN.fm Page 13 Monday, April 4, 2005 10:33 AM

–14–
MasterPage: Body
Still image, video files and voice files that are
stored in a recording medium can be copied to
the PC and played back on the PC.
1Perform the procedure in “Viewing the
Contents of a Recording Medium” (墌pg. 12).
The folders in the recording medium appear.
2Create a new folder, enter the folder name,
and then double-click it.
For example, create a new folder in the [My
Pictures] folder.
3Select the folder to be copied, and then
drag and drop that folder in the destination
folder.
To copy still images: Copy the folder within the
[DCIM] folder.
To copy video files: Copy the folder within the
[SD_VIDEO] folder.
To copy voice files: Copy the folder within the
[DCVC] folder.
●The ACCESS lamp on the camera lights or blinks,
and the folder is copied from the recording medium
to the PC.
NOTES:
●Never disconnect the USB cable while the
ACCESS lamp on the camera lights or blinks.
●File transfer takes considerable time in PCs using
USB 1.1. Usage of a PC that supports USB 2.0 is
recommended.
Still images
Use an application that can handle the JPEG file
format.
To view a still image, double-click the still image
file (extension “.jpg”).
Video files
Use the PowerDVD 5 NE.
You can install this software from the provided
CD-ROM. For more details of PowerDVD 5 NE,
refer to the User’s Guide. (墌pg. 17)
Voice files
Use the Windows MediaTM Player (version 6.4 or
later).
You can download the Windows MediaTM Player
from the Microsoft web site at:
http://www.microsoft.com/
NOTE:
When playing back a file in the recording medium on
your PC, copy the file to your PC, and then play it
back. If video file is played back directly from
recording medium (i.e. the camera is connected
through USB to your PC), it may be not played back
properly due to the inadequate processing speeds or
other problems.
Copying Files to the PC
Playing Back Files on the PC
M5S7_InstallGuide_EN.fm Page 14 Friday, April 1, 2005 8:53 PM

–15–
MasterPage: Body
To use the camera to play back video files
(MPEG2 files, with the extension ".mpg") which
have been edited using the provided software,
change the file name to "MOV_xxxx.mpg" (where
xxxx is a number) and move it to the [EXTMOV]
folder. (pg. 13)
The following video files cannot be played back
on the camera:
●Files which do not have correct file names
●Files which are not in MPEG2 format
●Files prepared on any application other than the
provided software
●Edited files which were not produced on a JVC
Digital Media Camera
Also, be sure to turn off the SVRT function when
editing the video files using PowerDirector
Express NE. (Do not check the checkbox [Use
SVRT to save rendering time].)
How to play back video files from the [EXTMOV]
folder on the camera
On the index display of video files, press the
recording start/stop button to display "MPG" on
the screen. After that, follow the usual operation
for playback. However, the forward/reverse skip
search, frame-by-frame playback and playlist
functions are not available.
Before loading or unloading recording mediums
or turning off the PC, first disconnect the USB
cable and turn off the camera.
1Confirm that the ACCESS lamp on the
camera does not light or blink.
●If the ACCESS lamp lights or blinks, wait until it is
turned off before proceeding.
2Double-click the [Safely Remove Hardware]
or [Unplug or Eject Hardware] icon in the
status bar.
The [Safely Remove Hardware] or [Unplug or
Eject Hardware] dialog box appears.
Windows®XP: If not, wait a while then go to
step 5.
3Select [USB Mass Storage Device] or [USB
Disk], and then click [Stop].
●Windows®2000/XP
Copying Edited Files back to Camera Disconnecting the USB cable
CONTINUED ON NEXT PAGE
M5S7_InstallGuide.book Page 15 Friday, April 1, 2005 8:26 PM

–16–
MasterPage: Body
●Windows®Me
The [Stop a Hardware device] dialog box
appears.
4Click [OK].
Windows®2000/Me: If a message indicating
that the device can be safely removed appears,
click [OK] and then click [Close].
●Windows®2000/XP
●Windows®Me
5Disconnect the USB cable.
6Set the camera’s power switch to off.
The camera turns off.
* The model name depends on the connected
camera.
* The model name depends on the connected
camera.
M5S7_InstallGuide.book Page 16 Friday, April 1, 2005 8:26 PM

–17–
MasterPage: Body
This manual only refers to software installation
and PC connection. For more details of each
software, refer to its user’s guide/help/Readme.
8CyberLink DVD Solution
Following steps are the example of CyberLink
PowerDirector Express NE.
1Click [Start], go to [All Programs] or
[Programs]– [CyberLink PowerDirector
Express], and then click User’s Guide/Help/
Readme depending on your preference.
8Digital Photo Navigator
The User’s Guide is included on the CD-ROM in
PDF format. Right-click the CD-ROM icon in [My
Computer], then click [Open]. Double-click the
[Docs] folder, then double-click the [PhotoNavi]
folder. Open the "Start.pdf" file and click the
button of the desired language. Note that Adobe®
Acrobat®ReaderTM or Adobe®Reader®must be
installed to read PDF files.
●Adobe®Reader®can be loaded from Adobe’s
web site: http://www.adobe.com/
User’s Guide/Help/Readme
INFORMATION
The programs in CyberLink DVD Solution are
versions with limited functionality. The User's
Guide and Help files are written for the
commercial version available in stores. For
information about the differences with the
commercial version, see the Readme file or the
following web site: http://www2.cli.co.jp/
products/ne/ for the respective program.
M5S7_InstallGuide.book Page 17 Friday, April 1, 2005 8:26 PM

–18–
MasterPage: BodyAcross
Creating DVDs and Writing Video Files Back to Camera
Subsidiary Information
(Main unit) Digital Media Camera
Write back
Video (recording media)
USB transfer
Create DVD
without title
DVD
player PC
Edit video
Create DVD
View
PowerDirector
Express NE
PowerProducer 2
Gold NE
PowerDVD 5 NE
Select
[Produce a Disc]
*1, 2
Create DVD *3
View DVD View DVD
Create DVD
with title
Select [Create a File
(GZ-MC Series)]
*4, 5
Create DVD *3, 6, 7
View edited video
with camera
Select [Create a File
(GZ-MC Series)]
*4, 8, 9
*1
*2
*4, 5 *6
M5S7_InstallGuide.book Page 18 Friday, April 1, 2005 8:26 PM

–19–
MasterPage: Body
A brief procedure is presented below for using
CyberLink DVD Solution to edit video files that
were shot with the camera and create a DVD-
Video, transfer the edited videos to the camera,
and then play back the videos in the camera.
(1) Copy the video files on the media to the PC.
(2) Start PowerDirector Express NE.
(3) Import the copied video files in the
PowerDirector Express NE library.
(4) Drag and drop the videos from the library to
the timeline/storyboard in the playback order.
(5) If necessary, edit the videos on the timeline/
storyboard.
(6) Click [Produce] on the main panel to open the
[Produce] screen.
(7) Select [Produce a Disc], and then click [Next].
(8) Select [DVD Format] and click [Next]. *1,2
(墌pg. 20)
(9) Click [Start] to create the file.
(10)After the completion of video file creation,
PowerProducer 2 Gold NE starts
automatically.
(1) Load a blank DVD media into the recordable
DVD drive. *3 (墌pg. 20)
(2) Click []] in the [Import/Capture Content]
screen of PowerProducer 2 Gold NE.
(3) Remove the check mark for [Include Menu] in
the [Preview] screen, and then click []].
(4) Insert a check mark for [Burn to disc] in the
[Final Output] screen, and then click [ ] to
create the DVD-Video.
(1) Copy the video files on the media to the PC.
(2) Start PowerDirector Express NE.
(3) Import the copied video files in the
PowerDirector Express NE library.
(4) Drag and drop the video files that you want to
edit from the library to the timeline/
storyboard.
(5) Edit the videos on the timeline/storyboard.
(6) Click [Produce] on the main panel to move to
the [Produce] screen.
(7) Click the [Create a File (GZ-MC Series)] and
then click [Next].
(8) Click the [Choose the format you want to
make] in the [Produce] screen and click
[Next]. *4, 5 (墌pg. 20)
(9) Clicking [Start] starts creation of the video
file. After the completion of video creation,
click [Home].
(10)If there are other video files to edit, repeat
steps (3) to (9).
(1) Load a blank DVD media into the recordable
DVD drive. *3 (墌pg. 20)
(2) Start PowerProducer 2 Gold NE.
(3) Click [Produce Movie Disc].
(4) Select [DVD] in the [Select Your Disc] screen
to select the [Video quality], and then click
[]]. *6 (墌pg. 20)
(5) Click [Video files] in the [Import/Capture
Content] screen.
(6) Select the video file that you want to make
into a DVD from the [Open] dialog box, and
then click [Open].
(7) Place the imported thumbnails into the
desired playback order on the storyboard,
and then click []].
(8) In the [Preview] screen, insert a check mark
for [Include Menu], and then click []] on the
screen. *7 (墌pg. 20)
(9) Insert a check mark for [Burn to disc] in the
[Final Output] screen, and then click [ ] to
create the DVD-Video.
CONTINUED ON NEXT PAGE
M5S7_InstallGuide_EN.fm Page 19 Monday, April 4, 2005 10:33 AM

–20–
MasterPage: Body
(1) Copy the video files on the media to the PC.
(2) Start PowerDirector Express NE.
(3) Import the copied video files in the
PowerDirector Express NE library.
(4) Drag and drop the videos that you want to
edit from the library to the timeline/
storyboard.
(5) Edit the videos on the timeline/storyboard.
(6) Click [Produce] on the main panel to move to
the [Produce] screen.
(7) Click the [Create a File (GZ-MC Series)] and
then click [Next].
(8) Click the [Choose the format you want to
make] in the [Produce] screen and click
[Next]. *4, 8
(9) Clicking [Start] starts creation of the video
file. After the completion of video creation,
click [Home].
(10)If there are other video files to edit, repeat
steps (3) to (9).
(11)Copy the created video file to the camera,
and change the name of file. *9
NOTES:
*1 If the video is [ULTRA FINE], [FINE], or
[NORMAL], select [High Quality NTSC (or PAL)
DVD].
If the video is [ECONOMY], select [Long Play
NTSC (or PAL) DVD].
Encoding is not performed on unedited video, and
high-speed processing is performed at the original
image quality.
*2 Insert a check mark for [Use SVRT to save
rendering time]. The minimum required encoding
is performed, and high-speed processing is
performed while keeping the original image
quality.
Insert a check mark for [After production, make
disc in PowerProducer].
]PowerProducer 2 Gold NE starts automatically.
*3 Before using PowerProducer 2 Gold NE, be sure
to load a blank DVD media into the recordable
DVD drive. Processing will stop if no blank DVD
media is loaded.
*4 Select the same recording mode as the edited
video. If you don't know the recording mode of
video, select [ULTRA FINE].
*5 Insert a check mark for [Use SVRT to save
rendering time]. The minimum required encoding
is performed for the edited scenes, and high-
speed processing is performed while keeping the
original image quality.
*6 The correlation between the modes in
PowerDirector Express NE and PowerProducer 2
Gold NE is shown below. Usage in the mode
corresponding to the video is recommended if
possible.
*7 To modify the menu, click [Customize Menu] of
[Actions].
*8 Turn off the SVRT function when playing back the
file on the camera after editing. (Do not check the
checkbox [Use SVRT to save rendering time].)
The video MOD file of the camera can be
viewed using one of the methods below.
(1) Drag and drop the MOD file to the
PowerDVD 5 NE icon.
(2) Start PowerDVD 5 NE, and then drag and
drop the MOD file to the screen window.
(3) Start PowerDVD 5 NE, and then click [ ]
on the operation panel, select [Open media
files] from the pull-down menu, and then
add the MOD file that you want to play to
the play list for playback. PowerDirector
Express NE
PowerProducer 2
Gold NE
ULTRA FINE HQ
FINE XP
NORMAL SP
ECONOMY EP
M5S7_InstallGuide.book Page 20 Friday, April 1, 2005 8:26 PM
